Alliance Laundry Systems B-Series Installation and operation manual

Operation/Maintenance
www.comlaundry.com
Washer-Extractors
Cabinet Hardmount
B-Series Microcomputer for OPL Models
2 Speed and Variable-Speed
Refer to Page 5 for Model Identification
CHM166C
NOTA: El manual en
español aparece después
del manual en inglés.
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. F232219R1
November 2005

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
F232219
© Copyright 2005, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
1
Table of
Contents
Safety Information.............................................................................. 3
Explanation of Safety Messages........................................................... 3
Important Safety Instructions ............................................................... 3
Introduction......................................................................................... 5
Model Identification ............................................................................. 5
Introduction........................................................................................... 5
Electronic Control Unit......................................................................... 5
Control Output Fuse Board................................................................... 6
Harnessing........................................................................................ 6
Nameplate Location.............................................................................. 7
Replacement Parts ................................................................................ 7
Customer Service.................................................................................. 7
Summary of Control Outputs and Inputs.............................................. 7
Outputs............................................................................................. 7
Inputs................................................................................................ 7
Control Voltage................................................................................ 7
Operation............................................................................................. 9
Control Panel ........................................................................................ 9
Summary of Major Features ................................................................. 10
Display Indicators................................................................................. 11
Operating Instructions .......................................................................... 13
Maintenance ........................................................................................ 15
Daily ..................................................................................................... 15
Beginning of Day............................................................................. 15
End of Day ....................................................................................... 15
Weekly.................................................................................................. 16
Monthly................................................................................................. 16
Quarterly ............................................................................................... 19
Care of Stainless Steel .......................................................................... 20

2F232219
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
F232219
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable; do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

Safety Information
F232219
4© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power source.
13. Use washer only for its intended purpose,
washing textiles.
14. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
15. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
16. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc. or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
17. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
18. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a qualified
service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
21. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT
bypass the loading door switch by permitting the
washer to operate with the loading door open.
22. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
23. Always follow the fabric care instructions
supplied by the textile manufacturer.
24. Never operate the washer with any guards
and/or panels removed.
25. DO NOT operate the washer with missing or
broken parts.
26. DO NOT bypass any safety devices.
27. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
F232219
Introduction
Model Identification
Information in this manual is applicable to these models:
Introduction
The “B” electronic control is composed of the
electronic control unit and the control fuse board with
wiring harness. Only an authorized person should look
inside the machine. First TURN OFF POWER, open
lid and remove any cover present. Make sure door lock
circuit has fully discharged. The door unlock capacitor
can retain high electrical charge, even when the
machine’s electrical inputs are disconnected, until it
has discharged. Some machines are equipped with an
“amber” indicator light facing upward in the control
compartment. If this is on, wait until it goes off
(indicating when high voltage in the door lock circuit
has discharged).
Electronic Control Unit
This portion of the control contains the “intelligence” –
the micro-controller and the miscellaneous components
on the printed circuit (PC) board. The board has a
metal cover, which MUST be in place at all times
during machine operation. Operation of the machine
without this cover installed will void the warranty.
The control unit monitors and responds to input, gives
information about the status of the washer and
monitors and responds to inputs from the user
interface (keypad). The control provides signals to the
control output unit, which in turn operates the
components that control the machine functions. This is
located behind the machine control panel.
HC20BN2 HC50BN2 HC80BNV SC40BN2 SC60BNF UC30BN2 UC60BN2
HC30BN2 HC60BN2 SC20BN2 SC50BN2 SC80BNV UC40BN2 UC60BNF
HC40BN2 HC60BNF SC30BN2 SC60BN2 UC20BN2 UC50BN2 UC80BNV

Introduction
F232219
6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Output Fuse Board
This portion of the control contains the power supply
for the control unit, and also the switching devices
which power the components in the machine, all of
which are on the output PC board. The switching
devices are controlled by the control unit, and are solid
state.
Harnessing
Wiring harnesses are modular – harnesses common to
various configurations are similar, while those specific
to a certain configuration can be added. There are
harnesses for inputs to the control unit, for outputs
from the control power/output unit to the machine
components, and for the main incoming power to the
control power/output unit.

Introduction
7
F232219 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Nameplate Location
The nameplate is located at the rear of the machine and
inside door. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.
Figure 1
Replacement Parts
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
Customer Service
For technical assistance, call: [phone] Ripon,
Wisconsin.
Summary of Control Outputs and
Inputs
Outputs
General outputs provide signals to operate the
following components.
1. Hot Fill Valve
2. Cold Fill Valve
3. Drain Valve (normally open)
4. Door Lock Solenoid Coil
5. Door Unlock Solenoid Coil
6. Supply 1 (detergent)
7. Supply 2 (bleach)
8. Supply 3 (sour/softener)
9. Supply 4
10. Supply 5 or Optional 3rd (auxiliary) Fill Inlet
(governed by the configuration settings)
11. Optional Heat
For standard models, the components for outputs
shown as “optional” will not be populated on the
output printed circuit board.
AC outputs are solid state outputs that operate either
120 Volt AC or 220 Volt AC (nominal voltage)
components, depending on the control voltage
configuration. Outputs are fused appropriately.
Inputs
1. Low Water Level
2. Medium Water Level
3. High Water Level
4. Door
5. Temperature Signal (only for machines with heat
option)
Control Voltage
The control power supply can be configured to operate
on 110 Volt AC nominal RMS input voltage
50/60 Hertz, OR 220 Volt AC nominal RMS input
voltage 50/60 Hertz.
CHM2060N
1Nameplate
C
1

Introduction
F232219
8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
* Denotes Brand
Figure 2
Model Number Familiarization Guide
Sample Model Number: *C60BN2OU60001
*C Model Number Prefix
60 Washer-Extractor Capacity (pounds dry weight of laundry)
BType of Electrical Control (B = B - Control)
NActuation (N = Non-Coin)
2Washer-Extractor Speed Capability (2 = 2 speed)
OElectrical Characteristics
U6 Design Series
0001 Option Identification (varies from machine to machine)
CHM487R
CHM487R
*C60BN2OU60001
00000000000
500000
208 – 240
60 3 3
0
18
3
60
N/A N/A
470
7
EXAMPLE OF NAMEPLATE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
F232219
Operation
Control Panel
†Set Up(*) keypad is used in cycle programming in program mode. Refer to Programming Manual.
CHM522N CHM1764C
1Cycle 1 11 Door Open LED
2Cycle 2 12 Spin Cycle LED
3Cycle 3 13 Rinse Cycle LED
4Cycle 4/Up Edit 14 Add Bleach LED
5Cycle 5 15 Wash Cycle LED
6Cycle 6 16 Out-of-Balance Indicator Dot
7Cycle 7 / Set Up (*) Keypad †(Variable-speed only)
8Cycle 8/Down Edit 17 High Water Level Indicator Dot
9START Keypad 18 Medium Water Level Indicator Dot
10 CLEAN FILTER Indicator LED
(Active for all C80, and C60 X Voltage ONLY
models)
19 Low Water Level Indicator Dot
Figure 3
CHM522N
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
CLEAN
FILTER
NORMAL
LIGHT SOIL
UNIFORMS
HEAVY SOIL
STAINED
DELICATE
HOT
HOT
HOT HOT
HOT
HOT
WARM
COLD
START
PERM PRESS
VISA
TM
CHM1764
C
60C 60C
40C 40C
95C 95C
<
<
30C
DOMESTIC MODELS INTERNATIONAL MODELS
1
5
6
7
8
4
10
2
16 17 18 19
39
11
12
13
14
15
1
5
6
7
8
4
10
2
16 17 18 19
39
11
12
13
14
15

Operation
F232219
10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Summary of Major Features
Table 1
LED for Machine Functions LED lights inform operator which machine function is active. DOOR LED lights to
inform operator that the door can be opened or should be closed. The circle LED
indicates that the filter needs cleaning.
Water Levels Three (3) – Contacts from pressure switch (test cycle)
Main LED display 4 digit LED display counts down cycle time. Lights in LED display indicate out-of-balance
conditions and, in test cycle, water level. Display shows “01” as the final spin time.
Cycle selection keypads Eight (8) cycle select keypads with LED indicator to show selected cycle. LED lights
will flash to prompt user to press a keypad.
START keypad Press to start a cycle after cycle selection is made. LED light will flash to prompt user to
press keypad.
Test Cycle with “Advance” For troubleshooting. Advance rapidly through test cycle by pressing the UP keypad.
Refer to PROGRAMMING manual.
Fill Temperatures Cold, Hot, Warm
Supplies Five (5) or Four (4) with extra fill value option.
Agitation Types Normal or Gentle
Drain Options Normally open gravity drain
Cycle Count 0 to 9999 cannot be reset – Rolls over after 9999
Rapid Advance Mode Rapid Advance can be enabled or disabled. Enabled allows user to advance through a
cycle. Refer to the Programming Manual.

Operation
11
F232219 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Display Indicators
Table 2 lists the various displays and what they
mean. The operator should become familiar with
these machine displays.
Display Meaning
tESt Diagnostic test cycle selected or enabled
SPIn Spin (extract) step
SUP1 Supply signal 1 (“S1” output), normally detergent
SUP2 Supply signal 2 (“S2” output), normally bleach
SUP3 Supply signal 3 (“S3” output), normally softener
SUP4 Supply signal 4
SUP5 Supply signal 5
SdLY Spin coast (motor coasts after high speed extract)
CFIL Cold Fill
HFIL Hot Fill
bFIL Warm Fill (cold + hot)
bLCH Control will also light “add bleach” indicator
PASS Variable-speed ONLY – balance “PASS” condition; shows in “test” cycle only
FAIL Variable-speed ONLY – balance “FAIL” condition; shows in “test” cycle only
bAL? Variable-speed ONLY – meaning: “Do you wish to enter balance detection test routine?”
CY__ Cycle number (followed by a space and number 1 through highest cycle number)
nornNormal agitation selected
gEnt Gentle (reduced) agitation selected
SPn1 Variable-speed ONLY – low spin speed (the lower of 2 spin speeds)
SPn2 Variable-speed ONLY – high spin speed (the higher of 2 spin speeds)
For Wash speed forward (during test cycle)
rEv Wash speed reverse (during test cycle)
dISt Variable-speed ONLY – distribution speed (during test cycle)
LO Low water level
nEd Medium water level
HI High water level
CEL Display all temperatures in degrees Celsius
FAr Display all temperatures in degrees Fahrenheit
___C The first 3 digits are reserved for temperature reading, C indicates “degrees Celsius”
Table 2 (Continued)

Operation
F232219
12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table 2 (Continued)
Display Meaning
___F The first 3 digits are reserved for temperature reading, F indicates “degrees Fahrenheit”
FILL “Fill error” – machine did not fill to programmed water level within 10 minutes; also
displays during Rapid Advance Mode.
door “Door” opened during cycle
SHUt/door Machine user must “shut door” of the washer to allow the cycle to begin
CAnt/OPEn Control cannot unlock the door
USH1 “Wash 1” segment
USH2 “Wash 2” segment
USH3 “Wash 3” segment
USH4 “Wash 4” segment
rIn1 “Rinse 1” segment
rIn2 “Rinse 2” segment
rIn3 “Rinse 3” segment
rIn4 “Rinse 4” segment (final rinse)
donE Cycle has concluded
drAI Drain selected for segment; also indicates in drain step during 2 speed version test cycle or
during Rapid Advance Mode.
---- Flashes for a period of time (for safety) after power up while keeping outputs OFF
Adv Machine set up for Rapid Advance
noAd Machine is not set up for Radid Advance
Erdn Drain count error (depending on model)
Erfl Fill error count (depending on model)
E Pr The number of times power has been interrupted during a cycle (will display in certain
models)
CyC Cycle counter

Operation
13
F232219 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions
1. Turn on main power source (circuit breaker) with
right hand.
2. With left hand, push and hold white rocker
button. Refer to Figure 4.
3. Push button and turn handle clockwise to open.
Refer to Figure 4.
Figure 4
4. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 5.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 5
5. Close door and turn handle counterclockwise
until button pops out. Refer to Figure 6.
Figure 6
6. The default wash cycle will display.
NOTE: Perm Press Hot is the default cycle if none
is selected.
Figure 7
CHM2027N
U003I
U005I
CHM522N
CHM1764C
U005I
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
CLEAN
FILTER
NORMAL
LIGHT SOIL
UNIFORMS
HEAVY SOIL
STAINED
DELICATE
HOT
HOT
HOT HOT
HOT
HOT
WARM
COLD
START
PERM PRESS
VISA
TM
DOMESTIC MODELS
CHM1764C
60C 60C
40C 40C
95C 95C
<
<
30C
INTERNATIONAL MODELS

Operation
F232219
14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
7. If desired, select a different cycle at this point.
The LED indicator for that cycle will light.
8. Add liquid and/or powder supplies to supply
dispenser. Refer to Figure 8.
a. Add detergent to compartment 1.
b. Add softener to compartment 3.
Figure 8
9. When applicable, add bleach to compartment 2
when the ADD BLEACH LED is lit.
10. Press the desired wash cycle keypad if none is
selected.
11. Press the START keypad.
12. During first fill, the desired wash cycle can be
changed. After first fill has ended, the wash cycle
active at that moment remains the chosen wash
cycle.
13. When cycle is complete, display shows “donE”.
CHM486R
1Detergent
2Bleach
3Softener
CHM486R
1
2
3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 15
F232219
Maintenance
IMPORTANT: Replace all panels that are removed
to perform service and maintenance procedures.
Do not operate the machine with missing guards or
with broken or missing parts. Do not bypass any
safety devices.
Daily
IMPORTANT: Door lock should be checked daily
to ensure proper operation. Also check that all
safety and instruction stickers are on the machine.
Any missing or illegible safety instructions stickers
should be replaced immediately.
Beginning of Day
1. Inspect water inlet valve hose connections on the
back of the machine for leaks.
2. Inspect steam hose connections for leaks (where
applicable).
3. Verify that insulation is intact on all external
wires and that all connections are secure. If
exposed wire is evident, call a service technician.
4. Check door interlock before starting operation:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door, and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
End of Day
1. Clean the door gasket of residual detergent and
all foreign matter.
2. Clean automatic supply dispenser lid and general
area. Flush dispenser with clean water.
3. Clean the machine’s top, front and side panels
with mild detergent. Rinse with clean water.
4. Leave loading door open at the end of each day to
allow moisture to evaporate.
NOTE: Unload the machine promptly after each
completed cycle to prevent moisture buildup. Leave
loading door open after each completed cycle to
allow moisture to evaporate.
Sharp edges can cause personal injury.
Wear safety glasses and gloves, use
proper tools and provide lighting when
handling sheet metal parts.
W366R1
WARNING

Maintenance
F232219
16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Weekly
1. For variable-speed models only, clean the AC
drive box filter(s) weekly or more frequently as
needed:
NOTE: If fan filter service indicator light is on, fan
filter must be cleaned immediately to prevent
possible damage. Thermostat automatically resets
after drive compartment cools down. LED will then
extinguish after cycle run.
IMPORTANT: If filter indicator is ignored,
repeated resets might shorten life of drive. Clean
filter regularly to avoid indicator prompt.
a. Open the top cover.
b. Grasp the filter handle and pull straight up to
remove filter.
c. Wash the filter with warm water and allow
filter to air-dry. As an alternative, the filter
may be vacuumed clean.
IMPORTANT: The control module cover and fan
filter must be in place for the fan to properly cool
the AC inverter drive. Failure to observe this
warning will void the warranty and could lead to
expensive AC inverter drive repair.
2. Check the machine for leaks.
a. Start an unloaded cycle to fill the machine.
b. Verify that door and door gasket do not leak.
c. Verify that the drain valve is operating and
that the drain system is free from obstruction.
If water does not leak out during the first wash
segment, the drain valve is closed and
functioning properly.
Monthly
NOTE: Disconnect power to the machine at its
source before performing the monthly maintenance
procedures.
1. Use the following procedures to determine if
V-belt(s) require replacement or adjustment. Call
a qualified service technician in either case.
a. Check V-belt(s) for uneven wear and frayed
edges.
b. Verify pulley alignment by placing a
straightedge across both pulley faces. The
straightedge should make contact with the
pulleys in four places. Refer to Figure 9.
Figure 9
H040I
1Motor
2Motor Pulley
3Straightedge
4Basket Pulley
H040I
1
23
4

Maintenance
17
F232219 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
c. For flat-pulley drive systems, verify allowable
distance of belt from edge of pulley. Refer to
Table 3 below.
d. For variable-speed models only, verify that
V-belts are properly tensioned by applying a
set force to the belts and measuring the
deflection to determine the belt tension. Refer
to Table 4 for the acceptable belt’s tension
ranges. Belt tension measurements should be
taken as close to the center of the belt span as
possible. Refer to Figure 10.
Figure 10
Flat-Pulley Alignment
Model Allowable
Distance from Edge
20 3/32 in. (2 mm)
25 3/32 in. (2 mm)
30 3/32 in. (2 mm)
40 3/32 in. (2 mm)
50 – 60 3/8 in. (10 mm)
Table 3
H039I
1Deflection
2Span Length
1
2
Belt Tension Testing for Variable-Speed Models
Model Belt Belt Span Deflection Range Force
Min – Max
35, 40 Motor-Basket 16.9 in. (428 mm) 5/16 – 11/32 in. (7.9 – 8.7 mm) 6.1 – 7.4 lbs. (27 – 33 N)
50, 60 Motor-Basket 16.8 in. (426 mm) 9/32 – 5/16 in. (7.1 – 7.9 mm) 6.1 – 7.4 lbs. (27 – 33 N)
80 Motor-Basket
Single Belt
22.1 in. (561 mm) 15/32 – 1/2 in. (11.9 – 12.7 mm) 4.9 – 7.3 lbs. (21.8 – 31.5 N)
80 Motor-Basket
Banded Belt
22.1 in. (561 mm) 7/32 – 1/4 in. (5.08 – 6.35 mm) 23 – 26 lbs. (102.3 – 115.6 N)
Tabl e 4

Maintenance
F232219
18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 11
2. For 80 pound capacity models only, lubricate
bearings and seals each month OR after every
200 hours of operation. Refer to Figure 11.
a. Use a premium-grade lithium-based #2
grease. Never mix two types of grease, such
as petroleum and silicone.
b. Pump the grease gun slowly, permitting only
the following number of strokes:
●Bearing grease fitting, 2 strokes
●Seal grease fitting, 1 stroke
Do not pump the grease gun until grease
comes out of the bearing housing. This can
result in overlubrication, causing damage to
bearings and seals.
H047I
1Bearing Grease Fitting
2Seal Grease Fitting
H047I
1
2
