Alliance Laundry Systems D355IE1B Owner's manual

Installation and Operation
Stacked Dryer
Metered and Nonmetered
Electric and Gas Models
Part No. 504524R3
June 1998
NOTA: El manual en español aparece después del manual en inglés.
D355IE1B

504524 1
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. (If the dryer changes ownership, be
sure this manual accompanies the dryer.)
IMPORTANT: Purchaser must consult the local gas supplier for suggested instructions to be
followed if the dryer user smells gas. The gas utility instructions plus the SAFETY and
WARNING note directly above must be posted in a prominent location near the dryer for
customer use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in your building.
– Clear the room, building or area of all occupants.
– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
– If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer, service agency or
the gas supplier. W052
FOR YOUR SAFETY, the information in this manual must be followed to minimize the
risk of fire or explosion or to prevent property damage, personal injury or death.W033
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
W053

2504524
Replacement Parts . . .
If replacement parts are required, contact the source
where you purchased your dryer, or contact Alliance Laundry Systems LLC Shepard Street
P.O. Box 990
Ripon, WI 54971-0990
Phone:
[phone]
for the name and address of the nearest authorized parts
distributor.
Table of
Contents
Replacement Parts ............................................................................... 2
Important Safety Instructions.............................................................. 3
Roughing In Dimensions ..................................................................... 5
Additional Security .............................................................................. 7
Slide Extension ..................................................................................... 7
Timer Cams ........................................................................................... 7
Lower Front Panel Security ................................................................ 7
Coin Slide Guards ................................................................................ 8
Before You Start ................................................................................... 9
Installing the Dryer
STEP 1 – Position and Level the Dryer Unit.................................. 10
STEP 2 – Connect Dryer Exhaust System ..................................... 10
STEP 3 – Connect Gas Supply Pipe............................................... 11
STEP 4 – Connect Electrical Plug..................................................12
STEP 5 – Wipe Out Inside of Each Dryer...................................... 13
STEP 6 – Plug in the Dryer Unit.................................................... 13
STEP 7 – Check Installation........................................................... 13
Heat Source Check ............................................................................. 14
Reversing Door Procedure ................................................................ 15
Electrical Requirements (Electric Dryers) ....................................... 16
Electrical Connection ......................................................................... 17
Three-wire Power Cord ................................................................. 17
Four-Wire Power Cord .................................................................. 19
Electrical Requirements (Gas Dryers) ............................................. 21
Gas Requirements ............................................................................. 23
Location Requirements ..................................................................... 24
Dryer Exhaust Requirements ........................................................... 25
Multi-Dryer Installation Exhuast Requirements ............................. 28
Lint Filter............................................................................................. 31
Motor Overload Protector.................................................................. 31
User-Maintenance Instructions ......................................................... 32
For Energy Conservation ................................................................... 32
Before Your Call for Service............................................................... 33
Operation Instructions For Electromechanical Dryers .................. 34
Operation Instructions for Electronic Control Dryers.................... 36
Information for Handy Reference .................................................... 39
Installer Check .................................................................... Back Cover
©Copyright 1998, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without
the written permission of the publisher.

504524 3
IMPORTANT SAFETY INSTRUCTIONS
(SAVE THESE INSTRUCTIONS)
1. Read all instructions before using the dryer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the dryer.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, other flammable
or explosive substances as they give off vapors
that could ignite or explode.
4. Do not allow children to play on or in the dryer.
Close supervision of children is necessary when
the dryer is used near children. This is a safety
rule for all appliances.
5. Before the dryer is removed from service or
discarded, remove the door to the drying
compartment.
6. Do not reach into the dryer if the cylinder is
revolving.
7. Do not install or store the dryer where it will be
exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the dryer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. ALWAYS clean the lint filter after every load. A
layer of lint in the filter reduces drying efficiency
and prolongs drying time.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust and dirt.
14. The interior of the dryer and the exhaust duct
should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Dryer will not operate with the loading door
open. DO NOT by-pass the door safety switch by
permitting the dryer to operate with the door
open. The dryer will stop tumbling when the door
is opened. Do not use the dryer if it does not stop
tumbling when the door is opened or starts
tumbling without pressing the START
mechanism. Remove the dryer from use and call
the service person.
17. Do not put articles soiled with vegetable or
cooking oil in the dryer, as these oils may not be
removed during washing. Due to the remaining
oil, the fabric may catch on fire by itself.
18. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc., or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with a dry-
cleaning solvent in the dryer.
19. Use the dryer only for its intended purpose,
drying clothes.
20. Always disconnect the electrical power to the
dryer before attempting service. Disconnect the
power cord by grasping the plug, not the cord.
21. Replace worn power cords and/or loose plugs.
22. Install this dryer according to the
INSTALLATION INSTRUCTIONS. All
connections for electrical power, grounding and
gas supply must comply with local codes and be
made by licensed personnel when required. Do
not do it yourself unless you know how!
23. Remove laundry immediately after the dryer
stops.
To reduce the risk of fire, electric shock, or
injury to persons when using your dryer,
follow these basic precautions:
W034
WARNING

4504524
24. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of reach of children at all times
(preferably in a locked cabinet).
25. Do not tumble fiber glass curtains and draperies
unless the label says it can be done. If they are
dried, wipe out the cylinder with a damp cloth to
remove particles of fiber glass.
26. ALWAYS follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the dryer with any guards and/or
panels removed.
28. DO NOT operate the dryer with missing or
broken parts.
29. DO NOT by-pass any safety devices.
30. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
IMPORTANT: Solvent vapors from dry-cleaning
machines create acids when drawn through the heater
of the drying unit. These acids are corrosive to the
dryer as well as to the laundry load being dried. Be
sure make-up air is free of solvent vapors.
IMPORTANT: Have your dryer installed properly.
Don’t do it yourself unless you know how!
NOTE: The WARNING and IMPORTANT
SAFETY INSTRUCTIONS appearing in this manual
are not meant to cover all possible conditions and
situations that may occur. Common sense, caution
and care must be exercised when installing,
maintaining, or operating the dryer.
Always contact your dealer, distributor, service agent or
the manufacturer about any problems or conditions you
do not understand.

504524 5
Roughing In Dimensions . . .
(Metered Models)
NOTE: Side, rear and bottom exhaust openings are
four inch (10.2 cm) ducting. Gas models cannot be
vented out left side of cabinet because of burner
housing.
IMPORTANT: The dryer should have sufficient
clearance around it for needed ventilation and for the
ease of installation and servicing. For maximum
drying performance, we recommend that more
clearance be allowed around the dryer than the
clearances that are listed throughout this manual.
ELECTRIC MODELS
D350IE2A
28.0"
(71.1 cm) 26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
4.0"
(10.2 cm)
* WITH LEVELING LEGS TURNED INTO BASE.
GAS MODELS
D351IE2A
28.0"
(71.1 cm)
26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
*WITH LEVELING LEGS TURNED INTO BASE.
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
4.0"
(10.2 cm) 2.8"
(7.1 cm)
43.5" (110.5 cm)
2.3"
(6 cm)
3/8"
NPT GAS
CONNECTION

6504524
Roughing In Dimensions . . .
(Nonmetered Models)
NOTE: Side, rear and bottom exhaust openings are
four inch (10.2 cm) ducting. Gas models cannot be
vented out left side of cabinet because of burner
housing.
IMPORTANT: The dryer should have sufficient
clearance around it for needed ventilation and for the
ease of installation and servicing. For maximum
drying performance, we recommend that more
clearance be allowed around the dryer than the
clearances that are listed throughout this manual.
ELECTRIC MODELS
D353IE2A
28.0"
(71.1 cm) 26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
*WITH LEVELING LEGS TURNED INTO BASE.
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
4.0"
(10.2 cm)
GAS MODELS
D352IE2A
28.0"
(71.1 cm) 26.9"
(68.3 cm)
23.5"
(59.7 cm)
4.0"
(10.2 cm)
*76.5" (194.3 cm)
*45.2" (114.8 cm)
*WITH LEVELING LEGS TURNED INTO BASE.
15.4"
(39.1 cm)
7.7"
(19.6 cm)
7.0"
(17.8 cm)
43.5" (110.5 cm)
4.0"
(10.2 cm) 2.8"
(7.1 cm)
2.3"
(6 cm)
3/8"
NPT GAS
CONNECTION

504524 7
Additional Security . . .
Torx security screws are available (as optional equipment
at extra cost) for securing both lower access panels to
each dryer base. Order part number 62853.
A Torx bit, part number 282P4, is available (as optional
equipment at extra cost) for installing the Torx security
screws.
A Torx bit holder, part number 24161, is available (as
optional equipment at extra cost) to be used with the Torx
bit.
Slide Extension . . .
(Metered Models)
Remove two slide extensions, four screws and
lockwashers from the accesssories bag (located in lower
cylinder) and install the extension on the top of the coin
slide.
IMPORTANT: Slide extension must be attached to
top side of the coin slides to make them long enough to
activate the accumulator.
NOTE: This dryer unit, as shipped from the factory,
does not include the coin slides, coin drawers, lock or
keys. These coin slide kits (or parts) must be ordered,
at extra cost, according to the purchaser’s
requirements direct from the coin kit manufacturer
of your choice.
Timer Cams . . .
(Metered Models)
The dryer timers are factory equipped with a 45 minute
timing cam. If this drying time is not suitable to your
installation, the following cams can be found in the
accessories bag (located in lower cylinder).
ELECTRIC DRYERS
2-53242 Cams (30 Minutes)
2-53240 Cams (60 Minutes)
GAS DRYERS
2-53242 Cams (30 Minutes)
A 60 minute timing cam, Part No. 53240, is available for
the gas dryers as optional equipment at extra cost.
Lower Front Panel Security . . .
(Optional)
(Metered Models)
For added security, remove the two screws (with
lockwashers) from accessories bag (located in lower
cylinder). Install screws as follows:
1. Unlock control panel.
2. Lift up on control panel and swing bottom of panel
out, then pull down and away from control cabinet.
3. Install the two screws down through holes in lower
flange of control cabinet and into top flange of lower
front panel.

8504524
Coin Slide Guards . . .
(Metered Models)
Using serrated hex head screws from accessories bag
(located in lower cylinder), install coin slide guards
(located in accessories bag in lower cylinder), to front of
dryer’s control cabinet. See illustration below.
A special security screw kit is available (as optional
equipment at extra cost) for securing the two coin slide
guards and both front panels to front of dryer unit. Order
Security Kit No. 298P3. A special driver, part number
56217, is available (as optional equipment at extra cost)
for installing the special security screws.
NOTE: Coin slides and coin drawers are shown for illustration only. You must obtain them locally.
PUSH TO START
IN USE
IN USE
PUSH TO START
FABRIC SELECTOR
FABRIC SELECTOR
PERM PRESS
NORMAL
DELICATE
FLUFF
(NO HEAT)
PERM PRESS
NORMAL
DELICATE
FLUFF
(NO HEAT)
COIN
SLIDE
GUARD
COIN
SLIDE
GUARD
SERRATED
HEX HEAD
SCREWS
SERRATED
HEX HEAD
SCREWS
D193IE3A

504524 9
Before You Start . . .
Tools
For most installations, the basic tools you will need are:
Exhaust
Use rigid metal duct and exhaust the dryer to the outside
by the shortest route possible.
NOTE: For more detailed information, refer to
Section on Dryer Exhaust Requirements.
Electrical
•ELECTRIC DRYER Dryer needs a 3 or 4 wire 120/
240 or 120/208 Volt, 60 Hertz, AC single Phase
electrical supply.
•GAS DRYER
Dryer needs a 120 Volt,
60 Hertz, polarized 3-slot effectively grounded
receptacle.
NOTE: For more detailed information, refer to
Section on Electrical Requirements.
Gas
Dryer is equipped for Natural Gas with a 3/8" NPT gas
supply connection. For more detailed information, refer
to Section on Gas Requirements.
Location
Place the dryer on a solid floor with an adequate air
supply. For more detailed information, refer to Section on
Location Requirements.
D074IE1F
DUCT TAPE TEFLON TAPE
WRENCH
LEVEL
SCREWDRIVERS
D354IE0A

10 504524
Installing the Dryer . . .
STEP 1:
Position and Level
the Dryer Unit
For further assistance refer to Section on Location
Requirements.
Install dryer before washer. This allows room for
attaching exhaust duct.
Install the four rubber cups found in the accessory bag.
Place the dryer in position, and adjust the legs until the
dryer is level.
STEP 2:
Connect Dryer Unit Exhaust System
For further assistance refer to Sections on Location
Requirements and Dryer Exhaust Requirements.
•DO NOT use plastic or thin foil flexible ducting.
•Locate dryer so exhaust duct is as short as possible.
•Be certain old ducts are cleaned before installing your
new dryer.
•Use 4" (10.2 cm) diameter rigid or flexible metal duct.
•Use as few elbows as possible.
•Use duct tape on all joints.
•Failure to exhaust dryer properly will void
warranty.
NOTE: Venting materials are not supplied with the
dryer (obtain locally).
D355IE1A
DRYER
BASE
LEVELING
LEG
RUBBER
CUP
A clothes dryer produces combustible lint. To
reduce the risk of fire and combustion gas
accumulation the dryer MUST be exhausted to
the outdoors.
WARNING
DON'T
D356IE0B
D354IE0C
DO
(continued))

504524 11
STEP 3: (Gas Dryer ONLY)
Connect Gas Supply Pipe
For further assistance, refer to Section on Gas
Requirements.
1. Make certain dryer is equipped for use with the type
of gas in laundry room. Dryer is equipped at the
factory for Natural Gas with a 3/8" NPT gas
connection.
2. Remove the shipping cap from the gas connection at
the rear of the dryer. Make sure you do not damage
the pipe threads when removing the cap.
3. Connect to gas supply pipe.
4. Tighten all connections securely. Turn on gas and
check all pipe connections (internal & external) for
gas leaks with a non-corrosive leak detection fluid.
5. For L.P. (propane) gas connection, refer to Section on
Gas Requirements.
3/8" NPT
GAS CONNECTION
1/8" NPT
PIPE PLUG
(For checking
inlet gas pressure)
NEW
STAINLESS STEEL
FLEXIBLE
CONNECTOR
USE ONLY
IF ALLOWED
BY LOCAL
CODES
(Use
Design A.G.A.
Certified
Connector)
EQUIPMENT
SHUT-OFF
VALVE
Install within
6' (1.8 m) of dryer
D233IE3D
BLACK IRON PIPE
Shorter than 20' (6.1 m) - use 3/8" pipe
Longer than 20' (6.1 m) - use 1/2" pipe

12 504524
STEP 4: (ELECTRIC DRYER ONLY)
Connect Electrical Plug
For further assistance, refer to Section on Electrical
Requirements.IMPORTANT: Use only a new U.L. listed No. 10 (copper wire only) three conductor power supply cord
kit rated 240 Volts (minimum) 30 Amperes and
labeled as suitable for use in a clothes dryer.
NOTE: For more detailed information on connecting
three-wire or four-wire plugs, refer to Section on
Electrical Plug Connection.
NOTE: Four-wire cord is required for mobile homes
or where codes do not permit grounding through
neutral.
STRAIN
RELIEF
NUT
TYPICAL
THREE-WIRE
RECEPTACLE POWER CORD
(Three-Wire)
STRAIN
RELIEF
D275IE0D
Three Wire
Three Wire
NUT
TYPICAL
FOUR-WIRE
RECEPTACLE POWER CORD
(Four-Wire)
STRAIN
RELIEF
D006IE0A
STRAIN
RELIEF
Four Wire
D276IE1A
CENTER
WIRE
(NEUTRAL)
STRAIN
RELIEF
(NOT SUPPLIED
WITH DRYER)
NEUTRAL
TERMINAL
GROUND
WIRE
"L2"
TERMINAL
"L1"
TERMINAL
GROUND
SCREW
GROUND
TO NEUTRAL
WIRE
Three-Wire Connection
D171IE1A
WHITE
WIRE
(NEUTRAL)
GROUND
SCREW
NEUTRAL
TERMINAL
"L1"
TERMINAL
BLACK
WIRE
GROUND
WIRE
STRAIN
RELIEF
(NOT SUPPLIED
WITH DRYER)
GROUND
WIRE
"L2"
TERMINAL
RED
WIRE
Four-Wire Connection
NOTE: Dryer is shown with access cover removed for illustration purposes only. NEVER operate dryer with
access cover removed.

504524 13
STEP 5:
Wipe Out Inside Of Each Dryer
Before using dryer for the first time, use an all-purpose
cleaner, or a detergent and water solution, and a damp
cloth to remove shipping dust from inside dryer drum.
STEP 6:
Plug in the Dryer Unit
Refer to Section on Electrical Requirements, and
connect the dryer to an electrical power source.
STEP 7:
Check Installation
Refer to Installer Check on the back cover of this manual
and make sure that dryer is installed correctly.
D340IE2A
D275IE0F
ELECTRIC
Connect each unit to 30 Amp
circuit.
D254IE0D
GAS
Plug each cord into separately
fused 15 Amp circuit.

14 504524
Heat Source Check . . .
(Electric Dryers)
Metered Models
Set the proper FABRIC SELECTOR switch at
NORMAL. Place coins in the slide and carefully push
slide in as far as possible. IN USE light will come on
indicating the dryer is ready to operate. Close the loading
door and press the PUSH-TO-START button firmly to
start the dryer. After either dryer has operated for three
minutes, the exhaust air or exhaust pipe should be warm.
Nonmetered Models
Set FABRIC SELECTOR switch at NORMAL and turn
timer knob to 50. Close the loading door and press the
PUSH-TO-START button. IN USE light will come on
indicating start of cycle. After either dryer has operated
for three minutes, the exhaust air or exhaust pipe should
be warm.
(Gas Dryers)
During the gas heat check, observe the burner flame. The
flame can be viewed by removing the lower front panel of
the dryer.
Metered Models
Set FABRIC SELECTOR switch at NORMAL. Place
coins in the slide and carefully push slide in as far as
possible. IN USE light will come on indicating the dryer
is ready to operate. Close the loading door and press the
PUSH-TO-START button firmly. The dryer will start, the
igniter will glow red and the main burner will ignite.
Nonmetered Models
Set FABRIC SELECTOR switch at NORMAL and turn
timer knob to 50. Close the loading door and press the
PUSH-TO-START button. IN USE light will come on
indicating start of cycle, igniter will glow red and main
burner will ignite.
IMPORTANT: If all air is not purged out of the gas
line, the gas igniter may go off before the gas is
ignited. If this happens, after approximately two
minutes the igniter will again attempt gas ignition.
All Models
After either dryer has operated for approximately five
minutes, observe burner flame. Adjust the air shutter to
obtain a soft, uniform blue flame. (A lazy, yellow tipped
flame indicates lack of air. A harsh, roaring, very blue
flame indicates too much air.) Adjust the air shutter as
follows:
1. Loosen the air shutter lockscrew.
2. Turn the air shutter to the left to get a luminous
yellow tipped flame, then turn it back slowly to the
right to obtain a steady soft blue flame.
3. After the air shutter is adjusted for proper flame,
tighten the air shutter lockscrew securely.
4. Reinstall the lower front panel.
After either dryer has operated for approximately three
minutes, the exhaust air or exhaust pipe should be warm.
For personal safety, lower front panel must be
in place during normal operation.
W046
WARNING
D157IE3C
AIR
SHUTTER
1/8" (3.1 mm)
PIPE PLUG
(For checking
manifold pressure)
OPEN
POSITION
CLOSED
POSITION SHUT-OFF
VALVE
HANDLE
AIR SHUTTER
LOCKSCREW

504524 15
Reversing Door Procedure . . .
The door on this dryer is completely reversible. To reverse door proceed as follows:
Remove four
hinge attaching
screws.
D347IE1A
12
D348IE1C
Remove all
nine screws.
D268PE1C
Pull bottom of
door liner out,
then pull down,
removing door
liner from door
panel.
B
A
3
D273PE1B
4
Rotate door panel
180 degrees
as shown.
D276PE1B
5
Remove door strike
from door liner
and reinstall on
opposite side.
D269PE1D
6
Insert liner under
flange on bottom of
door, then push
top of door
liner into place.
B
A
D270PE1B
7
Reinstall nine screws
removed in Step 2.
8
D345IE1B
Using a screwdriver,
remove two door
plugs, and reinstall
on opposite side
of door opening.
D346IE1A
9
Reinstall four
hinge attaching
screws removed
in Step 1.

16 504524
Electrical Requirements . . .
(Electric Dryers)
(120/240 Volt, 60 Hertz, 3-Wire Installation)
(120/208 Volt, 60 Hertz, 3-Wire Installation)
NOTE: The wiring diagram is located behind the
control panel, inside the control cabinet.
Grounding And Wiring Instructions
•Each dryer must be connected to a grounded metal,
permanent wiring system; or an equipment-grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead
on each dryer.
•Each dryer has its own terminal block that must be
connected to a separate branch, 60 Hertz, single phase
circuit, AC (alternating current) circuit, fused at 30
Amperes (the circuit must be fused on both sides of the
line). ELECTRICAL SERVICE FOR THE DRYER
UNIT SHOULD BE OF MAXIMUM RATED
VOLTAGE LISTED ON THE NAMEPLATE. DO
NOT CONNECT DRYER TO 110, 115, OR 120
VOLT CIRCUIT. Heating elements are available for
field installation in dryer units which are to be
connected to electrical service of different voltage than
that listed on nameplate, such as 208 Volt.
•If branch circuit to dryer unit is fifteen feet (4.50 m) or
less in length, use U.L. (Underwriters Laboratories)
listed No. 10 A.W.G. wire (copper wire only), or as
required by local codes. If over fifteen feet (4.50 m),
use U.L. (Underwriters Laboratories) listed No. 8
A.W.G. wire (copper wire only), or as required by local
codes. Allow sufficient slack in wiring so dryer can be
moved from its normal location when necessary.
•The power cord (pigtail) connection between wall
receptacle and dryer unit terminal block IS NOT
supplied with dryer unit. Type of pigtail and gauge of
wire must conform to local codes and with instructions
mentioned on the following pages.
The method of wiring the dryer unit is optional and
subject to local code requirements. See examples below.
To reduce the risk of fire, electric shock or
personal injury, all wiring and grounding
MUST conform with the latest edition of the
National Electrical Code ANSI/NFPA 70 or the
Canadian Electrical Code, CSA C22.1, and
such local regulations as might apply. It is the
customer’s responsibility to have the wiring
and fuses checked by a qualified electrician
to make sure the laundry room has adequate
electrical power to operate the dryer.
W035
WARNING
D003IE3A
POWER SUPPLY POWER SUPPLY
3-WIRE GROUNDED NEUTRAL
120/240 VOLT, 60 HERTZ AC 1 PHASE
SERVICE ENTRANCE SWITCH BOX
(SEE NOTE BELOW)
NEUTRAL WIRE NEUTRAL WIRE
METALLIC OR
NON-METALLIC
SHEATHED CABLE
(COPPER WIRE
ONLY)
PIGTAIL
TO DRYER
(SEE NOTE BELOW)
NEUTRAL
L1 L2
PIGTAIL CONNECTION
L1 L2
DIRECT CONNECTION
NEUTRAL
WALL
RECEPTACLE
INTERMEDIATE
FUSE BOX
(MAY BE
OMITTED IF
SERVICE
ENTRANCE
BOX IS FUSED)
INTERMEDIATE
SHUT-OFF BOX
(MAY OR MAY
NOT BE FUSED)
A typical
30-Amp
Three-wire
Receptacle
NEMA Type
10-30R
30 AMPERE FUSES OR
CIRCUIT BREAKER
TERMINAL BLOCK
IN DRYER
120 ±12
VAC
240 ±12
VAC
120 ±12
VAC
NOTE: The power cord (pigtail) is NOT supplied with the
electric dryer. Type of pigtail and gauge of wire must conform
to local codes and instructions.
The method of wiring the dryer is optional and subject to local
code requirements.
NOTE: Connect the dryer to the power supply with the
MAXIMUM RATED VOLTAGE listed on the nameplate.
NOTE: Use COPPER WIRE only.
Shorter than 15' (4.5 m) use 10 A.W.G.
Longer than 15' (4.5 m) use 8 A.W.G.

504524 17
Electrical Connection . . .
(Three-Wire Power Cord)
1. Remove the screw and terminal block access cover
from the rear of the dryer unit cabinet.
2. Insert ends of direct wire through power supply hole
(containing proper strain relief) in rear of dryer unit
cabinet. See following page. Connect the power
cord,or direct wiring, to the appropriate terminal
block terminals using the three wire-binding
(10-32x3/8") screws from the accessories pack in
the envelope shipped inside the dryer unit
cylinder. If the dryer unit had previously been
connected with a four-wire power cord, remove the
four-wire power cord by reversing procedures under
Four-Wire Power Cord instructions.
IMPORTANT: Use only a U.L. listed No. 10 AWG
(copper wire only) three conductor power supply cord
kit rated 240 Volts (minimum) 30 Amperes and
labeled as suitable for use in a clothes dryer unit.
3. Tighten these wire-binding screws firmly.
IMPORTANT: Failure to tighten these screws firmly
may result in wire failure at the terminal block.
4. Secure the strain relief to the power cord, or wires,
where they enter the dryer unit cabinet.
5. Check the continuity of the ground connection before
plugging the cord into an outlet. Use an acceptable
indicating device connected to the center grounding
pin of the plug and the green screw on the back of the
cabinet.
6. Reinstall access cover and screw.
The dryer unit is grounded to neutral
conductor at the terminal block. If local
codes do not permit grounding through the
neutral, proceed as shown on Four Wire
Connection instructions.
W148
To reduce the risk of electric shock,
disconnect the electrical service to the dryer
unit before proceeding.
W149
WARNING
D357IE3A
GROUNDING
PIN
INDICATING
DEVICE
(MUST SHOW
CONTINUITY)
GROUND SCREW
ON BACK
OF CABINET

18 504524
Three Wire Connection
D170IE2D
NEUTRAL
(WHITE
OR CENTER
WIRE)
GROUND
TO NEUTRAL
WIRE
TERMINAL
BLOCK
POWER CORD
OR DIRECT
WIRING
(Three-wire)
STRAIN
RELIEF
(NOT SUPPLIED
WITH DRYER)
NEUTRAL
TERMINAL
ACCESS
COVER
GROUND
WIRE
"L2"
TERMINAL
"L1"
TERMINAL
TERMINAL
BRACKET
GROUND
SCREW
SLOTTED
HEX HEAD
SCREWS
(Shipped
inside
the dryer)
Dryer unit is shown with the access cover removed for illustration purposes only. To reduce the
risk of an electric shock, NEVER operate the dryer unit with the access cover removed.
W150
WARNING
