Datasheet | Switches
AT-FS708LE
Unmanaged Fast Ethernet Switch
AT-FS708LE-xx
8port 10/100TX unmanaged switch
with external power supply
High Performance
Providing powerful 10/100 switching solutions
for desktop and small networkenvironments,
the Allied Telesis FS700 series of unmanaged
switches features full auto-negotiating 10/100
ports.These ports enable the switches to
detect the speed and duplex modes of attached
devices, enabling them to automatically configure
for the best possible performance.
Flexibility
Available as 5, 8, 16, or 24 port models, the
FS700 series meets a multitude of power
requirements with both internal and external
power-supply options. Also, wall desk, and
rackmounting options give users ultimate
flexibility in selecting the model that meets
their physical deployment requirements.
Simplified Installation
Fully auto-configuring FS700 series switches
require minimal set-up by the user. Auto-sensing
ports enable seamless and simple connectivity
between existing 10Mbps Ethernet and
100Mbps Fast Ethernet UTP devices—and all
units can be installed in minutes. Every FS700
series model is equipped with MDI/MDI-X
ports for simple connection to other hubs and
switches. Finally, easy to read front panel LEDs
show ongoing switch status and simplify
troubleshooting.
Quality and Reliability
Allied Telesis is a worldwide leader in unmanaged
Ethernet switches. Shipping more than 250,000
unmanaged switches each year, Allied Telesis
offers proven reliability and industry recognized
quality.
Key Features
•810/100TX ports
•Wirespeed technology
•Non-blocking architecture
•Auto-negotiation ports
•Auto MDI/MDI-X ports
•Transparent to VLAN packets
•Half and full-duplex flowcontrol
•External or internal power supply option
•Sturdy metal case

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2007 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000158 Rev. C
AT-FS708LE |Unmanaged Fast Ethernet Switches
Performance
14,800pps for 10Mbps Ethernet
148,000pps for 100Mbps Fast Ethernet
MAC addresses Up to 4K
Packet buffer 256K
Half/full-duplex
Auto-negotiation
Auto MDI/MDI-X on all ports
Interface Connections
10/100TX RJ-45
Power Characteristics
Frequency 50 to 60Hz
7.5vDC, 1A
Environmental Specifications
Operating temp. 0ºC to 40ºC (32ºF to 104ºF)
Non-operating temp. -25ºC to 70ºC (-13ºF to 158ºF)
Operating humidity 5% to 80% non-condensing
Storage humidity 5% to 95% non-condensing
Technical Specifications
Physical Characteristics
Dimensions 3.6cm x 24.9cm x 11.6cm
(H x W x D) (1.4" x 9.8" x 4.6")
Weight 0.4kgs (0.75lbs)
Wall-mount or Desktop
Units come with wall-mount brackets
Standards and Compliance
IEEE 802.3 10T Ethernet
IEEE 802.3u 100TX Fast Ethernet
IEEE 802.3x Flow control
Electrical/Mechanical Approvals
UL 1950
CSA 22.2 No. 950
FCC/EN55022 Class B
VCCI Class B
EN60950 (TUV)
EN55024
CE
Ordering Information
AT-FS708LE-xx
8port 10/100TX unmanaged switch with
external power supply
Where xx = 10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
