Alliance Laundry Systems PHM798N User manual

Installation
www.comlaundry.com
Washer-Extractors
Pocket Hardmount
UniLinc and M30 Control
Refer to Page 8 for Model Numbers
PHM798N
PHM802N
PHM798N
PHM802N
M30 35 – 125 Models
UniLinc 35 – 125 Models
PHM1422C
PHM1422C
UniLinc 150 Model
Part No. F8138601R11
June 2011
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F8138601 1
Table of
Contents
Safety Information............................................................................. 2
Explanation of Safety Messages........................................................... 2
Important Safety Instructions ............................................................... 2
Safety Decals ........................................................................................ 4
Operator Safety..................................................................................... 5
Safe Operating Environment ................................................................ 6
Environmental Conditions ............................................................... 6
Machine Location ............................................................................ 6
Input and Output Services................................................................ 7
AC Inverter Drive ............................................................................ 7
Introduction......................................................................................... 8
Model Identification ............................................................................. 8
Delivery Inspection............................................................................... 9
Name plate Location............................................................................. 9
Nameplate Location - UniLinc Models ........................................... 9
Replacement Parts ................................................................................ 9
Customer Service.................................................................................. 9
Specifications and Dimensions........................................................... 11
Machine Dimensions ............................................................................ 15
UWTV Models Through 3/31/09 .................................................... 15
UW Design 1 and Design 2 Models
Starting 4/1/09 Through 10/3/10 ................................................... 18
UW Design 3 Models starting 10/4/10 ........................................... 21
Machine Foundation Requirements...................................................... 24
Concrete Foundation Pad Installation................................................... 25
Floor Load Data ............................................................................... 27
Mounting Bolt Installation Requirements ............................................ 30
Machine Mounting and Grouting..................................................... 31
Mounting Bolt Hole Locations ............................................................. 32
Grout Placement ................................................................................... 37
Gap Setting for Vibration Switch .................................................... 38
Drain Connection Requirements........................................................... 42
Water Connection ................................................................................. 44
Electrical Installation Requirements..................................................... 46
Steam Requirements (Steam Heat Option Only).................................. 51
Chemical Injection Supply System....................................................... 52
External Supplies .................................................................................. 55
Chemical Injection Using Internal 24VAC Control Transformer ... 56
Chemical injection Using External AC Power Source .................... 57
External Supply Signals................................................................... 58

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8138601
2
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas
is flammable, do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
3
F8138601
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power
source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a
qualified service person.
20. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
29. Do not attempt to open the door until the washer
has drained and all moving parts have stopped.
30. Do not climb onto or into the machine.
31. Be aware that hazardous chemicals may be
present.
32. Be aware that hot water is used to flush the
supply dispenser.
33. Wear hand and eye protection when adding
detergents and chemicals.
34. Avoid opening the dispenser lid while the
machine is running.
35. Do not attach anything to the supply dispenser’s
nozzles. The air gap must be maintained.
36. Use only low-sudsing, no-foaming types of
commercial detergent.
37. Do not operate the machine without the water
reuse plug or water reuse system in place.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8138601
4
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance are
provided. Never allow the inspection and
maintenance space to be blocked.
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage.
W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
F8138601
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8138601
6
Safe Operating Environment
Safe operation requires an appropriate operating
environment for both the operator and the machine. If
questions regarding safety arise, contact the
manufacturer immediately.
Environmental Conditions
Ambient Temperature. Water in the machine will
freeze at temperatures of 32°F (0°C) or below.
Temperatures above 104°F (40°C) will result in
more frequent motor overheating and, in some
cases, malfunction or premature damage to solid
state devices that are used in some models.
Special cooling devices may be necessary.
Water pressure switches are affected by increases
and decreases in temperature. Every 25°F (10°C)
change in temperature will have a 1% effect on
the water level.
Humidity. Relative humidity above 90% may
cause the machine’s electronics or motors to
malfunction or may trip the ground fault
interrupter. Corrosion problems may occur on
some metal components in the machine.
If the relative humidity is below 30%, belts and
rubber hoses may eventually develop dry rot.
This condition can result in hose leaks, which
may cause safety hazards external to the machine
in conjunction with adjacent electrical
equipment.
Ventilation. The need for make-up air openings
for such laundry room accessories as dryers,
ironers, water heaters, etc., must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the available air
opening significantly.
Radio Frequency Emissions. A filter is available
for machines in installations where floor space is
shared with equipment sensitive to radio
frequency emissions.
Elevation. If the machine is to be operated at
elevations of over 3280 feet (1000 m) above sea
level, pay special attention to water levels and
electronic settings (particularly temperature) or
desired results may not be achieved.
Chemicals. Keep stainless steel surfaces free of
chemical residues.
Water Damage. Do not spray the machine with
water. Short circuiting and serious damage may
result. Repair immediately all seepage due to
worn or damaged gaskets, etc.
Machine Location
Foundation. The concrete floor must be of
sufficient strength and thickness to handle the
floor loads generated by the high extract speeds
of the machine.
Service/Maintenance Space. Provide sufficient
space to allow comfortable performance of
service procedures and routine preventive
maintenance.
Consult installation instructions for specific details.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel
reducers, carbon tetrachloride, gasoline,
benzene, naptha, etc. Doing so could
result in serious personal injury and/or
damage to the machine.
SW002
DANGER
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any safety
devices.
SW019
CAUTION

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
7
F8138601
Input and Output Services
Water Pressure. Best performance will be
realized if water is provided at a pressure of 30 –
85 psi (2.0 – 5.7 bar). Although the machine will
function properly at lower pressure, increased fill
times will occur. Water pressure higher than 100
psi (6.7 bar) may result in damage to machine
plumbing. Component failure(s) and personal
injury could result.
Steam Heat (Optional) Pressure. Best
performance will be realized if steam is provided
at a pressure of 30 – 80 psi (2.0 – 5.4 bar). Steam
pressure higher than 125 psi (8.5 bar) may result
in damage to steam components and may cause
personal injury.
For machines equipped with optional steam heat,
install piping in accordance with approved
commercial steam practices. Failure to install the
supplied steam filter may void the warranty.
Drainage System. Provide drain lines or troughs
large enough to accommodate the total number of
gallons that could be released if all machines on
the site drained at the same time from the highest
attainable level. If troughs are used, they should
be covered to support light foot traffic.
Power. For personal safety and for proper
operation, the machine must be grounded in
accordance with state and local codes. The
ground connection must be to a proven earth
ground, not to conduit or water pipes. Do not use
fuses. An easy-access cutoff switch should also
be provided.
Always disconnect power and water supplies before a
service technician performs any service procedure.
Where applicable, steam and/or compressed air
supplies should also be disconnected before service is
performed.
AC Inverter Drive
Machines equipped with the AC inverter drive require
special attention with regard to the operating
environment.
An especially dusty or linty environment will
require more frequent cleaning of the AC inverter
drive cooling fan filter and of the AC inverter
drive itself.
Power line fluctuations from sources such as
uninterruptible power supplies (UPS) can
adversely affect machines equipped with the AC
inverter drive. Proper suppression devices should
be utilized on the incoming power to the machine
to avoid problems.
A clean power supply free from voltage spikes
and surges is absolutely essential for machines
equipped with the AC inverter drive. Nonlinear
inconsistencies (peaks and valleys) in the power
supply can cause the AC inverter drive to
generate nuisance errors.
The following conditions must be corrected:
input voltage above 240V or 480V, phase to
ground voltage exceeds 125% of normal line to
line voltage, or 240V open delta configuration
(stinger leg). Contact the distributor or the
manufacturer for assistance.
Sufficient space to perform service procedures
and routine preventive maintenance is especially
important for machines equipped with the AC
inverter drive.
Ensure that a ground wire from a proven
earth ground is connected to the ground
lug near the input power block on this
machine. Without proper grounding,
personal injury from electric shock could
occur and machine malfunctions may be
evident.
SW008
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8138601
8
Introduction
Model Identification
Information in this manual is applicable to these
models:
UW35TV UWL060K1L UWN035K1L UWN100K1M UWU060K1L
UW60TV UWL060K1M UWN035K1M UWN100T3V UWU060K1M
UW80TV UWL060T3L UWN035T3L UWN125K1M UWU060T3L
UW100TV UWL060T3M UWN035T3M UWN125K1V UWU060T3M
UW125TV UWL060T3V UWN035T3V UWN125T3V UWU060T3V
UW150TV UWL080K1M UWN060K12 UWN150T3V UWU080K1M
UWL035K12 UWL080T3V UWN060K1L UWU035K12 UWU080T3V
UWL035K1L UWL100K1M UWN060K1M UWU035K1L UWU100K1M
UWL035K1M UWL100T3V UWN060T3L UWU035K1M UWU100T3V
UWL035T3L UWL125K1M UWN060T3M UWU035T3L UWU125K1M
UWL035T3M UWL125T3V UWN060T3V UWU035T3M UWU125T3V
UWL035T3V UWL150T3V UWN080K1M UWU035T3V UWU150T3V
UWL060K12 UWN035K12 UWN080T3V UWU060K12

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
9
F8138601
This manual is designed as a guide to the installation
of the Pocket Hardmount washer-extractor.
NOTE: All information, illustrations, and
specifications contained in this manual are based
on the latest product information available at the
time of printing. We reserve the right to make
changes at any time without notice.
IMPORTANT: Warranty is void unless washer-
extractor is installed according to instructions in
this manual. Installation should comply with
minimum specifications and requirements, and
with applicable municipal building codes, water
supply regulations, electrical wiring regulations
and any other relevant statuary regulations. Due to
varied requirements, applicable local codes should
be thoroughly understood and all pre-installation
work arranged for accordingly.
Delivery Inspection
Upon delivery, visually inspect crate, protective cover,
and unit for any visible shipping damage. If the crate,
protective cover, or unit is damaged or signs of
possible damage are evident, have the carrier note the
condition on the shipping papers before the shipping
receipt is signed, or advise the carrier of the condition
as soon as it is discovered.
Remove the crate and protective cover as soon after
delivery as possible. If any damage is discovered upon
removal of the crate and/or protective cover, advise the
carrier and file a written claim immediately.
Name plate Location
The nameplate is located on the back of the machine.
Always provide the machine’s serial number and
model number when ordering parts or when seeking
technical assistance. Refer to Figure 1 and Figure 2.
Nameplate Location - UniLinc Models
On UniLinc models, nameplate information is also
programmed into the control. To access machine ID
through the control:
1. Press and hold , then , then
keypads at the same time.
2. Press the keypad until Diagnostic is
highlighted.
3. Press the keypad.
4. Press the keypad until machine ID is
highlighted.
5. Press the keypad.
Always provide the machine’s serial number and
model number when ordering parts or when seeking
technical assistance. Refer to Figure 1.
Figure 1
Replacement Parts
If literature or replacement parts are required, contact
the source from which the washer-extractor was
purchased or contact Alliance Laundry Systems LLC
at [phone] for the name of the nearest
authorized parts distributor. A parts manual may be
ordered by returning the reply card provided with each
washer-extractor.
Customer Service
For technical assistance, contact your local distributor
or call:
[phone]
Ripon, Wisconsin
A record of each washer-extractor is on file with the
manufacturer. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance. Refer to Figure 1
and Figure 2.
PHM798N
1In Control (UniLinc Models)
2At Back of Machine
2
MODEL EXAMPLE OF NAMEPLATE LOCATION
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
F8138601
10
Figure 2
Model Number Familiarization Guide - Models Through 3/31/09
Sample Model Number: UW60TVQU10001
UW Model Number Prefix
60 Washer-Extractor Capacity (60 pounds dry weight of laundry)
TType of Electrical Control T = UniLinc Control
VWasher-Extractor Speed Capabilities V = 8 Speeds
QElectrical Characteristics Refer to Table 10.
U1 Design Series
0001 Option Identification (varies from machine to machine)
Model Number Familiarization Guide - Models Starting 4/1/09
Sample Model Number: UWN060T3VXU1001
UW Model Number Prefix
NMarket Approvals
060 Washer-Extractor Capacity (60 pounds dry weight of laundry)
TType of Electrical Control T = UniLinc Control
3Spray/Dispenser Feature
VWasher-Extractor Speed Capabilities V = 8 Speeds
XElectrical Characteristics Refer to Table 10.
U1 Design Series
0Heat Feature
01 Option Identification (varies from machine to machine)
PHM769N
PHM769N
UWN060T3VXU1001
00000000000
200 – 240
319
HzHz PhasePhase
Supply Water:Supply Water: BARBAR
Number of wires :Number of wires : FLA :FLA : ampsamps
30
Circuit Breaker Size :Circuit Breaker Size : ampsamps
50-60 3
Serial No.Serial No.
Model No.Model No.
VoltageVoltage
60
30 - 85 psi, 2 - 5.7
Max. Load :Max. Load :
Schematic :Schematic :
KGKG
27
LBLB
EXAMPLE OF SERIAL PLATE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 11
F8138601
Specifications and Dimensions
.
UWTV Models Through 3/31/09
Specifications 35 60 80 100 125 150
Overall Dimensions
Overall width, in (mm) 32.5 (826) 36.625 (930) 41.5 (1054) 41.5 (1054) 48 (1219) 50.25 (1277)
Overall height, in (mm) 55.5 (1410) 64.5 (1638) 68.5 (1740) 68.5 (1740) 72 (1829) 79 (2007)
Overall depth, in (mm) 43.625 (1108) 45 (1143) 51.5 (1308) 54.5 (1384) 58 (1473) 63 (1600)
Weight And Shipping Information
Net weight, lb (kg) 1030 (468) 1300 (590) 1730 (785) 1770 (805) 2420 (1100) 2970 (1347)
Basket Weight, lb (kg) 150 (68) 200 (92) 330 (150) 360 (163) 550 (250) 572 (260)*
Domestic shipping weight, lb (kg) 1085 (493) 1340 (608) 1795 (814) 1835 (832) 2525 (1148) 3022 (1371)
Domestic shipping volume,
ft3(m3)
66 (1.9) 84 (2.4) 119 (3.4) 119 (3.4) 166 (4.7) 172 (4.87)
Domestic shipping dimensions,
WxDxH, in (mm)
38x47x64
(970x1200x
1630)
40x49x74.5
(1016x1245x
1892)
44x60.5 x77.25
(1118x1537x
1962)
44x60.5x77.25
(1118x1537x
1962)
61.5x60x77.75
(1560x1520x
1980)
54.5x69x79
(139x176x
201)
Export shipping weight, lb (kg) 1150 (522) 1464 (664) 1990 (903) 2030 (921) 2800 (1270) 3350 (1520)
Export shipping volume, ft3(m3) 78 (2.2) 96 (2.7) 134 (3.8) 134 (3.8) 184 (5.3) 220 (6.3)
Export shipping dimensions,
WxDxH, in (mm)
41x50x65.5
(1050x1280x
1670)
43x52.125x74.5
(1092x1324x
1892)
47x63.5x77.25
(1194x1613x
1962)
47x63.5x77.25
(1194x1613x
1962)
63.5x63x80
(1620x1610x
2030)
61.5x71x87
(1562x1804x
2210)
Wash Cylinder Information
Cylinder diameter, in (mm) 26.25 (667) 32 (813) 36 (914) 36 (914) 42 (1067) 43 (1093)
Cylinder depth, in (mm) 18.375 (467) 20 (508) 21 (533) 27 (686) 24 (610) 27.8125 (706)
Cylinder volume, ft3(l) 5.76 (163) 9.31 (264) 12.4 (350) 15.9 (450) 19.2 (544) 23.4 (662)
Perforation size, in (mm) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8)
Perforation open area, % 18 22 23 23 24 21.5
Door Opening Information
Door opening size, in (mm) 14.375 (365) 17.5 (445) 17.5 (445) 17.5 (445) 20 (508) 24.75 (629)
Height of door bottom above floor,
in (mm)
23.75 (603) 28.25 (718) 29 (737) 29 (737) 29 (737) 32 (813)
Drive Train Information
Numberofmotorsindrivetrain111111
Drive motor power, hp (kW) 5.0 (3.7) 5.0 (3.7) 7.5 (5.6) 7.5 (5.6) 10 (7.5) 10 (7.5)
* Basket Only

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
F8138601
12
UWTV Models Through 3/31/09 (Continued)
Specifications 35 60 80 100 125 150
Cylinder Speeds / Centrifugal Force Data
1/2 Wash/reverse, rpm (g) 26 (.25) 26 (.31) 26 (.35) 26 (.35) 26 (.40) 23 (.31)
Wash/reverse, rpm (g) 42 (.66) 40 (.73) 40 (.82) 40 (.82) 37 (.82) 36 (0.8)
Distribution, rpm (g) 83 (2.57) 71 (2.29) 73 (2.57) 70 (2.50) 62 (2.29) 61 (2.29)
Very Low extract, rpm (g) 401 (60) 364 (60) 343 (60) 343 (60) 317 (60) 314 (60)
Low extract rpm (g) 568 (120) 514 (120) 485 (120) 485 (120) 449 (120) 444 (120)
Medium extract, rpm (g) 695 (180) 630 (180) 594 (180) 594 (180) 550 (180) 543 (180)
High extract, rpm (g) 803 (240) 727 (240) 686 (240) 686 (240) 565 (190) 627 (240)
Very High extract, rpm (g) 898 (300) 813 (300) 766 (300) 766 (300) 579 (200) 701 (300)
Balance Detection
Vibration switch installed STD STD STD STD STD STD
Direct Steam Heating (Optional)
Steam inlet connection size,
in (mm)
0.5 (13) 0.5 (13) 0.5 (13) 0.5 (13) 0.75 (19) 0.75 (19)
Numberofsteaminlets111111
Steam required to
raise bath temperature
10°F, lb (10°C, kg)
LOW 2.1 (1.5) 3.3 (2.4) 4.6 (3.3) 5.7 (4.1) 6.7 (4.9) 8.3 (6.0)
MED 2.3 (1.7) 3.7 (2.6) 5.2 (3.8) 6.5 (4.7) 7.8 (5.6) 9.5 (6.9)
HIGH 2.7 (1.9) 4.1 (2.9) 6.1 (4.4) 7.6 (5.5) 9.1 (6.6) 11.1 (8.0)
Average consumption per
cycle, BHP (kg)
1.4 (21.4) 2.1 (33.4) 3.1 (48.4) 3.8 (60.4) 4.6 (72.0) 5.8 (91.0)
Electrical Heating (Optional)
Total electrical heating
capacity, kW
15.6 27.4 41.2 (Q-Volt)
27.4 (N-Volt)
41.2 (Q-Volt)
27.4 (N-Volt)
N/A N/A
Number of electrical heating
elements
6699N/AN/A
Electrical heating element size,
kW
2.64.24.24.2N/AN/A
Time required to
raise bath temperature
10°F, min (5°C, min)
LOW 2.4 (3.6) 2.4 (3.7) 2.2 (3.4) 2.8 (4.2) N/A N/A
MED 2.7 (4.1) 2.7 (4.1) 2.5 (3.9) 3.2 (4.8) N/A N/A
HIGH 3.1 (4.7) 3.0 (4.6) 3.0 (4.5) 3.7 (5.6) N/A N/A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
13
F8138601
UWL, UWN and UWU Models Starting 4/1/09
Specifications 35 60 80 100 125 150
Overall Dimensions
Overall width, in. (mm) 32.37 (822) 36.07 (916) 41.06 (1043) 41.06 (1043) 47.91 (1217) 50.23 (1256)
Overall height, in. (mm) 54.45 (1383) 64.5 (1638) 67.88 (1724) 67.88 (1724) 72.31 (1837) 78.9 (2004)
Overall depth, in. (mm) 44.49 (1130) 47.24 (1200) 49.88 (1267) 55.85 (1419) 56.54 (1436) 62.43 (1586)
Weight And Shipping Information
Net weight, lb. (kg) 925 (420) 1270 (576) 1750 (793) 1800 (816) 2190 (993) 2890 (1311)
Basket Weight, lb. (kg) 147 (67) 200 (92) 330 (150) 360 (163) 550 (250) 572 (260)*
Domestic shipping weight,
lb. (kg)
944 (428) 1302 (591) 1814 (823) 1870 (848) 2292 (1040) 2944 (1335)
Domestic shipping volume,
ft3(m3)
61.5 (1.7) 83.25 (2.3) 111 (3.2) 111 (3.2) 135 (3.89) 171.5 (4.94)
Domestic shipping
dimensions, WxDxH,
in. (mm)
37.5x48x59
(952x1219x1498)
41.5x50.25x69
(1054x1276x1753)
44x60x72.75
(1118x1524x1848)
44x60x72.75
(1118x1524x1848)
50.5x60x77
(1283x1524x1956)
54.5x69x78.75
(1385x1753x2000)
Export shipping weight,
lb. (kg)
1050 (476.27) 1430 (648.63) 2010 (911.72) 2060 (934.40) 2570 (1165.73) 3270 (1483.24)
Export shipping volume,
ft3(m3)
79.5 (2.27) 99.25 (2.83) 152.5 (4.35) 152.5 (4.35) 173 (4.93) 215 (6.13)
Export shipping dimensions,
WxDxH, in. (mm)
42x51x64
(1067x1295x1626)
46x53.25x70
(1168x1353x1778)
48.5x63x86.25
(1232x1600x2191)
48.5x63x86.25
(1232x1600x2191)
55x63x86.25
(1397x1600x2191)
59x72x87.5
(1499x1829x2223)
Wash Cylinder Information
Cylinder diameter, in. (mm) 26.25 (667) 32 (813) 36 (914) 36 (914) 42 (1067) 43 (1093)
Cylinder depth, in. (mm) 18.375 (467) 20 (508) 21 (533) 27 (686) 24 (610) 27.8125 (706)
Cylinder volume, ft3(l) 5.76 (163) 9.31 (264) 12.4 (350) 15.9 (450) 19.2 (544) 23.4 (662)
Perforation size, in. (mm) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8) 0.1875 (4.8)
Perforation open area, % 18 22 23 23 24 21.5
Door Opening Information
Door opening size, in. (mm) 14.375 (365) 17.5 (445) 17.5 (445) 17.5 (445) 20 (508) 24.75 (629)
Height of door bottom above
floor, in. (mm)
23.48 (596) 28.07 (713) 29.46 (748) 29.46 (748) 28.5 (724) 31.41 (798)
Drive Train Information
Number of motors in. drive
train
1111 1 1
Drive motor power, hp (kW) 2.0 (1.3)
(2-speed models)
5.0 (3.7)
(Variable-speed
models)
3.0 (2.2)
(2-speed models)
5.0 (3.7)
(Variable-speed
models)
7.5 (5.6) 7.5 (5.6) 10 (7.5) 10 (7.5)
* Basket Only

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
F8138601
14
UWL, UWN and UWU Models Starting 4/1/09 (Continued)
Specifications 35 60 80 100 125 150
Cylinder Speeds / Centrifugal Force Data
1/2 Wash/reverse, rpm (g)
(Variable-speed models only)
26 (.25) 26 (.31) 26 (.35) 26 (.35) 26 (.40) 23 (.32)
Wash/reverse, rpm (g) 44 (.73) 42 (.66) 40 (0.8) 40 (0.8) 37 (0.8) 36 (0.8)
Distribution, rpm (g)
(Variable-speed models only)
83 (2.57) 74 (2) 70 (2.50) 70 (2.50) 62 (2.29) 61 (2.29)
Very Low extract, rpm (g)
(Variable-speed models only)
401 (60) 364 (60) 343 (60) 343 (60) 317 (60) 314 (60)
Low extract rpm (g)
(Variable-speed models only)
568 (120) 514 (120) 485 (120) 485 (120) 449 (120) 444 (120)
Medium extract, rpm (g)
(Variable-speed models only)
695 (180) 630 (180) 594 (180) 594 (180) 550 (180) 543 (180)
High extract, rpm (g) 803 (240)
(Variable-speed
models)
492 (90)
(2-speed models)
727 (240)
(Variable-speed
models)
482 (106)
(2-speed models)
686 (240) 686 (240) 565 (190) 627 (240)
Very High extract, rpm (g)
(Variable-speed models only)
898 (300) 813 (300) 766 (300) 766 (300) 579 (200) 701 (300)
Balance Detection
Vibration switch installed STD (Variable-
speed models)
N/A (2-speed
models)
STD (Variable-
speed models)
N/A (2-speed
models)
STD STD STD STD
Direct Steam Heating (Optional)
Steam inlet connection size,
in. (mm)
0.5 (13) 0.5 (13) 0.5 (13) 0.5 (13) 0.75 (19) 0.75 (19)
Numberofsteaminlets111111
Steam required to
raise bath temperature
10°F, lb. (10°C, kg)
LOW 2.1 (1.5) 3.3 (2.4) 4.6 (3.3) 5.7 (4.1) 6.7 (4.9) 8.3 (6.0)
MED 2.3 (1.7) 3.7 (2.6) 5.2 (3.8) 6.5 (4.7) 7.8 (5.6) 9.5 (6.9)
HIGH 2.7 (1.9) 4.1 (2.9) 6.1 (4.4) 7.6 (5.5) 9.1 (6.6) 11.1 (8.0)
Average consumption per
cycle, BHP (kg)
1.4 (21.4) 2.1 (33.4) 3.1 (48.4) 3.8 (60.4) 4.6 (72.0) 5.8 (91.0)
Electrical Heating (Optional)
Total
electrical heating
capacity,
kW (N/A for 2 speed
models)
200V 10.8 19.1 28.6 28.6 N/A N/A
240V 15.6 27.4 41.2 41.2 N/A N/A
380V 9.8 17.2 17.2 17.2 34.4 N/A
415V 11.7 20.5 20.5 20.5 41.0 N/A
480V 15.6 27.4 27.4 27.4 54.8 N/A
Number of electrical heating
elements
669912N/A
Electrical heating element size,
kW
2.64.24.24.24.2N/A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
15
F8138601
Machine Dimensions
Dimensional Clearances
Allow a minimum of 24 inches (60 cm) at the rear and
6 inches (15.24 cm) at the sides for maintenance,
inspection, and adjustment. Allow at least 6 inches
(15.24 cm) between machines in multiple installations.
NOTE: The dimensions shown here are for
planning purposes only. They are approximate and
subject to normal manufacturing tolerances. If
exact dimensions are required for construction
purposes, contact the distributor or the
manufacturer. We reserve the right to make
changes at any time without notice.
UWTV Models Through 3/31/09
Crush hazard.
To avoid personal injury and/or property
damage, do not tip the UW150 machine
more than 25 degrees in any direction.
W642
WARNING
(Refer to Figure 3 and Figure 4)
Dimension
35 60 80 100 125 150
in mm in mm in mm in mm in mm in mm
A30.125 765 35.625 905 41.125 1045 41.125 1045 48 1219 50.25 1277
B133.375 848 36.625 930 41.5 1054 41.5 1054 48 1219 50.25 1277
C23.75 603 28.25 718 29 737 29 737 29 737 32 813
D43.625 1108 45 1143 51.5 1308 54.5 1384 58 1473 63 1600
E2.5 13 1 25 3 76 3 76 1.5 38 2.9 73
F55.5 1410 64.5 1638 68.5 1740 68.5 1740 72 1829 79 2007
G236 914 36 914 43.75 1111 43.75 1111 48 1219 56 1422
H8 203 15.5 394 16.875 429 16.875 429 11.375 289 15.75 400
J43.14 1096 49.8 1265 53.54 1360 53.54 1360 56.4 1433 62.85 1596
K46.64 1185 53.3 1354 57.04 1449 57.04 1449 59.9 1521 66.35 1685
L5.12 130 5.12 130.05 7.12 181 7.12 181 7.12 181 7.12 181
M2.62 66 2.62 66 3.62 92 3.62 92 3.62 92 3.62 92
N1.37 35 1.37 35 2.25 57 2.25 57 2.25 57 2.25 57
O3.87 98 3.87 98 5 127 5 127 5 127 5 127
P2.5 64 2.5 64 2.75 70 2.75 70 2.75 70 2.75 70
Q2.5 64 2.5 64 3.5 89 3.5 89 3.5 89 3.5 89
1Overhang dimensions for the optional starch dispenser are as follows:
UW35TV, 3.88 inches (9.86 cm); UW60TV, 1.75 inches (4.45 cm);
UW80TV and UW100TV, 0.33 inch (0.83 cm). (The starch dispenser does not overhang the UW125TV.) (No longer available.)
2The overhang dimension for the premium wet clean module option (compatible with wet-clean-capable washer-extractors only) adds
24 inches (60.96 cm) to combined machine dimensions E and G.
Table 1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
F8138601
16
PHM735N
1External Supply Control Mounting Bracket
(Models Through 6/30/08)
9Water Inlet Valves
10 Steam Connection (Optional)
2Door Unlock Button 11 Shell Vent
3Supply Valve Box 12 Power Input (Electric Heat Models)
4Emergency Stop Button 13 Power Input (Non-Electric Heat Models)
5Supply Dispenser 14 Drain (UW80TV, UW100TV and UW125TV
models only)
6Door Handle
7Spray Rinse Nozzle 15 Drain
8Recirculation Inlet 16 Overflow Vent
Figure 3
3
5
2
9
13
C
A (BASE)
B(OVERALL)
G (BASE)
D(OVERALL)
UW35TV - UW125TV MODELS
F
J
H
7
15
6
14
4
8
E
10
3
11
12
16
K
M
N
L
O
P
Q
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
17
F8138601
PHM736N
1External Supply Control Mounting Bracket
(Models Through 6/30/08)
8Basket Jog Buttons
9Recirculation Inlet
2Door Unlock Button 10 Shell Vent
3Emergency Stop Button 11 Water Inlet Valves
4Supply Valve Box 12 Steam Connection (Optional)
5Supply Dispenser 13 Power Input
6Spray Rinse Nozzle 14 Drain
7Door Handle 15 Overflow Vent
Figure 4
TMB736N
4
5
7
911
C
A (BASE)
B(OVERALL)
E
G (BASE)
D(OVERALL)
UW150TV MODELS
F
J
H
6
13
14
3
8
2
11 15
M
N
L
O
P
Q
J
K
10
12
10
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
F8138601
18
UW Design 1 and Design 2 Models
Starting 4/1/09 Through 10/3/10
(Refer to Figure 5 and Figure 6)
Dimension
35 60 80 100 125 150
in. mm in. mm in. mm in. mm in. mm in. mm
A30.125 765 35.625 905 41.125 1045 41.125 1045 48 1219 50 1270
B132.37 822 36.07 916 41.06 1043 41.06 1043 47.91 1217 50.23 1276
C23.48 596 28.07 713 29.46 748 29.46 748 28.5 723 31.41 798
D44.49 1130 47.24 1200 49.88 1267 55.85 1418 56.54 1436 62.43 1586
E54.45 1383 64.52 1639 67.88 1724 67.88 1724 72.31 1837 78.9 2004
F236.15 918 38.87 987 45.48 1155 47.70 1212 48.52 1232 56.32 1431
G7.66 195 14.72 374 15.92 404 15.92 404 11.9 302 15.73 400
H43.15 1096 49.81 1265 53.54 1359 53.54 1359 56.4 1432 62.91 1598
J46.65 1185 53.31 1354 57.04 1449 57.04 1449 59.9 1521 66.41 1687
K5.12 130 5.12 130.05 7.12 181 7.12 181 7.12 181 7.12 181
L2.62 66 2.62 66 3.62 92 3.62 92 3.62 92 3.62 92
M1.37 35 1.37 35 2.25 57 2.25 57 2.25 57 2.25 57
N3.87 98 3.87 98 5 127 5 127 5 127 5 127
O2.5 64 2.5 64 2.75 70 2.75 70 2.75 70 2.75 70
P2.5 64 2.5 64 3.5 89 3.5 89 3.5 89 3.5 89
1Overhang dimensions for the optional starch dispenser are as follows:
35, 3.88 inches (9.86 cm); 60, 1.75 inches (4.45 cm);
80 and 100, 0.33 inch (0.83 cm). (The starch dispenser does not overhang the 125.) (No longer available.)
2The overhang dimension for the premium wet clean module option (compatible with wet-clean-capable washer-extractors only) adds
24 inches (60.96 cm) to combined machine dimensions E and G.
Table 2
