Datasheet | Pluggable Transceivers
AT-G8LX10
10km 1000LX GBIC
Industry Standard
The AT-G8 series offers the latest industry
standards in flexible, full-duplex Gigabit Ethernet
connectivity.These hot-swappable, fiber
interfaces simply plug into a GBIC slot on
Allied Telesis GBIC compatible products.
Configurations can be optimized to meet varied
distance and service requirements.
Options
The AT-G8 series offers short-haul and long-
haul solutions. From the inexpensive AT-G8SX01
to the far-reaching AT-G8LX70, you have the
option to extend your network to the distances
that meet your performance needs.The CWDM
version allows you to takeadvantage of the
CWDM technology in an existing network
infrastructure, maximizing fiber efficiency.
Product Compatibility
The AT-G8 series GBICs are compatible with all
of the Allied T
elesis range of products that
support GBIC uplink connections.
Technical Specifications
Media Type SMF
Wavelength 1310nm
Maximum Data Rate 1.25Gbps
Distance 10km
Transmit Power (min) -9.5dBm
Transmit Power (typ) -7dBm
Transmit Power (max) -3dBm
Receive Sensitivity (max) -20dBm
Power Budget 11.5dB
Interface Support SC
Standard Data Rate Supported
Optical Gigabit Ethernet
Environmental Specifications
Operating Temp. 0°Cto 60°C
Operating Humidity 5% to 95% (non-condensing)
Storage Temperature -40°C to 85°C
Storage Humidity 5% to 95% (non-condensing)
Key Features
•Copper and fiber solutions
•Connect up to 70km
•Compact size
•Flexible architecture
•Plug & Play ease-of-use
•Self-locking mechanism
•‘Colored’ wavelength for CWDM use
•Two year warranty
Ordering Information
AT-G8LX10
10km 1000LX 9 Micron SMF (1310nm)
AT-G8LX10
GBIC GigaBit Interface Converter
