ALLOY ACCESS KLIKFOLD UNIT User manual

For all those tight corners where
height and space is limited, gain
speedy, easy access with the Klik
Fold Unit.
Ideal for one man use, unfold the
unit, fit the board and start work.
Easily portable and manoeuvrable,
either open or closed, the unit
passes easily through standard
doorways.
Both lightweight and robust.
Provides a working platform
0.7m wide and 2m long.
Six optional platform levels
between 0.2m and 1.7m will suit
most requirements.
Fitted with lockable 5” castors
and non-slip platform boards.
Captive folding bracing system
means minimum components.
When closed the board will hook
onto the unit for compact
storage.
Easily transportable, folds flat to
fit in a small van, or on a roof
rack.
Klikfold Unit
Manufactured To a TUV Certified ISO 9001:2008 Quality Control System
LOW LEVEL KLIKFOLD UNIT
Optional Extra’s Include
Adjustable Legs and Castors –
for uneven ground
Extension packs to generate
platform levels of 3m, 3.6 and
5.4m.
Low Level Tool Tray
No Bumps Impact Protector

Klikfold Unit
Platform Height
0.2m –1.7m
Safe Working Load
250Kg
Dimensions
0.7m Width x 2m Length
Weights
Basic Unit = 44 Kgs
G’rail Pack = 12.5 Kgs
LOW LEVEL KLIKFOLD UNIT
Manufactured To a TUV Certified ISO 9001:2008 Quality Control System
Klikfold Unit
Assembly Instructions
Ensure all parts are present and are not damaged before
assembling
Klikfold Basic Unit
Comprising of…
4 x K548 - Castors with adaptors
1 x KFFU - Klikfold Base unit
1 x KFPT - Klikfold Trapdoor platform
1. Ensure that all castors are firmly fitted to the folding frame by
tightening the bolt located directly under the castor housing.
2. Open folding frame and engage toggle clamps.
3. Position platform on a rung at desired level.
4. Always gain access to the platform via the trapdoor, when
appropriate.
Klikfold Guardrail Set
Comprising of…
2 x TTGF - Guardrail frames
4 x BKH1 - 2m Horizontal braces
1. Fit the guardrail frame to folding frame
2. Engage interlock clips
3. Fit four horizontal braces to vertical
members of the frames. Hooks must face
outwards on the vertical.
1.
Klikfold Toeboard Set
Comprising of…
2 x TKL1 - 2m Toeboard length
2 x TKSW - Single width Toeboard end
1. Fit the toeboards around the platform as
illustrated to create a barrier around the
foot area.
1.
General Safety Rules:
1. Do not use on unstable ground such as loose
bricks, boxes or blocks.
2. Remove all personnel and materials before
moving the unit.
3. When moving the unit, apply force manually by
pushing at the base.
4. Do not gain extra height by using boxes,
ladders, on the platform.
5. Ensure that the castors are locked before use.
6. Do not overload the unit.
7. Do not overreach out of the unit.
MAX SAFE WORKING LOAD FOR
PLATFORM / STRUCTURE
250KG
