Performance Tool W41018 User manual

WARNING
It is the owner and/or operators’ responsibility to study all WARNINGS,
operating, and maintenance instructions contained on the product label and
instruction manual prior to operation of this tool. The owner/operator shall retain
product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or
warning labels and while in use, maintaining the unit in good working order. If the
owner and/or operator are not fluent in English, the product warnings and instructions
shall be read and discussed with the operators’ native language by the purchaser/
owner or his designee. Make sure that the operator comprehends its contents. Safety
information shall be emphasized and understood prior to usage. The tool shall be
inspected per the operating instructions.
Users of this tool must fully understand these instructions. Each person operating this
product must also be of sound mind and body and must not be under the influence of
any substance that might impair their vision, dexterity, or judgment. Protect yourself
and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service
department at: 1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.
ADJUSTABLE ENGINE SUPPORT
OWNERS MANUAL
Stock Number W41018
On occasion, after printing of our literature is completed, our manufacturers may make
changes and/or modifications to merchandise which will not be reflected in this manual.
Although we strive to maintain complete and accurate information, it is possible in some
instances, that the product may differ slightly from printed specifications. Illustrations are
intended for reference only. Actual merchandise may vary. Wilmar is not responsible for
typographical errors.
Please read these instructions carefully and retain them for future use.
© Copyright 2016 WILMAR CORPORATION,
P.O. Box 88259 Tukwila, WA 98138
1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail
purchasers. These warranties give specific legal rights. Except where prohibited by local law, the
law of the State of Washington governs all warranties and all exclusions and limitations of
warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship
under normal use and service. A defective product may be returned for a free replacement within 90
days from the date of purchase, provided that product is returned to place of purchase immediately
after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE
TOOL® will replace at no charge any parts which our examination shall disclose to be defective and
under warranty. These warranties shall be valid only when a sales receipt showing the date of
purchase accompanies the defective product or defective part (s) being returned. For part (s) after 90
days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables
which must be replaced under normal use and service. These warranties shall not apply to any
product or part which is used for a purpose for which it is not designed, or which has been repaired
or altered in any way so as to affect adversely its performance or reliability, nor shall these
warranties apply to any product or part which has been subject to misuse, neglect, accident or wear
and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume
any liability in connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE
TOOL® makes no express or implied warranties of any kind with respect to its products. In
particular, PERFORMANCE TOOL® makes no implied warranty of merchantability and no implied
warranty of fitness for any particular purpose, except that for goods purchased primarily for
personal, family or household use and not for commercial or business use, PERFORMANCE
TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics,
and for the duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations
may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages
resulting from or in any manner related to any product, or to the design, use, or any inability to use
the product. The sole and exclusive remedy for a defective product or part shall be the repair, or
replacement thereof as provided above. The laws on limitation of remedies or on consequential,
incidental or special damages may vary from state to state, so the above limitations may not apply in
all cases.
© Copyright 2016 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138

Specifications are subject fo change without notice
OPERATION
SAFETY IMFORMATION
1. Always wear eye protection and other safety equipment such as dust
mask, non-skid safety shoes, hard hat, hearing protection, and work
gloves. Using safety equipment that fits the appropriate conditions will
reduce personal injuries.
2. Maintain all labels on the tool. They contain important safety information. If
unreadable or missing, contact Performance Tool for a replacement label.
3. Never exceed the maximum weight limit of 700 Pounds.
4. Do not work on an engine that is only supported by the Engine Support. Do
not intentionally jar, jostle or move the engine. Moving the engine in any way
creates a safety hazard. This may cause the engine support to jump the fender
channels and fall resulting in serious personal injury or property damage.
5. Never work underneath an engine while it is supported only by the
Engine Support.
6. The warnings, precautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied by
the operator.
1. Read the vehicle owner’s manual to determine the location of its lifting points.
2. Never try to move a running or hot engine. Give sufficient time for the engine to cool
down entirely before beginning any operations.
3. Park the car on a flat surface, apply the parking brakes and chock the wheels.
4. Loosen Wing Bolts (10) and spread the standing base assemblies (5.1). Place the feet
of the base assembly over the lips adjacent to the fenders of the car. Center the
engine support bar assembly over the engine, tighten the Wing Bolts (10).
5. Attach the Chains (6) to the engine at the appropriate lifting points. Some models
have a lifting plate mounted to the top of the engine for lifting. If not then loop the
chains around the engine and secure to a place capable of holding the weight, not to
exceed 700 pounds.
6. Attach the other end of the chain to the bottom of the Support Hook (7).
7. Turn the Handles (9) clockwise until the Chains are taut and the engine is held securely
in place.
8. Loosen the engine mounts and turn the Handle (9) slowly clockwise until the engine’s
weight is supported by the chains.
8. Never work on the engine while it is supported only by the Engine Support. Moving the
engine while it is suspended only by the Engine Support can cause the Engine
Support to fail or shift, resulting in serious personal injury and/or property damage.
9. To prevent accidents, lower and reconnect the engine when finished working. The
Engine Support is not intended to be used as a long-term suspension device.
ASSEMBLY
1. Place the Standing Block (5) on the Standing Bracket (5.1). Hold in place with
clevis pin (11), washer (12) and pin (13).
2. Use provided hand knob (1) and washer (2), attach standing base assembly
(5/5.1) to extension (4). Repeat on the other side of the Engine Support. Tighten
knobs (1).
3. Slide the stand /extension assembly into the crossbeam (3). Adjust to t and
tighten bolts (10). Slide the hook (7) through beam (3) and secure with the wash-
er (8) and handle (9). The hook can be adjusted once the chain (6) is attached to
the engine, or engine bracket.
This Engine Support Bar is designed for engines 700 lbs. or less. Enables parts
or mechanisms underneath the engine to be accessed for repair or removal.
Provides time savings and safety to the mechanic.
NO. DESCRIPTION Q’TY NO. DESCRIPTION Q’TY
1 Handwheel ...................................2 7 Hook.........................................1
2 Washer .........................................2 8 Washer......................................1
3 Crossbeam ...................................1 9 Handle......................................1
4 Extension......................................2 10 Bolt ........................................2
5, 5.1 Base .............................................2 11 Pin .........................................2
6 Chain ............................................1 12 Washer......................................2
13 Pin.............................................1
