Alliance Laundry Systems 70444901R3 Owner's manual

Programming
www.comlaundry.com
Tumble Dryer
OPL Electronic Control
Refer to Page 3 for Model Identification
Part No. 70444901R3
July 2011
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
70444901 1
Table of
Contents
Introduction......................................................................................... 3
Model Identification ............................................................................. 3
Nameplate Location.............................................................................. 5
Preliminary Information.................................................................... 6
About the Control ................................................................................. 6
Power Failure Recovery................................................................... 6
Communications .............................................................................. 6
Audit Information ........................................................................... 6
Restore to Factory Defaults ............................................................ 7
Entering Program Mode................................................................... 7
Control Identification......................................................................... 8
Operational Keypad .............................................................................. 8
Operation Modes .................................................................................. 10
General Modes of Operation............................................................ 10
Power-up Mode................................................................................ 10
Idle Mode ......................................................................................... 10
Run Mode......................................................................................... 10
Rapid Advance Mode ...................................................................... 10
Pause Mode...................................................................................... 10
Error Mode....................................................................................... 10
Communication Mode ..................................................................... 11
Cool Down Mode............................................................................. 11
End of Cycle Mode .......................................................................... 11
Extended Tumble Mode................................................................... 11
Reversing Mode (reversing models only)........................................ 11
Entering Diagnostic Mode From Idle Mode.................................... 11
Machine Cycle Definition and Operation......................................... 12
Machine Cycle Operation ..................................................................... 12
Time Dry Cycle................................................................................ 12
Auto-Dry Cycle................................................................................ 12
Moisture Dry Cycle (if equipped).................................................... 12
Rotation Sensor Equipped Machines.................................................... 12
To Start a Cycle .................................................................................... 12
Entering the Manual Mode................................................................ 13
How to Enter the Manual Mode ........................................................... 13
Programming Control ........................................................................ 15
What Can Be Programmed? ................................................................. 15
How to Program a Cycle....................................................................... 15
Programmable Options Available......................................................... 15
Collecting Audit Information ............................................................ 25
How to Enter Audit Feature............................................................. 25
How to Read Audit Data.................................................................. 25
How to Exit Audit Feature............................................................... 25
Manual Reset....................................................................................... 26
How to Enter Manual Reset............................................................. 26

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
270444901
Testing Machine and Electronic Control Functions........................ 27
How to Enter Testing Feature .......................................................... 27
How to Start Tests............................................................................ 27
How to Exit Testing Feature ............................................................ 27
Diagnostic Test Descriptions................................................................ 29
Control Software Version Number Test .......................................... 29
Loading Door Test ........................................................................... 29
Lint Door Test.................................................................................. 29
Heater Interlock Test........................................................................ 29
Dip Switch Status............................................................................. 30
ICM Alarm Status ............................................................................ 30
ICM Reset Test ................................................................................ 30
External Alarm Test......................................................................... 30
Tumbler On Temperature Test......................................................... 31
Thermistor Temperature Test .......................................................... 31
Machine Configuration Display #2 Test.......................................... 31
Machine Configuration Display #3 Test.......................................... 32
Airflow Switch Test ......................................................................... 32
Fan Motor Test................................................................................. 32
Damper Motor Test.......................................................................... 32
Reverse Motor Test.......................................................................... 32
Production Test Cycle........................................................................... 33
To Enter Production Test Cycle....................................................... 33
To Exit Production Test Cycle......................................................... 33
Machine Errors................................................................................... 34
PDA Communications Error................................................................. 34
Open Thermistor Error ......................................................................... 34
Shorted Thermistor Error...................................................................... 34
Stove and Cabinet Limit Errors ............................................................ 34
Auto Ignition Retry (Gas Models Only)............................................... 35
Air Flow Switch Errors......................................................................... 35
Airflow Switch Sensed Closed While Not In Run Mode ................ 35
Airflow Switch Does Not Close After Cycle Started ...................... 35
Airflow Switch Bounces During A Running Cycle......................... 35
Rotation Sensor Error ........................................................................... 35
Fan Motor Contactor Error ................................................................... 36
Fan Motor Centrifugal Switch Error..................................................... 36
DIP Switch/Harness Index Mismatch Error ......................................... 36
Moisture Sensor Error........................................................................... 36
Error Codes......................................................................................... 37
Communications Mode ...................................................................... 39
Infra-red Communications.................................................................... 39
How to Begin Communications with An External Device.............. 39
Cycle Charts ........................................................................................ 40

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
70444901
Introduction
Model Identification
Gas Steam/Thermal Oil Electric
25
Pound
CHD25G2-CA025L
CHD25G2-CA025N
CHD25G2-CT025L
CHD25G2-CT025N
CHD25G2-CU025L
CHD25G2-CU025N
DR25G2-BA025L
DR25G2-BA025N
DR25G2-BT025N
DR25G2-BT025L
DR25G2-BU025N
DR25G2-BU025L
HA025L
HA025N
HT025L
HT025N
HU025L
HU025N
IPD25G2-IT025N
IPD25G2-IT025L
SA025L
SA025N
ST025L
ST025N
SU025L
SU025N
UA025L
UA025N
UT025L
UT025N
UU025L
UU025N
CHD25S2-CU025S
CHD25S2-CT025S
DR25S2-BT025S
DR25S2-BU025S
HT025S
HU025S
IPD25S2-IT025S
ST025S
SU025S
UT025S
UU025S
CHD25E2-CT025E
CHD25E2-CU025E
DR25E2-BT025E
DR25E2-BU025E
HT025E
HU025E
IPD25E2-IT025E
ST025E
SU025E
UT025E
UU025E
30
Pound
CHD30G2-CA030L
CHD30G2-CA030N
CHD30G2-CT030L
CHD30G2-CT030N
CHD30G2-CU030L
CHD30G2-CU030N
DR30G2-BA030N
DR30G2-BA030L
DR30G2-BT030D
DR30G2-BT030L
DR30G2-BT030N
DR30G2-BU030N
DR30G2-BU030L
SA030L
SA030N
HA030L
HA030N
HT030D
HT030L
HT030N
HU030L
HU030N
IPD30G2-IT030N
IPD30G2-IT030L
ST030D
ST030L
ST030N
SU030L
SU030N
UA030L
UA030N
UT030L
UT030N
UU030L
UU030N
CHD30S2-CU030S
CHD30S2-CT030S
DR30S2-BT030S
DR30S2-BU030S
HT030S
HU030S
IPD30S2-IT030S
ST030S
SU030S
UT030S
UU030S
CHD30E2-CU030E
CHD30E2-CT030E
DR30E2-BT030E
DR30E2-BU030E
HT030E
HU030E
IPD30E2-IT030E
ST030E
SU030E
UT030E
UU030E
30
Pound
Stacked
CHD30STG2-CAT30L
CHD30STG2-CAT30N
CHD30STG2-CTT30L
CHD30STG2-CTT30N
CHD30STG2-CUT30L
CHD30STG2-CUT30N
DRST30G2-BAT30L
DRST30G2-BAT30N
DRST30G2-BTT30D
DRST30G2-BTT30L
DRST30G2-BTT30N
DRST30G2-BUT30L
DRST30G2-BUT30N
HAT30L
HAT30N
HTT30D
HTT30L
HTT30N
IPD30STG2-ITT30N
IPD30STG2-ITT30L
HUT30L
HUT30N
SAT30L
SAT30N
STT30D
STT30L
STT30N
SUT30L
SUT30N
CHD30STS2-CUT30S
CHD30STS2-CTT30S
DRST30S2-BUT30S
DRST30S2-BTT30S
HTT30S
HUT30S
IPD30STS2-ITT30S
STT30S
SUT30S
CHD30STE2-CUT30E
CHD30STE2-CTT30E
DRST30E2-BUT30E
DRST30E2-BTT30E
HTT30E
HUT30E
IPD30STE2-ITT30E
STT30E
SUT30E
35
Pound
CHD35G2-CA035L
CHD35G2-CA035N
CHD35G2-CT035L
CHD35G2-CT035N
CHD35G2-CU035L
CHD35G2-CU035N
DR35G2-BA035N
DR35G2-BA035L
DR35G2-BT035N
DR35G2-BT035L
DR35G2-BU035N
DR35G2-BU035L
HA035L
HA035N
HT035L
HT035N
HU035L
HU035N
IPD35G2-IT035L
IPD35G2-IT035N
SA035L
SA035N
ST035L
ST035N
SU035L
SU035N
UA035L
UA035N
UT035L
UT035N
UU035L
UU035N
CHD35S2-CU035S
CHD35S2-CT035S
DR35S2-BT035S
DR35S2-BU035S
HT035S
HU035S
IPD35S2-IT035S
ST035S
SU035S
UT035S
UU035S
CHD35E2-CT035E
CHD35E2-CU035E
DR35E2-BT035E
DR35E2-BU035E
HT035E
HU035E
IPD35E2-IT035E
ST035E
SU035E
UT035E
UU035E
Models continued on next page.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
70444901
4
(Continued)
Gas Steam/Thermal Oil Electric
45
Pound
Stacked
CTT45L
CTT45N
DRST45G2-BAT45L
DRST45G2-BAT45N
DRST45G2-BTT45D
DRST45G2-BTT45L
DRST45G2-BTT45N
DRST45G2-BUT45L
DRST45G2-BUT45N
HAT45L
HAT45N
HTT45D
HTT45L
HTT45N
HUT45L
HUT45N
IPD45STG2-ITT45N
IPD45STG2-ITT45L
SAT45L
SAT45N
STT45D
STT45L
STT45N
SUT45L
SUT45N
Not Applicable Not Applicable
50
Pound
CA050L
CA050N
CT050L
CT050N
CU050L
CU050N
DR55G2-BA050N
DR55G2-BA050L
DR55G2-BT050D
DR55G2-BT050L
DR55G2-BT050N
DR55G2-BU050N
DR55G2-BU050L
HA050L
HA050N
HT050D
HT050L
HT050N
HU050L
HU050N
IPD50G2-IT050N
IPD50G2-IT050L
SA050L
SA050N
ST050D
ST050L
ST050N
SU050L
SU050N
UA050L
UA050N
UT050L
UT050N
UU050L
UU050N
CT050S
CT050T
CU050S
CU050T
DR55S2-BT050T
DR55S2-BT050S
DR55S2-BU050S
DR55S2-BU050T
HT050S
HT050T
HU050S
HU050T
IPD50S2-IT050S
IPD50S2-IT050T
ST050S
ST050T
SU050S
SU050T
UT050S
UT050T
UU050S
UU050T
CT050E
CU050E
DR55E2-BT050E
DR55E2-BU050E
HT050E
HU050E
IPD50E2-IT050E
ST050E
SU050E
UT050E
UU050E
55
Pound
CA055L
CA055N
CT055L
CT055N
CU055L
CU055N
HA055L
HA055N
HT055D
HT055L
HT055N
HU055L
HU055N
IPD55G2-IT055N
IPD55G2-IT055L
SA055L
SA055N
ST055D
ST055L
ST055N
HU055L
HU055N
SU055L
SU055N
UA055L
UA055N
UT055L
UT055N
UU055L
UU055N
Not Applicable
CT055E
CU055E
HT055E
HU055E
IPD55E2-IT055E
ST055E
SU055E
UT055E
UU055E
75
Pound
CA075L
CA075N
CT075L
CT075N
CU075L
CU075N
DR80G2-BA075N
DR80G2-BA075L
DR80G2-BT075D
DR80G2-BT075L
DR80G2-BT075N
DR80G2-BU075N
DR80G2-BU075L
HA075L
HA075N
HT075D
HT075L
HT075N
HU075L
HU075N
IPD75G2-IT075L
IPD75G2-IT075N
SA075L
SA075N
ST075D
ST075L
ST075N
STF75L
STF75N
SU075L
SU075N
UA075L
UA075N
UT075L
UT075N
UTF75L
UTF75N
UU075L
UU075N
CT075S
CT075T
CU075S
CU075T
DR80S2-BT075T
DR80S2-BT075S
DR80S2-BU075T
DR80S2-BU075S
HT075S
HT075T
HU075S
HU075T
IPD75S2-IT075T
IPD75S2-IT075S
ST075S
ST075T
SU075S
SU075T
UT075S
UT075T
UU075S
UU075T
CT075E
CU075E
DR80E2-BT075E
DR80E2-BU075E
HT075E
HU075E
IPD75E2-IT075E
ST075E
SU075E
UT075E
UU075E
Models continued on next page.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
5
70444901
Includes models with the following control suffixes:
EO – OPL electronic RE – reversing OPL electronic
Nameplate Location
The nameplate is located on the back of the machine
and is programmed in the Control.
(Continued)
Gas Steam/Thermal Oil Electric
120
Pound
CA120L
CA120N
CT120L
CT120N
CU120L
CU120N
DR120G2-BA120L
DR120G2-BA120N
DR120G2-BT120L
DR120G2-BT120N
DR120G2-BU120L
DR120G2-BU120N
HA120L
HA120N
HT120L
HT120N
HU120L
HU120N
IPD120G2-IT120N
IPD120G2-IT120L
SA120L
SA120N
ST120L
ST120N
SU120L
SU120N
UA120L
UA120N
UT120L
UT120N
UU120L
UU120N
CT120S
CT120T
CU120S
CU120T
DR120S2-BT120T
DR120S2-BU120S
DR120S2-BU120T
DR120S2-BT120S
HT120S
HT120T
HU120S
HU120T
IPD120S2-IT120S
IPD120S2-IT120T
ST120S
ST120T
SU120S
SU120T
UT120S
UT120T
UU120S
UU120T
Not Applicable
170
Pound
CA170L
CA170N
CT170L
CT170N
CU170L
CU170N
DR170G2-BA170L
DR170G2-BA170N
DR170G2-BT170L
DR170G2-BT170N
DR170G2-BU170L
DR170G2-BU170N
HA170L
HA170N
HT170L
HT170N
HU170L
HU170N
IPD170G2-IT170N
IPD170G2-IT170L
SA170L
SA170N
ST170L
ST170N
SU170L
SU170N
UA170L
UA170N
UT170L
UT170N
UU170L
UU170N
CT170S
CT170T
CU170S
CU170T
DR170S2-BT170T
DR170S2-BU170S
DR170S2-BU170T
DR170S2-BT170S
HT170S
HT170T
HU170S
HU170T
IPD170S2-IT170T
IPD170S2-IT170S
ST170S
ST170T
SU170S
SU170T
UT170S
UT170T
UU170S
UU170T
Not Applicable

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
670444901
Preliminary Information
About the Control
This control is an advanced, programmable computer
that lets the owner control most machine features by
pressing a sequence of keypads.
The control allows the owner to program custom
cycles, run diagnostic cycles, and retrieve audit and
error information.
Tumblers shipped from the factory have default cycles
and other settings built in. The owner can change the
default cycle or any cycle.
IMPORTANT: It is extremely important that the
tumbler has a positive ground and that all
mechanical and electrical connections are made
before applying power to or operating the tumbler.
Power Failure Recovery
If a cycle is in progress when the power fails, and if
the power outage lasts three or more seconds, the cycle
is lost and cannot be resumed when power recovers. If
the power outage lasts less than three seconds, the
control will resume the cycle when the power
recovers.
Communications
The control has the ability to communicate with a
PDA and a laptop with an IrDA device running the
control software. Devices such as PDAs and laptops
that are IrDA capable (able to transmit information to
machine) that have been tested and approved for use
with the software can be used as a tool for managing
the machine.
Audit Information
The control collects and stores audit information,
which can be accessed with a PDA or PC. Refer to the
following list for some of the available audit
information. Refer to PC and PDA Application User
Instructions.
Total Number of Individual Cycle Counters
End of Cycle to Loading Door Open Time
End of Cycle to Start of Next Cycle Time
Total Number of Machine Cycles
Total Number of Operating Minutes
Power Failure Audit Data
The PDA or PC can receive audit and program data
from the control, and send programming data and
diagnostic commands to the control. Refer to PC and
PDA Application User Instructions for additional
information.
Some of the above listed audit data is available
manually. Refer to Collecting Audit Information
section.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Preliminary Information
7
70444901
Restore to Factory Defaults
When the user resets to factory default, the control
resets all of the default values. The control also resets
Machine Cycles #1 through #30. The control will also
reset the following to factory-defaults:
Default Global Settings
Ignition Retries = 3
Temperature Units = Fahrenheit (°F)
High (H) Temperature = 190 (°F)
Medium (M) Temperature = 160 (°F)
Low (L) Temperature = 140 (°F)
Very Low (VL) Temperature = 120 (°F)
Cool Down Temperature = 100 (°F)
Cool Down Time = 2 minutes
Rapid Advance = Disabled
Multi-Segment Cycles = Disabled
Daylight Saving = Enabled
Key Pad Audio = Enabled
End of Cycle Audio = Enabled (5 seconds)
End of Cycle External Signal = Enabled (5 seconds)
Clean Lint Screen Reminder = Off
Display Limit Errors = Disabled
Manual Diagnostics = Enabled
*Manual Programming = Enabled
**Reverse Cylinder Rotate Time = 120 (seconds)
**Reverse Cylinder Stop Time = 6 (seconds)
**Advanced Reversing = Disabled
***Advanced Options for Moisture Dry = Disabled
***Display Moisture Sensor Error = Disabled
*If manual programming is disabled, programming
changes to the control can only be made with an
external communication device. Refer to PC and PDA
Application User Instructions.
**Only available on units equipped with reversing
feature.
***Only available on units equipped with moisture
sensing feature.
Refer to Factory Defaults, Menu section for
information on Restoring Factory Defaults.
Entering Program Mode
1. Press and hold Stop ( ), then Back ( ), then
Up ( ) to enter the programming options.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
870444901
Control Identification
Operational Keypad
The control includes five keypads. These functions are
available to the operator and are intended to control
and manage operation of the tumbler. Refer to
Figure 1, Figure 2, Figure 3, Figure 4 and Table 1.
S Models
H Models
U Models
B, C, and I Models
NOTE: The reversing feature is not available on all
models.
TMB1345R
Figure 1
TMB1346R
Figure 2
PROGRAM REVERSING ENERGY
SAVER
HEATING
START
STOP
BACK
PROGRAM RE V E RSING ENE RGY
SAVER
HEATING
STOP
START
BACK
TMB1371R
Figure 3
TMB1375R
Figure 4
PROGRAM RE V ERSI NG EN ERGY
SAVER
HEATING
STOP
BACK
START
ECO

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Identification
9
70444901
Keypad Description
UP ARROW Press to scroll through menu options and edit parameter values.
DOWN ARROW Press to scroll through menu options and edit parameter values.
BACK ARROW
Press to go to the list of parameters without saving the value when adjusting the value of a
programming parameter. Also, press to go to the previous menu when the control displays a
parameter, return to Idle Mode when the control displays the main menu or clear an error
message from the display.
STOP Press to pause a cycle while in Run Mode or abort a cycle if the control is in Pause Mode.
START Press to start the selected cycle, select an option when in the menu or save a value when
editing a parameter.
Status Indicator LED Description
PROGRAM LED will light up if the control is in Manual Programming Mode or if a cycle is being
modified.
REVERSING LED will light up when cylinder is reversing.
ENERGY SAVER LED will light up when a Moisture Dry or Auto Dry cycle is running.
HEATING LED will light up when the machine is in the heat portion of the cycle.
Table 1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Identification
70444901
10
Operation Modes
General Modes of Operation
In each mode of operation, the user may press keypads
or communicate with the control to change the
displayed menu.
Power-up Mode
The control enters this mode at power-up. When
power is applied to the tumbler, the control becomes
active and will display its software version as “XX”
(“XX” is the version number) for one second. If the
control was not powered down during a running cycle,
it will enter the Idle Mode. After the control completes
operation in the Power-up Mode it will enter Idle
Mode.
Idle Mode
The control is ready for operation in Idle Mode.
Control can display different menus depending on user
input (keypad press, opening or closing the loading
door, or PDA communication). If there is no user input
for 10 minutes, display will turn off.
While in Idle Mode the control will display the active
cycles. Anytime the control returns to Idle Mode after
a cycle has been run, the control will display the last
run cycle (except the first time the control is powered
up it will show the first cycle).
Press the up arrow ( ) to increment the cycle number.
Press the down arrow ( ) to decrease the cycle
number. If the Start ( ) keypad is pressed and
either the loading door or lint door is open the control
will show “” for five seconds or until door is
closed.
If the control is in Idle Mode, Cycle Menu is
displayed, loading and lint door closed, and the
Start ( ) keypad is pressed, control will enter Run
Mode.
Run Mode
The Control enters Run Mode during a cycle. Display
shows machine cycle time remaining, the current cycle
type, segment and temperature. Loading and lint doors
are closed during Run Mode. Press Stop ( ) keypad
to stop cycle and enter Pause Mode. Control enters
Pause Mode if loading or lint door opens. Press
Start ( ) to Rapid Advance.
Rapid Advance Mode
If the Rapid Advance Option is enabled, the user can
advance a running machine cycle by pressing the
Start ( ) keypad. In a Time Dry cycle, pressing the
Start ( ) keypad will decrease the remaining time
by one minute. Pressing and holding the Start ( )
keypad will decrease the remaining time by four
minutes per second until the end of the cycle.
In the Auto-Dry and Moisture Dry cycles, pressing the
Start ( ) keypad will advance the cycle to the next
enabled segment. Note that Auto-Dry cycles only have
one programmable segment.
In the Cool Down segment, pressing the Start ( )
keypad will decrease the remaining time by one
minute.
When the cycle is completed, the audit counter, Total
Rapid Advance Cycles, is incremented rather than the
Total Machine Cycles audit counter. If the Rapid
Advance Option is disabled preventing a manual
Rapid Advance, the user may still execute a Rapid
Advance using the PDA or PC. Refer to PC and PDA
Application User Instructions for additional
information on using a PDA or PC to Rapid Advance a
cycle.
Pause Mode
If Stop ( ) keypad is pressed or the loading or lint
door is opened while in Run Mode, control enters
Pause Mode.
If the door was opened to enter Pause Mode, the
control will show “” until the door is closed or
Pause Mode is exited. If the door is closed, the control
will show “” for one second followed by
“” for one second as well as flash the
Start ( ) keypad LED one second on/one second
off.
If the Stop ( ) keypad was pressed to enter Pause
Mode and the loading door is closed, the control will
show “” until Pause Mode is exited.
Any time “” is shown on the control, the
Start ( ) keypad LED will flash one second on/one
second off to prompt the user to restart the cycle.
Error Mode
This mode will be entered to display all fatal machine
errors.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Identification
11
70444901
Communication Mode
This mode is entered whenever the control is
communicating with a PDA. Refer to PC and PDA
Application User Instructions.
Cool Down Mode
The control enters the Cool Down Mode after the heat
segment of the cycle is completed. The control turns
the heater off and for steam heated units turns the
damper motor on. The cool down segment will end
once the cool down temperature has been reached or
the programmed cool down time expires, which ever
happens first.
End of Cycle Mode
The control enters End of Cycle Mode after the cool
down segment is finished. The display will toggle
between “” and “” for one second each
until End of Cycle Mode is exited. If the door has not
been opened or a keypad has not been pressed after
two minutes, the machine will enter Extended Tumble
Mode. This mode is exited when the door is opened or
Stop ( ) keypad is pressed. The control will then
return to Idle Mode.
Extended Tumble Mode
The Extended Tumble Mode has two portions. The
Anti-Wrinkle Tumble is entered two minutes after the
cycle has ended if the door is not opened. The cylinder
will tumble for 30 seconds every two minutes for up to
one hour.
If the door hasn’t been opened and no keys have been
pressed one hour after the Anti-Wrinkle Tumble has
ended, the control increments the Anti-Wrinkle Time
Exceeded audit counter and enters the Delayed
Tumble. The cylinder will tumble for two minutes
every 60 minutes for up to 18 hours.
Reversing Mode (reversing models only)
Models equipped with the reversing feature will rotate
in the forward direction, pause, rotate in the reverse
direction and then pause for programmable times and
segments of the cycle. Factory default rotate time is
120 seconds and reversing stop time is 6 seconds for
all cycles with reversing enabled.
Entering Diagnostic Mode From Idle Mode
When entered from the Idle Mode, the control will be
running a test selected by the user via keypad presses
or communication with a device.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
12 70444901
Machine Cycle Definition and Operation
There are 30 machine cycles that can be selected and
run. Machine cycles can be modified or made
“unavailable” by manually editing them in Modify
Cycle Menu or by using the PDA to download a
modified machine cycle into the control. Machine
cycles cannot be deleted, but can be made
“unavailable” so that they are not visible from the
Cycle Menu. New machine cycles cannot be created,
but existing machine cycles that have been edited to be
“unavailable” may be re-edited to be available again.
Machine Cycle Operation
When a cycle is run, the control runs the cycle
segment by segment in a sequence. First the control
examines the Cycle Type chosen to determine if it is a
Time Dry, Auto-Dry or Moisture Dry (if equipped)
cycle type. Then the first segment is examined to see if
it is programmed to “” or “”. If the segment is
programmed to “”, control skips to the next
segment.
At the start of some machine cycles, the control
displays a Total Remaining Cycle time. This time is
taken from the machine cycles as they are
programmed. The Total Remaining Cycle Time begins
to count down as soon as the cycle is started.
Time Dry Cycle
In this type of cycle, the control will regulate the
temperature and time duration as programmed for the
cycle chosen.
Auto-Dry Cycle
If this type of cycle is selected, the control determines
the cycle time based on the temperature and dryness
level programmed for the cycle chosen.
Moisture Dry Cycle (if equipped)
In this type of cycle, the control checks the
programmed material type, programmed target
moisture content, programmed temperature and the
data received from the moisture sensing system to
achieve the desired results.
Rotation Sensor Equipped
Machines
On machines equipped with a rotation sensor, the
control monitors the rotation sensor to verify the
cylinder is rotating. The control calculates the
cylinder’s RPM. If the RPM drops to zero while the
cylinder is supposed to be rotating, the control will
advance to the Cool Down segment of the cycle and an
error message will be displayed.
To Start a Cycle
1. Press the Up ( ) or Down ( ) keypad to change
cycles.
2. Press Start ( ) to start selected cycle.
NOTE: If door is not closed when the Start ( )
keypad is pressed, display will show “”.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 13
70444901
Entering the Manual Mode
For programming, testing, and retrieving information
from the control, it is often necessary to enter the
Manual Mode by following the steps below.
For an overview of entering the Manual Mode, refer to
the flowchart on the following page.
How to Enter the Manual Mode
1. Control must be in Idle Mode.
2. Press and hold the Stop ( ) keypad, then press
and hold the Back ( ) keypad, then press the
Up ( ) keypad.
3. The display will show “”.
4. Press the Up ( ) or the Down ( ) keypad to
scroll through the options until the desired option
appears in the display.
5. Press the Start ( ) keypad to enter the
displayed mode.
6. To exit, press the Back ( ) keypad. The control
will revert back to Idle Mode.
Manual Programming can only be turned on or off
with an external device. Refer to the appropriate
instruction manual. Diagnostics can be turned on and
off using an external device by manual programming.
By default, Manual Programming is turned “”.
The manual features available in each group are as
follows (the menu displayed on the display in this
mode is in parentheses).
Manual Programming ()
Manual Read Audit ()
Manual Reset ()
Diagnostic Tests ()
If a manual parameter is turned off or unavailable
(ex: trying to enter diagnostics while a cycle is
running), the display will change from the selected
feature to “”, an audio signal will sound for one
second and the features in the parameter cannot be
entered. The display will then return to the selected
feature.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Entering the Manual Mode
70444901
14
Manual Mode: Enter by pressing
Stop ( ), then Back (), then
Up () keypads
“Prog”
Manual
Programming
“Avdit”
Manual Read
Audit
“rESEt”
Manual Reset
“diAg”
Diagnostic
Tests
Press the Up () or
the Down () keypad
to scroll through the
Manual Mode options.
Press the Start ( /) keypad to
enter Manual Programming.
Refer to Manual
Programming flowchart.
“CyCLE”
Total machine cycles
“totHrS”
Total Run Hours
“rA CyC”
Total Rapid
Advance Cycles
“HEAtHr”
Total Heat Hours
Press the
Up ()
or the
Down ()
keypad to
scroll through
the Audit
options.
Press the
Start ( /) keypad.
Press the Start ( /)
keypad to reset control.
Press the Start ( /) keypad to
enter Diagnostic Tests. Refer to
Diagnostic Tests flowchart. TMB1372R
Press the Start ( /)
keypad to read audit.
“Ab CyC”
Total Aborted Cycles
“End2OP”
Average Time From End
of Cycle to Door Open
“AntiCt”
Total Time
Anti-wrinkle Exceeded
To enter a programming
option, press the Start ( /)
keypad. To exit, press
the Back ()keypad.
Press the Start ( /)
keypad to read audit.
Press the Start ( /)
keypad to read audit.
Press the Start ( /)
keypad to read audit.
Press the Start ( /)
keypad to read audit.
Press the Start ( /)
keypad to read audit.
Press the Start ( /)
keypad to read audit.
“End2St”
Average Time From End
of Cycle to Run Mode
Press the Start ( /)
keypad to read audit.
TMB1372R

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 15
70444901
Programming Control
What Can Be Programmed?
This feature allows the owner to program cycle
parameters and other features by using the keypads.
The control must have the Manual Programming Mode
enabled, which is the factory default. This mode can
only be turned OFF and ON by using an external
device. Refer to this section when programming the
control.
For an overview of the programming organization,
refer to the flowcharts on the following pages.
For more advanced users, a quick reference list of the
options available through the programming mode is
located on this page.
NOTE: The codes in the Option Display column of
the Programmable Options List are what will show
in the display when that option is selected.
How to Program a Cycle
1. Press the Up ( ) or Down ( ) keypad to scroll
through the option list.
2. Press Start ( ) to select an option to program.
3. Press the Up ( ) or Down ( ) keypad to change
the value of that option.
4. Press Start ( ) to save the change.
NOTE: Press the Back ( ) keypad to leave the
option without saving any change.
5. After pressing Start ( ), control will go to the
next option in the list.
6. Press Back ( ) keypad to go to Idle Mode.
Programmable Options Available
Option
Number
Option
Display Description Default Value Value Range
1“”Cycle Programming --
a“” Cycle XX (XX represents cycles 1-30) - -
1“” Cycle XX Enable Disable - on/oFF
2“” Cycle XX Type - tinE (Time Dry), Auto (Auto Dry), noist
(Moisture Dry)
3“” Cycle XX Material Type - 0 (Cotton), 1 (Blend), 2 (Bedding), 3
(Delicate), 4 (Synthetic), 5 (Wool)
4“” Cycle XX Time Past Target (minutes) - 0-15
5“” Segment 1 - CXXS11 (Segment 1 Enable/Disable),
CXXS12 (Segment 1 Time),
CXXS13 (Segment 1 Temperature),
CXXS14 (Segment 1 Auto Dry Target
Level),
CXXS15 (Segment 1 Moisture Dry Target
Moisture),
CXXS16 (Segment 1 Reversing Enable/
Disable)
6“” Segment 2 - CXXS21 (Segment 2 Enable/Disable),
CXXS22 (Segment 2 Time),
CXXS23 (Segment 2 Temperature),
CXXS24 (Segment 2 Auto Dry Target
Level),
CXXS25 (Segment 2 Moisture Dry Target
Moisture),
CXXS26 (Segment 2 Reversing Enable/
Disable)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
70444901
16
Option
Number
Option
Display Description Default Value Value Range
7“” Segment 3 - CXXS31 (Segment 3 Enable/Disable),
CXXS32 (Segment 3 Time),
CXXS33 (Segment 3 Temperature),
CXXS34 (Segment 3 Auto Dry Target
Level),
CXXS35 (Segment 3 Moisture Dry Target
Moisture),
CXXS36 (Segment 3 Reversing Enable/
Disable)
8“” Segment 4 - CXXS41 (Segment 4 Enable/Disable),
CXXS42 (Segment 4 Time),
CXXS43 (Segment 4 Temperature),
CXXS44 (Segment 4 Auto Dry Target
Level),
CXXS45 (Segment 4 Moisture Dry Target
Moisture),
CXXS46 (Segment 4 Reversing Enable/
Disable)
9“” Segment 5 - CXXS51 (Segment 5 Enable/Disable),
CXXS52 (Segment 5 Time),
CXXS53 (Segment 5 Temperature),
CXXS54 (Segment 5 Auto Dry Target
Level),
CXXS55 (Segment 5 Moisture Dry Target
Moisture),
CXXS56 (Segment 5 Reversing Enable/
Disable)
10 “” Cool Down - CXXCd1 (Cool Down Temperature),
CXXCd2 (Cool Down Time),
CXXCd3 (Cool Down Segment Reversing
Enable/Disable)
11 “” Reversing - CXX r1 (Cycle Reversing Enable/Disable),
CXX r2 (Cycle Reversing Rotate Time),
CXX r3 (Cycle Reversing Stop Time)
2“”Global Cool Down - -
a“ ” Cool Down Temperature 100°F/38°C 70°-110°F/21°-43°C
b“ ” Cool Down Time (minutes) 2 1-15
3“” Global Reversing Parameters - -
a“ ” Rotate Time (seconds) 7 (120) 3-9 (30-540 seconds)
b“ ” Stop Time (seconds) 0 (6) 0-4 (6-10 seconds)
c“ ” Advanced Reversing 0 0 (oFF), 1 (on)
4“” Global Temperatures - -
a“ ” Global Very Low Temperature 120°F/49°C 100°-120°F/38°-49°C
b“ ” Global Low Temperature 140°F/60°C 120°-140°F/49°-60°C (50, 75, 120, 170
Pound Models), 105°-145°F/41°-63°C (25,
30, T30 Pound Models), 125°-155°F/52°-
68°C (35, T45, 55 Pound Models)
c“ ” Global Medium Temperature 160°F/71°C 140°-160°F/60°-71°C (50, 75, 120, 170
Pound Models), 135°-160°F/57°-71°C (25,
30, T30 Pound Models), 145°-165°F/63°-
74°C (35, T45, 55 Pound Models)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
17
70444901
Option
Number
Option
Display Description Default Value Value Range
d“ ” Global High Temperature 190°F/88°C 160°-190°F/71°-88°C (35, T45, 55, 50, 75,
120, 170 Pound Models), 155°-190°F/68°-
88°C (25, 30, T30 Pound Models)
5“” Global Audio Signal - -
a“ ” End of Cycle 1 0 (oFF), 1 (on)
b“ ” End of Cycle Duration (seconds) 5 1-120
c“ ” Keypad Feedback 1 0 (oFF), 1 (on)
6“” External Signal - -
a“ ” External Signal End of Cycle 1 0 (oFF), 1 (on)
b“ ” External Signal End Of Cycle Duration
(seconds)
5 1-120
7“” Multi-Segment Cycles 0 1 (Enable), 0 (Disable)
8“” Advanced Moisture Dry Options 0 1 (Enable), 0 (Disable)
9“”ErrorDisplays - -
a“” Display Limit Errors 0 1 (Enable), 0 (Disable)
b“ ” Display Moisture Sensor Error 1 1 (Enable), 0 (Disable)
10 “” Temperature 0 0 (Fahrenheit), 1 (Celsius)
11 “” Auto Ignite Retry 3 0-255
12 “” Clean Lint Reminder 0 0 (off)-255
13 “” Real Time Clock - -
a“ ” Minutes - 0-59
b“ ” Hours - 0-23
c“ ”Day - 1-7
d“ ” Date - 1-31
e“ ” Month - 1-12
f“ ” Year - 0-99
g“ ” Daylight Saving 1 1 (Enable), 0 (Disable)
14 “” Manual Rapid Advance 0 1 (Enable), 0 (Disable)
15 “” Manual Diagnostics 1 1 (Enable), 0 (Disable)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
70444901
18
“CyCLE-”
Cycle Programming
“CXXEn”
Cycle XX Enable Disable
“CyCXX”
Cycle to be programmed
“CXXtyP”
Cycle XX Type
Press the
“CXXnt”
Cycle XX Material Type
“CXXtPt”
Cycle XX
Time Past Target
“Prog”
Manual Programming
“on”
Enable
“oFF”
Disable
“tinE”
Time Dry
“Avto”
Auto Dry
“noist”
Moisture Dry
“0”
Cotton
“1”
Blend
“2”
Bedding
“3”
Delicate
“4”
Synthetic
“5”
Wool
Start ( /) keypad
To enter a programming
option, press the Start ( /)
keypad. To exit, press
the Back ()keypad.
continued
continued
Press the Up ()
or the Down ()
keypad to scroll
through the
programmable options.
TMB1373R-a
TMB1373R-a
