Alliance Laundry Systems Metered models User manual

Installation/Operation
www.alliancelaundry.com
Automatic
Washers
Metered and Nonmetered
W446I
Part No. 201940R3
September 2012
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
REMARQUE : Le
guide est rédigé en
anglais et en français.
La version française
figure à la suite de la
version anglaise.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
201940 1
IMPORTANT: Read the complete
INSTALLATION/OPERATION INSTRUCTIONS
before using the washer.
For your safety and to reduce the risk of
fire or an explosion, do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
W022
WARNING

© Copyright 2012, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2201940
Table of
Contents
Safety Information.............................................................................. 4
Explanation of Safety Messages........................................................... 4
Important Safety Instructions ............................................................... 4
Installation........................................................................................... 6
Dimensions and Specifications............................................................. 6
Before You Start................................................................................... 7
Tools ................................................................................................ 7
Installing the Washer ............................................................................ 7
Step 1: Remove the Shipping Brace and Shipping Plug.................. 7
Step 2: Wipe Out Inside of Washtub ............................................... 8
Step 3: Connect Fill Hoses............................................................... 8
Step 4: Connect Drain Hose to Drain Receptacle............................ 10
Step 5: Position and Level the Washer ............................................ 11
Step 6: Plug In the Washer............................................................... 12
Step 7: Add Water to the Washer .................................................... 13
Step 8: Check Lid Switch ................................................................ 14
Step 9: Check Installation ................................................................ 14
Vending................................................................................................. 15
Meter Case ....................................................................................... 15
Slide Extension Assembly – Models through Serial No. 1211........ 15
Slide Extension Assembly – Models Starting Serial No. 1211 ....... 16
Models Prepped for Card Reader..................................................... 18
Additional Washer Security............................................................. 18
Operation............................................................................................. 20
Operation Instructions for Coin Slide Operated and
Nonmetered Washers ......................................................................... 20
Step 1: Add Detergent...................................................................... 20
Step 2: Load Laundry....................................................................... 20
Step 3: Close Lid.............................................................................. 20
Step 4: Set Wash Temperature and Fabric/Cycle Selector .............. 21
Step 5: Start Washer......................................................................... 22
Indicator Lights................................................................................ 22
Control Modes ................................................................................. 23
Rapid Advance................................................................................. 24
Setting Dipswitch............................................................................. 24
Operation Instructions for MDC Washers............................................ 25
Step 1: Add Detergent...................................................................... 25
Step 2: Load Laundry....................................................................... 25
Step 3: Close Lid.............................................................................. 25
Step 4: Choose Small Load, if Desired............................................ 26
Step 5: Set Fabric Selector and Wash Temperature......................... 26
Step 6: Insert Money or Card........................................................... 26
Step 7: Start Washer......................................................................... 27
Indicator Lights................................................................................ 27

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
201940 3
Maintenance ........................................................................................ 28
User-Maintenance Instructions............................................................. 28
Cold Weather Care........................................................................... 28
Care of Your Washer ....................................................................... 28
Replacing Hoses............................................................................... 28
Filter Screens ................................................................................... 28
Reinstallation of Shipping Materials ............................................... 28
Motor Overload Protector..................................................................... 28
Troubleshooting .................................................................................. 29
Contact Information........................................................................... 31
Installer Checklist................................................................ Back Cover

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201940
4
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and
those maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the washer.
2. Install the washer according to the
INSTALLATION INSTRUCTIONS. Refer to the
GROUNDING INSTRUCTIONS in the
INSTALLATION manual for the proper
grounding of the washer. All connections for
water, drain, electrical power and grounding must
comply with local codes and be made by licensed
personnel when required. Do not do it yourself
unless you know how!
3. Do not install or store the washer where it will be
exposed to water and/or weather.
4. Do not add the following substances or textiles
containing traces of the following substances to
the wash water: gasoline, kerosene, waxes,
cooking oils, vegetable oils, machine oils, dry-
cleaning solvents, flammable chemicals, thinners
or other flammable or explosive substances.
These substances give off vapors that could
ignite, explode or cause the fabric to catch on fire
by itself.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. THE
GAS IS FLAMMABLE, DO NOT SMOKE OR
USE AN OPEN FLAME DURING THIS TIME.
6. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power
source.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
201940
7. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This appliance
is not intended for use by persons (including
children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning the use of
the appliance by a person responsible for their
safety. This is a safety rule for all appliances.
8. Do not reach into the washer if the washtub or
agitator is moving.
9. Never operate the washer with any guards, panels
and/or parts removed or broken. DO NOT tamper
with the controls or bypass any safety devices.
10. DO NOT operate individual units if they have
been separated from a stack unit.
11. Use your washer only for its intended purpose,
washing clothes. Always follow the fabric care
instructions supplied by the garment
manufacturer.
12. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. To reduce the risk of poisoning or chemical
burns, keep them out of the reach of children at
all times (preferably in a locked cabinet). Heed
all warnings or precautions.
13. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
14. Lid MUST BE CLOSED any time the washer is
to agitate or spin. DO NOT bypass the lid switch
by permitting the washer to agitate or spin with
the lid open. A brake will stop the washtub
within seconds if the lid is opened during
spinning. If the washtub does not stop when the
lid is opened, remove the washer from use and
call the service person.
15. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
16. Keep your washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have your washer checked by a
qualified service person.
17. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out. ALWAYS disconnect the
washer from electrical supply before attempting
any service.
18. Disconnect the power cord by grasping the plug,
not the cord. If the supply cord is damaged, it
must be replaced by a special cord or assembly
available from the manufacturer or its service
agent.
19. Before the washer is removed from service or
discarded, remove the lid or door to the washing
compartment.
20. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Always contact your dealer, distributor, service agent
or the manufacturer about any problems or conditions
you do not understand.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201940
6
Installation
Dimensions and Specifications
1Pilot Hole TLW2051N
C
H
TLW2051N
65.1 cm (25.63 in.)
74.47 cm (30.5 in.)
108.59 cm (42.75 in.)
1.12 cm
(0.44 in.) 66.04 cm (26 in.)
73.02 cm (28.75 in.)
109.22 cm (43 in.)
91.44 cm (36 in.)
129.54 cm (51 in.)
1
71.12 cm (28 in.)
Coin Slide Models
102.56 cm (40.38 in.)
Electronic Control Models
97 cm (38.19 in.)
Coin Slide Models
54.76 cm (21.56 in.)
Electronic Control Models
57 cm (22.44 in.)
METERED MODELS
TLW2050N
C
H
TLW2050N
65.1 cm (25.63 in.)
74.47 cm (30.5 in.)
71.12 cm (28 in.)
1.12 cm
(0.44 in.) 66.04 cm (26 in.)
NONMETERED MODELS
109.22 cm (43 in.)
91.44 cm (36 in.)
129.54 cm (51 in.)
73.02 cm (28.75 in.)
102.56 cm (40.38 in.)
54.76 cm (21.56 in.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
7
201940
Before You Start
Tools
For most installations, the basic tools you will need
are:
Figure 1
NOTE: If the washer is delivered on a cold day
(below freezing), or is stored in an unheated room
or area during the cold months, do not attempt to
operate it until the washer has had a chance to
warm up.
IMPORTANT: Install dryer before washer. This
allows room for attaching exhaust duct.
Installing the Washer
Step 1: Remove the Shipping Brace and
Shipping Plug
Remove the shipping brace from under the lid.
The shipping plug will be released from the base of the
washer when removing the cardboard base from the
washer. Refer to Figure 2.
The shipping brace and plug should be saved and must
be reinstalled whenever washer is moved or
transported to a new location. This will prevent
damage to washer components.
Do not tilt washer to front or sides when moving.
Refer to User-Maintenance section for instructions on
reinstalling shipping brace and shipping plug.
Figure 2
D074I
1Wrench
2Screwdriver
3Pliers
4Level
D074I
12
4
3
TLW2052N
1Shipping Brace
2Shipping Plug
3Cardboard Base
TLW2052N
1
2
3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
8
Step 2: Wipe Out Inside of Washtub
Prior to first wash, use an all purpose cleaner or a
detergent and water solution and a damp cloth to
remove shipping dust from inside of washtub.
Figure 3
Step 3: Connect Fill Hoses
Table 1
Table 2
Water Supply Requirements
Water supply faucets must fit standard 19.1 mm
(3/4 inch) female garden hose couplings. DO NOT
USE SLIP-ON OR CLAMP-ON CONNECTIONS.
NOTE: Water supply faucets should be readily
accessible to permit turning them off when washer
is not being used.
Water level in washer is controlled by a water level
switch.
W396I
W396I
Mixing Valve Flow Rates - MDC Models without
Small Load Switch
Pressure
(psi)
HOT
gallons per
minute
(liters per
minute)
COLD
gallons per
minute
(liters per
minute)
WA R M
gallons per
minute
(liters per
minute)
35 2.4
(9.1)
4.5
(17.0)
7.15
(27.1)
55 3.5
(13.2)
6.2
(23.5)
9.2
(34.8)
Mixing Valve Flow Rates - Coin Slide Operated,
Nonmetered, MDC Model with Small Load Switch
Pressure
(psi)
HOT
gallons per
minute
(liters per
minute)
COLD
gallons per
minute
(liters per
minute)
WA R M
gallons per
minute
(liters per
minute)
35 4.22
(15.97)
5.37
(20.33)
8.65
(32.74)
55 5.24
(19.84)
6.85
(25.93)
10.83
(41)
Under certain conditions, hydrogen gas
may be produced in a hot water system
that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If
the hot water system has not been used
for such a period and before using the
washer, turn on all hot water faucets and
let the water flow from each for several
minutes. This will release any
accumulated hydrogen gas. The gas is
flammable. Do not smoke or use an open
flame during this time.
W029
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
9
201940
Recommended cold water temperature is 10° to 24°
Celsius (50° to 75° Fahrenheit). Recommended
maximum hot water temperature is 51° Celsius (125°
Fahrenheit). Warm water is a mixture of hot and cold
water. (Warm water temperature is dependent upon the
water temperature and the pressure of both the hot and
cold water supply lines.)
Pressure must be a minimum of 138 to a maximum of
827 kPa (20 to 120 psi) static pressure measured at the
faucet.
NOTE: Water pressure under 138 kPa (20 psi) will
cause an extended fill time in the washer.
Turn on the water supply faucets and flush the lines for
approximately two minutes to remove any foreign
materials that could clog the screens in the water
mixing valve. (This is especially important when
installing your washer in a newly constructed or
renovated building.)
Connecting Hoses
Insert rubber washers and filter screens (from
accessories bag) in water fill hose couplings (two
hoses supplied with washer). Connect fill hoses to
water supply faucets. Then connect the hoses to the
hot and cold valve connections at the rear of the
washer. Refer to Figure 4.
NOTE: If using hoses with metric coupling,
connect the BLACK colored hose coupling end of
the fill hoses (with filter screens) to the water
supply faucets. Then connect end of hoses with the
brass colored hose couplings to the hot and cold
water mixing valve connections at rear of washer.
Thread hose couplings onto valve connections finger
tight. Then turn 1/4 turn with pliers.
IMPORTANT: DO NOT cross thread or
overtighten couplings.
IMPORTANT: Hoses and other natural rubber
parts deteriorate after extended use. Hoses may
develop cracks, blisters or material wear from the
temperature and constant high pressure they are
subjected to.
All hoses should be checked on a monthly basis for
any visible signs of deterioration. Any hose showing
the signs of deterioration listed above should be
replaced immediately. All hoses should be replaced
every five years.
IMPORTANT: Turn off water supply faucets after
check-out and demonstration. Owner should turn
off water supply whenever there will be an
extended period of non-use.
NOTE: Longer fill hoses are available (as optional
equipment at extra cost) if the hoses (supplied with
the washer) are not long enough for the
installation. Order hoses as follows:
No. 20617 Fill Hose 2.44 m (8 feet)
No. 20618 Fill Hose 3.05 m (10 feet)
To prevent personal injury, avoid contact
with inlet water temperatures higher than
51° Celsius (125° Fahrenheit) and hot
surfaces.
W750
WARNING
TLW1988N
1Filter Screen (Screen must be facing
outward)
2Fill Hose
3Rubber Washer (Plain)
4Cold Water Connection
5Hot Water Connection
6Install this end of hose to valve connections
at rear of washer.
7Install this end of hose to water supply
faucet. (Black colored coupling for metric)
8Faucet
Figure 4
TLW1988N
HOT
COLD
C
H
2
13
4
5
6
8
7

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
10
Risers
Risers (or air cushions) may have to be installed if the
pipes knock or pound when flow of water stops. The
risers are more efficient when installed as close as
possible to the water supply faucets. Refer to Figure 5.
Figure 5
Step 4: Connect Drain Hose to Drain
Receptacle
Drain Facilities
IMPORTANT: The drain hose installation is a very
important factor in the washer installation. If care
is not taken when the drain hose is installed, a
siphoning action can be started which will cause
water to be siphoned from the washer during the
cycle.
End of drain hose should never be in water as
siphoning action can be started that will cause
water to be siphoned back into the washer.
The curved end of drain hose MUST be installed
even with or above the height of the cabinet top of
the washer to prevent siphoning. Refer to Figure 6.
The standpipe or drain receptacle must be capable of
handling a minimum of 3.8 cm (1-1/2 inches) outside
diameter drain hose. The drain hose should fit loose
within the standpipe (it should not be snug fit). Never
install the drain hose into a “sealed” drain system as
air cannot escape and will restrict the water from being
drained from the washer. A sealed drain system may
also allow water to be pumped back into the washer
during agitation. Both of these conditions may result
in flooding of the washer.
Remove the drain hose from its shipping position on
the rear of the washer by unhooking the hose from the
retainer clamp.
W005I
1Risers (Air cushions)
2Water Supply Faucets
W005I
2
1
W294I
1Drain Hose
2Standpipe
Figure 6
W294I
2
1
RECOMMENDED
STANDPIPE
HEIGHT
91.44 cm
MINIMUM
(36 in.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
11
201940
If necessary, follow the instructions for your type of
drain receptacle (high standpipe or low standpipe) to
properly install the drain hose.
High Standpipe Installation
NOTE: No. 562P3 Siphon Break Kit and No. 25863
Hose Coupling are not required for this type of
installation.
Figure 7
IMPORTANT: Drain receptacle must be capable of
handling a minimum of 3.8 cm (1-1/2 inches)
outside diameter drain hose.
Low Standpipe Installation
If the drain facility is lower than the cabinet top, a
siphon break kit, Part No. 562P3, must be installed in
the drain hose to prevent siphoning action and drain
hose MUST be cut to fit the washer installation. Refer
to Figure 8. Use one No. 25863 Hose Coupling to
splice hose. The No. 562P3 Siphon Break Kit and No.
25863 Hose Coupling are available as optional
equipment at extra cost through an authorized dealer
or parts distributor. Installation instructions are
supplied with the kit.
OPTIONAL: Raise the standpipe to the recommended
height of 91.44 cm (36 in.).
IMPORTANT: Drain receptacle must be capable of
handling a minimum of 3.8 cm (1-1/2 inches)
outside diameter drain hose.
Figure 8
Step 5: Position and Level the Washer
Position washer so it has sufficient clearance for
installation and servicing.
Place washer in position on a clean, dry, and
reasonably firm floor. Installing the washer on any
type of carpeting is not recommended.
Place rubber cups on all four leveling legs.
Place a level on the cabinet top and check if the
washer is level from side to side and front to back.
If washer is not level, tilt washer back to access the
front leveling legs. Loosen the locknuts and adjust legs
by screwing into or out of washer base.
Once adjusted, tilt the washer forward on front legs
and lower back down into position to set the rear self-
leveling legs.
Washer must not rock. After washer is at desired
height, tighten locknuts securely against bottom of
washer base. If these locknuts are not tight, washer
will not remain stationary during operation.
Improper installation or flexing of weak floor will
cause excessive vibration.
W296I
1Drain Hose
2Cut Drain Hose off at This End to Fit the
Washer Installation
3Standpipe
{
W296I
3
1
MAXIMUM
STANDPIPE
HEIGHT NOT TO
EXCEED 1.5 m
(5 ft.)
2
W295I
1Drain Hose Elbow
2562P3 Siphon Break Kit
3Standpipe
4Cut Hose in This Area and Install No. 25863
Hose Coupling
525863 Hose Coupling
W295I
{
2
1
5
4
3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
12
Do not slide washer across floor once the leveling legs
have been extended, as legs and base could become
damaged.
NOTE: For areas with uneven floors, a No. 566P3
Adjustable Rear Leg Extension Kit is available as
optional equipment at extra cost.
Verify that unit does not rock.
Figure 9
Step 6: Plug In the Washer
Electrical Requirements
(120 Volt, 60 Hertz with 3-Prong Grounding Plug)
NOTE: The wiring diagram is located in the
control hood.
When plugging in the washer:
DO NOT overload circuits.
DO NOT use an extension cord.
DO NOT use an adapter.
DO NOT operate other appliances on the same
circuit. Use separately fused 15 Amp circuits.
The washer is designed to be operated on a separate
branch, polarized, three-wire, effectively grounded,
120 Volt, 60 Hertz, AC (alternating current), circuit
protected by a 15 ampere fuse, equivalent fusetron or
circuit breaker.
The three-prong grounding plug on the power cord
should be plugged directly into a polarized three-slot
effectively grounded receptacle rated 110/120 Volts
AC (alternating current) 15 Amps. Refer to Figure 10
to determine correct polarity of the wall receptacle.
TLW2053N
1Washer Base
2Locknut
3Leveling Leg
4Rubber Cup
512.7 mm (1/2 in.) Clearance Between
Washers
6Level
TLW2100N
1
3
2
5
4
6
To reduce the risk of fire, electrical shock
or personal injury, all wiring and
grounding MUST conform with the latest
edition of the Canadian Electrical Code,
Parts I and II, and such local regulations
as might apply. It is the customer’s
responsibility to have the wiring and
fuses checked by a qualified electrician to
make sure the laundry room has adequate
electrical power to operate the washer.
W110
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
13
201940
Grounding Instructions
The washer must be grounded. In the event of
malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current.
The washer is equipped with a cord having an
equipment-grounding conductor and a three-prong
grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
DO NOT modify the plug provided with the
washer – if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
If the laundry room’s electrical supply does not
meet the above specifications and/or if you are
not sure the laundry room has an effective
ground, have a qualified electrician or your local
electrical utility company check it and correct
any problems.
Step 7: Add Water to the Washer
To prevent damage to pump, do not run washer before
adding at least one quart water to the tub. If the washer
is run before any water is added, the pump seal may
overheat, causing the pump to leak. Once installed, the
water retained in the drain system from the previous
cycle will provide sufficient cooling to prevent pump
seal damage.
NOTE: The agitator should not be removed except
for service. The washtub is designed to be self-
cleaning.
Figure 11
DRY2022N
1 L1
2Ground
3Neutral Side
4Round Grounding Prong
5Neutral
Figure 10
1
2
3
45
Standard 120 Volt, 60 Hertz
3-Wire Effectively
Grounded Circuit
0 V.A.C.
120±12
V.A.C.
120±12
V.A.C.
To reduce the risk of an electric shock or
fire, DO NOT use an extension cord or an
adapter to connect the washer to the
electric power source.
W082
WARNING
TLW2056N
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service person if you are in
doubt as to whether the washer is
properly grounded.
W327
WARNING
Any disassembly requiring the use of
tools must be performed by a suitably
qualified service person.
W299
WARNING
TLW2056N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
14
Step 8: Check Lid Switch
Washer should stop filling, agitating and spinning
when lid is opened.
Figure 12
Step 9: Check Installation
Refer to Installer Checklist on the back cover of this
manual and make sure that washer is installed
correctly.
Run washer through one complete cycle to make sure
it is operating properly.
TLW1974N
TLW1974N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
15
201940
Vending
Meter Case
The factory mounted coin meter case does not include
the service door lock, coin slide, coin drawer, coin
drawer lock or keys. These parts must be ordered (at
extra cost) according to the purchaser’s requirements
direct from the manufacturer of your choice.
NOTE: You have the option of using a screw type
lock or a 1/4 turn lock on the meter case service
door. If you choose to use a screw lock, then the
special bracket (located inside the meter case) must
be used. DO NOT use the special bracket if a
1/4 turn lock is used.
Coin Drawer Security – For additional security, drill
out the two pilot holes on each side of the front of the
meter case to 6.4 or 7.9 mm (1/4 or 5/16 inch) holes
and install a bicycle lock through these holes.
NOTE: A 20.32 cm (8 in.) coin drawer is required
for coin operated electronic control models.
Slide Extension Assembly – Models
through Serial No. 1211
(Coin Slide Models Only)
1. Remove slide extension parts from parts
accessories bag included in unit.
2. If installing a Greenwald coin slide, position
extension lever (to be installed on extension
bracket) with arm that has one star facing down.
Refer to Figure 13.
3. If installing a Monarch or ESD coin slide,
position lever with arm that has two stars facing
down. Refer to Figure 13.
4. Install extension lever with rounded corner facing
away from extension bracket using bolt, one or
two flat washers (shims) (use number of washers
included in kit) and nut. Refer to Figure 14. Make
sure washers are flat against bracket.
5. Torque nut between 2 and 2.26 Nm (18 and 20
inch-pounds), or tighten nut firmly.
6. Install extension spring in bracket hole and hole in
upper arm of lever. Refer to Figure 14.
7. Bend loops closed after installation.
8. Check to make sure the lever swings freely.
Installing Extension Onto Coin Slide:
Option 1
1. Install slide extension onto top of coin slide using
two remaining screws and lockwashers. Refer to
Figure 15.
2. Insert coins and partially extend coin slide.
TLW2088N
Figure 13
Greenwald
Coin Slide
Monarch or
ESD Coin Slide
One Star Two Stars
TLW2089N
Figure 14
Figure 15
TLW2089N
Extension Bracket
Spring Bolt One or Two
Flat Washers (Shims)
Nut
Extension Lever
Star(s) Facing Down
Loops
Rounded Corner
Coin Slide
Slide
Extension
Attaching
Screws
Lockwashers
TLW1564K

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
16
3. Insert coin slide on its side through meter case
opening. Then rotate 90 degrees to its proper
orientation.
4. Return coin slide and hook slide pins onto meter
case.
5. Continue coin slide installation according to
manufacturer’s instructions.
NOTE: During coin slide installation, make sure
activation lever is up and off the switch. Refer to
Figure 16.
6. Check to make sure coin slide is operating
properly by inserting coins and starting a cycle.
The IN USE light will turn on, or flash if it is
already on, to indicate proper operation.
Installing Extension Onto Coin Slide:
Option 2
1. Install coin slide according to manufacturer’s
instructions.
2. Insert coins into coin slide and slowly push slide
in. Stop before coins fall into coin box. This will
allow installing extension through meter case
service door opening.
3. Install slide extension onto top of coin slide using
two screws and lockwashers. Refer to Figure 15.
NOTE: Make sure extension lever is above switch
activation lever.
4. Check to make sure coin slide is operating
properly by inserting coins and starting a cycle.
The IN USE light will turn on, or flash if it is
already on, to indicate proper operation.
Slide Extension Assembly – Models
Starting Serial No. 1211
1. Remove slide extension parts from parts
accessories bag included in unit.
2. Install extension lever with arm that has one star
facing down. Refer to Figure 17.
NOTE: If more switch down-force is required,
install lever with arm that has two stars facing
down to provide additional switch travel.
3. Install extension lever with rounded corner
facing away from extension bracket using bolt,
washer and nut. Refer to Figure 18.
4. Install extension bracket and lever assembly onto
coin slide bracket using two screws and locknuts.
Refer to Figure 19.
IMPORTANT: Install coin slide bracket with side
marked "A" facing up and toward extension
bracket and lever assembly. Refer to Figure 19.
TLW2090N
1Lever Off Switch
Figure 16
TLW2090N
1
Figure 17
Figure 18
One Star
TLW2088N
TLW1580K
Extension
Bracket
Bolt Washer
Extension
Lever
Nut
Rounded
Corner
TLW1580K

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
17
201940
5. Install coin slide extension assembly onto top of
coin slide using two remaining screws and
lockwashers. Refer to Figure 20.
6. Before installing coin slide and extension, make
sure ground wire is tucked under control shield to
provide clearance for coin slide. Refer to
Figure 21.
Installing Extension Onto Coin Slide:
Option 1
1. Insert coins and partially extend coin slide.
2. Insert coin slide on its side through meter case
opening. Then rotate 90 degrees to its proper
orientation.
3. Return coin slide and hook slide pins onto meter
case.
4. Continue coin slide installation according to
manufacturer’s instructions.
5. Check to make sure coin slide is operating
properly by inserting coins and starting a cycle.
The IN USE light will turn on, or flash if it is
already on, to indicate proper operation.
Installing Extension Onto Coin Slide:
Option 2
1. Install coin slide according to manufacturer’s
instructions.
2. Insert coins into coin slide and slowly push slide
in. Stop before coins fall into coin box. This will
allow installing extension through meter case
service door opening.
3. Install slide extension onto top of coin slide using
two screws. Refer to Figure 20.
4. Check to make sure coin slide is operating
properly by inserting coins and starting a cycle.
The IN USE light will turn on, or flash if it is
already on, to indicate proper operation.
Figure 19
Figure 20
Coin Slide Bracket -
Letter "A"
Extension Bracket and
Lever Assembly
TLW2155N
Coin Slide Extension
Assembly
TLW2156N
TLW2157N
Figure 21
Ground Wire Placement

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
201940
18
Models Prepped for Card Reader
The machine is shipped from the factory with the
Electronic Control Diagnostic Harness Assembly
unplugged. To avoid unauthorized manual
programming or vending, perform the following steps.
1. Open control panel. Refer to Figure 22.
2. Locate diagnostic harness on electronic control.
3. Plug connectors for “white/black” wire and “red/
blue” wire together.
Figure 22
Additional Washer Security
(Coin Models Only)
Located on the service door of the washer is a flat
Phillips head screw. During shipment, this screw is
used to attach the service door to the meter case. For
additional security, this screw can be reinstalled inside
the control hood of your washer. Refer to instructions
below for installation.
Tamper-resistant screws also can be installed for
additional security. Tamper-resistant screws, bits and
bit holder are available as optional equipment at extra
cost. Part numbers are:
Bit (No. 8 screws) Part No. 281P4
Bit (No. 12 screws) Part No. 282P4
Bit Holder (3/8 drive) Part No. 24161
Control panel tamper-resistant screw Part No.
35528
Front panel tamper-resistant screw Part No.
35527
The following list is the procedure required to install
the Phillips head screw and tamper-resistant screws:
1. Remove the Phillips head screw from service
door (refer to Figure 23).
2. Remove two screws holding control panel to
control hood.
FLW6R
1Control Panel
1
To reduce the risk of electric shock, fire,
explosion, serious injury or death:
• Disconnect electric power to the washer
before servicing.
• Never start the washer with any guards/
panels removed.
• Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
washer is properly grounded.
W003
WARNING
Any disassembly requiring the use of
tools must be performed by a suitably
qualified service person.
W299
