The CentreCOM
AT-MC12T
Media Converter User’s Guide
Overview
The Allied Telesyn AT-MC12T is used in addition to a transceiver
(MAU) to convert another Ethernet physical layer to 10BASE-T. It is
connected to a transceiver of the required conversion type. The
power adapter supplies power to the AT-MC12T and to the attached
transceiver.
Table 1: Possible Media Conversion
MDI/MDI-X Switch
The MDI/MDI-X switch located on the side of the unit, is a straight-
through crossover cable selection switch. It enables the 10BASE-T
(RJ45) port to be connected to a repeater or to a DTE without using a
special crossover cable.
The default setting of the switch is MDI-X, which means you can
connect the 10BASE-T port to a workstation or to any other DTE that
uses a straight-through cable. In the MDI configuration, slide the
switch to the MDI side and you can connect the 10BASE-T port to a
repeater/hub/concentrator using a straight-through cable.
Figure 1:
Typical Configuration
Transceiver (MAU) Conversion Type
MC12T MX40F, MX55F, MX50
(10BASE-FL MAU) UTP—Fiber Optic
MC12T MX10S
(10BASE2 MAU) UTP—Thin Coax
10BASE-T
REPEATER
or 10BASE-T
WORKSTATION
NODE
NODE
NODE
AT-MC12T AT-MX
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table 2: RJ45 Pinout
NOTE
The transceiver (MAU) attached at the AUI connector must have the
SQE (heartbeat) test disabled for proper operation.
LED Explanation
There are four LEDs next to the 10BASE-T port of the MC12T
Table 3: LED Guide
Power Requirements
The AT-MC12T draws power from the wall-mount AC-DC power
adapter attached at its DC jack. ATI supplies the TUV/UL/CSA
licensed safety compliant AC power adapter for the 120 and 240 VAC
versions with an unregulated output of 12 VDC at 1A. The power
required for the AT-MC12T is:
Installing the AT-MC12T
1. Choose the correct switch settings for the AT-MC12T and the
attached transceiver.
2. Make sure that the SQE test is OFF.
3. Plug the AT-MC12T onto the 15-pin male connector on the
transceiver or on the AUI cable.
4. Slide the connector latch in place.
5. Connect the power adapter to the AT-MC12T and then to an AC
outlet.
Warranty
The AT-MC12T Media Converter has a lifetime warranty. The power
supply has a one year warranty.
RJ45—MDI Pinout RJ45—MDI-X Pinout
Pin Signal Pin Signal
1 TD+ 1 RD+
2 TD- 2 RD-
3 RD+ 3 TD+
6 RD- 6 TD-
4, 5, 7, 8 N/A 4, 5, 7, 8 N/A
LED Name Meaning When LED Is Lighted
PWR Indicates power is applied
LNK Indicates link is established
ACT Indicates data is received on RJ45 or AUI port
COL Indicates a collision is detected on RJ45 or AUI
port
12 to 18 VDC, 700 mA
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Electrical Safety and Installation Requirements
RADIATED ENERGY
U.S. Federal Communications
Note: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates,uses, andcan radiateradio frequencyenergy and,if notinstalled andused inaccordance with
this instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void
your right to operate this equipment.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
STANDARDS: This product meets the following standards
RFI EmissionEN55022 Class A
WARNING: In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
Immunity EN50082-1
Electrical Safety EN60950, UL1950, CSA 950
SAFETY
LIGHTNING DANGER
DANGER: DO NOT WORK on equipment or CABLES during periods of LIGHTNING ACTIVITY.
Operating temperature
This product is designed for a maximum ambient temperature of 40 degrees C.
Environmental Air Notice
Caution:UL listedfor usein otherEnvironmental AirSpaces inAccordance withArticle 300-22(C)of the
U.S.A National Electrical Code. Note: Product is not Plenum rated.
All Countries: Install product in accordance with local and National Electrical Codes.
NORMEN: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen.
Hochfrequenzstörung EN55022 Klasse A
WARNUNG: Bei Verwendung zu Hause kann dieses Produkt Funkstörungen hervorrufen. In diesem
Fall müßte der Anwender angemessene Gegenmaßnahmen ergreifen.
Störsicherheit EN50082-1
Elektrische Sicherheit EN60950, UL1950, CSA 950
SICHERHEIT
GEFAHR DURCH BLITZSCHLAG
GEFAHR: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters ausführen
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr als 40 ° C
entworfen.
Alle Länder: Installation muß örtlichen und nationalen elektrischen Vorschriften entsprechen.
Radiofrekvens forstyrrelsesemission EN55022 Klasse A
ADVARSEL: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse. Bliver det tilfældet,
påkræves brugeren muligvis at tage tilstrækkelige foranstaltninger.
Immunitet EN50082-1
Elektrisk sikkerhed. EN60950, UL1950, CSA 950.
SIKKERHED
FARE UNDER UVEJR
FARE: UNDLAD at arbejde på udstyr eller KABLER i perioder med LYNAKTIVITET.
Betjeningstemperatur
Dette apparat er konstrueret til en omgivende temperatur på maksimum 40 grader C.
Alle lande: Installation af produktet skal ske i overensstemmelse med lokal og national lovgivning for
elektriske installationer.
RFI Emissie EN55022 Klasse A
WAARSCHUWING: Binnenshuis kan dit product radiostoring veroorzaken, in welk geval de gebruiker
verplicht kan worden om gepaste maatregelen te nemen.
Immuniteit EN50082-1
Electrische Veiligheid EN60950, UL1950, CSA 950
VEILIGHEID
GEVAAR VOOR BLIKSEMINSLAG
GEVAAR: NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
Bedrijfstemperatuur
De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius.
Alle landen: het toestel installeren overeenkomstig de lokale en nationale elektrische voorschriften.
NORMES : ce produit est conforme aux normes de suivantes :
Emission d’interférences radioélectriques EN55022 Classe A
MISE EN GARDE : dans un environnement domestique, ce produit peut provoquer des interférences
radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures adéquates.
Immunité EN50082 -1
Sécurité électrique EN60950, UL1950, CSA 950
SÉCURITÉ
DANGER DE FOUDRE
DANGER : NE PAS MANIER le matériel ou les CÂBLES lors d’activité orageuse.
TEMPÉRATURE DE FONCTIONNEMENT
Ce matériel est capable de tolérer une température ambiante maximum de 40 degrés Celsius.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Pour tous pays : Installer le matériel conformément aux normes électriques nationales et locales.
Radioaaltojen häirintä EN55022 Luokka A
VAROITUS: Kotiolosuhteissatämä laite voi aiheuttaa radioaaltojenhäiröitä, missä tapauksessa laitteen
käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin.
Kestävyys EN50082-1
Sähköturvallisuus EN60950, UL1950, CSA 950
TURVALLISUUS
SALAMANISKUVAARA
HENGENVAARA: ÄLÄ TYÖSKENTELE laitteiden tai KAAPELEIDEN KANSSA SALAMOINNIN AIKANA.
KÄYTTÖLÄMPÖTILA
Tämä tuote on suunniteltu ympäröivän ilman maksimilämpötilalle 40 ° C.
Kaikki maat: Asenna tuote paikallisten ja kansallisten sähköturvallisuusmääräysten mukaisesti.
Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A
AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza.
In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti.
Immunità EN50082-1
Sicurezza elettrica EN60950, UL1950, CSA 950
NORME DI SICUREZZA
PERICOLO DI FULMINI
PERICOLO: NON LAVORARE sul dispositivo o sui CAVI durante PRECIPITAZIONI TEMPORALESCHE.
Temperatura di funzionamento
Questo prodotto è concepito per una temperatura ambientale massima di 40 gradi centigradi.
Tutti i paesi: installare il prodotto in conformità delle vigenti normative elettriche nazionali.
RFI stråling EN55022 Klasse A
ADVARSEL: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake radioforstyrrelse.
Hvis dette skjer, må brukeren ta de nødvendige forholdsregler.
Immunitet EN50082-1
Elektrisk sikkerhet EN60950, UL1950, CSA 950
SIKKERHET
FARE FOR LYNNEDSLAG
FARE: ARBEID IKKE på utstyr eller KABLER i TORDENVÆR.
Driftstemperatur
Dette produktet er konstruert for bruk i maksimum romtemperatur på 40 grader celsius.
Alle land: Produktet må installeres i samsvar med de lokale og nasjonale elektriske koder.
Emissão de interferência de radiofrequência EN55022 Classe A
.
AVISO: Num ambiente doméstico este produto pode causar interferência na radiorrecepção e, neste
caso, pode ser necessário que o utente tome as medidas adequadas.
Imunidade EN50082-1
Segurança Eléctrica EN60950, UL1950, CSA 950
SEGURANÇA
PERIGO DE CHOQUE CAUSADO POR RAIO
PERIGO: NÃO TRABALHE no equipamento ou nos CABOS durante períodos suscetíveis a QUEDAS DE
RAIO.
TEMPERATURA DE FUNCIONAMENTO
Este produto foi projetado para uma temperatura ambiente máxima de 40 graus centígrados.
Todos os países: Instale o produto de acordo com as normas nacionais e locais para instalações
elétricas.
Emisión RFI EN55022 Clase A
ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo
caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto.
Inmunidad EN50082-1
Seguridad eléctrica EN60950, UL1950, CSA 950
SEGURIDAD
PELIGRO DE RAYOS
PELIGRO: NO REALICE NINGUN TIPO DE TRABAJO O CONEXION en los equipos o en LOS CABLES
durante TORMENTAS ELECTRICAS.
Temperatura requerida para la operación
Este producto está diseñado para una temperatura ambiental máxima de 40 grados C.
Para todos los países: Monte el producto de acuerdo con los Códigos Eléctricos locales y
nacionales.
Radiostörning EN55022 Klass A
VARNING: Dennaproduktkan geupphov tillradiostörningar ihemmet, vilketkantvinga användarentill
att vidtaga erforderliga åtgärder.
Immunitet EN50082-1
Elsäkerhet EN60950, UL1950, CSA 950
SÄKERHET
FARA FÖR BLIXTNEDSLAG
FARA: ARBETA EJ på utrustningen eller kablarna vid ÅSKVÄDER.
DRIFTSTEMPERATUR
Denna produkt är konstruerad för rumstemperatur ej överstigande 40 grader Celsius.
Alla länder: Installera produkten i enlighet med lokala och statliga bestämmelser för elektrisk
utrustning.
Allied Telesyn International
19015 North Creek Parkway Suite 200
Bothell, WA 98011
Tel [phone] • Fax [phone]
Technical Support Tel [phone] • Fax [phone]
PN 613-10379-00 Rev. C 970128
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group is your source for quality
new and certied-used/pre-owned equipment
• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
REMOTE INSPECTION
Remotely inspect equipment before purchasing with
our interactive website at www.instraview.com
LOOKING FOR MORE INFORMATION?
Visit us on the web at www.artisantg.com for more
information on price quotations, drivers, technical
specications, manuals, and documentation
Contact us: (888) 88-SOURCE | [e-mail] | www.artisantg.com
SM
View
Instra
