Alliance Laundry Systems 513123 User manual

for your dryer
www.comlaundry.com
Inside …
Safety Information. . . . . 3
Before Drying . . . . . . . . . . 6
Drying Special Items . . . 8
Operating Your Dryer. . . 11
Clothing Care Labels. . . . 14
Maintenance . . . . . . . . . . . 15
Troubleshooting. . . . . . . . 17
Part No. 513123
January 2009
Para bajar una copia de estas instrucciones en
español, visite www.comlaundry.com.

-2-
513123
IMPORTANT: Purchaser must consult the local gas supplier for suggested instructions to be followed if
the dryer user smells gas. The gas utility instructions plus the SAFETY and WARNING note directly
above must be posted in a prominent location near the dryer for customer use.
•Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
•WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in your building.
– Clear the room, building or area of all occupants.
– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
– If you cannot reach your gas supplier, call the fire department.
•Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
W052
FOR YOUR SAFETY, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury or
death.
W033
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
W053

-3-
513123
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for
the personal safety of the operator, user, servicer,
and those maintaining the machine.
Additional precautionary statements
(“IMPORTANT” and “NOTE”) are followed by specific
instructions.
IMPORTANT: The word “IMPORTANT” is used to
inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the dryer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the dryer.
3. Do not dry articles that have been previously
cleaned in, soaked in, washed in, or spotted
with gasoline, dry-cleaning solvents, other
flammable or explosive substances as they
give off vapors that could ignite or explode.
4. Do not allow children to play on or in the dryer.
Close supervision of children is necessary
when the dryer is used near children. This is a
safety rule for all appliances.
5. Before the dryer is removed from service or
discarded, remove the door to the drying
compartment.
6. Do not reach into the dryer if the cylinder is
revolving.
7. Do not install or store the dryer where it will be
exposed to the water and/or weather.
8. Do not tamper with the controls.
Indicates an imminently hazardous
situation that, if not avoided, will
cause severe personal injury or death.
DANGER
Indicates a hazardous situation that, if
not avoided, could cause severe
personal injury or death.
WARNING
Indicates a hazardous situation that, if
not avoided, may cause minor or
moderate personal injury or property
damage.
CAUTION
To reduce the risk of fire, electric
shock, serious injury or death to
persons when using your dryer, follow
these basic precautions:
W130
WARNING
© Copyright 2009, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or
transmitted in any form or by any means without the expressed written
consent of the publisher.

-4-
513123
9. Do not repair or replace any part of the dryer,
or attempt any servicing unless specifically
recommended in the User-Maintenance
Instructions or in published user-repair
instructions that you understand and have
the skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or
product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter after every load. A
layer of lint in the filter reduces drying
efficiency and prolongs drying time.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust and dirt.
14. The interior of the dryer and the exhaust duct
should be cleaned periodically by qualified
service personnel.
15. This gas appliance contains or produces a
chemical or chemicals which can cause death
or serious illness and which are known to the
State of California to cause cancer, birth
defects, or other reproductive harm. To reduce
the risk from substances in the fuel or from
fuel combustion, make sure this appliance is
installed, operated, and maintained according
to the manufacturer’s instructions.
16. Dryer will not operate with the loading door
open. DO NOT bypass the door safety switch
by permitting the dryer to operate with the
door open. The dryer will stop tumbling when
the door is opened. Do not use the dryer if it
does not stop tumbling when the door is
openedor starts tumbling without pressing or
turning the START mechanism. Remove the
dryer from use and call the service person.
17. Do not put articles soiled with vegetable or
cooking oil in the dryer, as these oils may not
be removed during washing. Due to the
remaining oil, the fabric may catch on fire by
itself.
18. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable
substances such as machine oil, flammable
chemicals, thinner, etc. or anything containing
wax or chemicals such as in mops and cleaning
cloths, or anything dry-cleaned at home with
dry-cleaning solvent in the dryer.
19. Use the dryer only for its intended purpose,
drying clothes.
20. Always disconnect the electrical power to the
dryer before attempting service. Disconnect
the power cord by grasping the plug, not the
cord.
21. If supply cord is damaged, it must be replaced
by a special cord or assembly available from
the manufacturer or its service agent.
22. Install this dryer according to the
INSTALLATION INSTRUCTIONS. All
connections for electrical power, grounding
and gas supply must comply with local codes
and be made by licensed personnel when
required. Do not do it yourself unless you know
how!
23. Remove laundry immediately after the dryer
stops.
24. Always read and follow manufacturer’s
instructions on packages of laundry and
cleaning aids. Heed all warnings or
precautions. To reduce the risk of poisoning or
chemical burns, keep them out of reach of
children at all times (preferably in a locked
cabinet).
25. Do not tumble fiberglass curtains and
draperies unless the label says it can be done.
If they are dried, wipe out the cylinder with a
damp cloth to remove particles of fiberglass.

-5-
513123
26. ALWAYS follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the dryer with any guards and/
or panels removed.
28. DO NOT operate the dryer with missing or
broken parts.
29. DO NOT bypass any safety devices.
30. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which
can produce bodily injury and/or property
damage.
NOTE: The WARNING AND IMPORTANT SAFETY
INSTRUCTIONS appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. Observe and be aware
of other labels and precautions that are located
on the machine. They are intended to provide
instructions for safe use of the machine. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the dryer.
Always contact your dealer, distributor, or service
agent about any problems or conditions you do not
understand.

-6-
513123
Before Drying
Energy Saving Tips
•Make sure the lint filter is always clean.
•Do not overload the dryer.
•Do not overdry items.
•Remove items to be ironed while still damp.
•Large loads of similar fabrics dry the most
efficiently. However, dry permanent press in
smaller loads to prevent wrinkling.
•Use the correct cycle for the type of fabric
being dried.
•Locate your dryer so the exhaust duct is as
short and straight as possible.
•Do not open the door during the drying cycle.
•Plan to do your laundry on low humidity days;
your clothes will dry faster.
•Dry multiple loads of clothes one right after
another so dryer interior does not have to be
reheated for each load.
Helps and Hints
•The directions for installation and proper
exhausting are given in the Installation
Instructions which are included with the dryer.
•Static electricity may cause garments of
synthetic fibers (as in lingerie) to cling
together, especially if they are overdried. The
use of a liquid fabric softener in the rinse
water of the washer, or a fabric softener
sheet in the dryer, will soften clothes and
reduce static electricity.
•Do not wash or dry clothes that shed lint in
the same load with permanent press or knit
garments.
•Remove permanent press loads immediately
after dryer stops.
•Follow the care labels on FLAME RETARDANT,
SCOTCH- GUARD™, etc., garments for the
proper washing and drying.
•If loads should be damp for ironing, turn timer
knob to the ENERGY SAVER setting, if
applicable, marked with a dot (•), in
AUTOMATIC or TIME DRY cycles.
Sort
If you have correctly sorted the items for washing,
they should be properly sorted for drying too.
1. Sort by color.
2. Separate lint shedding fabrics and lint
receiving fabrics.
Towels, flannels, chenille, cottons, rugs, etc., shed
lint. Corduroys, knits (including socks), permanent
press, and synthetics attract lint.
3. Separate no heat, low heat and high heat
items.
In any kind of drying, lightweight fabrics will dry
faster than heavyweight fabrics. If mixed loads are
dried together (such as sheets and towels),
remove the lighter weight fabrics when they are dry
to prevent overdrying and wrinkling. The best
method is to dry clothes which require the same
time and temperature in the same load.
TLW1991N
TLW1991N

-7-
513123
Load
•Do not overload your dryer. Bulk, not weight,
determines the load size. If the dryer is
overloaded, it could cause discoloration or
permanent heat damage to the load.
•There should be space in the dryer for the
clothes to tumble freely and help to reduce
wrinkles.
•Large and small pieces together make up loads
which will tumble well. Permanent press loads
should be smaller to provide room for tumbling.
Proper tumbling allows for fewer wrinkles.
•A load can be too small. Just a few small
pieces will not tumble properly. They will take
longer to dry and they may be wrinkled. For
small loads, add a couple of large towels or non
lint shedding items to aid in tumbling.
•The following illustrations show the ideal load
sizes for fabrics. The average load will fill the
cylinder one third to half full when wet.
Do not wash or dry items soiled with
vegetable or cooking oils. Some oils
may remain after washing and may
cause the fabric to catch on fire by
itself.
W527
WARNING
DRY2031N
DRY2031N
Cylinder with wet linens and cottons
DRY2032N
DRY2032N
Cylinder with wet permanent press items

-8-
513123
Drying Special Items
Type of Load Special Instructions
Bedspreads • Choose heat for fabric.
• Dry one double or two single spreads.
• Chenille and tufted spreads will shed lint and should be dried by themselves.
• New spreads will contain loose lint. Tumble on NO HEAT Fabric Selector setting
before washing to remove loose lint.
• Dry completely.
Blankets
Electric
Synthetic Fibers
Thermal Cotton
Wool
• Choose DELICATE or NO HEAT Fabric Selector setting.
• If drying items in dryer is recommended by the manufacturer, dry as for wool.
• Do not stretch the blanket because of the wiring.
• Some electric blankets may have an insulation on the thermostats or on the wiring
which will not withstand dryer heat. Do not dryer dry unless the blanket manufacturer
says it can be done.
• Choose DELICATE or NO HEAT Fabric Selector setting.
• Some blankets are fluffy and will shed lint. Tumble on NO HEAT Fabric Selector
setting before washing to remove loose lint.
• Dry in dryer until just dry.
• Clean lint filter half way through drying cycle.
• Choose AUTOMATIC REGULAR/DELICATE cycle.
• Agitation and tumbling contribute to the shrinkage and felting of wool. Follow
blanket manufacturer’s instructions for proper care.
• Use approximately five dry bath towels and place them between folds in blanket to
lessen the tumbling.
• Set dryer for 20 minutes on the TIME DRY cycle. Use REGULAR Fabric Selector
setting. Check blanket when timer reaches 10. Wool blankets must be removed from
the dryer when damp.
• Stretch item gently to shape and finish drying in a flat position.
Curtains
Cotton
Fiberglass
Synthetic Fibers
• Choose AUTOMATIC REGULAR/DELICATE or TIME DRY cycle.
• Remove damp items for ironing or dry completely and then steam iron.
• DO NOT dry in the dryer unless recommended by the manufacturer.
• Fiberglass may shred. Particles may remain in the dryer and rub off on the next load.
• “Beta” fiberglass may be dryer dried if recommended by the manufacturer.
• Choose DELICATE or NO HEAT Fabric Selector settings.
• Allow room for tumbling to prevent wrinkling.
• Delicate or sheer curtains must be dried by themselves so they will not be snagged by
hooks or crushed by other clothes in the load.
• Some sheer curtains are heat sensitive. Dry 10 minutes only, plus the cool down
period. Remove from dryer immediately and hang.
• If the dryer has been heated from a previous load, the NO HEAT Fabric Selector
setting may be sufficient.
Denim, Corduroy • Choose AUTOMATIC REGULAR/DELICATES cycle.
• Dry completely and remove from dryer when seams are slightly wet to minimize
shrinkage.

-9-
513123
Draperies • Remove hooks and weights before washing.
• Choose heat for fabric and allow space in the dryer for tumbling.
• Some draperies may be removed when slightly damp and hung immediately.
• Lined draperies should be dry-cleaned because they have a tendency to pucker.
Knit Articles
Cottons
Synthetic Fibers
Wool
Knit fabrics are usually manufactured under tension (stretching). Cotton knits especially
may relax or draw together if every bit of moisture is removed from them. It is best to take
them out of the dryer with a trace of moisture remaining, then stretch to shape. If items
shrink from overdrying, rewet them and dry properly.
• Choose AUTOMATIC REGULAR/DELICATE or TIME DRY cycle.
• Remove slightly damp to minimize ironing.
• Reshape, smooth seams and pockets, etc.
• Choose AUTOMATIC REGULAR/DELICATE or AUTOMATIC PERMANENT
PRESS/KNITS cycle.
• Turn inside out to prevent pilling.
• Dry sweaters only with similar fabrics because they are lint receivers.
• Make sure the load is large enough for tumbling.
• Dry completely and remove from dryer immediately to minimize wrinkling.
• Choose DELICATE or NO HEAT Fabric Selector setting.
• For wool labeled “machine washable,” follow manufacturer’s directions. For other
wool, use wool blanket method.
• Do not dryer dry loosely knit wool or hand knits.
• Dry flat and stretch to shape from a pattern drawn before washing.
Lingerie
Cotton
Elastic
Foam Rubber
(Bras, bathing suits,
sun suits, etc.)
Spandex
Stretch Fabrics
Synthetic Fibers
• Choose AUTOMATIC REGULAR/DELICATE cycle.
• Elastic may be dried as for fabric.
•Donotoverdry.
• DO NOT dry foam rubber items in the dryer with heat. Fire may result. Use NO
HEAT Fabric Selector setting only.
• Choose DELICATE or NO HEAT Fabric Selector setting.
•Donotoverdry.
• Choose heat for the most delicate fiber.
• Dry completely as stretch fabrics will stretch into shape.
• Avoid drying with lint shedding fabrics.
• Choose TIME DRY cycle. Use DELICATE Fabric Selector setting.
• Some sheer fabrics, especially sheer knits, can be heat sensitive. Dry until just dry
(about 10 minutes) and remove from dryer immediately.
• Sheer fabrics should not be washed and dried with garments containing hooks or
zippers.
• Manufactured fabrics will create static electricity if overdried.
• Use fabric softener and avoid overdrying.
Type of Load Special Instructions
continued

-10-
513123
Mattress Pads • Read and carefully follow the fabric care instructions supplied by the mattress pad
manufacturer.
• Some mattress pads made of synthetic fibers are very heat sensitive. These pads can
be flammable if over-heated or over-dried. To avoid a fire hazard do not over-dry
mattress pads.
• Remove mattress pads from the dryer while they are still damp.
Pillows
Feather and
Down-Filled
Fiber-Filled (polyester)
Foam Rubber
• Ticking must be strong and seams secure.
• After washing, shake pillow to fluff feathers.
• Dry one large or two smaller pillows. Use TIME DRY cycle. Use DELICATE or
PERM PRESS Fabric Selector setting.
• Shake and reposition pillows several times during drying.
• Pillows must be dry in the center to prevent mildew.
• Drying may take two hours or longer. Reset dryer timer if necessary.
• Follow manufacturer’s directions.
• Do not dry in the dryer.
Quilts • Choose heat and cycle for fabric.
• Old quilts may be too fragile to machine wash or dry.
• Quilts filled with cotton may become lumpy.
• Remove from dryer slightly damp and stretch gently to shape. Quilted articles may
shrink if overdried.
Rugs
Cotton With Cotton
Backing
Rubber-Backed
Synthetic Fibers
• Choose AUTOMATIC REGULAR/DELICATE or TIME DRY cycle.
• Dry one large or several small rugs. For one small rug, add towels.
• Heat tends to deteriorate many types of rubber.
• Some types of rubber-like materials are flammable under certain conditions. DO
NOT dry foam rubber and rubber-like materials with heat. Use NO HEAT Fabric
Selector setting only.
• Choose DELICATE or NO HEAT Fabric Selector setting.
• Follow manufacturer’s suggestions.
• Some rugs are heat sensitive and should be removed from the dryer when damp, or
dried with no heat.
Slip Covers • Choose heat for fabric.
•Closezippers.
• Dry one couch cover, two chair covers or five or six pillow covers at one time.
• Remove from dryer when slightly damp.
• Press pleats, if necessary, and replace on furniture immediately.
• Stretch fabrics and knits should be dried completely so they will fit snug when
replaced on furniture.
Stuffed Animals and Toys • Make sure the filling and covering can be dryer dried.
• Cotton filling may become lumpy.
• Protect glass eyes by covering with a stocking or tie toy into a pillowcase.
• Choose heat for most sensitive fiber.
• Dry enough clothes in the load for good tumbling. DO NOT dry toys stuffed with
foam rubber or kapok in the dryer with heat.
• Use no HEAT Fabric Selector setting only.
Tennis Shoes • Choose DELICATE or NO HEAT Fabric Selector setting.
• Use a drying rack or tumble with at least four old bath towels.
Type of Load Special Instructions
