Alliance Laundry Systems Speed Queen DR7004WE User manual

User's Guide
for Dryers
DRY737C_SVG
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the
machine.
(If this machine changes ownership, this manual
must accompany machine.)
www.speedqueen.com
Part No. D518541ENR4
May 2023

WARNING
WARNING
Risk of fire. Highly flammable material.
W881
Hazardous voltage inside. Disconnect power before
servicing.
Read all instructions before using unit.
WARNING
FOR YOUR SAFETY, the information in this manual
must be followed to minimize the risk of fire or ex-
plosion or to prevent property damage, personal in-
jury or death.
W033
WARNING
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
• WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Clear the room, building or area of all occu-
pants.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
• Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
W052
IMPORTANT: Purchaser must consult the local gas
supplier for suggested instructions to be followed if
the dryer user smells gas. The gas utility instructions
plus the SAFETY and WARNING note directly above
must be posted in a prominent location near the dryer
for customer use.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. D518541ENR4

WARNING
• Installation of unit must be performed by a quali-
fied installer.
• Install clothes dryer according to manufacturer’s
instructions and local codes.
• DO NOT install a clothes dryer with flexible plas-
tic venting materials. If flexible metal (foil type)
duct is installed, it must be of a specific type
identified by the appliance manufacturer as suita-
ble for use with clothes dryers. Refer to section
on connecting exhaust system. Flexible venting
materials are known to collapse, be easily crush-
ed, and trap lint. These conditions will obstruct
clothes dryer airflow and increase the risk of fire.
W729R1
WARNING
To reduce the risk of severe injury or death, follow all
installation instructions. Save these instructions.
W894
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
W053
This product uses FreeRTOS V7.2.0 (www.freertos.org).
The following information applies to the state of Massachu-
setts, USA.
• This appliance can only be installed by a Massachusetts li-
censed plumber or gas fitter.
• This appliance must be installed with a 36 inch [910 mm]
long flexible gas connector.
• A “T-Handle” type gas shut-off valve must be installed in
the gas supply line to this appliance.
• This appliance must not be installed in a bedroom or bath-
room.
EPA EST. NO.:101050-WI-1
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. D518541ENR4

Register Your Product
Welcome to the Speed Queen family.
Thank you for your support of our truly commercial quality
products. Please take a moment to register your product.
Benefits of registering your product:
• Provides verification of ownership
• Receive product notifications
• Simplifies warranty service, if needed
• Grants access to leave a product review
• Opt-in for latest offers and promotions
It's quick and easy to register.
Simply go to:
www.speedqueen.com/register/
Or scan:
Register Your Product
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. D518541ENR4

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and “CAU-
TION”), followed by specific instructions, are found in this man-
ual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and
those maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions
Save These Instructions
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons when using your dryer, fol-
low these basic precautions:
W130
• Read all instructions before using the dryer.
• Install this dryer according to the INSTALLATION INSTRUC-
TIONS. Refer to the EARTH/GROUND INSTRUCTIONS in the
INSTALLATION manual for the proper earth/ground connec-
tion of the dryer. All connections for electrical power, earth/
ground and gas supply must comply with local codes and
be made by licensed personnel when required. Do not do it
yourself.
• Do not install or store the dryer where it will be exposed to
water and/or weather.
• Do not dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline or machine
oils, vegetable or cooking oils, cleaning waxes or chemi-
cals, dry-cleaning solvents, thinner, anything containing
chemicals such as in mops and cleaning cloths, or other
flammable or explosive substances as they give off vapors
that could ignite, explode or cause fabric to catch on fire by
itself.
• Do not place items exposed to cooking oils in your dryer.
Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch fire. To
reduce the risk of fire due to contaminated loads, the final
part of a tumble dryer cycle occurs without heat (cool down
period). Avoid stopping a tumble dryer before the end of
the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Items that have been soiled with substances such as cook-
ing oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers, should be washed in
hot water with an extra amount of detergent before being
dried in the tumble dryer.
• To reduce the risk of fire, DO NOT DRY plastics or articles
containing foam or latex rubber or similarly textured rubber-
like materials, such as shower caps, water proof textiles,
rubber-backed articles, and clothes or pillows filled with
foam rubber pads.
• Do not tumble fiberglass curtains and draperies unless the
label says it can be done. If they are dried, wipe out the cyl-
inder with a damp cloth to remove particles of fiberglass.
• Do not allow children to play on or in the dryer. Close super-
vision of children is necessary when the dryer is used near
children. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or men-
tal capabilities, or lack of experience and knowledge, un-
less they have been given supervision or instruction con-
cerning the use of the appliance by a person responsible
for their safety. This is a safety rule for all appliances.
• Cleaning and user maintenance shall not be made by chil-
dren without supervision.
• Children less than three years should be kept away unless
continuously supervised.
• Do not reach into the dryer if the cylinder is revolving.
• Use the dryer only for its intended purpose, drying clothes.
ALWAYS follow the fabric care instructions supplied by the
garment manufacturer and only use the dryer drum to dry
textiles that have been washed in water.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. D518541ENR4

• Always read and follow manufacturer’s instructions on
packages of laundry and cleaning aids. Heed all warnings
or precautions. To reduce the risk of poisoning or chemical
burns, keep them out of reach of children at all times (pref-
erably in a locked cabinet).
• Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product.
• Remove laundry immediately after the dryer stops.
• DO NOT operate the dryer if it is smoking, grinding or has
missing or broken parts or removed guards and/or panels.
DO NOT tamper with the controls or bypass any safety devi-
ces.
• DO NOT operate individual units if they have been separat-
ed from a stack unit.
• Dryer will not operate with the loading door open. DO NOT
bypass the door safety switch by permitting the dryer to op-
erate with the door open. The dryer will stop tumbling when
the door is opened. Do not use the dryer if it does not stop
tumbling when the door is opened or starts tumbling with-
out pressing the START mechanism. Remove the dryer from
use and call the service person.
• ALWAYS clean the lint filter after every load. A layer of lint in
the filter reduces drying efficiency and prolongs drying
time. Keep area around the exhaust opening and adjacent
surrounding area free from the accumulation of lint, dust
and dirt. The interior of the dryer and the exhaust duct
should be cleaned periodically by qualified service person-
nel.
• Do not repair or replace any part of the dryer, or attempt
any servicing unless specifically recommended in the user-
maintenance instructions or in published user-repair in-
structions that you understand and have the skills to carry
out. ALWAYS disconnect the electrical power to the dryer
before attempting service. Disconnect the power cord by
grasping the plug, not the cord.
• Electric Models: If supply cord is damaged, it must be re-
placed by a special cord or assembly available from the
manufacturer or its service agent.
• Gas Models: If supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• Before the dryer is removed from service or discarded, re-
move the door to the drying compartment.
• Failure to install, maintain, and/or operate this machine
according to the manufacturer’s instructions may result in
conditions which can produce bodily injury and/or property
damage.
NOTE: The WARNING and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Observe and be aware of other labels and pre-
cautions that are located on the machine. They are in-
tended to provide instruction for safe use of the ma-
chine. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
dryer.
Always contact your dealer, distributor, service agent or the
manufacturer about any problems or conditions you do not un-
derstand.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. D518541ENR4

Table of Contents
Before Drying.......................................................................................... 9
Energy Saving Tips.........................................................................................9
Helps and Hints.............................................................................................9
Sort...............................................................................................................9
Load............................................................................................................. 9
Operating Your Dryer............................................................................. 11
Cycle Selection............................................................................................ 11
Auto-Sensing............................................................................................11
Pet Plus™................................................................................................ 11
Manual....................................................................................................12
Steam......................................................................................................12
Selections................................................................................................... 12
Temp....................................................................................................... 12
Dryness................................................................................................... 12
Options....................................................................................................... 12
Extended Tumble..................................................................................... 12
Steam Boost............................................................................................12
Anti-Static................................................................................................13
Signal...................................................................................................... 13
Favorites..................................................................................................13
Status......................................................................................................... 13
Alerts.......................................................................................................... 13
Digital Display............................................................................................. 13
To Dry Clothes............................................................................................. 13
Optional Drying Rack................................................................................... 15
Maintenance.........................................................................................16
Lubrication.................................................................................................. 16
Care of Your Dryer........................................................................................16
Motor Overload Protector............................................................................. 16
Lint Filter.....................................................................................................16
Troubleshooting.................................................................................... 18
Warranty Repairs.........................................................................................19
Contact Information.....................................................................................20
© Copyright 2023, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. D518541ENR4

Before Drying
Energy Saving Tips
• Make sure the lint filter is always clean.
• Do not overload the dryer.
• Do not overdry items.
• Remove items to be ironed while still damp.
• Large loads of similar fabrics dry the most efficiently. How-
ever, dry permanent press in smaller loads to prevent wrin-
kling.
• Use the correct cycle for the type of fabric being dried.
• Locate your dryer so the exhaust duct is as short and
straight as possible.
• Do not open the door during the drying cycle.
• Plan to do your laundry on low humidity days; your clothes
will dry faster.
• Dry multiple loads of clothes one right after another so dry-
er interior does not have to be reheated for each load.
Helps and Hints
WARNING
To reduce the risk of fire, explosion, serious injury or
death, clothes which have traces of any flammable
substances such as cooking oil, machine oil, flam-
mable chemicals, thinner, etc. must not be put into
the dryer.
W131
• The directions for installation and proper exhausting are
given in the Installation Instructions which are included
with the dryer.
• Static electricity may cause garments of synthetic fibers (as
in lingerie) to cling together, especially if they are overdried.
The use of a liquid fabric softener in the rinse water of the
washer, or a fabric softener sheet in the dryer, will soften
clothes and reduce static electricity.
• Do not wash or dry clothes that shed lint in the same load
with permanent press or knit garments.
• Remove permanent press loads immediately after dryer
stops.
• Follow the care labels on FLAME RETARDANT, SCOTCH-
GUARD™, etc., garments for proper washing and drying.
• If loads should be damp for ironing, use the Damp Dryness
setting, in an Automatic cycle.
Sort
If you have correctly sorted the items for washing, they should
be properly sorted for drying too.
1. Sort by color.
2. Separate lint shedding fabrics and lint receiving fabrics.
Towels, flannels, chenille, cottons, rugs, etc., shed lint. Cor-
duroys, knits (including socks), permanent press, and syn-
thetics attract lint.
3. Separate no heat, low heat and high heat items.
In any kind of drying, lightweight fabrics will dry faster than
heavyweight fabrics. If mixed loads are dried together (such as
sheets and towels), remove the lighter weight fabrics when
they are dry to prevent overdrying and wrinkling. The best
method is to dry clothes which require the same time, temper-
ature or dryness level in the same load.
Load
WARNING
Do not wash or dry items soiled with vegetable or
cooking oils. Some oils may remain after washing
and may cause the fabric to catch on fire by itself.
W527
• Do not overload your dryer. Bulk, not weight, determines
the load size. If the dryer is overloaded, it could cause dis-
coloration or permanent heat damage to the load.
• There should be space in the dryer for the clothes to tum-
ble freely and help to reduce wrinkles.
• Large and small pieces together make up loads which will
tumble well. Permanent press loads should be smaller to
provide room for tumbling. Proper tumbling allows for fewer
wrinkles.
• A load can be too small. Just a few small pieces will not
tumble properly. They will take longer to dry and they may
be wrinkled. For small loads, add a couple of large towels
or non lint shedding items to aid in tumbling.
• The following illustrations show the ideal load sizes for fab-
rics. The average load will fill the cylinder one third to half
full when wet.
Cylinder with wet linens and cottons
D665I_SVG
Before Drying
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. D518541ENR4

Cylinder with wet permanent press items
D666I_SVG
Before Drying
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. D518541ENR4

Operating Your Dryer
DRY2870N_SVG
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons, read the Safety Information
section before operating the dryer.
W520
Cycle Selection
The following cycle descriptions will help determine which cy-
cle to choose depending on the type of laundry being dried.
NOTE: Always check fabric care label for proper care
instructions.
Auto-Sensing
The Auto-Sensing drying cycle operation is determined by the
type of cycle selected as well as the moisture sensing system,
which can be set by changing the Dryness setting. Auto-Sens-
ing cycles are Energy Saver cycles that help prevent over-dry-
ing.
When a wet load is put into the dryer it takes a certain amount
of time to reach the desired dryness level. The time will vary
with load size, type of fabric, amount of moisture in the load,
air flow and the laundry room environment. The estimated
time will be shown in the digital display.
NOTE: The time shown before starting the cycle is esti-
mated by averaging the last 5 cycles run on the select-
ed cycle/dryness combination.
Use Heavy Duty for heavy items such as blankets.
Use Regular for sturdy items like play or work clothes.
Use Perm Press for permanent press items and synthetics.
Use Delicate to dry delicate items.
NOTE: This is an ENERGY STAR ® certified dryer. To
use the energy saving setting, select the Auto-Sensing
Regular cycle, set the Dryness Selection to Near Dry,
and turn on EcoDry.
NOTE: Use the Time Dry Cycle for No Heat tumble. Us-
ing Automatic cycles with No Heat will result in very
short cycle times. Automatic cycles are designed to
dry loads using heat to the dryness level selected.
Pet Plus™
The Pet Hair Remover cycle is used to remove pet hair from dry
items. It is a set 10-minute cycle and can be used as a stand-
alone refresh, or as pre-wash cycle before putting items in the
washer. Anti-Static is on by default and can be turned off.
NOTE: Clean lint filter before each use. Excessive hair
build-up may impact results. A second Pet Hair Remov-
er cycle may be necessary if there is a large amount of
hair in the lint filter.
The Pet Items cycle dries and refreshes bulky pet items. The
default cycle is a 55-minute, high-temperature heat cycle with
Anti-Static and Steam Boost on. This cycle can be fully custom-
ized to the pet item being dried. Temperature, Time, and Op-
tions can be adjusted as needed. You can save these cycles
using the Favorites option to quickly use again.
NOTE: Clean out dryer cylinder after using Pet Plus cy-
cles. Pet items may cause stains or odors on subse-
quent loads.
WARNING
This cycle is only intended for laundry items such as
clothing, bedding, and pet items. It is not intended
for pets or people.
W1073
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. D518541ENR4

Manual
There are two manual cycles: Time Dry and Quick Dry. These
cycles will run for the set number of minutes shown on the dig-
ital display. The cycle time can be increased or decreased us-
ing the up and down arrow keypads. Select the temperature
based on the fabric care label. The time and temperature se-
lection may be adjusted manually at any time before or during
the cycle. The time may need to be adjusted up if the items
are still damp or down if the items are overdry.
Steam
The Steam Sanitize cycle sanitizes your laundry by killing
99.9% of common household bacteria*. It is a 75-minute cycle
that applies high-temperature heat to sanitize the load, as well
as steam to help keep your laundry soft and wrinkle free. It is
recommended for medium size loads and is not recommend-
ed for all fabric types. Be sure to follow fabric care labels.
To use Steam Sanitize, press the Steam Sanitize keypad and
allow the cycle to complete uninterrupted. Time can be extend-
ed higher than 75 minutes by using the up and down arrow
keypads.
NOTE: The Sanitize setting uses high heat. Check the
fabric label for proper care instructions.
The Steam Refresh cycle releases wrinkles and refreshes your
items. It is recommended for 1-4 items. There are two preset
cycles. The default cycle applies a medium-temperature heat
for 30 minutes to the load. The alternate cycle applies a high-
temperature heat for 20 minutes.
To use Steam Refresh, press the Steam Refresh keypad and
the default cycle for 30 minutes at medium heat will be initiat-
ed. To initiate the 20-minute, high-heat cycle, toggle the Temp
selection to High. Select the 30-minute medium heat or 20-mi-
nute high heat temperature based on fabric type.
*Bacteria tested by an independent lab were Staphylococcus
aureus, Pseudomonas aeruginosa, Klebsiella pneumoniae. In-
dividual results may vary.
IMPORTANT: Do not use dryer sheets when using
steam cycles.
IMPORTANT: Do not run steam with no load to help
prevent water from staining the cylinder.
NOTE: Do not overload machine for steam cycles.
Overloading during a steam cycle may cause the load
to have wet spots at the end of the cycle.
NOTE: Using steam on overly damp items may result in
load not completely drying.
Selections
The following selections can be used to modify the currently
chosen cycle. The default selections will be lit after choosing a
cycle.
Temp
Press the Temp keypad to change the cycle's temperature on
Manual Cycles, Pet Items, and Steam Refresh. Choose from
No Heat, Low, Medium, or High depending on fabric type.
NOTE: The No Heat cycle will take longer to dry items.
Dryness
Press the Dryness keypad to change the dryness level in an
Auto-Sensing cycle. Choose from Damp, Less Dry, Near Dry or
Dry.
Use Damp to leave load slightly damp for easier ironing.
Use Less Dry for lightweight items such as sheets and shirts.
Use Near Dry for normal loads.
Use Dry for heavy items such as blue jeans and blankets.
Over-drying can cause wrinkling, shrinking, excessive lint con-
ditions, and will use more energy than necessary. To increase
energy savings and to make sure loads are dried without over-
drying, set your Auto-Sensing loads on Near Dry or Less Dry. If
items are damp or over-dry at the end of a cycle, increase or
decrease the Dryness setting the next time these loads are
dried. Remember the settings that work best to get ideal dry-
ing results. To finish drying damp items, use Quick Dry and ad-
just the time as needed.
Options
The following options can be used to modify the currently
chosen cycle, adjust the signal volume, and save favorite cy-
cles.
Extended Tumble
The Extended Tumble option prevents wrinkling by tumbling
the clothes load after the end of the cycle every two minutes
for up to 60 minutes. The display will show the time remaining.
The Extended Tumble LED light will be lit during the Extended
Tumble portion of a cycle. The option will end if the door is
opened.
Extended Tumble can be used along with the Steam Boost and
Anti-Static options. Steam Boost runs first, followed by Anti-
Static and then Extended Tumble.
NOTE: The Steam Boost option is not available with the
ENERGY STAR ® setting.
Steam Boost
Use to release wrinkles and soften fabrics. Available with Auto-
Sensing Heavy Duty, Regular, and Perm Press cycles as well as
Pet Items (Medium or High heat only). Dryness/Auto-Dryness
must be set to Near Dry or Dry. Cannot be used with EcoDry.
Steam Boost can be used along with the Anti-Static option.
Steam Boost runs before Anti-Static.
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. D518541ENR4

Anti-Static
The Anti-Static option reduces static build-up by adding a
small amount of steam toward the end of the cycle. To use,
press the Anti-Static keypad. It is available with Heavy Duty,
Regular, Perm Press, Delicates, Pet Items, and Pet Hair Re-
mover cycles only. Dryness must be set to Near Dry or Dry on
Auto-Sensing cycles. Anti-Static can be used along with the
Steam Boost option. Steam Boost runs before Anti-Static. It
cannot be used with EcoDry.
EcoDry
The EcoDry option will reduce total energy consumption by de-
creasing the temperature of the cycle setting by 10% after the
initial temperature setting has been reached.
Signal
Pressing the Signal keypad will change the end of cycle signal
volume. There are four settings: Off, Low, Medium, High.
If the Extended Tumble option is selected the signal will sound
each time the dryer tumbles.
Favorites
Use the Favorites option to save different cycles, selections
and options for later use. Nine favorite cycles can be saved.
1. Press the Favorites keypad. The control will display the cy-
cle and modifier settings for the first Favorites cycle. The 2-
digit display will switch between F1 and the cycle time for
the selected cycle.
2. Press the keypads for the desired cycle, selection and op-
tion settings.
3. Press the Favorites keypad to save the settings. The next
Favorites cycle, F2, will be displayed. It can be programmed
now.
4. Press the Start/Pause keypad to save the settings and
start the cycle.
5. Press the Power/Cancel keypad to discard the current set-
tings and exit Favorites mode.
Status
The Status lights are lit during the cycle to show what part of
the cycle is running.
The Sensing status light is lit when the dryer is detecting mois-
ture levels.
The Heating status light is lit to indicate that a heat portion of
the cycle is currently operating.
The Cooling status light is lit during the cool-down portion of
the cycle.
The Complete status light is lit when the cycle is finished.
Alerts
The Door Open alert is lit any time that the dryer door is open.
The Control Lock alert will be lit when the Control Lock is
turned on. To turn on the Control Lock press and hold the Sig-
nal keypad for three seconds. While Control Lock is on, no oth-
er keypad presses are allowed. Press and hold the Signal key-
pad again to turn the option off.
The Extended alert is lit during the Extended Tumble option.
Digital Display
The two-digit display is used to show the time remaining in a
cycle.
When the control is powered off, the right-most decimal in the
display will flash every one to five minutes to indicate that the
machine is in Idle Mode.
The display also shows diagnostic codes.
Idle Mode
If no keypads have been pressed for five minutes after a cycle
is finished, the control will enter Idle Mode. A light in the lower
right corner of the digital display will flash every one to five mi-
nutes. Press the Power/Cancel keypad to exit this mode and
power the display for cycle/option selection. This light will flash
again after five minutes when it re-enters Idle Mode.
To Dry Clothes
This appliance shall not be used to dry off solvents or dry
cleaning fluids. Fabric softeners, or similar products, should
be used as specified by the fabric softener instructions.
IMPORTANT: Refer to the INSTALLATION INSTRUC-
TIONS before using dryer.
IMPORTANT: Before using dryer for the first time, use
an all-purpose cleaner or a detergent and water solu-
tion and a damp cloth to remove shipping dust from in-
side of dryer drum.
NOTE: This appliance is designed for repeated normal
operation according to operating instructions.
1. Sort items into separate loads.
NOTE: Remove all objects from pockets such as
lighters and matches.
IMPORTANT: Oil affected items can ignite spontane-
ously, especially when exposed to heat sources
such as in a tumble dryer. The items become warm,
causing an oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape, the items
can become hot enough to catch fire. Piling, stack-
ing or storing oil affected items can prevent heat
from escaping and so create a fire hazard.
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. D518541ENR4

NOTE: Remove all sharp objects from laundry to
avoid tears and rips to items during normal machine
operation.
2. Clean lint filter (if using lint filter guard, remove first).
1. Lint Filter Guard (optional)
2. Lint Filter
Figure 1
WARNING
To reduce the risk of fire and risk of lint collecting
in exhaust duct, do not operate dryer without lint
filter in place.
W771
NOTE: The Lint Filter Guard is an optional accesso-
ry to help prevent items from falling in the lint filter.
3. Load dryer half full with laundry ( 18 pounds [8.2 kg] maxi-
mum dry clothes load). Add fabric softener sheet, if de-
sired, except with steam cycles.
WARNING
To reduce the risk of fire, explosion, serious in-
jury or death, clothes which have traces of any
flammable substances such as cooking oil, ma-
chine oil, flammable chemicals, thinner, etc. must
not be put into the dryer.
W131
NOTE: To avoid damage to dryer, do not use more
than one fabric softener sheet per load.
D666I_SVG
4. Close loading door. Dryer will not operate with the door
open.
D668IE0A
5. If not already on (control lights will be lit), turn on the dryer
by pressing the Power/Cancel button.
NOTE: You will not be able to press the Start/Pause
button to Pause the cycle until the motor is running.
If the Start/Pause button is pressed while attempting
to run the motor (during the warm-up period), an in-
valid keypress tone will sound.
6. Select the Cycle and, if desired, change the Selections and
Options settings. Follow garment manufacturer’s care la-
bels for recommended temperature settings.
7. Press the Start/Pause button to begin the cycle.
WARNING
To prevent the risk of fire, never stop a dryer be-
fore the end of the drying cycle unless all items
are quickly removed and spread out so that the
heat is dissipated.
W756
IMPORTANT: The final part of dryer cycle occurs
without heat (cool down cycle) to ensure that items
in dryer are left at a temperature that ensures that
the items will not be damaged.
NOTE: To stop dryer at any time, open the door or
press the Start/Pause button. To restart dryer, close
door and press the Start/Pause button again.
8. Remove laundry immediately after dryer stops at end of cy-
cle.
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. D518541ENR4

DRY2544N_SVG
Optional Drying Rack
A drying rack, Part No. D512082, is available at extra cost
through your Factory Authorized Service Center.
The drying rack can be used in Manual cycles (Time Dry or
Quick Dry) only for no-tumble drying of articles such as tennis
shoes, sweaters, stuffed toys or other delicate items.
DRY2332N_SVGDRY2332N_SVG
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. D518541ENR4

Maintenance
Lubrication
All moving parts are sealed in a permanent supply of lubricant
or are equipped with oilless bearings. Additional lubrication
will not be necessary.
Care of Your Dryer
WARNING
To reduce the risk of an electric shock, serious injury
or death, disconnect the electrical service to the dry-
er before cleaning the interior.
W132
Dryer Interior
Wipe the surfaces using a soft cloth and household cleaner or
a non-abrasive paste of powdered laundry detergent and hot
water, followed by a short heat cycle with a load of rags.
To remove crayon or ball point ink off the dryer drum, put the
heat on high and use old rags in the dryer to absorb the crayon
or ink. If unsuccessful, contact the appliance dealer. DO NOT
use any chemicals in the dryer.
IMPORTANT: The use of chlorine bleach for removing
any discolorations should be avoided because bleach
could damage the finish.
Cabinet
Wipe the dryer cabinet as needed. If detergent, bleach or oth-
er washing products have been spilled on the dryer, wipe im-
mediately. Some products will cause permanent damage if
spilled on the cabinet.
Control Panel
Use only a damp or sudsy cloth for cleaning the control panel.
Some spray pretreat products may harm the finish on the con-
trol panel. DO NOT use products that contain alcohol on the
control panel.
Exhaust System
WARNING
To reduce the risk of electric shock, disconnect the
electrical service to the dryer before cleaning.
W043
WARNING
Any disassembly requiring the use of tools must be
performed by a suitably qualified service person.
W299
The exhaust duct should be inspected after one year of use
and cleaned if necessary by a qualified service person to re-
move any lint build-up. Inspect and clean exhaust duct every
one to two years as required thereafter.
Every two years a qualified service person should remove all
front panels and vacuum the inside of the dryer
NOTE: This recommended maintenance is not covered
under the terms of the warranty.
The weather hood should be checked frequently to make sure
the dampers move freely, dampers are not pushed in and that
nothing has been set against them.
Keep dryer area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
Do not obstruct the flow of combustion and ventilation air.
NOTE: Verify proper operation after servicing.
Motor Overload Protector
The dryer’s motor overload protector stops the motor automati-
cally in the event of an overload. The control’s digital display
will show “Er”, “ro” alternately. After cooling, the overload pro-
tector will reset itself.
The control can be cleared by pressing START and the dryer
can be restarted by pressing START again. If overload protector
cycles again, remove the dryer from use and call the service
person to correct the problem.
Lint Filter
The lint filter is located at the front of the dryer in the lower
part of the door opening.
CLEAN THE LINT FILTER BEFORE DRYING EACH LOAD. (If using
optional lint filter guard, remove first).
Annually remove lint filter and screw to vacuum the duct under
it.
Maintenance
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. D518541ENR4

DRY2782N_SVG
1
1. Lint Filter
Figure 2
Maintenance
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. D518541ENR4

Troubleshooting
Try these troubleshooting tips before making a service call.
They may save you time and money.
Dryer Symptom Possible Cause/Solution
Dryer won’t start • Make sure the power cord is plugged all the way into the electrical
outlet.
• Make sure loading door is closed.
• Press Start/Pause button to start dryer.
• Make sure the laundry room fuse(s) isn’t blown or loose, or circuit
breakers aren’t open.
• The dryer itself does not have an electrical fuse. An electric dryer
has an electrical circuit with two fuses.
• Check if motor overload protector has cycled. Wait 10 minutes and
try again.
Dryer won’t heat • Electric dryers only – Some homes may have two fuses or circuit
breakers for an electric dryer; both fuses or circuit breakers should
be checked. Make sure the laundry room fuse(s) isn’t blown or
loose, or that the circuit breakers aren’t open.
• Make sure control is not in Cooling part of cycle, Extended LED is
lit, or that the Temp selection is not set to No Heat.
• Gas dryer only – Make sure equipment and main gas line valve is
turned on.
• Check exhaust duct to outside to see if it is kinked, blocked or
needs cleaning.
• Check weather hood to make sure flapper moves freely, has not
been pushed in or has not been blocked.
Dryer doesn’t dry clothes satisfactorily • Check exhaust duct to outside to see if it is kinked, blocked or
needs cleaning.
• Check weather hood to make sure flapper moves freely, has not
been pushed in or has not been blocked.
• Auto-Sensing cycle – Adjust Dryness selection.
• Manual cycles - Allow more or less time.
• Clean the lint filter.
• Make sure the load isn’t too small. Small loads may not tumble
properly or dry evenly.
• The Auto-Sensing cycles are not suggested to be used for small
loads such as two small towels. For those loads, use the Man-
ual cycles.
• Check load being dried. Heavy items dried with lightweight items
will not dry as quickly as the rest of the load.
• Refer to Sort section for proper sorting information.
Table continues...
Troubleshooting
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. D518541ENR4

Dryer Symptom Possible Cause/Solution
Dryer is noisy • Check dryer for foreign objects (nails, coins, bobby pins, metal,
plastic toys, etc.). Remove items from dryer.
• Make sure dryer is level. Uneven leveling can cause vibration.
• Normal operating sounds include the heat source going on and off
and the humming of air moving through the dryer and exhaust sys-
tem.
Clothes are too wrinkled • Check heat setting. Overdrying can cause wrinkling.
• Check load size. Large loads may not tumble properly and may
cause wrinkling.
• On Auto-Sensing cycles, try using Steam Boost to release wrinkles.
Clothes have odor • Check room for odors before drying clothes. Any odor (fried foods,
paint, varnish, cleaners, burning wood, etc.) will transfer to clothing
as the dryer draws air from the room.
• Ventilate room before drying clothes.
Cycle advances too slowly • When in an Auto-Sensing cycle, the time it takes depends on the
type and size of the load being dried. When clothing has more
moisture, the cycle takes longer than when the clothes are more
dry.
Er, ro on digital display • The dryer’s motor overload protector has cycled.
• The control can be cleared by pressing the Start/Pause button and
the dryer can be restarted by pressing the Start/Pause button
again.
• If this code is displayed again, remove the dryer from use and call
a service person.
Items still wrinkled after the steam cycle. • Do not overload the machine. Overloading the machine can cause
wrinkles to not be completely removed.
Items are damp or wet after steam cycle. • Do not overload the machine. Overloading during the steam cycle
can cause the load to have wet spots at the end of the cycle.
• Do not use overly damp items. This may result in the load not dry-
ing completely.
Small amount of water on door or in the drum. • When using the steam options, it is normal for condensation to oc-
cur.
Small amount of water on the floor in front of the dry-
er.
• Condensation may occur and drip from door when opened.
• Too small of a load may result in additional condensation on door.
Try adding more items to the load.
Small amount of water on the floor behind the dryer. • Check the hose connections and tighten them if needed.
• Check that the rubber washer is intact. If not, install the rubber
washer.
Warranty Repairs
If your appliance needs repair, you can locate an authorized
service provider directly from our Support page at www.speed-
queen.com.
Before scheduling service, please consult Limited Warranty for
full terms. As a reminder, the following items are not covered
by the limited warranty and, if a service technician is called,
you will be responsible for payment of the service call.
• Plugged or restricted venting
Troubleshooting
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. D518541ENR4

• Kinked venting
• Cleaning lint from within the dryer
• Home electrical issues
• Home gas issues
• Foreign objects found inside the dryer
• Instruction on how to use machine
• Issues related to improper installation
As detailed in the Limited Warranty, if the unit is operated in a
multiple-user setting or commercial application, the unit's lim-
ited warranty is three (3) years parts only. Labor coverage is
not included in this warranty.
Contact Information
If you have any questions or need assistance with your appli-
ance, please visit us online at www.speedqueen.com. From
our website you can:
• Register your appliance
• Find manuals and other product literature
• Locate authorized service providers near you
• Locate replacement parts
If additional support is needed, contact us using one of the fol-
lowing methods:
Phone: [phone] or [phone]
Contact Us Form: www.speedqueen.com/contact/
Mail: Speed Queen
Shepard Street
P.O. Box 990
Ripon, WI 54971-0990
When contacting us, please provide the following information:
Date Purchased
Model Number
Serial Number
The Model and Serial Numbers are located on the serial plate.
The serial plate will be in the location shown.
DRY2527N_SVG
1
1. Serial Plate
WARNING
To reduce the risk of serious injury or death, DO NOT
repair or replace any part of the unit or attempt any
servicing unless specifically recommended in the
user-maintenance instructions or in published user-
repair instructions that you understand and have the
skills to carry out.
W329
Troubleshooting
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. D518541ENR4
