Datasheet | Media Converters
AT-MC115XL
10/100TX to 10FL/100SX 850nm fiber
ST media converter
AT-MC116XL
10/100TX to 10FL/100SX 850nm fiber
SC media converter
Fiber Connections
The Allied Telesis range of 850nm fiber Fast
Ethernet media converters allows users to
extend the sizeof UTP networks with the use
of fiber cabling. Converting between 10T and
10FL or 100TX and 100SX fiber quickly and
reliably, the AT-MC115XL and AT-MC116XL
address the growing demand for a low-cost
solution for fiber installations of up to 300
meters for 100SX and up to 2km for 10FL.To
maximize flexibility, the converters are available
in ST (AT-MC115XL) and SC (AT-MC116XL)
fiber connector styles.
Auto-Negotiation
The AT-MC115XL and AT-MC116XL auto-
negotiate during the link-up phase of the
connection to set the speed (10/100) and
operation mode (full or half-duplex). When
connecting media converters to auto-
negotiating Fast Ethernet switches, these media
converters will automatically connect the link in
either full or half-duplex mode, allowing the link
to be established with the greatest bandwidth.
MissingLink™
The MissingLink feature allows accurate
reporting to network management systems as
well as allowing devices with redundant link
capability to be inter-connected with these
media converters, failure in one fiber link will be
signalled to the switch, allowing the second link
to become active.
Simple Installation
All the media converters with a UTP
connection feature an internal MDI/MDI-X
switch, allowing the converter to be connected
to either a PC, hub or switch with a simple UTP
cable.The media converters also allow the
installer to test the integrity of fiber connection,
by forcing the converters to communicate over
the fiber cable.This link test feature allows
installers to check for cable faults without the
need for expensive fiber optic test equipment.
Standalone or Rack-mountable
Each media converter is powered by an
external power supply unit for use in standalone
applications. Where multiple media converters
are being used, up to 12 devices can be
inserted into a low-cost rack-mount chassis,
allowing all the convertersto be powered by a
single internal power supply. In critical
applications, a second load sharing internal
power supply can be installed into the rack-
mount chassis.
Key Features
•10/100TX copper port
•10/100SX fiber port
•Half and full-duplex operation
•Transparent to IEEE 802.1Q packets
•Rack-mountable using optional AT-MCR12,
AT-TRAY4 or AT- TRAY1 chassis
•MDI/MDI-X
•MissingLink
•Link test
•Auto-negotiation
•Wall-mountable using optional AT-WLMT
bracket
MC11x Series
Fast Ethernet Media Converters
Allied T
elesis www.alliedtelesis.com

Technical Specifications
Status Indicators
Power Indicates power is applied to
the converter
Normal Indicates converter is operating in
normal mode
Recieve Indicates port receiving or
transmitting data
10 Indicates link established at 10Mbps
100 Indicates link established at 100Mbps
Packet Transmission Characteristics
Round trip delay 0.4µs maximum
Bit Error Rate (BER) <10-12
Twisted Pair Interface
UTP Differential Output Voltage
Typical Min. Max.
980mv 950mv 1050mv
Overshoot Voltage
Typical Max.
4% 5%
Signal Amplitude Symmetry
Typical Min. Max.
1.0062 0.98 1.02
Rise and Fall Time
Typical Min. Max.
Rise 4.6ns 3.0ns 5.0ns
Fall 4.2ns 3.0ns 5.0ns
Rise and Fall Time Symmetry
Typical Max.
0.4ns 0.5ns
Fiber Interface Parameters
Typical Min. Max.
Wavelength 850nm
Transmit power -12 dBm -15dBm -10dBm
Receive sensitivity -34.4dBm -7.6dBm
Linkbudget 11.7dbm
Power Characteristics
External power supply 120V AC, 60Hz (US model)
240V AC, 50Hz
(European models)
Input supply voltage 12vDC
Max current 500mA
Power consumption 6W
Environmental Specifications
Operating temp. 0°C to 50°C
Storage temp. -20°C to 80°C
Relative humidity 5% to 95% non-condensing
Operating altitude 0 to 3.000m (10.000ft)
Electrical/Mechanical Approvals
EMC FCC Class A, FCC Class B
Safety UL-Cul, CSA/CSA, NRTL, TUV,
CE compliant
Ordering Information
AT-MC115XL-XX
10/100TX to 10FL/100SX 850nm media converter with ST
fiber connectors
AT-MC116XL-XX
10/100TX to 10FL/100SX 850nm media converter with SC
fiber connectors
Where xx = 10 AC power supply, US power cord
20 AC power supply, European power cord
30 AC power supply, UK power cord
40 AC power supply, Australian power cord
Associated Products
AT-MCR12-xx
12 slot power distribution chassis
AT-TRAY4
19-inch rack-mount chassis for up to four media
converters
AT-TRAY1
19-inch rack-mount chassis for one media converter
AT-WLMT
Wall-mount bracket for one media converter
MC11x Series |Fast Ethernet Media Converters
