Alliance Laundry Systems WB2 350B Series Maintenance and service guide

Installation/Maintenance
Washer-Extractors
Barrier Washer
Refer to Page 15 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. D2615ENR1
January 2023

Table of Contents
Safety Information................................................................................. 5
Explanation of Safety Messages....................................................................... 5
Important Safety Instructions........................................................................... 5
Safety Precautions.........................................................................................10
Introduction..........................................................................................15
Model Identification......................................................................................15
Serial Plate Location..................................................................................... 15
Software Identification.................................................................................. 16
Manufacturing Date...................................................................................... 16
Delivery Inspection....................................................................................... 17
Replacement Parts.........................................................................................17
Customer Service..........................................................................................17
Specification and Dimensions................................................................18
General Specifications...................................................................................18
Machine Dimensions.....................................................................................20
Mounting Bolt Hole Location and Placement into Hygienic Barrier...................34
Installation........................................................................................... 36
Handling Transport and Storage..................................................................... 36
Unpacking................................................................................................ 38
Placement into Hygienic Barrier with Guards (on Request)...............................39
Machine Anchoring.......................................................................................41
Weighing System Installation (on Request)......................................................41
Machine Anchoring with Weighing System - Uneven Surfaces (On Request)..... 42
Drain Connection..........................................................................................43
Drain under the Machine............................................................................43
Side Drain (on Request)............................................................................. 44
Main Drain Channel-pipe...........................................................................44
Water Connection Requirements.....................................................................45
Connecting Hoses......................................................................................... 46
Bath Sample Tap...........................................................................................47
Connection of the Ventilation Valve (optional, used for Indirect Steam Heating op-
tion), 36 kg / 360 L Models........................................................................ 47
Electrical Installation Requirements................................................................47
Residual Current Device - RCD..................................................................48
Supply Protection Device...........................................................................49
Supply Cable............................................................................................ 49
Determining AWG Sizes............................................................................ 50
Machine Protective Earth Connection and Equipotential Bonding.................. 50
Electrical Specifications................................................................................ 51
© Copyright 2023, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. D2615ENR1

Input Power Conditioning..............................................................................53
Input Voltage Requirements........................................................................53
Circuit Breakers and Quick Disconnects......................................................... 53
Connection Specifications..............................................................................54
Phase Adder..............................................................................................54
Thermal Overload Protector....................................................................... 54
Steam Connection.........................................................................................54
Press Air Connection.....................................................................................54
Venting........................................................................................................ 55
Liquid Soap Connection................................................................................ 55
Electrical Connection of the Liquid Soap Supply System..................................56
Chemical Injection Suppy System.................................................................. 57
Maintenance......................................................................................... 58
General........................................................................................................ 58
Checking and Maintenance Daily................................................................... 58
Checking and Maintenance Every Three Months............................................. 58
Checking and Maintenance Every Six Months................................................. 58
Safety Vibration Switch.................................................................................59
Spring Unit...................................................................................................61
Belts Replacement and Adjusting Tension.......................................................61
Lubrication...................................................................................................62
Water Filters.................................................................................................62
Tightening Moments..................................................................................... 63
Replacement Washer Fuses............................................................................ 63
Troubleshooting....................................................................................64
Unlocking of the Door lock in Case of Emergency........................................... 64
Error Indication Shown on Display.................................................................64
List of Recommended Spare Parts.................................................................. 64
Disposal of Unit.................................................................................... 65
Disconnecting the Machine............................................................................65
Machine Disposal......................................................................................... 65
Possibility of the Machine Disposal by the Specialized Company.................. 65
Possibility of the Machine Liquidation by Own Potential.............................. 65
China Restriction of hazardous substances (RoHS)............................... 66
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. D2615ENR1

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions
WARNING
Read all the instructions before using the ma-
chine. Safe these Instructions for future reference.
Electrical shock prevention
DANGER
Electrical shock hazard will result in death or serious
injury. Before inspecting, maintenance or servicing
machines, power supply must be turned OFF. The
servicer needs to wait for at least ten (10) minutes af-
ter turning the power OFF. This machine must be
connected to a grounded metal, permanent wiring
system, and an equipment grounding conductor
must be run with the supply conductors and connec-
ted to the equipment grounding terminal on the ma-
chine. When the main switch is turned off, the inlet
terminals of the main switch are still under current.
The inverter remains charged with high voltage for
some time after powering OFF. Before starting in-
spection of the inverter, check for residual voltage
across main circuit terminals " + " and " - ". This
voltage must be below 30 VDC before the servicer
can access the inverter for inspection. Do NOT con-
nect manufacturer or other devices to the inverter to
manipulate the inverter behavior. No modification to
the settings are allowed. This is an imminently haz-
ardous situation that, if not avoided, will cause se-
vere personal injury or death.
Install ‐ Maintenance prevention
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. D2615ENR1

WARNING
Machine installations must comply with minimum
specifications and requirements stated in the appli-
cable Installation Manual, any applicable municipal
building codes, water supply regulations, electrical
wiring regulations and any other relevant statutory
regulations. Due to varied requirements and applica
ble local codes, this machine must be installed, ad-
justed, troubleshooting and serviced by qualified
maintenance technician which is familiar with the ap-
plicable local codes and the construction and opera-
tion of this type of machinery. They must also be fa-
miliar with the potential hazards involved. Failure to
observe this warning may result in personal injury,
property damage, and/or equipment damage, and
will void the warranty.
Ensure and install the machine on a level floor of
sufficient strength. Ensure that the recommended
clearances for inspection and maintenance are pro-
vided. Never allow the inspection and maintenance
space to be blocked. To reduce the risk of fire, this
appliance must be installed and secured to an un-
covered not obstructed concrete floor. Do not install
the machine over an open water storage or drain
system. Adequate ventilation must be provided to
avoid the back flow of gases into the room from ap-
pliances burning other fuels.
WARNING
ALWAYS disconnect the machine from Electrical
power, Water, Steam and all other connected sup-
plies during installation, before attempting any serv-
ice, replacing parts and maintenance.
electricity, steam, compressed air), than such means
must be part of the fixed installation external to the
machine. Such isolators shall be clearly identified.
They shall be capable of being locked if reconnec-
tion could endanger persons. After the energy
source is disconnected, follow the install procedure
to safely, dissipate any energy remaining or stored in
the circuits of the machine. Use machine only for its
intended purpose, laundry textiles. Never wash/dry/
iron something else than suitable linen, like poly-
mers, machine parts, automotive parts or other ferro
materials in the machine. This could result in serious
injury and machine damage.
WARNING
In case the machine is provided with shipping bra-
ces, they must be removed prior to putting into serv-
ice. See Install instruction for safely remove them.
Sharp edges can cause personal injury. Wear safety
glasses and gloves, use proper tools and provide
lighting when handling sheet metal parts. Failure to
do so may result in conditions which can produce
serious injury, death and/or property damage.
The washer is provided with Air vents where from
Vapors can escape! Do not connect or cover them!
The automatic door-lock unlocking devices must not
be utilized or installed on machines that are fitted
with a drain pump or reverse function drain valve.
The new hose sets supplied with the appliance are to
be used. Old hose sets should not be reused.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. D2615ENR1

Electrical - Energy prevention
WARNING
Machine must be hard-wired.
Refer to the Earthing (grounding) instructions in the
INSTALLATION manual for the proper grounding of
the machine. In event of malfunction, breakdown or
leakage current, grounding will reduce the risk of
electrical shock and serve as a protecting device by
providing a path of least resistance of electrical cur-
rent. Therefore, it is very important, and the respon-
sibility of the qualified installer to assure the ma-
chine is adequately grounded at installation, follow-
ing all the national and local requirements. If there
are other washers or appliances with exposed con-
ductive parts, which can touch simultaneously, make
sure to make equipotential bonding between all
these appliances. The external protective terminal
for this purpose is located on the rear side of the ma-
chine frame. The minimum protection conductor's
cross section depends on the supply cable cross
section of the appliance of the highest current rating.
If the machine is not equipped with a supply mains
disconnecting device, means for disconnection must
by incorporated in fixed wiring in accordance with
overvoltage category Ill conditions and the relevant
local wiring rules. If disconnection is foreseen by
means of a plug, it must be placed and installed in
such a way that an operator can check from any of
the points to which he has access, that the plug re-
mains removed. If this is not possible, due to its in-
stallation, a disconnection with a locking system in
the isolated position shall be provided. Dangerous
voltages are present inside the machine. Disconnect
power from the machine before removing any cover
and guards, and before attempting any maintenance,
troubleshooting or service procedures or replacing
parts. To reduce the risk of an electric shock or fire,
DO NOT use an extension cord or an adapter to con-
nect the machine to the electrical power source. The
machine is not designed for use in IT networks. Ap-
plicable measures need to be provided.
Use Limitation
WARNING
The machine cannot used by children aged under 8
years.
This appliance cannot be used by children aged from
8 and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge, unless they have been given super-
vision and instruction concerning use of the ma-
chine in a safe way and understand the hazard in-
volved, by a person responsible for their safety. Chil-
dren should be supervised to ensure that they do not
play on, in or with the machine. Close supervision of
children is necessary when the machine is used near
children. Cleaning and maintenance shall not be
made by children.
Operation Prevention
WARNING
Never operate the machine with any guards, panels
and/or parts removed or broken. Do NOT bypass any
safety devices or tamper with the controls.
Safety decals appear at crucial locations on the ma-
chine. Failure to maintain legible safety decals could
result in injury to the operator or service technician.
Use only authorized spare parts in the event of fail-
ure. Do not repair or replace any part of the machine
or attempt any servicing unless specifically recom-
mended in the user-maintenance instructions or in
published user-repair instructions that the user un-
derstands and has the skills to carry out.
If the supply cord is damaged, it must be replaced by
a qualified technician to avoid a hazard.
Never touch internal or external steam pipes, con-
nections, or components. These surfaces can be ex-
tremely hot and will cause severe burns. The steam
supply must be turned off and allow the pipe, con-
nections and components to cool before the pipe
can be touched.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. D2615ENR1

WARNING
Avoid contact with hot inlet water temperatures high-
er than 125° Fahrenheit [51°C] and hot surfaces.
Never interfere with the setting of the door handle.
Never try to modify the setting or repair the handle!
Any interference with its setting may lead to serious
risk for the operator! A damaged or incorrectly func-
tioning door handle must always be immediately re-
placed with a new original part by qualified person-
nel.
Loading door must be closed any time the machine
is operating.
Do NOT attempt to open the door until the machine
has drained and all moving parts have stopped. NEV-
ER insert hands or objects into basket until it has
completely stopped.
Do NOT bypass the door switches that permits the
machine to operate with the loading door open.
Operating the washer with severe out-of-balance
loads could result in personal injury and serious
equipment damage.
Before using the emergency door opening function,
turn off the machine's main switch. Never open the
door while the basket is still running or if the ma-
chine parts feel too warm or if "Too hot" is indicated.
Always wait to open the door until there is no water
in the drum.
WARNING
Open the door only at the loading side to prevent
contamination at the clean side.
WARNING
In case the machine is provided with tilting function-
ality, when activating the tilting function or unload
rotation, stands always sideways of the machine.
During unload rotation do not attempt to pull the lin-
en out, it comes out of the drum by itself. Avoid ac-
cess of any person in the front or behind the ma-
chine during its tilting action.
Injury Prevention
WARNING
To reduce the risk of fire, electric shock, or in jury to
persons when using your machine, follow these pre-
cautions, including the following:
• Do not install or store the washer where it will be
exposed to water and/or weather conditions.
• To prevent fire and explosion, keep the area
around machine free from flammable and com-
bustible products. Do not add the following sub-
stances or textiles containing traces of the follow-
ing substances to the wash water: gasoline, kero-
sene, waxes, cooking oils, vegetable oils, ma-
chine oils, dry-cleaning solvents, flammable
chemicals, thinners, or other flammable or explo-
sive substances. These substances give off va-
pors that could ignite, explode or cause the fabric
to catch fire by itself.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using a washing
machine or combination washer-dryer, turn on all
hot water faucets and let the water flow from each
for several minutes. This will release any accumu-
lated hydrogen gas. The gas is flammable, do not
smoke or use an open flame during this time.
• Use only low-sudsing, no-foaming types of com-
mercial deter gent. Be aware that hazardous
chemicals may be present. Wear hand and eye
protection when adding detergents and chemi-
cals. Always read and follow manufacturer's in-
structions on packages of laundry and cleaning
aids. Read all warnings or precautions. To reduce
the risk of poisoning or chemical burns, always
keep them out of the reach of children [preferably
in a locked cabinet].
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. D2615ENR1

WARNING
• Do not use fabric softeners or products to elimi-
nate static unless recommended by the manufac-
turer of the fabric softener or product.
• Always follow the fabric care instructions sup-
plied by the textile manufacturer.
• Do not climb or stands on the washer, not reach
or climb into the drum.
• Be aware that water is used to flush the supply
dispenser. Avoid opening the dispenser lid while
the machine is running.
• Do not attach anything to the supply dispenser's
nozzles, if applicable. The air gap and overflows
must be maintained.
WARNING
• Do not attach anything to the supply dispenser's
nozzles, if applicable. The air gap and overflows
must be maintained.
• Do not operate the machine without the water re-
use plug or water reuse system in place, if appli-
cable.
• Be sure that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
• Keep washer in good condition. Bumping or drop-
ping the washer can damage safety features. If
this occurs, have washer checked by a qualified
service person.
• Before the washer is removed from service or dis-
carded, remove the door to the washing compart-
ment.
• To avoid machine corrosion and component fail-
ure, do not use corrosive chemicals in the ma-
chine. The use of hypochlorite will cause corro-
sion which may cause component failure under
certain circumstances.
• Always contact your dealer, distributor, service
agent or the manufacturer on any problems or
conditions you do not understand.
• Read all instructions before using the washer.
• Install the washer according the INSTALLATION instruc-
tions. Refer to the EARTHING instructions in the INSTAL-
LATION manual for the proper earthing of the washer. All
connections for water, drain, electrical power and earthing
must comply with local codes and be made by licensed per-
sonnel when required. It is recommended that the machine be
installed by qualified technicians.
• Do not install or store the washer where it will be exposed to
water and/or weather.
• To prevent fire and explosion, keep the area around machine
free from flammable and combustible products. Do not add
the following substances or textiles containing traces of the
following substances to the wash water: gasoline, kerosene,
waxes, cooking oils, vegetable oils, machine oils, dry-clean-
ing solvents, flammable chemicals, thinners, or other flamma-
ble or explosive substances. These substances give off vapors
that could ignite, explode or cause the fabric to catch fire by
itself.
• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using a
washing machine or combination washer-dryer, turn on all hot
water faucets and let the water flow from each for several mi-
nutes. This will release any accumulated hydrogen gas. The
gas is flammable, do not smoke or use an open flame during
this time.
• To reduce the risk of an electric shock or fire, DO NOT use an
extension cord or an adapter to connect the washer to the elec-
trical power source.
• Do not allow children to play on or in the washer. Close su-
pervision of children is necessary when the washer is used
near children. This appliance is not intended for use by young
children or infirm persons without supervision. Young chil-
dren should be supervised to ensure that they do not play with
the appliance. This is a safety rule for all appliances.
• DO NOT reach and/or climb into the tub or onto the washer,
ESPECIALLY if the wash drum is moving. This is an immi-
nently hazardous situation that, if not avoided, will cause se-
vere personal injury or death.
• Never operate the washer with any guards, panels and/or parts
removed or broken. DO NOT bypass any safety devices or
tamper with the controls.
• Use washer only for its intended purpose, washing textiles.
Never wash machine parts or automotive parts in the ma-
chine. This could result in serious damage to the basket or
tub.
• Use only low-sudsing, no-foaming types of commercial deter-
gent. Be aware that hazardous chemicals may be present.
Wear hand and eye protection when adding detergents and
chemicals. Always read and follow manufacturer’s instruc-
tions on packages of laundry and cleaning aids. Heed all
warnings or precautions. To reduce the risk of poisoning or
chemical burns, keep them out of the reach of children at all
times (preferably in a locked cabinet).
• Do not use fabric softeners or products to eliminate static un-
less recommended by the manufacturer of the fabric softener
or product.
• Always follow the fabric care instructions supplied by the tex-
tile manufacturer.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. D2615ENR1

• Open the door only at the loading side to prevent contamina-
tion at the clean side.
• In case the machine is provided with tilting functionality,
when activating the tilting function or unload rotation, stands
always sideways of the machine. During unload rotation do
not attempt to pull the linen out, it comes out of the drum by
itself. Avoid access of any person in the front or behind the
machine during its tilting action.
• Loading door MUST BE CLOSED any time the washer is to
fill, tumble or spin. DO NOT bypass the loading door switch
by permitting the washer to operate with the loading door
open. Do not attempt to open the door until the washer has
drained and all moving parts have stopped.
• To reduce the risk of burning, do not touch the door glass
when the machine is running, especially after the heating
phase of the wash cycle.
• Do not attach anything to the supply dispenser’s nozzles, if
applicable. The air gap must be maintained.
• To avoid machine corrosion and component failure, do not
use corrosive chemicals in the washer-extractor. Warranty
claims related to damage caused by corrosive chemicals will
be denied.
• Do not operate the machine without the water reuse plug or
water reuse system in place, if applicable.
• Be sure water connections have a shut-off valve and that fill
hose connections are tight. CLOSE the shut-off valves at the
end of each wash day.
• Keep washer in good condition. Bumping or dropping the
washer can damage safety features. If this occurs, have wash-
er checked by a qualified service person.
• DANGER: Before inspecting or servicing machine, power
supply must be turned OFF. The servicer needs to wait for at
least 3 minutes after turning the power OFF and needs to
check for residual voltage with a voltage meter. The inverter
capacitor or EMC filter remains charged with high voltage for
some time after powering OFF. This is an imminently hazard-
ous situation that, if not avoided, will cause severe personal
injury or death.
• Do not repair or replace any part of the washer, or attempt any
servicing unless specifically recommended in the user-mainte-
nance instructions or in published user-repair instructions that
the user understands and has the skills to carry out. ALWAYS
disconnect the washer from electrical, power and water sup-
plies before attempting any service.
• Disconnect the power cord by grasping the plug, not the cord.
Replace worn power cords and/or loose plugs. If the supply
cord is damaged, it must be replaced by a special cord or as-
sembly available from the service agent.
• Before the washer is removed from service or discarded, re-
move the door to the washing compartment.
• Failure to install, maintain, and/or operate this washer accord-
ing to the manufacturer’s instructions may result in conditions
which can produce bodily injury and/or property damage.
• The use of hypochlorite will cause corrosion which may cause
component failure under certain circumstances.
• The warranty of the machine cannot be accepted in case cor-
rosion was caused by chlorine and chlorine compounds im-
pact.
•CAUTION
Machines referred to by model in this manual are
NOT intended for domestic use by private con-
sumers in the home environment as well as used
by the general public such as vended or similar
applications. Machines referred to by model in
this manual are designed and intended for use in
industrial laundry premises, which includes ho-
tels, hospitals, nursing homes, prisons and simi-
lar premises. These machines must be operated
by skilled or trained personnel.
NOTE: The WARNINGS and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
washer.
Always contact your dealer, distributor, service agent or the man-
ufacturer on any problems or conditions you do not understand.
NOTE: ll appliances are produced according the EMC-
directive (Electro-Magnetic-Compatibility). They can be
used in restricted surroundings only (comply minimally
with class A requirements). For safety reasons there
must be kept the necessary precaution distances with
sensitive electrical or electronic device(s). These ma-
chines are not intended for domestic use by private
consumers in the home environment.
Safety Precautions
WARNING
Save these instructions for later use. Failure to com-
ply with the instructions may lead to incorrect use of
the appliance, and may result in risk of fire, bodily in-
juries or death and/or damage to the laundry and/or
the appliance.
C003
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. D2615ENR1

WARNING
Read the important safety instructions in this manual
carefully before operating the appliance. Improper
use of the appliance may cause risk of fire, electrical
shock or serious body injuries or death as well as
serious damage to the appliance.
C244
• Follow the instruction written in manuals and keep the man-
uals in a proper place by the machine for later use.
• Safety instructions included in manuals for personnel operat-
ing the appliance must be printed and posted on a visible
place near the machine in the laundry room.
• The washer extractor is designed for fabrics washing only,
other objects can damage the washer and can cause damage or
injuries.
• If the machine is used for special applications follow the in-
structions and warning to avoid person injury.
• The manufacturer is not responsible for the damage to the
fabrics that are washed by an inappropriate washing method.
• Always follow the instructions and/or warnings that are stated
on the fabrics, washing products or cleaning products men-
tioned by the manufacturer.
• The washer must be set up in accordance with the instruc-
tions. All drain, inlet, electrical connections, ventilation,
groundings and other connections must be done in according
to the installation manual, in compliance with the local stand-
ards done by qualified technicians with proper authorization.
• The valid standards for connecting to the local power network
(TT,TN,IT,…) must be followed. In the standard execution,
the appliance may not be suitable for connecting to an IT sup-
ply system. Contact your commercial distributor for assis-
tance.
• All appliances are produced according the EMC-directive
(Electro-Magnetic-Compatibility). They can be used in re-
stricted surroundings only (comply minimally with class A re-
quirements). For safety reasons there must be kept the neces-
sary precaution distances with sensitive electrical or electron-
ic device(s). These machines are not intended for domestic
use by private consumers in the home environment.
• Do not change the parameters of the frequency inverter. This
can cause serious injury, fire, washer damage, etc.
• During transportation and storage never use excessive forces
on the packing because components can be damaged protrud-
ing the contour line of the appliance.
• Use copper conductors only. This appliance must be connec-
ted to a supply circuit to which no lighting units or general-
purpose receptacles are connected.
• Any changes concerning the installation which are not descri-
bed in this Installation Manual must be approved by the sup-
plier or manufacturer. Otherwise, the supplier and manufac-
turer are not responsible for potential injuries to operators or
for any damages. Interventions in the appliance execution or
functions are not allowed, and the manufacturer refuses any
responsibility in such cases.
• The washer extractor must be installed on level. If not, the
washer may become unbalanced during extraction and, al-
though fitted with an unbalance safety, the washer may be-
come seriously damaged what may result in bodily injuries.
• Never put the washer in operation when the transporting bra-
ces are not removed. The washer should always be tested be-
fore use.
• It is possible that there are residues of products used during
the production process in the new washer. These residues
could cause stains on your laundry. Therefore, you must first
run at least 1 hot wash with old rags before using for your
normal laundry.
• Keep the appliance top and surface and the area around clean
and clear of combustible or flammable products.
• The use of hypochlorite will cause corrosion which may cause
component failure under certain circumstances.
• The warranty of the machine cannot be accepted in case cor-
rosion was caused by chlorine and chlorine compounds im-
pact.
• The washer extractor is not designed for work which may cre-
ate an explosive atmosphere inside the machine and will not
be used for this purpose.
• Do not expose the washer extractor to the weather, extreme
low or high temperature and humidity.
• Do not store flammable materials around the appliances. De-
fine the dangerous areas in the laundry room and obstruct an
admission to them during appliances operating.
• Do not wash articles that have been previously cleaned in,
wash in soaked in, or spotted with gasoline, dry-cleaning sol-
vents, or other flammable or explosive substances as they
give off vapors that could ignite or explode. Such fabrics must
first be washed by hand and air dried.
• Do not add gasoline, dry-cleaning solvents, or other flamma-
ble or explosive substances to the wash water. These substan-
ces give off vapors that could ignite or explode.
• TEMPERATURE IN WASHING MACHINE TUB: The elec-
tronic controller uses the temperature sensor in the tub to con-
trol the temperature of the washing bath. There are a lot of
things that have influence on the temperature measurement.
Therefore the temperature control of the washing bath is not
very precise.
• Always strictly comply with the instructions that are written
on the laundry chemicals-, laundry aids-, dry-cleaning sol-
vents- and disinfectants packaging to avoid personal injury.
• Do not tamper the washer-extractor controls and do not by-
pass the safety instructions and the warnings.
• By danger turn off the main switch or other emergency dis-
connection devices.
• Do not put some part on the soap dispenser lid to held it open
by filling or when the machine operates.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. D2615ENR1

• Do not operate the appliance when parts are broken or miss-
ing or when covers are open. The appliance must not be oper-
ated until the fixed guards are put correctly in place.
• The appliance must not be stored, installed or exposed to the
weather, extreme low or high temperature and humidity lev-
els. Do not hose down the washer. NEVER allow the appli-
ance to get wet. Avoid damp conditions where water or mois-
ture could run down the walls and covers of the washer or
cover the floor around the washer. Do not install the washer
above an open gutter. Close any nearby gutters so that waste
water steam cannot collect near/inside the washer.
• Check the functioning of the door lock mechanism on regular
base. NEVER bypass the doorlock mechanism.
• To avoid premature bearing failure, do not operate the ma-
chine while the basket is empty.
• Disconnect the power and close all water and steam supply
before cleaning, servicing and at the end of each operating
day.
• Vapour or hot air can escape out of the venting. Do not cover
the vent but protect it sufficiently. It serves air gap and as a
vapor outlet to prevent pressure building in the washer.
• Do not repair or replace any part of the appliance or attempt
any servicing unless specifically recommended in the service
manual or published user-repair instructions that you under-
stand and have the skills to carry out. Only qualified service
personnel may open the appliance to carry out servicing.
• Information contained in this manual is intended for use by a
qualified service technician familiar with proper and safe pro-
cedures to be followed when repairing an electrical appliance.
All tests and repairs should be performed by a qualified serv-
ice technician equipped with proper tools and measuring devi-
ces. All component replacements should be made by a quali-
fied service technician using only factory approved replace-
ment parts.
• Improper assembly or adjustment may occur if service or re-
pair is attempted by persons other then qualified service tech-
nicians or if parts other then approved replacement parts are
used. Improper assembly or adjustment can create hazardous
conditions.
• There can be a risk of injury or electrical shock while per-
forming services or repairs. Injury or electrical shock can be
serious or even fatal. Consequently, extreme caution should
be taken while performing voltage checks on individual com-
ponents or a product. PLEASE NOTE: Except as necessary to
perform a particular in servicing a product, the electrical pow-
er supply should ALWAYS be disconnected when servicing a
product.
• All industrial (OPL - On Premise Laundry) washers are de-
signed for use in Laundry with professionally trained attend-
ants.
• Before the appliance is removed from service or discarded,
remove the door.
• Any Water or Steam Leaks Must Be Repaired Immediately.
Closed supply immediately.
• If any problems or failures should arise, immediately contact
your dealer, serviceman or manufacturer.
• The manufacturer reserves the right to change the manuals
without previous notice.
• Norm IEC335 is applied for machines with a net usable cage
volume between 60 and 150 l. Norm EN60204-1 is used for a
net usable cage volume above 150 l.
WARNING
If the installed appliance operate with coin, token or
similar operation for use in self-service situations,
then the owner-installer must provide a remote-loca-
ted emergency stop device. This device must be
placed in such a way that it is easy and safely acces-
sible for the users. The emergency stop device takes
care that at least the control circuit of the appliance
is interrupted.
C004
WARNING
Do not touch the doorglass until cycle has been
completed. Do not open door until cylinder remains
stopped and water has been drained from cylinder.
Do not put articles soiled with explosive solvents
and/or dangerous chemical products in the machine.
This machine should not be used by children. Do not
let children play in, on, or around the machine. Be-
fore turning the machine “on”, make sure that there
are no people or animals present in or around the
machine.
C005
WARNING
Original or identical parts must be used for replace-
ment in this machine. After servicing replace and se-
cure all panels in the original way. Take these meas-
ures for continued protection against electrical
shock, injury, fire and/or property damage.
C007
WARNING
Looking at the machine from the front, drum rotation
during extraction must be clockwise.
C008
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. D2615ENR1

WARNING
This appliance must be connected to a grounded
metal, permanent wiring system, and additionally an
equipment-grounding conductor must be run with
the circuit conductors and connected to the equip-
ment-grounding terminal or lead on the appliance.
C180
WARNING
In order to minimize the risk of fire, electrical shock
and injury, THIS WASHER MUST BE PROPERLY
GROUNDED. Never plug in or direct-wire an appli-
ance unless it is properly grounded in accordance
with all local and national codes.
If more appliances in the same location, mutual
grounding must be applied where possible.
C181
WARNING
Although the appliance may be in the “off” position,
there is still electrical power to the switch supply ter-
minals.
C186
WARNING
When power supply has been switched off wait for at
least 10 minutes before starting inspection or servic-
ing the washer. Before starting inspection of fre-
quency inverter, check for residual voltage across
main circuit terminals + and -. This voltage must be
below 30 VDC before you can access the inverter for
inspection.
C187
WARNING
Do not allow children to play on, in or around the ap-
pliance at any time. Close supervision of children.
C188
WARNING
If the door safety lock does not work, do not use
washer until the door lock mechanism is repaired.
C226
WARNING
Follow all valid basic safety rules and laws. The in-
structions in this manual cannot account for every
possible dangerous situation. They must be general-
ly understood. Caution and care are factors which
can not included in the design of the appliance and
all persons who install, operate or maintain the appli-
ance must be qualified and familiar with the operat-
ing instructions. It is up to the user to take proper
care when operating the appliance.
C227
WARNING
Do not remove warning signs placed on the appli-
ance. Observe signs and labels to avoid personal in-
juries. Safety labels appear at crucial locations on
the appliance. Failure to maintain legible safety la-
bels could result in injury to the operator or service
technician.
C228
CAUTION
Machine with weighing system: never carry load sen-
sors by their cables! Avoid electric welding near the
load sensors! An impact might cause permanent
damage to the load sensors! Avoid unequal load dis-
tribution between the load sensors when putting the
machine down. When the power of the machine is
switched on, the system needs a 10-minutes warm-
up time. This is important when the power has been
off for more than five minutes. Ignoring warm-up
might result in a major error in weighing.
C229
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. D2615ENR1

WARNING
The recycling tank must be installed by qualified and
authorised technicians only. The installation must be
done in accordance with all local standards and reg-
ulations.
C230
WARNING
Never interfere with the setting of the door handle.
Never try to modify the setting or repair the handle!
Any interference with its setting may lead to serious
risk for the operator! A damaged or incorrectly func-
tioning door handle must always be immediately re-
placed with a new original part.
C014
IMPORTANT: Before each wash cycle verify that ALL
plastic soap dispenser cups are in the correct position
in the Soap Dispenser even if they are not programmed
or/and used, independently of the selected wash pro-
gram. Before each wash cycle, verify if the Soap Dis-
penser lid is closed rigidly. Do not use the Soap Dis-
penser Cups for something else than for what they are
intended.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. D2615ENR1

Introduction
Model Identification
Information in this manual is applicable to these models:
Models
WB360B WB500B WB2x350B
IMB500_EVOLIS_ELITE IMC500V PMC500V SMC500V UMC500V
IMB700_EVOLIS_ELITE IMC700V PMC700V SMC700V UMC700V
MXB360_X_CONTROL_FLEX_PLUS IMM360V PMM360V SMM360V UMM360V
MXB500_X_CONTROL_FLEX_PLUS IMM500V PMM500V SMM500V UMM500V
MXB700_X_CONTROL_FLEX_PLUS IMM700V PMM700V SMM700V UMM700V
SMB360_QUANTUM_TOUCH IMU360V PMU360V SMU360V UMU360V
SMB500_QUANTUM_TOUCH IMU500V PMU500V SMU500V UMU500V
SMB700_QUANTUM_TOUCH IMU700V PMU700V SMU700V UMU700V
UMB360_UNILINC_TOUCH IMY360V PMY360V SMY360V UMY360V
UMB500_UNILINC_TOUCH IMY500V PMY500V SMY500V UMY500V
UMB700_UNILINC_TOUCH IMY700V PMY700V SMY700V UMY700V
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. D2615ENR1

Serial Plate Location
1. Serial plate Location
Figure 1
The serial plate is located on the side of the machine and on the
frame inside the machine.
Software Identification
1. From the System Menu, select to enter the Diagnostics
Figure 2
2. From the Diagnostics, select Machine ID.
The display includes Front-End Control Software Version and I/O
Board Software version.
Figure 3
Always provide the machine serial number, model type and
Front-End Control Software Version and I/O Board Software ver-
sion when ordering parts or when seeking technical assistance.
Manufacturing Date
The manufacturing date for your unit can be found on the serial
number. The last two characters indicate first the year and then
the month. Refer to Table 1 and Table 2 . For example, a unit with
serial number 520I000001QK was manufactured in May 2020.
Manufacturing Date - Year
Year Serial Number Character
2020 Q
2021 S
2022 U
2023 W
2024 Y
Table 1
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. D2615ENR1

Manufacturing Date - Month
Month Serial Number Character
January A or B
February C or D
March E or F
April G or H
May J or K
June L or M
July N or Q
August P or S
September R or U
October T or W
November V or Y
December X or Z
Table 2
Delivery Inspection
Upon delivery, visually inspect crate, protective cover, and unit
for any visible shipping damage. If signs of possible damage are
evident, have the carrier note the condition on the shipping pa-
pers before the shipping receipt is signed, or advise the carrier of
the condition as soon as it is discovered.
Replacement Parts
If literature or replacement parts are required, contact the source
from which the machine was purchased or contact Alliance Laun-
dry Systems at [phone] for the name and address of the
nearest authorized parts distributor.
Customer Service
For technical assistance, contact your local distributor or contact:
Alliance Laundry Systems
Shepard Street
P.O. Box 990
Ripon, Wisconsin 54971-0990
U.S.A.
www.alliancelaundry.com
Phone: [phone]
Ripon, Wisconsin
or
Alliance Laundry CE s.r.o
Mistecka 1116
Pribor, 742 58
Czech Republic Europe
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. D2615ENR1

Specification and Dimensions
General Specifications
Machine kg / L 36 / 360 50 / 500 70 / 700
Weight and Shipping Dimensions
Net weight, lb [kg] 2116 [960] 2491 [1130] 2888 [1310]
Shipping weight, lb [kg] 2403 [1090] 2822 [1280] 3241 [1470]
Shipping height, in. [mm] 78.94 [2005] 78.94 [2005] 78.94 [2005]
Shipping width, in. [mm] 60.24 [1530] 72.05 [1830] 90.15 [2290]
Shipping depth, in. [mm] 49.41 [1255] 49.41 [1255] 49.41 [1255]
Dimensions (Standard) Refer to Table 4 Refer to Table 5
Inner Drum Dimensions
Type of drum Standard Standard 2 Standard Drums
Pullman Pullman
Number of chambers Standard: 1 Standard: 1 1
Pullman: 2 Pullman: 2
Volume, ft3 [l] 12.71 [360] 17.66 [500] 24.72 [700]
Depth, in. [mm] 30.08 [764] 41.73 [1060] 2 x 29.21 [2 x 742]
Diameter, in. [mm] 30.51 [775] 30.51 [775] 30.51 [775]
Drive Train Information
Motor size, HP [kW] 5.36 [4] 10.06 [7.5] 10.06 [7.5]
Drum Speed
Wash, (RPM) 41 41 41
Extraction, (RPM) 900 900 900
G-Factor 350 350 350
Heating
Hot water, °F [°C] 194 [90]
Electrical, (kW) 36 48 60
Minimum and Maximum Steam pres-
sure, PSI [bar]
15 - 116 [1 - 8]
Connection
Water valves connection, BSP male,
(in.)
3 x 1, DN25
Table 3 continues...
Specification and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. D2615ENR1

Machine kg / L 36 / 360 50 / 500 70 / 700
Inlet flow capacity per inlet, gal/min
at 14.5 PSI [l/min. at 1 bar]]
48.3 [183]
Inlet flow capacity per inlet, gal/min
at 87 PSI [l/min at 6 bar]
118.6 [449]
Minimum and Maximum Water pres-
sure, PSI [bar]
15 - 87 [1 - 6]
Recommended water pressure, PSI
[bar]
43.5 - 72.5 [3 - 5]
Drain valve, outer ø in. [mm] 2x 3 [76]
Flow amount with drain valve, (l/
min)
2 x 210
Steam valve connection - inlet, BSP
male, (in.)
3/4 DN20
Steam outlet connection (Steam Ex-
changer - optional), used for Indirect
Steam Heating option if selected,
BSP male, (in.)
1/2 DN12 N/A
Noise Emissions
Wash sequence, dB 43.9 49.7 47.8
Extract sequence, dB 68 69.9 69
Wash sequence, isolation for energy
and noise reduction, dB
42.6 43.6 47.4
Extract sequence, isolation for energy
and noise reduction, dB
64.9 67.8 67.2
Floor Load Data
Maximum static load on floor, lbf
[kN]
2774.14 [12.34] 3450.81 [15.35] 4325.32 [19.24]
Maximum dynamic load on floor, lbf
[kN]
2115.45 ± 535 [9.41 ± 2.38] 2526.85 ± 696.90 [11.24
± 3.10]
2965.23 ± 991.40 [13.19
± 4.41]
Frequency of dynamic load, (Hz) 15 15 15
General Data
Ambient temperature, °F [°C] 41-95 [5-35]
Relative humidity 30% to 90% without condensation
Height above sea level, ft [m] to 3281 [1000]
Storage temperature and shipment, °F
[°C]
34-131 [1-55]
Table 3
Specification and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. D2615ENR1

Machine Dimensions
36 kg / 360 L and 50 kg / 500 L Models Loading Side (Dirty Side)
1. Emergency Stop
2. Control Panel
3. Drain Outlet Bottom (optional)
4. Drain Outlet Side (optional)
5. Water Tap
6. Soap Hopper
7. Steam Outlet Connection (Steam Exchanger (optional) - used for Indirect Steam Heating option if selected), 36 kg / 360 L Mod-
els
8. T and U - Load Insertion opening dimensions refer to Table 4
Figure 4
Specification and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. D2615ENR1
