Alliance Laundry Systems DRY688C Operating instructions

Troubleshooting
DRY688C
DRY684C
D715I
DRY684C
DRY688C
Part No. D512176R3
January 2018
Home Dryers
Refer to Page 6 for Model Numbers
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2018Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without
the expressed written consent of the publisher.
D512176 1
Table of
Contents
Section 1 – Safety Information
Locating an Authorized Servicer ..................................................... 4
Section 2 – Introduction
Customer Service ............................................................................ 5
Nameplate Location ........................................................................ 5
Model Identification ........................................................................ 6
How Your Dryer Works .................................................................. 7
Section 3 – Dryer Troubleshooting
1. No Timer Advance In Automatic Cycles ................................. 8
2. Dryer Motor Does Not Run ...................................................... 10
3. Dryer Stops in Cycle; Quits After the First Few Loads;
Has a Burning Smell; Cycles On Motor Thermal
Protector ................................................................................... 12
4. Dryer Motor Runs But Cylinder Does Not Turn ...................... 13
5. Dryer Motor Does Not Stop .................................................... 14
6. Dryer Runs Only When Door is Open ..................................... 15
7. Dryer Heating Assembly Does Not Heat or Burner
Does Not Ignite ......................................................................... 16
8. Igniter Does Not Glow (Gas Supply Sufficient) –
Gas Dryer Models ..................................................................... 18
9. Burner Ignites and Goes Out Repeatedly –
Gas Dryer Models ..................................................................... 19
10. Igniter Glows But Burner Does Not Ignite –
Gas Dryer Models ..................................................................... 20
11. Dryer Heater Assembly or Burner Shuts Off Prematurely ....... 21
12. Dryer Heater Assembly or Burner Repeatedly Cycles
Off On Limit Thermostat .......................................................... 22
13. Dryer Heater Assembly or Burner Does Not Shut Off ............. 24
14. Clothes Do Not Dry in Dryer ................................................... 25
15. Timer Does Not Advance in Automatic Cycle ......................... 26
16. Clothes Are Too Hot When Removed From Dryer .................. 27
17. Excessive Chattering or Vibrating Noise in Dryer ................... 28
18. Excessive Humming or Whistling Noise in Dryer ................... 29
Section 4 – Adjustments
19. Leveling Legs ........................................................................... 30
20. Burner Flame (Gas Models) ..................................................... 31
Section 5 – Test Procedures
21. Timer Contacts ......................................................................... 32
22. Fabric Selector Switch .............................................................. 33
23. Drive Motor .............................................................................. 34
24. Motor Switch ............................................................................ 37
25. Burner System Operation ......................................................... 39
26. Electrical Circuit To Ignition System (Gas Models) ................ 40

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2D512176
27. Gas Valve Coils Check (Gas Models) ...................................... 40
28. Sensor Check (Gas Models) ..................................................... 41
29. Igniter Check (Gas Models) ..................................................... 41
30. Thermal Fuse (Electric Models) ............................................... 42
31. Heater Assembly (Electric Models) ......................................... 42
32. Cycling or Limit Thermostat .................................................... 42
33. Door Switch .............................................................................. 43
Section 6 – Internal Wiring of Dryer Motor Switch

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
D512176
Section 1
Safety Information
Throughout this manual and on machine decals, you will find precautionary statements (“CAUTION,”
“WARNING” and “DANGER”) followed by specific instructions. These precautions are intended for the personal
safety of the operator, user, servicer, and those maintaining the machine.
DANGER
Danger indicates an imminently hazardous situation that, if not avoided, will cause severe personal injury or death.
WARNING
Warning indicates a hazardous situation that, if not avoided, could cause severe personal injury or death.
CAUTION
Caution indicates a hazardous situation that, if not avoided, may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and “NOTE”) are followed by specific instructions.
IMPORTANT
The word “IMPORTANT” is used to inform the reader of specific procedures where minor machine damage will
occur if the procedure is not followed.
NOTE
The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is
important but not hazard related.
In the interest of safety, some general precautions relating to the operation of this machine follow.

To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
4D512176
Section 1 Safety Information
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
NOTE: The WARNINGS and IMPORTANT INSTRUCTIONS appearing in this manual are not meant to
cover all possible conditions and situations that may occur. Common sense, caution and care must be
exercised when installing, maintaining or operating the machine.
Always contact your dealer, distributor, service agent or the manufacturer about any problems or conditions you do
not understand.
Locating an Authorized Servicer
Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper
service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is
required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized
technician and using authorized factory parts.
• Failure to install, maintain, and/or operate this machine according to the manufacturer’s
instructions may result in conditions which can produce serious injury, death and/or
property damage.
• Do not repair or replace any part of the machine or attempt any servicing unless specifically
recommended or published in this Service Manual and that you understand and have the
skills to carry out.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the machine is properly grounded and to reduce the risk of fire,
electric shock, serious injury, or death.
W284
WARNING
Repairs that are made to your products by unqualified persons can result in hazards due to
improper assembly or adjustments subjecting you, or the inexperienced person making such
repairs, to the risk of serious injury, electrical shock, or death.
W007
WARNING
If you or an unqualified person perform service on your machine, you must assume the
responsibility for any personal injury or property damage which may result. The manufacturer
will not be responsible for any injury or property damage arising from improper service and/or
service procedures.
W286
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
D512176
Section 2
Introduction
Customer Service
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Nameplate Location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on nameplate(s) as shown.
D412PE1A
Nameplate

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 2 Introduction
D512176
6
Model Identification
Information in this manual is applicable to these dryers:
ADE30RGS171TW01
ADE3LRGS171TW01
ADE41FSS171TN01
ADE4BFGS171TW01
ADE4BRGS171TW01
ADG30RGS111TW01
ADG3LRGS111TW01
ADG41FSS111TN01
ADG4BFGS111TW01
ADG4BRGS111TW01
AES17AWF
AES20AWF
AES28AWF
AES28AWF1500
AES68AWF
AES68AWF1500
AGS17AWF
AGS20AWF
AGS28AWF
AGS68AWF
ASE30FGW171TW01
ASG30FGW111TW01
CES68AWF
CES68AWF1500
CGS68AWF
KES18AWF
KES18AWF1500
KGS18AWF

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 2 Introduction
7
D512176
How Your Dryer Works
The dryer uses heated air to dry loads of laundry. When the motor is started, the exhaust fan pulls room temperature
air in through louvers at the rear of the dryer and over the heat source (burner flame for gas and heating element for
electric). The heated air moves through the heater duct and into the cylinder, where it circulates through the wet
load. The air then passes through the lint filter, air duct, and exhaust fan, where it is vented to the outdoors.
The dryer has an automatic drying feature. At cycle start, when fabric is wet and the temperature inside dryer is
cool, the heat source (burner on gas models and heating element on electric models) is energized and heats the
cylinder until operating temperature (as set on Fabric Selector) is reached. Power is not supplied to timer motor
while heat source is energized during an automatic cycle. The heat source runs for longer periods of time in the
beginning of the cycle, when it is working to reach the operating temperature, resulting in very little timer
advancement. As the fabric dries and the cylinder heat is maintained, the heat source is powered less, allowing the
timer to advance to cycle end. If dryer heats but timer does not advance, refer to Paragraph 1.
DRY1819S
Lint
Filter
Cylinder
Heater
Duct Blower
Fan
DRY1819S

To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT D512176
8
Section 3
Troubleshooting
IMPORTANT: Refer to wiring diagram for aid in
testing dryer components.
1. NO TIMER ADVANCE IN AUTOMATIC
CYCLES
For a description of Automatic drying feature, refer to
SECTION 2. If dryer heats but the timer does not
advance, perform the following service procedures:
Electric Dryers
1. Remove any damp clothing from the dryer.
2. Set the timer to an Automatic cycle. Set fabric
selector switch to Regular.
3. Remove the top 3 screws holding the control
hood to the rear panel.
4. Start dryer by pushing in timer knob.
5. Using a volt/ohm meter set to AC voltage,
measure the voltage across terminal “T” and
terminal “M” on timer. Refer to Figure 1.
6. Meter should read no voltage when the unit is
first started and the dryer is still heating.
Continue to monitor these points until the heating
element has shut off (this will take several
minutes even with an empty load). When the
heating element shuts off, meter should read 120
Volts and the timer motor should advance the
cycle.
7. If meter does not read 120 Volts after the unit has
reached proper operating temperature use meter
to check for 120 AC Voltage between terminal
“A” and terminal “N” (neutral) on the timer.
8. If voltage is present, recheck voltage between
“T” and “M”.
9. If voltage is present, but timer does not advance,
replace timer.
10. If meter does not read 120 Volts at “A” and “N”,
check the wire connections at the heating element
and timer (blue/black wire). If the connections
are good, UNPLUG dryer, remove wire at
terminal “A” on timer and perform an ohms
check on wire continuity between the heating
element and timer. If the wire shows continuity,
replace timer.
