Allen-Bradley DeviceNet 1747-SDN User manual

1747-SDN
DeviceNetScanner
Module
Catalog Number
1747-SDN, Series C
User Manual

Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. Safety Guidelines for the Application,
Installation and Maintenance of Solid State Controls (publication SGI-1.1
available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com) describes some important
differences between solid state equipment and hard-wired electromechanical
devices. Because of this difference, and also because of the wide variety of
uses for solid state equipment, all persons responsible for applying this
equipment must satisfy themselves that each intended application of this
equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for
indirect or consequential damages resulting from the use or application of
this equipment.
The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with
any particular installation, Rockwell Automation, Inc. cannot assume
responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to
use of information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without
written permission of Rockwell Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware
of safety considerations.
Rockwell Automation, TechConnect, SLC, SLC 500, RSNetWorx for DeviceNet, RediSTATION, Series 9000, DH+, Data Highway
Plus, RSLogix 500, FLEX I/O, ControlFlash, RSView, PLC-5, PanelView, RSLinx Classic, are trademarks of Rockwell Automation,
Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING Identifies information about practices or circumstances that can cause
an explosion in a hazardous environment, which may lead to personal
injury or death, property damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application and
understanding of the product.
ATTENTION Identifies information about practices or circumstances that can lead
to personal injury or death, property damage, or economic loss.
Attentions help you identify a hazard, avoid a hazard, and recognize
the consequence
SHOCK HAZARD Labels may be on or inside the equipment, for example, a drive or
motor, to alert people that dangerous voltage may be present.
BURN HAZARD Labels may be on or inside the equipment, for example, a drive or
motor, to alert people that surfaces may reach dangerous
temperatures.

3Publication 1747-UM655B-EN-P - June 2007
Summary of Changes
The information below summarizes the changes to this manual since
the last publication.
To help you find new and updated information in this release of the
manual, we have included change bars as shown to the right of this
paragraph.
This manual contains this updated information.
Topic Page
The length of the M0 and M1 files 64
Numeric code 65 for normal operation when
AutoScan is enabled was added 91
DeviceNet explicit messaging chapter was
added Chapter 8
AutoScan function chapter was added Chapter 9
Information about programming the module
by using the SLC M0 and M1 files was
added
123…127
Information on the 1747-SDN module’s
firmware history was added Appendix C
Information about data organization was
added Appendix D
Information about explicit message program
control was added Appendix E

Publication 1747-UM655B-EN-P - June 2007
4Summary of Changes

5Publication 1747-UM655B-EN-P - June 2007
Table of Contents
Preface
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
The Example Application . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Common Techniques Used in This Manual. . . . . . . . . . . . . . 11
Additional Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 1
Before You Begin
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 13
What You Need to Know . . . . . . . . . . . . . . . . . . . . . . . . . . 13
What Your 1747-SDN Module Does . . . . . . . . . . . . . . . . . . . 14
Communicating with Your Devices . . . . . . . . . . . . . . . . . . . 16
Communicating with Your SLC 500 Processor. . . . . . . . . . . . 18
1747-SDN Module Data Tables . . . . . . . . . . . . . . . . . . . . . . 19
RSNetWorx Software as a Configuration Tool . . . . . . . . . . . . 20
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Chapter 2
Planning Your Configuration and
Data Mapping Your Devices
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 23
What You Need to Know . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Beginning the Process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The Example Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Chapter 3
Hardware Setup
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 31
Installing the 1770-KFD Module. . . . . . . . . . . . . . . . . . . . . . 31
Installing the SLC 500 Processor. . . . . . . . . . . . . . . . . . . . . . 32
Installing the ControlNet RS-232 Interface Module . . . . . . . . 35
Installing the 1747-SDN Module. . . . . . . . . . . . . . . . . . . . . . 40
Installing the RediSTATION Operator Interface. . . . . . . . . . . 43
Installing the Series 9000 Photoeye . . . . . . . . . . . . . . . . . . . 44
How Your Network Will Look . . . . . . . . . . . . . . . . . . . . . . . 45
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chapter 4
Configuring the DeviceNet
Network
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 47
Installing the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Use RSLinx Software to Configure the DeviceNet Driver . . . . 48
Using RSNetWorx for DeviceNet Software to Configure the
1747-SDN Module Scanlist . . . . . . . . . . . . . . . . . . . . . . . . . . 50
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Publication 1747-UM655B-EN-P - June 2007
6Table of Contents
Chapter 5
Communicating with the
DeviceNet Network from Another
Network
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 63
Additional Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Communicating with the DeviceNet Network via
an Ethernet Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Communicate with the DeviceNet Network via
a DH+ Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Chapter 6
Creating and Running the Example
Application Program
What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 79
Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Create the Example Application Program . . . . . . . . . . . . . . . 80
Download and Run the Program . . . . . . . . . . . . . . . . . . . . . 82
What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Chapter 7
Troubleshooting
Module Status Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Network Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Numeric Display Code Summary . . . . . . . . . . . . . . . . . . . . . 90
Chapter 8
DeviceNet Explicit Messaging
DeviceNet Explicit Message Instruction Overview. . . . . . . . . 93
DeviceNet Explicit Message (DEM) . . . . . . . . . . . . . . . . . . . 94
Chapter 9
AutoScan
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Implementing AutoScan . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Other Important Information about AutoScan. . . . . . . . . . . 112
Appendix A
Data Map Example
What This Appendix Contains . . . . . . . . . . . . . . . . . . . . . . 115
Example Input Mapping Scheme . . . . . . . . . . . . . . . . . . . . 115
Example Output Mapping Scheme. . . . . . . . . . . . . . . . . . . 118
Appendix B
Configuring the M0/M1 Files by
Using RSLogix 500 Software
RSLogix 500 I/O Configuration . . . . . . . . . . . . . . . . . . . . . 121
Programming the Module by Using the SLC M0
and M1 Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Publication 1747-UM655B-EN-P - June 2007
Table of Contents 7
Appendix C
1747-SDN Module Firmware
History
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Revision 8.002. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Revisions 7.005 and 7.006 Known Anomalies . . . . . . . . . . . 129
Revision 6.002. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Revision 5.001. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Revision 4.026. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Appendix D
Data Organization
Understand the Data Organization of the Module . . . . . . . . 133
Upload Input Data from the Module to the SLC Processor. . 134
Download Output Data to the Module. . . . . . . . . . . . . . . . 138
Appendix E
Explicit Message Program Control
Using Explicit Message Program Control . . . . . . . . . . . . . . 143
Glossary
Index

Publication 1747-UM655B-EN-P - June 2007
8Table of Contents

9Publication 1747-UM655B-EN-P - June 2007
Preface
Introduction
This user manual is designed to provide you enough information to
get a small example application up and running. Use this manual if
you are knowledgeable about DeviceNet and SLC 500 products, but
may not have used the products in conjunction. The information
provided is a base; modify or expand the examples to suit your
particular needs.
The manual contains instructions on configuring a DeviceNet network
by using RSLinx and RSNetWorx for DeviceNet software. It also
describes how to use the SLC 500 pass-through feature to
communicate with the DeviceNet network for adjustment and tuning
of network devices via an Ethernet and Data Highway Plus (DH+)
network.
The example application demonstrates how to perform control on a
DeviceNet network by using an SLC 500 processor and the 1747-SDN
module. You use RSLogix 500 programming software to create a
ladder logic program to control a photoeye and a RediSTATION
operator interface.
Audience
This manual is intended for control engineers and technicians who are
installing, programming, and maintaining a control system that
includes an SLC 500 processor communicating on a DeviceNet
network through a 1747-SDN module.
We assume that you:
•are developing a DeviceNet network by using a SLC 500
processor in conjunction with a 1747–SDN module.
•know each of your device’s I/O parameters and requirements.
•understand SLC processor programming and operation.
•are experienced with the Microsoft Windows environment.
•are familiar with RSNetWorx for DeviceNet software.
IMPORTANT This user manual should be used in conjunction with the
1747-SDN DeviceNet Scanner Module Installation Instructions,
publication 1747-IN058. The installation instructions contain
important information on configuring your scanner.

Publication 1747-UM655B-EN-P - June 2007
10 Preface
The Example Application
This manual describes how to set up an example application. The
manual provides examples of each step of the setup, with references
to other manuals for more details.
System Components
We used the following devices and software for the example
application. For your own application, substitute your own devices to
fit your needs. The recommended configurations in this user manual
will help you set up the test system and get it working. Your eventual
configuration will depend on your application.
TIP If you use different software or fimware versions of these
products, some of your dialogs may appear slightly different
from those shown in the example.
Quantity Product Name Catalog Number Series/Revision
Hardware
1 SLC 500 modular chassis 1746-A4, 1746-A7, 1746-A10,
1746-A13 B
1 SLC 500 power supply 1746-P1, 1746-P2, 1746-P3,
1746-P4, 1746-P5, 1746-P6 -
1 SLC 5/04 processor 1747-L541, 1747-L542,
1747-L543 -
1 SLC 5/05 processor (Ethernet
network) 1747-L551, 1747-L552, 1747-L553 -
1 DeviceNet scanner module 1747-SDN/B -
1 ControlNet RS-232 interface
module 1747-KFC15 B
1 DeviceNet quad-tap 1492-DN3TW -
1 RediSTATION operator interface
module 2705-TxDN1x42x-xxxx -
1 Series 9000 photoeye 42GNU-9000 or equivalent -
1 DeviceNet RS-232 interface
module 1770-KFD -
1 RS-232 cables 1787-RSCABL/A (personal
computer to 1770-KFD) -
DeviceNet dropline or trunk
cables, as needed 1787-PCABL, 1787-TCABL, 1787-MCABL -

Publication 1747-UM655B-EN-P - June 2007
Preface 11
Common Techniques Used
in This Manual
The following conventions are used throughout this manual:
•Bulleted lists provide information, not procedural steps.
•Numbered lists provide sequential steps.
Additional Resources
These documents contain additional information concerning related
Rockwell Automation products.
1 24V power supply Any regulated 24V dc, 8 A -
1 Personal computer IBM-compatible Pentium+
Windows 2000 or later -
Software
RSLogix 500 9324-RL0300xxx Rev 4.00
RSNetWorx for DeviceNet 9357-DNETL3 Rev 2.22
RSLinx 9355-WAB Rev 2.10
Quantity Product Name Catalog Number Series/Revision
TIP This symbol identifies helpful tips.
Resource Description
1747-SDN DeviceNet Scanner Module
Installation Instructions, publication 1747-IN058 Provides information on installing and connecting the module.
ControlFlash Firmware Upgrade Kit Quick Start,
publication 1756-QS105 Provides instructions on using the ControlFlash utility to upgrade the
firmware.
Getting Results with RSLogix 500, publication
LG500-GR002 Provides information on RSLogix 500 software.
Getting Results with RSLinx Classic, publication
LINX-GR001 Provides information on RSLinx software.
DeviceNet Media Design and Installation Guide,
publication DNET-UM072 Provides information on using DeviceNet communication network.
Getting Results with RSNetWorx for DeviceNet,
publication DNET-GR001 Provides information on using RSNetWorx for DeviceNet
software.
DeviceNet RS-232 Interface Module, publication
1770-5.6 Provides information on connecting and installing the DeviceNet
RS-232 Interface module.
SLC 500 ControlNet RS-232 Interface User
Manual, publication 1747-5.34 Provides information about the 1747-KFC15 module.

Publication 1747-UM655B-EN-P - June 2007
12 Preface
You can view or download publications at
http://literature.rockwellautomation.com. To order paper copies of
technical documentation, contact your local Rockwell Automation
distributor or sales representative.
ControlNet Coax Media Planning and Installation
Guide, publication CNET-IN002 Provides information on planning and installing ControlNet coax
media systems.
RediSTATION operator interface User Manual,
publication 2705-UM001 Provides information on installing and using the RediSTATION
operator interface.
SLC 500 Module Hardware Style User Manual,
publication 1747-UM011 Provides information on installing, wiring, startup, and maintenance of
SLC modular hardware.
Quick Start for experienced Users, publication
1747-10.4 Provides information on features, setup, configuration, and
communication for the SLC 500
Ethernet processors.
Resource Description

13 Publication 1747-UM655B-EN-P - June 2007
Chapter 1
Before You Begin
What This Chapter Contains
This chapter provides an overview of communication between the
SLC 500 processor and DeviceNet devices via the 1747-SDN module.
The configuration data tables and the RSNetWorx for DeviceNet
software dialogs and dialogs used to configure the data tables are also
described.
The following table identifies what this chapter contains and where to
find specific information.
What You Need to Know
Before configuring your 1747-SDN module, you must understand:
•the data exchange between the an SLC 500 processor and
DeviceNet devices through the 1747-SDN module.
•user-configurable 1747-SDN module data tables.
•the role of RSNetWorx for DeviceNet software.
Topic Page
What You Need to Know 13
What Your 1747-SDN Module Does 14
Communicating with Your Devices 16
Communicating with Your SLC 500
Processor 18
1747-SDN Module Data Tables 19
RSNetWorx Software as a Configuration
Tool 20
What’s Next? 22

Publication 1747-UM655B-EN-P - June 2007
14 Before You Begin
What Your 1747-SDN
Module Does
In a typical configuration, the 1747-SDN module acts as an interface
between DeviceNet devices and the SLC 500 processor.
Typical DeviceNet Network
The 1747-SDN module communicates with DeviceNet devices over
the network to:
•read inputs from a device.
•write outputs to a device.
•download configuration data.
•monitor a device’s operational status.
The 1747-SDN module communicates with the processor in the form
of M1/M0 File Transfers and/or Discrete I/O. Information exchanged
includes the following:
•Device I/O data
•Status information
•Configuration data
A processor to I/O DeviceNet configuration is shown in the following
figure. See the referenced chapters for more information.
SLC 500 Modular Chassis Computer with RSNetWorx
for DeviceNet Software
1770-KFD PC
Communication Module
1747-SDN Interface
Module
SLC 500
Processor
Series 9000
Photoeye RediSTATION
Operator
Interface
1305 Drive
FLEX I/O
Rack
DeviceNet
Devices

Publication 1747-UM655B-EN-P - June 2007
Before You Begin 15
Processor to I/O
The 1747-SDN interface module can also be used to bridge a
DeviceNet network with another network.
Configuring Devices and Data Collection on Higher-level Networks via
SLC 500/SDN Module
Configure SDN Module (Chapter 4)
Mapping Table (Chapters 2 and 4)
Input
Device
Output
Device
Input Data from
Device to SDN
(Chapter 2)
Output Write by
Processor (Chapter 2)
DeviceNet Network
Output Data to Devices
from SDN (Chapter 2)
Input Read by Processor (Chapter 2) Configure SDN Module (Chapter 4)
Computer
Running
RSNetWorx for
DeviceNet
Software
Target device to
be configured. Source device
to collect data.
Configuration of device
using RSNetWorx
software (Chapter 4).
DeviceNet Network
Industrial
workstationrunning
RSView software. Laptop computer
runningRSNetWorx
software.
DH+ or Ethernet Network (Chapter 5)
Collection of status
or alarm data
(Chapter 6).
1747-SDN
Module

Publication 1747-UM655B-EN-P - June 2007
16 Before You Begin
Communicating with Your
Devices
The 1747-SDN module communicates with a device via strobe, poll,
change of state, and/or cyclic messages. It uses these messages to
solicit data from or deliver data to each device. Data received from the
devices, or input data, is organized by the 1747-SDN module and
made available to the processor. Data received from your SLC 500
processor, or output data, is organized in the 1747-SDN module and
sent on to your devices.
IMPORTANT Throughout this document, input and output are defined from
the SLC 500 processor’s point of view. Output is data sent from
the SLC 500 processor to a device. Input is data collected by the
SLC 500 processor from a device.
All data sent and received on a DeviceNet network is in byte
lengths. A device may, for example, produce only two bits of
input information. Nevertheless, since the minimum data size
on a DeviceNet network is one byte, two bits of information are
included in the byte of data produced by the device. In this
example (only two bits of input information), the upper six bits
are insignificant.

Publication 1747-UM655B-EN-P - June 2007
Before You Begin 17
Communicating With Other Devices
1747-SDN Module DeviceNet Devices
Input Data Storage Input Data From
DeviceNet Devices
E
X
Y
Y
Different portions of data from a single
device can be mapped to separate
1747-SDN memory locations. For example,
On/Off values can be mapped to one
location, diagnostic values to another. This
is known as map segmenting. This concept
is illustrated by byte A, stored separately
as segments A1 and A2.
Output Data Storage
Output Data To
DeviceNet Devices
Byte
0
1
2
3
4
5
6
Z
Y
Y
Y
Output from
the SLC 500
processor.
B
A1
C
D
A2
E
E
Input from
the devices
to the
SLC 500
processor.
B
C
D
X
Z
A1 A2

Publication 1747-UM655B-EN-P - June 2007
18 Before You Begin
Communicating with Your
SLC 500 Processor
The 1747-SDN module does not send data to your processor. Data
transferred between the module and the processor must be initiated
by the processor. Output data is sent, or written, to the scanner by
your processor by placing the data in the M0 file. This data is
organized in the scanner, which in turn passes the data on to the
scanned devices via strobe, poll, change of state, or cyclic messages.
Data Flow
SLC 500 Processor 1747-SDN Module
B
A1
C
D
A2
E
E
X
Y
Y
Z
Y
Y
C
D
A2
X
Z
Y
Y
Y
Y
Discrete Input Image
M1/M0 File Transfer Data File
A1
B
E
E
Internal Input
Data Storage
I/O Map
Input from
the devices.
Discrete Output Image
M0 Data File
Internal
Output Data
Storage
I/O Map
Discrete I/O
Transfer
Discrete I/O
Transfer
M1 File
Transfer
(Read)
Output to
the devices.
M0 File
Transfer
(Write)

Publication 1747-UM655B-EN-P - June 2007
Before You Begin 19
1747-SDN Module Data
Tables
To manage the flow of data between your SLC 500 processor and the
network devices, the 1747-SDN module uses the following data tables:
•Scanner configuration table (SCT)
•Scanlist table (SLT)
•Device input data table
•Device output data table
•Device active table
•Device failure table
•Client/Server transaction tables
You can configure the first two of these data tables through
RSNetWorx for DeviceNet software.
•Scanner configuration table (SCT)
•Scanlist table (SLT)
These two tables are stored in the 1747-SDN module’s nonvolatile
memory and used to construct all other data tables.
Scanner Configuration Table (SCT)
The SCT controls basic information your 1747-SDN module needs to
function on your DeviceNet network. It tells your 1747-SDN module:
•if it can transmit and receive input and output data.
•how long it waits after each scan before it scans the devices
again.
•when to send out its poll messages.
Scanlist Table (SLT)
The SLT supports I/O updating for each of your devices on the
network. It also makes it possible for your 1747-SDN module to make
device data available to your SLC processor. The SLT tells your
1747-SDN module:
•which device node addresses to scan.
•how to scan each device (strobe, poll, change of state, cyclic, or
any valid combination).
•how often to scan your devices.
•exactly where in each device’s total data to find the desired data.

Publication 1747-UM655B-EN-P - June 2007
20 Before You Begin
•the size of the input data/output data.
•exactly where to map the input or output data for your
processor to read or write.
•how your processor reads each device’s input data (M1/M0 file
or discrete I/O).
RSNetWorx Software as a
Configuration Tool
RSNetWorx for DeviceNet software is used to configure the 1747-SDN
module’s data tables. This software tool connects to the 1747-SDN
module over the DeviceNet network via a computer RS-232 interface
(1770-KFD module) or PC Card (1784-PCD, 1784-PCID, or
1784-PCIDS).
The configuration dialog map below shows the RSNetWorx for
DeviceNet dialogs used to configure the 1747-SDN module and the
navigation paths between them.
The use of these dialogs is described in Chapter 4.
Data Table Information
User-configured Tables Data in This Table RSNetWorx Software Configuration
Dialog
SCT •Basic operation parameters
•I/O communication data
(enable/disable)
•Interscan delay
•Background poll ratio
1747-SDN module configuration
SLT •Device-specific identification data Scanlist editor (SLE)
•Data transfer method
•Transmit/receive data size
Edit device I/O parameters
•Input and output data source and
destination locations These values can be configured automatically through the AutoMap
function or manually through the Data Table
Map
TIP RSNetWorx for DeviceNet software can also communicate with
the 1747-SDN module via an Ethernet or Data Highway Plus
network.
See Chapter 5.
