Alliance Laundry Systems HA025L Troubleshooting guide

Operation/Maintenance
www.comlaundry.com
Tumble Dryers
25 Pound Capacity
30 Pound Capacity
35 Pound Capacity
55 Pound Capacity
Starting Serial No. 0602004144
Refer to Page 3 for Model Identification
Part No. 70380401R9EN
January 2012
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70380401 (EN) 1
Installation must conform with local codes or in the absence of local codes with:
In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1/
NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”
In Canada, installation must comply with Standards CAN/CSA-B149.1 or Natural Gas and Propane Code
CSA C22.1, latest edition, Canadian Electric Code, Part I.
In Australia, installation must comply with the Australian Gas Association Installation Code for Gas
Burning Appliances and Equipment.
IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the
user smells gas. These instructions must be posted in a prominent location. Step-by-step instructions of the
above safety information must be posted in a prominent location near the tumble dryer for customer use.
FOR YOUR SAFETY, the information in this
manual must be followed to minimize the
risk of fire or explosion or to prevent
property damage, personal injury or death.
W033
WARNING
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Clear the room, building or area of all
occupants.
– Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
– If you cannot reach your gas supplier,
call the fire department.
• Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
W052
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
W053
• Évitez de ranger ou d’utiliser de
l’essence ou tout autre liquide
inflammable ou produisant des vapeurs
inflammables à proximité de cet appareil
ou de tout autre appareil.
• PRÉCAUTIONS À PRENDRE SI VOUS
SENTEZ UNE ODEUR DE GAZ :
– Ne tentez d’allumer aucune veilleuse.
– Évitez tout contact avec les
interrupteurs électriques; ne vous
servez d’aucun téléphone de votre
édifice.
– Évacuez toute personne du local, de
l’édifice ou de la zone concerné(e).
– Téléphonez immédiatement à votre
fournisseur du gaz en vous servant du
téléphone d’un voisin. Suivez les
instructions du fournisseur du gaz.
– Si vous n’arrivez pas à vous mettre en
contact avec votre fournisseur du gaz,
appelez les pompiers.
• L’installation et l’entretien de cet appareil
doivent être exécutés par un installateur
qualifié, un centre de service agréé ou
votre fournisseur du gaz.
W052FR
•POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence ou
autres gaz et liquides inflammables au
voisinage de cet appareil ou de tout autre.
W053FR
POUR VOTRE SÉCURITÉ, veillez à bien
respecter les indications de ce manuel afin
de minimiser les risques d’incendie ou
d’explosion ou d’écarter les dangers de
dommages matériels, corporel ou de mort.
W033FR
MISE EN GARDE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2
© Copyright 2012, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
70380401 (EN)
Table of
Contents
Introduction......................................................................................... 3
Model Identification ............................................................................. 3
Customer Service.................................................................................. 4
Wiring Diagram .................................................................................... 4
Serial Plate Location............................................................................. 4
Safety Information.............................................................................. 5
Explanation of Safety Messages........................................................... 5
Important Safety Instructions ............................................................... 6
Operating Instructions ....................................................................... 8
Emergency Stop Button on CE Models................................................ 8
Operating Instructions .......................................................................... 8
Control Instructions .............................................................................. 9
Dual Digital Timer Control.............................................................. 9
Electronic OPL Control ................................................................... 11
Single Drop Control......................................................................... 12
MDC Coin Control .......................................................................... 14
MDC Card Control .......................................................................... 15
NetMaster Coin Control................................................................... 16
NetMaster Card Control................................................................... 17
Quantum Control ............................................................................. 18
LED OPL Control ............................................................................ 19
UniLinc OPL Control ...................................................................... 20
Ignition Control Operation for
Non-CE Models.................................................................................. 21
Ignition Control Operation for CE Models........................................... 22
Maintenance ........................................................................................ 24
Daily ..................................................................................................... 24
Monthly................................................................................................. 26
Quarterly ............................................................................................... 26
Bi-Annually .......................................................................................... 26
Annually ............................................................................................... 26
Before You Call for Service ............................................................... 30
Customer Service.................................................................................. 30

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
70380401 (EN)
Introduction
Model Identification
Information in this manual is applicable to these models.
Includes models with control suffixes:
Gas Steam Electric
25 Pound
HA025L
HA025N
HT025L
HT025N
HU025L
HU025N
SA025L
SA025N
ST025L
ST025N
SU025L
SU025N
UA025L
UA025N
UT025L
UT025N
UU025L
UU025N
YT025L
YT025N
YU025L
YU025N
HT025S
HU025S
ST025S
SU025S
UT025S
UU025S
YT025S
YU025S
HT025E
HU025E
ST025E
SU025E
UT025E
UU025E
YT025E
YU025E
30 Pound
HA030L
HA030N
HT030D
HT030L
HT030N
HU030L
HU030N
SA030L
SA030N
ST030D
ST030L
ST030N
SU030L
SU030N
UA030L
UA030N
UT030L
UT030N
UU030L
UU030N
YT030L
YT030N
YU030L
YU030N
HT030S
HU030S
ST030S
SU030S
UT030S
UU030S
YT030S
YU030S
HT030E
HU030E
ST030E
SU030E
UT030E
UU030E
YT030E
YU030E
35 Pound
AT035L
AT035N
HA035L
HA035N
HT035L
HT035N
HU035L
HU035N
SA035L
SA035N
ST035L
ST035N
SU035L
SU035N
UA035L
UA035N
UT035L
UT035N
UU035L
UU035N
YT035L
YT035N
YU035L
YU035N
AT035S
HT035S
HU035S
ST035S
SU035S
UT035S
UU035S
YT035S
YU035S
AT035E
HT035E
HU035E
ST035E
SU035E
UT035E
UU035E
YT035E
YU035E
55 Pound
HA055L
HA055N
HT055D
HT055L
HT055N
HU055L
HU055N
SA055L
SA055N
ST055D
ST055L
ST055N
SU055L
SU055N
UA055L
UA055N
UT055L
UT055N
UU055L
UU055N
Not
Applicable
HT055E
HU055E
ST055E
SU055E
UT055E
UU055E
BC – basic electronic, coin NC – NetMaster coin UO – UniLinc OPL
BL – basic electronic, central pay NR – NetMaster card WC – network ready coin
BX – basic electronic, prep for coin NX – NetMaster, prep for coin WX – network ready, prep for coin
BY – basic electronic, prep for card NY – NetMaster, prep for card WY – network ready, prep for card
EO – LED OPL OM – OPL micro ZC – NetMaster network coin
LC – network adaptable coin QT – dual digital timer ZR – NetMaster network card
LX – network adaptable, prep for coin SD – single drop ZX – NetMaster network, prep for coin
LY – network adaptable, prep for card SX – single drop, prep for coin ZY – NetMaster network, prep for card

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
70380401 (EN)
4
Customer Service
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Wiring Diagram
The wiring diagram is located in the junction or
contactor box. The wiring diagram part number in the
lower portion of the electrical data on the serial plate.
Serial Plate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are found on serial plate on
rear of machine, and inside door hinge. Refer to
Figure 1.
Figure 1
TMB2098N
1Serial Plate
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
70380401 (EN)
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
IMPORTANT: Warranty is void unless tumble
dryer is installed according to instructions in the
Installation Manual. Compliance with minimum
specifications and requirements detailed herein,
and with applicable local gas fitting regulations,
municipal building codes, water supply regulations,
electrical wiring regulations, and any other
relevant statutory regulations. Because of varied
requirements, applicable local codes should be
thoroughly understood and all pre-installation
work arranged for accordingly.
NOTE: The WARNING and IMPORTANT
instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. It must be understood
that common sense, caution and carefulness are
factors which CANNOT be built into this tumble
dryer. These factors MUST BE supplied by the
person(s) installing, maintaining or operating the
tumble dryer.
Always contact your dealer, distributor, service agent
or the manufacturer on any problems or conditions you
do not understand.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
Failure to install, maintain, and/or operate
this machine according to manufacturer’s
instructions may result in conditions which
can produce serious injury, death and/or
property damage.
W051R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
70380401 (EN)
6
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the tumble
dryer.
2. Refer to the GROUNDING INSTRUCTIONS
for the proper grounding of the tumble dryer.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, other flammable
or explosive substances as they give off vapors
that could ignite or explode.
4. Do not allow children on or in the tumble dryer.
This appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
5. Before the tumble dryer is removed from service
or discarded, remove the door to the drying
compartment and the door to the lint
compartment.
6. Do not reach into the tumble dryer if the cylinder
is revolving.
7. Do not install or store the tumble dryer where it
will be exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the tumble
dryer, or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter daily.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust and dirt.
14. The interior of the tumble dryer and the exhaust
duct should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Tumble dryer will not operate with the loading
door open. DO NOT bypass the door safety
switch to permit the tumble dryer to operate with
the door open. The tumble dryer will stop
tumbling when the door is opened. Do not use the
tumble dryer if it does not stop tumbling when
the door is opened or starts tumbling without
pressing or turning the START mechanism.
Remove the tumble dryer from use and call for
service.
17. Tumble dryer will not operate with lint panel
open. DO NOT bypass lint panel safety switch to
permit the tumble dryer to operate with the lint
panel open.
18. Do not put articles soiled with vegetable or cooking
oil in the tumble dryer, as these oils may not be
removed during washing. Due to the remaining
oil, the fabric may catch on fire by itself.
19. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc. or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with dry-cleaning
solvent in the tumble dryer.
20. Use the tumble dryer only for its intended
purpose, drying fabrics.
21. ALWAYS disconnect and lockout the electrical
power to the tumble dryer before servicing.
Disconnect power by shutting off appropriate
breaker or fuse.
22. Install this tumble dryer according to the
INSTALLATION INSTRUCTIONS. All
connections for electrical power, grounding, and
gas supply must comply with local codes and be
made by licensed personnel when required.
Hazardous Voltage. Can cause shock, burn
or cause death. Allow machine power to
remain off for two minutes prior to working
in and around AC inverter drive.
W359
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
7
70380401 (EN)
23. Remove laundry immediately after tumble dryer
stops.
24. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of reach of children at all times
(preferably in a locked cabinet).
25. Do not tumble fiberglass curtains and draperies
unless the label says it can be done. If they are
dried, wipe out the cylinder with a damp cloth to
remove particles of fiberglass.
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the tumble dryer with any guards
and/or panels removed.
28. DO NOT operate the tumble dryer if it is
smoking, grinding, has missing or broken parts.
29. DO NOT bypass any safety devices.
30. Solvent vapors from dry-cleaning machines
create acids when drawn through the heater of the
drying unit. These acids are corrosive to the
tumble dryer as well as to the laundry load being
dried. Be sure make-up air is free of solvent
vapors.
31. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
WARNING
To reduce the risk of serious injury, install
lockable door(s) to prevent public access
to rear of tumble dryers.
W055R1

70380401 (EN)
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
8
Operating Instructions
Emergency Stop Button on CE
Models
All CE approved OPL tumble dryers are factory
equipped with an emergency stop button located on
the front panel. Refer to Figure 2.
Figure 2
To operate emergency stop button:
a. Press red emergency stop button to stop all
action.
b. To restart machine, pull red emergency stop
button out and press START pad or button.
NOTE: Activation of the emergency stop button
stops all machine control circuit functions, but
DOES NOT remove all electrical power from
machine.
Operating Instructions
Step 1: Clean Lint Screen/Compartment
Remove any accumulated lint from the lint screen and
compartment. Close panel tightly against tumble dryer
frame and lock panel securely, if applicable.
IMPORTANT: Clean lint screen and lint
compartment daily. Failure to clean the lint screen
daily will result in higher than normal
temperatures that may damage laundry.
Step 2: Load Laundry
Open loading door and load cylinder with laundry. DO
NOT OVERLOAD.
NOTE: Overloading causes slow drying and
wrinkling.
Close loading door. Tumble dryer will not operate with
the door open.
Step 3: Determine Control Type and
Temperature Setting
Refer to the various controls, pages 9 - 20, follow
instructions for the appropriate control type.
The type of fabric being dried will determine the
temperature setting. Consult the fabric care label or
fabric manufacturer to determine proper temperature
setting.
IMPORTANT: Always follow the fabric care
instructions supplied by the garment manufacturer.
Step 4: Remove Laundry
When the cycle is complete, open door and remove the
laundry.
To reduce the risk of fire:
• DO NOT DRY articles containing foam rubber or similarly textured rubberlike materials.
• DO NOT DRY plastics, anything containing wax or chemicals such as mops and cleaning
cloths, or anything dry-cleaned at home with a dry-cleaning solvent.
• DO NOT TUMBLE fiberglass curtains and draperies unless the label says it can be done. If
they are dried, wipe out the cylinder with a damp cloth to remove particles of fiberglass.
W076
To reduce the risk of serious injury, allow cylinder to stop before cleaning lint screen.
W412
WARNING
TMB1664N
1Emergency Stop Button
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
9
70380401 (EN)
Control Instructions
Figure 3
Dual Digital Timer Control
QT Control Suffix
1. Select HIGH, MED, LOW or NO HEAT by
turning the temperature knob.
HIGH temperature 190°F (87°C)
MED temperature 170°F (77°C)
LOW temperature 120°F (49°C)
2. Set the HEAT TIME for the number of minutes
(from 0 - 60) desired.
3. Set the COOL DOWN TIME for the number of
minutes (from 0 - 15) desired.
4. Display will show minutes remaining before end
of cycle.
NOTE: One touch drying is available for repetitive
loads. If the START button is pressed while the
machine is in Idle Mode, when the display is dark,
the tumble dryer will repeat the last drying cycle. If
the cycle time is adjusted before the cycle is started,
the time displayed when the start button was
pressed will be used for future cycles.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. If the loading
door or lint panel door is opened during the cycle,
the heating system will shut off and the motor will
stop. To restart the cycle, both doors must be closed
and the START button must be pressed in.
If the load cools to 90° F before cool down time
expires, the control will flash “Lr” (load ready) in the
heat time display. If the door is not opened, the tumble
dryer completes the selected cool down time. If the
door is opened after reaching “Lr” temperature, the
cycle will be terminated.
NOTE: If display shows an error code, refer to
Error Codes section.
5. When the cycle is complete, open door and
remove the laundry. Anti-wrinkle feature will
tumble the load without heat for 30 seconds
every 2 minutes for 1 hour OR until the loading
door is opened.
NOTE: This machine includes an anti-wrinkle/
extended tumble feature. After the drying cycle is
complete, the cylinder will tumble without heat
every few minutes. The intermittent tumbling will
continue for one hour or until the door is opened.
TMB2133N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
70380401 (EN)
10
Error Codes
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the tumble dryer before servicing.
• Close gas shut-off valve to gas tumble dryer before servicing.
• Close steam valve to steam tumble dryer before servicing.
• Never start the tumble dryer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the tumble dryer is properly grounded.
W002R1
WARNING
Display Definition Corrective Action
OP
Open thermistor error • Check thermistor. Replace if inoperative.
• Check wiring diagram between control and thermistor.
Refer to wiring diagram for proper wiring.
• Check control. Replace if inoperative.
SH
Shorted thermistor error • Check thermistor. Replace if inoperative.
• Check wiring between control and thermistor. Refer to
wiring diagram for proper wiring.
• Check control. Replace if inoperative.
AF - 1 Airflow switch closed when cycle
started
• Check airflow switch. Replace if inoperative.
AF - 2 Airflow switch failed to close after cycle
started
• Check airflow switch. Replace if inoperative.
AF (Flashing)
Bouncing Airflow Switch • Check airflow switch to ensure that it is properly
aligned and securely mounted in the mounting bracket.
• Make sure airflow switch can open and close freely.
• Check installation and make sure there is adequate
airflow.
• Make sure exhaust is not blocked.
• Clean the lint screen.
• Replace airflow switch if inoperative.
AF (Solid)
Airflow Switch Closed when Resuming
Cycle
• Allow up to 20 seconds for this condition to clear.
• Check if airflow switch opens at end of cycle.
• Replace airflow switch if inoperative.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
11
70380401 (EN)
Figure 4
Electronic OPL Control
OM Control Suffix
1. To use an Automatic Cycle, press an ON/
SELECT pad. Select HIGH, MEDIUM,
MED LOW, LOW or NO HEAT for items that
should not be dried with heat. A light to the left
of the selected pad lights up.
HIGH temperature (25, 30 lbs.) 185°F (85°C)
HIGH temperature (35, 55 lbs.) 190°F (88°C)
MED temperature (25, 30 lbs.) 160°F (71°C)
MED temperature (35, 55 lbs.) 165°F (74°C)
MED LOW temperature (25, 30 lbs.) 145°F (63°C)
MED LOW temperature (35, 55 lbs.) 155°F (68°C)
LOW temperature (25-55 lbs.) 120°F (49°C)
To use a Time Dry or Custom Cycle, refer to the
Programming Manual.
NOTE: Do not press directly on lights or the center
of pad. For proper selection, press on pad slightly
to the right of center. Refer to Figure 5.
Figure 5
2. Press START pad to start tumble dryer.
NOTE: All pads can be pressed in any sequence
without damaging control or tumble dryer. To stop
the tumble dryer at any time, open the door or
press STOP/RESET. The window display will flash.
Press STOP/RESET twice (within 3 seconds) to end
the cycle and reset the control to idle status. To
restart the tumble dryer, CLOSE door and press
START pad.
IMPORTANT: If the loading door or lint panel
door is opened during the cycle, the heating system
will shut off and the motor will stop. To restart the
cycle, both doors must be closed and the PUSH TO
START button must be pressed in.
3. When the cycle is complete, open door and
remove the laundry.
NOTE: This machine includes an anti-wrinkle/
extended tumble feature. After the drying cycle is
complete, the cylinder will tumble without heat
every few minutes. The intermittent tumbling will
continue for one hour or until the door is opened.
TMB1789N
STATUS
DRYING
COOL DOWN
DOOR OPEN
CUSTOM
HIGH
MEDIUM
MED LOW
LOW
NO HEAT
TEMP
DISPLAY
SIGNAL
F/ C
TEMP
PROGRAM
AUTO
SPECIAL
CYCLE
MORE
CONDITION
SPECIAL
TIME
COOL
DOWN
LESS
SAVE
CUSTOM
TIME
*
+--
*
PROG
AUTO
AUTO
ON / SELECT
START
STOP/RESET
TMB1789N
TMB806N
TMB806N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
70380401 (EN)
12
Figure 6
Single Drop Control
SD and SX Control Suffixes
1. Select HIGH, MED, LOW or NO HEAT by
turning the temperature knob.
HIGH temperature 190°F (87°C)
MED temperature 160°F (71°C)
LOW temperature 130°F (54°C)
2. Insert the coin(s) in the coin slot.
3. Press START button to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START
button.
NOTE: If display show an error code, refer to
Error Codes section.
4. When the cycle is complete, open door and
remove the laundry.
NOTE: This machine includes an extended tumble
feature. Starting 20 minutes after a cycle ends, the
cylinder will tumble for two minutes every hour
without heat, up to 18 hours or until door is
opened.
Preliminary Control Information
Power-Up Mode
When power is applied to the tumble dryer the control
will enter Ready Mode, unless a cycle was in process
prior to a disruption of power. If a power disruption is
less than 5 seconds, with a cycle in process, the control
will enter Run Mode once power is restored and
continue the cycle. If a power disruption is more than
5 seconds, with a cycle in process, the control will
enter Start Mode once power is restored.
If the dry time dipswitch settings have not changed
from the factory default, the IN USE LED will flash
two to five times, depending on model.
Ready Mode
In Ready Mode, the control waits for the vend to be
satisfied before entering Start Mode.
Start Mode
In Start Mode, the vend has been satisfied, but the
Start button has not been pressed. The IN USE LED
will be lit. The timer will not count down until the
Start button is pressed.
Run Mode
In Run Mode, the control is running a cycle. The IN
USE LED is lit.
TMB2123N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
13
70380401 (EN)
Door Open Mode
In Door Open Mode, the control turns off the heater
and motor when the door is opened during a run cycle.
The timer will continue to count down time and the IN
USE LED is lit.
End of Cycle Mode
In End of Cycle Mode, a cycle is complete and the IN
USE LED is off. The control remains in this mode
until the door is opened or additional vend has been
satisfied.
Topoffs
Any time the control receives a coin drop pulse during
a cycle it will add the programmed dry time to the time
currently remaining in the cycle. The maximum cycle
time is 99 minutes, the control will not add time
beyond 99 minutes. The cool down time will not
change.
If the control receives a coin drop pulse during cool
down the IN USE LED will flash briefly to indicate the
coin input, the machine will exit cool down and it will
start heating. The cycle time will be equal to the
programmed dry time
Temperature Selector Switch
For five minutes after the control is powered up, there
is a diagnostic feature that allows the temperature
selector switches to be tested.
When the temperature selector is changed, the new
setting is displayed by flashing the IN USE LED as
follows:
High/Normal: 4 flashes
Medium/PP: 3 flashes
Low/Delicate: 2 flashes
No Heat: 1 flash
NOTE: To change dipswitch settings refer to
Installation Manual.
To Program a Short Test Cycle:
1. Unplug machine power cord.
2. Write down machine control dip switch settings,
then set them all to the off position. Refer to
Figure 7.
3. Plug machine in and start a cycle.
NOTE: With all control dip switches off, the total
cycle time will be 2 minutes long (1 minute of heat
and 1 minute of cool down).
4. Once all testing is complete, unplug machine and
re-set dip switches to their original settings.
5. Plug machine in.
Figure 7
Error Codes
TMB2216N
1 2 3 4 5 6 7 8 O
N
12345678
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the tumble dryer before servicing.
• Close gas shut-off valve to gas tumble dryer before servicing.
• Close steam valve to steam tumble dryer before servicing.
• Never start the tumble dryer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the tumble dryer is properly grounded.
W002R1
WARNING
Display Definition Corrective Action
AF (flashing) Airflow switch opened/closed 5 or
more times in a running cycle.
• Check airflow switch. Replace if inoperative.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
70380401 (EN)
14
Figure 8
MDC Coin Control
BC and BX Control Suffixes
1. Select HIGH TEMP, MED TEMP, LOW TEMP
or DELICATES by pressing the appropriate
temperature pad.
2. Insert the coin(s) in the coin slot.
3. Press START pad to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START pad.
4. When the cycle is complete, open door and
remove the laundry.
TMB1964N
SELECT
TEMP
PUSH
START
COOL
DOWN
DRYING
DELICATES
START
25C
or
INSERT
CARD
INSERT
COINS

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
15
70380401 (EN)
Figure 9
MDC Card Control
BL and BY Control Suffixes
1. Select HIGH TEMP, MED TEMP, LOW TEMP
or DELICATES by pressing the appropriate
temperature pad.
2. Insert card into opening.
3. Press START pad to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START pad.
4. When the cycle is complete, open door and
remove the laundry.
TMB1965N
SELECT
TEMP
PUSH
START
COOL
DOWN
DRYING
DELICATES
START
INSERT CARD HERE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
70380401 (EN)
16
Figure 10
NetMaster Coin Control
NC, NX, ZC and ZX Control Suffixes
1. Select HIGH TEMP, MED TEMP, LOW TEMP
or NO HEAT by pressing the appropriate
temperature pad.
2. Insert the coin(s) in the coin slot.
3. Press START pad to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START pad.
4. When the cycle is complete, open door and
remove the laundry.
C851I

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
17
70380401 (EN)
Figure 11
NetMaster Card Control
NR, NY, ZR and ZY Control Suffixes
1. Select HIGH TEMP, MED TEMP, LOW TEMP
or NO HEAT by pressing the appropriate
temperature pad.
2. Insert card into opening. DO NOT remove the
card until “REMOVE CARD” LED is lit.
3. Press START pad to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START pad.
4. When the cycle is complete, open door and
remove the laundry.
C852I
C852I

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
70380401 (EN)
18
Quantum Control
LC, LX, LY, WC, WX and WY Control Suffixes
1. Select HIGH, MED, LOW, NO HEAT or
DELICATES by pressing the appropriate
temperature pad.
2. Insert the coin(s) in the coin slot or card into the
card opening.
3. Press START pad to start tumble dryer.
IMPORTANT: To stop the tumble dryer at any
time during a cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START pad.
4. When the cycle is complete, open door and
remove the laundry.
NOTE: This machine includes an extended tumble
feature. Starting 20 minutes after a cycle ends, the
cylinder will tumble for two minutes every hour
without heat, up to 18 hours or until door is
opened.
DRY576R
Figure 12
