Alliance Laundry Systems CPD6C Installation and operation manual

Operation/Maintenance
www.comlaundry.com
Washer-Extractors
Cabinet Freestanding
Refer to Page 3 for Model Identification
CFD6C
Part No. 9001001R4
April 2007
KeepTheseInstructionsforFutureReference.
(If this machine changes ownership, this manual must accompany machine.)
Para bajar una copia de estas instrucciones
en español, visite www.comlaundry.com.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2007, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
9001001 1
Table of
Contents
Introduction......................................................................................... 3
Model Identification ............................................................................. 3
Nameplate Location.............................................................................. 5
Replacement Parts ................................................................................ 5
Customer Service.................................................................................. 5
SafetyInformation.............................................................................. 7
Explanation of Safety Messages........................................................... 7
Important Safety Instructions ............................................................... 7
PreliminaryInformation.................................................................... 9
About the Control ................................................................................. 9
Power Failure Recovery ....................................................................... 9
Control Identification............................................................................ 10
Operation............................................................................................. 11
Load the Machine ................................................................................. 11
Start a Program ..................................................................................... 12
Special Options in Run Mode............................................................... 13
Advance Mode...................................................................................... 13
Chemical Hold Feature ......................................................................... 13
Stop the Machine .................................................................................. 14
Error Messages ..................................................................................... 15
Maintenance........................................................................................ 19
Daily ..................................................................................................... 19
Weekly.................................................................................................. 20
Monthly................................................................................................. 20
Yearly ................................................................................................... 21
Daily Preventive Maintenance Checklist.............................................. 22
Weekly Preventive Maintenance Checklist.......................................... 23
Monthly Preventive Maintenance Checklist......................................... 24
Yearly Preventive Maintenance Checklist............................................ 25

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
29001001
Notes

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
9001001
Introduction
Model Identification
Information in this manual is applicable to these
models:
18
HX18PVQM6 SX18PVQM6 UX18PVNA6 HX18PVQU6 SX18PVQU6 UX18PVNU6
HX18PVQM7 SX18PVQM7 UX18PVNA7 HX18PVXU6 SX18PVXU6 UX18PVPU6
HX18PVXM6 SX18PVXM6 UX18PVPA6 UX18PVQU6
HX18PVXM7 SX18PVXM7 UX18PVPA7 UX18PVXU6
UX18PVQA6
UX18PVQA7
UX18PVQM6
UX18PVQM7
UX18PVXA6
UX18PVXA7
UX18PVXM6
UX18PVXM7
25
HX25PVQM6 SX25PVQM6 UX25PVNA6 HX25PVQU6 SX25PVQU6 UX25PVNU6
HX25PVQM7 SX25PVQM7 UX25PVNA7 HX25PVXU6 SX25PVXU6 UX25PVPU6
HX25PVXM6 SX25PVXM6 UX25PVPA6 UX25PVQU6
HX25PVXM7 SX25PVXM7 UX25PVPA7 UX25PVXU6
UX25PVQA6
UX25PVQA7
UX25PVQM6
UX25PVQM7
UX25PVXA6
UX25PVXA7
UX25PVXM6
UX25PVXM7
35
HX35PVQM6 SX35PVQM6 UX35PVNA6 HX35PVQU6 SX35PVQU6 UX35PVNU6
HX35PVQM7 SX35PVQM7 UX35PVNA7 HX35PVXU6 SX35PVXU6 UX35PVPU6
HX35PVXM6 SX35PVXM6 UX35PVPA6 UX35PVQU6
HX35PVXM7 SX35PVXM7 UX35PVPA7 UX35PVXU6
UX35PVQA6
UX35PVQA7
UX35PVQM6
UX35PVQM7
UX35PVXA6
UX35PVXA7
UX35PVXM6
UX35PVXM7
continued

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
9001001
4
continued
55
HX55PVNU6 SX55PVNU6 UX55PVNU6
HX55PVNU7 SX55PVNU7 UX55PVNU7
HX55PVQU6 SX55PVPU6 UX55PVPU6
HX55PVQU7 SX55PVPU7 UX55PVPU7
HX55PVXU6 SX55PVQU6 UX55PVQU6
HX55PVXU7 SX55PVQU7 UX55PVQU7
SX55PVXU6 UX55PVXU6
SX55PVXU7 UX55PVXU7
75
HX75PVNU6 SX75PVNU6 UX75PVNU6
HX75PVNU7 SX75PVNU7 UX75PVNU7
HX75PVQU6 SX75PVQU6 UX75PVPU6
HX75PVQU7 SX75PVQU7 UX75PVPU7
UX75PVQU6
UX75PVQU7
100
HX100PVNU6 SX100PVNU6 UX100PVNU6
HX100PVNU7 SX100PVNU7 UX100PVNU7
HX100PVQU6 SX100PVQU6 UX100PVPU6
HX100PVQU7 SX100PVQU7 UX100PVPU7
UX100PVQU6
UX100PVQU7
135
HX135PVNU6 SX135PVNU6 UX135PVNU6
HX135PVNU7 SX135PVNU7 UX135PVNU7
HX135PVQU6 SX135PVQU6 UX135PVPU6
HX135PVQU7 SX135PVQU7 UX135PVPU7
UX135PVQU6
UX135PVQU7
165
HX165PVNU6 SX165PVNU6 UX165PVNU6
HX165PVNU7 SX165PVNU7 UX165PVNU7
HX165PVQU6 SX165PVQU6 UX165PVPU6
HX165PVQU7 SX165PVQU7 UX165PVPU7
UX165PVQU6
UX165PVQU7

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
5
9001001
Nameplate Location
The nameplate is located at the rear of the machine.
Always provide the machine’s serial number and
model number when ordering parts or when seeking
technical assistance.
Figure 1
Replacement Parts
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
Customer Service
For technical assistance, call [phone].
CFD6C
1Nameplate
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
9001001
6
* Denotes Brand
Model Number Familiarization Guide
Sample Model Number: *X55PVXM60001
*X Model Number Prefix
55 Washer-Extractor Capacity (pounds dry weight of laundry)
PType of Electrical Control (P = WE-6 Computer)
VWasher-Extractor Speed Capabilities
XElectrical Characteristics
M6 Design Series
0001 Option Identification (varies from machine to machine)
CFD29N
Figure 2
CFD29N
X55PVXM60001
12
55 25
50 60
15
2/3+PE 1/3
1000
*
EXAMPLE OF NAMEPLATE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 7
9001001
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and
those maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT:Theword“IMPORTANT”isused
toinformthereaderofspecificprocedureswhere
minormachinedamagewilloccuriftheprocedure
isnotfollowed.
NOTE:Theword“NOTE”isusedtocommunicate
installation,operation, maintenanceor servicing
informationthatisimportantbutnothazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, or other
flammable or explosive substances as they give
off vapors that could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable, do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
This appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
9001001
8
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power source.
13. Use washer only for its intended purpose,
washing textiles.
14. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
15. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
16. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
17. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
18. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a qualified
service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
21. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT
bypass the loading door switch by permitting the
washer to operate with the loading door open.
22. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
23. Always follow the fabric care instructions
supplied by the textile manufacturer.
24. Never operate the washer with any guards and/or
panels removed.
25. DO NOT operate the washer with missing or
broken parts.
26. DO NOT bypass any safety devices.
27. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE:TheWARNINGSandIMPORTANT
SAFETYINSTRUCTIONSappearinginthis
manualarenotmeantto coverallpossible
conditionsandsituationsthatmayoccur.Common
sense,cautionandcaremustbeexercisedwhen
installing,maintaining,oroperatingthewasher.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
9001001
Preliminary Information
About the Control
WE-8 computer on the washer-extractor is an
advanced, programmable computer that allows the
owner to create wash programs.
The control is factory set-up with 42 pre-programmed
cycles and is ready for operation. Refer to Pre-
Programmed Cycles section in the Programming
manual.
WE-8 allows the owner to program custom cycles on
the machine or with a PC and the Alliance planner
software.
IMPORTANT:Intheeventofapowerfailure,
WE-8willnothavetobereprogrammed.It is
designedwithamemorysystemthatwillremember
howitwasprogrammeduntiltheelectricalpower
isrestored.
Power Failure Recovery
If a cycle is in process and the power fails, cycle status
is saved in memory without power being applied.
If power resumes, the control will enter into the Start
Mode at the beginning of the cycle step where the
power failed.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Preliminary Information
9001001
10
Control Identification
Figure 3
M172
1Keypad 4Key Switch
2Display 5Serial Port
3Emergency Stop Button

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 11
9001001
Operation
Load the Machine
For 18 - 75 models:
Push the black button and pull the door handle towards
you to open the door.
Load the drum to the specified capacity.
Close the door by pushing the door handle towards the
machine.
For 100 - 165 models:
Push on the doorlock system to open the door.
Load the drum to the specified capacity.
Close the door by pushing the door handle towards the
machine.
M179A
Figure 4
M179B
Figure 5
CFD63N
Figure 6
CFD64N
Figure 7

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
9001001
12
Start a Program
After powering up the control, “Cycle 00” will show
on the display.
Press the desired program number
(example: program 23).
The display will show the cycle (example: “Cycle
23”).
Press “Start” to run the program.
If the program does not exist, the display will show
“No Cycle 23”. See program mode to create a
program.
If the door is not closed, the display will show “Please
close door”. After closing the door the program will
start.
If the door is closed and the program exists, the
program will start. The name of the program will show
on the display for 2 seconds and the machine will start.
When the machine is started the display will show the
following information.
S01: Step 1
C23: Program number 23
0:04:59: The time of step 1. This will count down to
0 and then go to step 2 (S02).
80°F: The temperature of the bath that is
programmed.
High: The water level in step 1 that is
programmed.
Cycle 00
Cycle 23
No Cycle 23
Please close
door
Restaurant 2
S01 C23 0:04:59
80°F High

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
13
9001001
Special Options in Run Mode
While the machine is running press the “Display
Temp” button.
Level: 2.5 cm: Water level in the bath. If the
machine is filling with water this value will
increase. If in a drain step this value will
decrease.
62°F: The water temperature.
40rpm: The measured rpm of the drum.
L: Rotation direction of the drum
L (left), R (right)
Press the “Display Temp” button to go back.
Advance Mode
Press the “Advance” button to proceed to the next step
in the progam.
Chemical Hold Feature
Chemical supply injection can be paused. Refer to
section Setup of the Chemical Hold Feature in
Programming manual.
S01 C23 0:04:59
80°F High
S01 C23 0:04:59
80°F High
Level : 2.5 cm
62°F 40rpm L

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
9001001
14
Stop the Machine
Press the Stop button.
If there is water in the machine the display will show
“Waterlevel xx.x cm” while the machine is draining
the water.
If the machine is spinning the display will show
“Coast down”.
When the water is out and the drum has stopped
moving the display will flash between “Please open
door” and “Done cycle 23” until the door is open.
S01 C23 0:04:00
Spin 1
Done Cycle 23
Waterlevel
10.2 cm
Coast down
Please open door

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
15
9001001
Error Messages
DoorError
If the door is closed after start the control will try to
lock the door. If the door will not lock “Door error”
will display.
Possible Faults:
●Wiring is not connected properly.
●Coil to lock the door has failed.
●Mechanical problem on the door lock.
FillAlarm
If machine does not reach programmed water level
within time programmed for step, a fill alarm occurs.
Machine will continue filling and agitating, while
sounding beeper and flashing “Didn’t fill within time”
on display.
Condition will continue for up to two (2) minutes. If
programmed water level is reached before two minute
fill alarm time ends, condition ends, and machine
resumes operation. If Enter key is pressed during fill
alarm, condition will end and step will start over. If
programmed water level is not reached within
programmed step time, fill alarm will occur again. If
Clear (STOP) key is pressed while fill alarm is in
effect, cycle will end, and door will unlock. If no
action is taken, and fill level is not reached within
two minute alarm time limit, cycle will end and door
can be unlocked (provided no water level is sensed).
Whenever a fill alarm occurred during a cycle, display
will repeat following messages at end of stop routine,
before door is opened, to indicate alarm condition
occurred in cycle.
Door error
Enter to retry
Clear to stop
Didn’t fill
within time
Done Cycle CC
Please open door
During step N
Didn’t fill
within time
(CC = cycle number;
N = step number in which the
alarm occurred).

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
9001001
16
FillAlarm(Continued)
Possible Faults:
●Wiring is not connected properly to the inlet
valves.
●The inlet valve is broken.
●There is a problem with the water supply.
●The inlet valves are blocked by dirt.
●The water pressure hose is broken or not
connected properly.
DrainAlarm
If drain step is NOT followed by a spin and if machine
does not empty within the time programmed for drain
step, a drain alarm occurs. Display will read “Didn’t
drain within time.”
During drain alarm, beeper sounds on and off, and
machine continues attempting to drain. If machine
does not empty, condition continues. If Enter key is
pressed, drain alarm ends, and drain step starts over at
beginning. If machine has not emptied when drain step
time expires, alarm occurs again. If Clear (STOP) key
is pressed while drain alarm is in effect, display shows
water level (inches or centimeters), but otherwise takes
no new action since machine has not emptied.
When cycle ends, display repeats following messages
briefly until door is opened (to indicate that an alarm
condition occurred in the cycle):
If machine drains during a spin step prior to
accelerating into high speed and if machine has not
emptied within approximately 2 minutes of starting
drain procedure, a drain alarm occurs. There is no
rotation during this alarm; messages displayed are
identical to drain alarm during a drain step not
followed by a spin. Pressing Enter (START) during
drain alarm in a spin step ends alarm and begins spin
step again at start, with machine rotating at wash speed
forward, then to distribution speed. After drain begins
(i.e., drain open, pumping begins), if 2 additional
minutes elapse, alarm occurs again.
Enter to retry
Clear to stop
Didn’t drain
within time
Done Cycle CC
Please open door
During step N
Didn’t drain
within time
(CC = cycle number;
N = step number in which the
alarm occurred).

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
17
9001001
If there was a problem during heating in a step at the
end of the program, the control will show
“Temperature sensor error”. The temperature was
never reached in this cycle.
Possible Faults:
●Bad temperature probe.
●Wiring to electrical or steam heating relay has
failed.
●Electrical heating elements or steam valve is
broken.
NOTE:Ifthe cycleaborted,itmaybeduetoa
temperaturesensorerror.
The control did not sense any pulses or the control
sensed wrong pulses from the rpm sensor.
Possible Faults:
●Rpm sensor is broken.
●Distance from rpm sensor to pulley is too large
(>2mm).
●Bad motor.
●V-belt is broken.
●Problems with the inverter.
●Wiring connection is bad.
An error occurred at the end of a spin stop or during
coast down, where the rpm sensor suddenly failed to
give output pulses.
Possible Faults:
●Rpm sensor failure.
●Rpm sensor dislocated (too far from pulley).
●Broken V-belt.
●Wiring disconnected.
Rotation
sensor error
Speed detection
error
Temperature
sensor error

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001
18
Notes
