ALORAIR Ironmen28L-B User manual

Ironmen28L-B
ALORAI R
E-mail: [e-mail]
Add: North Carolina USA
Registrate by scanning

※ ※Table of Contents
Introduction
Specifications
Notice priorities
Operation Panel
Use Instructions
Maintenance
.............................................................................................................................. 01
........................................................................................................................... 01
....................................................................................................................... 02
....................................................................................................................... 03
Preparing the Unit for Use..................................................................................................... 05
....................................................................................................................... 06
............................................................................................................................. 08
Troubleshooting...................................................................................................................... 0 9
DEHUMIDIFIERS
The machine through a vapor compression refrigeration principle , which can efficiently
remove airborne moisture . Especially for the home , office and other space dehumidification
range to prevent items from moisture , mildew , dry clothes can protect senior musical
instruments, high-end furniture and other unaffected humid environment , to create a good
living environment is a good helper .
※ ※Features/Specifications
Low Sound Levels <45dBA
Super Cop,3.0L/Kwh
The temperature control defrosting , more thorough, and more quick
large Water trank
Humity can be fixed within 1%
Human handspike design
Water Full protection
R410a Refrigerant
Self-Checking Function
Automatic humidistat control,Display Tube TEM
Timing Memory starting
Universal Wheel
Purification
Note: This dehumidification capacity is at room temperature 30 ℃, relative humidity of
80% income test conditions
Customer Service:
For additional questions concerning the operation of your dehumidifier,
Identification:
Model Number Ironmen 28L-B
Serial Number__________________________ Date of Purchase__________________________
For future reference, write down the model, serial number, and date of purchase so you
can identify your unit when seeking assistance. NOTE: data label on back of unit includes
serial number.
※Introduction※
-1-
DEHUMIDIFIERS
Warranty....................................................................................................................................10

-2-
WARNING
1Unplug when cleaning or storing this dehumidifier .
2. Do not immerse the machine in water or near water .
3. Do not place the machine near a heating device or flammable dangerous place.
4. Do not put your fingers or other objects into the outlet or plug the outlet .
5. Do not sit on this machine table .
6. Follow the requirements of the tank to drain .
7. Do not use this machine in a sealed environment to avoid fire.
8. Make sure the condensate drain down the installation so that you can continue to be
excluded .
9. If the power cord is damaged , please find the manufacturer or a qualified service
organization .
10. prohibit people with and without self-care ability or children to use the machine without
a guardian.
11. The machine must have a reliable ground lead or grounded outlet.
.
When using this machine , please note the following safety warnings :
DEHUMIDIFIERS
※ Rear View
Control panel
Air Intake
Air Outlet
Tank cover
Filter
External Pipe
-3-
DEHUMIDIFIERS
※Unit Overview※
※ Front View
Front cover
Wheel
Handle
LOGO
Subject
Power line
ALOEAIR
Installation:
WARNING! 240 Volts AC may cause serious injury from electric shock.
1. Disconnect electrical power before servicing 2. Only plug unit into grounded electrical outlet
3. Do not use extension cord 4. Do not use plug adapter
Power Supply: 220V, 50 Hz AC Only 1 Phase
Outlet Requirement: 3-Prong, GFI
Circuit Protector: 15 Amp Time Delay Fuse or Circuit Breaker

※Preparing the Unit for Use※
A. The placement of the machine : The machine can be placed in the figure requires full
play to its performance.
-4-
DEHUMIDIFIERS
-5-
DEHUMIDIFIERS
≥
≥
≥
≥
（ ） Running lights : After power- beep is heard, the machine into standby mode, and this
does not light , turned on, the lights lit , after the shutdown , the lights off . ( Note: The standby
display digital display profit or humidity )
（2）Water full indicator: When the water tank is full ( ie, magnetic switch off ) , the machine
automatically standby , the lights flash , the buzzer sounds five beeping . Water full signal disappears
, then automatically the original mode, the compressor 3 minutes effective protection .
1
※Lamp operation
success. While holding down the Up and Down keys 2S can lock the keys , lock button to exit the
same way ).
C. Air Purifier Button :Press this button to start the air purification , dehumidification function off
.
D. Anion Button : Press this button to start the anion .
E. Timing Button: In case the machine is running , pressing the button for the time off, but the
machine on a lower power operation , press this button for regular boot .
A. Power Button:
B. " Up" and "Down" Button:
“Switch”key: turn on or off for each time in the boot, the conver sion between
off once . Note shutdown after fan delay stopped after 1 minutes.
1）Adjust the humidity figures used for the humidity set button once every 1% rise or fall .
2）Adjust the time used for digital switch time setting, up or down button once every hour.
Note: The "up" and "down" button to set within the 10S does not operate after that set
※Control Panel Operation
（3）
lamp is off .
（4）Defrost indicator: When entering this light Always defrost operation , defrost termination
or other states , this lamp is off .
（5）Air purification lights: Anion lights are only lit when it is enabled , other state off.
（6）The lamp timer setting : Press time setting key to set the timer switch , the light flashes,
the setting is complete or in timing.
Continuous running lights : In continuous mode , the lights lit , the other states , this
EDC
Working
Defrost
》
》
88
Power
Cont.
Timing
Anion
Air
Purif.
Full Indication
Digital display
B
A
※Operating instructions※

-6-
DEHUMIDIFIERS
1 . " On / Off " Button :
a.Press this " "Button, the unit will start running .
b.Press this" "button again,the unit will stop running .
※ Preferably stand for 3 minutes , so that the remaining water droplets on the evaporator
flows into the water tanks .
Put External pipe through
the Vias on radiator cap
and connect it to the water
pipe which been fixed on
water collector
※Use Instructions※
-7-
DEHUMIDIFIERS
Please unplug the power cord after the machine is turned off to save standby power
consumption and avoid the risk of accidents .
2 ."Up" and "Down" Button
Used to adjust the set humidity , also used to adjust the timing shutdown and timing for the
start of the set time.
• Humidity setting adjustment range : Between 35 to 90 percent , up or down button once for
each 1% , when the set humidity < 35% , digital display "C0" enter the continuous dehumidification
mode , the first power-on defaults "50 %." ( Note : Continuous dehumidification mode not affected
by humidity )
• Time setting adjustment range : 00, 01 to 24 hours, up or down button once every 1 hour , 00
digital display indicates the timing when setting off or regular boot cancellation or no timing
settings.
Note: The regular boot and shutdown timing not both timing and timing is automatically
canceled after a power failure , do not remember.
3. Air Purifier :Press the button, air purification function is activated .
4. Anion : Press this button to start the anion .
5. Time off and Time on operations
Boot mode, press the " timer setting " key to start the timer off function , digital timer flashes
set the time, The display number of initial timing is 00,press the arrow keys to adjust the settings
within 5S(no flashes when Hold the Up/Down key continuously).adjusted to the time required and
leave your finger from panel,said the setuo is completed after 5S with no touch ,display back to
present condition humidity.( Note : In standby mode, press the " timer settings " button to star t
the timer on function )
Always one Buzzer sound with every successful key pressing,only one Buzzer sound as weel
as to continuously press when finger left to Button.
6. Tank operations Notes
1 ) After the machine stops running when pulling the tank to maintain a steady water tank
removed.
2) While moving the tank ready to pour with both hands to hold up the bottom of the tank.
3 ) Do not move and damage the tank float .
Remove the air intake frame
then Install the HAPE fliter
or Activated Carbon Fliter in
F. In order to avoid the repeated water tank caring,It is in strongly recommendation that to
extend the draining to ground if this unit would in long term running.if the outlet pipe get wrapped
or deflated,it would resulte bad water follow and even cause dead machine.
B. This machine uses a value consistent with the nameplate power outlet must be grounded
port.
C. Remove the power cord and reliably , securely plugged into a power outlet.
D. Make sure the machine 's inlet and outlet is not blocked or blocking other objects. Ensure the
inlet and outlet of the machine can effectively play the smooth performance of the machine and
reduce electricity costs .
E. Before Switch to air purification model,you should Install in the HAPE fliter or Activated
Carbon Fliter in side the air intake frame.

-8-
DEHUMIDIFIERS
3. Do not use the machine near the stove , heaters and other heat sources or air outlet of places, so as not to
affect the dehumidifying effect or danger.
4. Do not use machine in where have Water Splash potential problem,to prevent the leakage of dangerous
5. After the machine should be placed firmly before use, to prevent dumping, to avoid injury.
6. When using dehumidifiers in wooden furniture , floors and other environments in attention control
humidity , excessive dry conditions may cause the wood to crack.
7. Severe turbulence , impact and tilt angles are large damage the machine : If running noise becomes larger
and so on . And the inclination angle of the large residual moisture may cause the machine overflow.
8. Storage H, dehumidifier
When you are not using the product for a long time , and intended to be stored or collection,
consider the following steps:
1) The residual water tank emptying.
2) The dust filter clean .
3) Placement. fresh dry environment .
※ Troubleshooting ※
Solution
Trouble cause
Machine Won’t Work/
Display is Blank
Display Blank. Power outage
or poor connection
Check Power Supply
Check both ends of powercord
for good connection
Place unit on flat surface
in vertical orientation
Room temperature whether in
5℃~ 35℃this inner?
machinery not exceed
water or dehumidify
quantity small
Clear the filter
Filtration net whether jam
Room inner humidity temperature
too low Normal work condition
Water Full protection Repositioning or pour water tank
Reinstall the float
Outlet or the outlet is blocked Clear obstructions
Trouble code:E1 Humidity Sensor or
communication error
Check sensor cable is properly
connected.Replace the Senser
-9-
DEHUMIDIFIERS
Trouble code HI:
Trouble code L0: Unit is sensing room temperature
below 33°F.
Trouble code E4: Water Full protection
Unit is sensing room temperature
above 100°F.
Decrease Room Temp
Check Sensor
Check Sensor Cable
Increase room temperature
Check Sensor
Check Sensor Cable
The water tank float tank drained
or re- install the float switch
normal contact
1. Clean the filter
Because of the air filter is easy to
accumulate dust , blocking the air intake
p a s s a g e , t h e r e b y a f f e c t i n g t h e
dehumidification effect , therefore, must be
regularly cleaned.
If the machine is in larger dust places,
should be cleaned once a ~ 5 days .
If the machine is used in relatively clean
environment can be cleaned once a month.
Clean the filter method :
1.Remove the filter,Filiter may be cleaned by
Vacumming or By washing with warm water(no soap or Solvents),Insure Fliter is dry prior to Restarting unit
2. Make Tank Empty and Unplug the Unit when it is not in using.
Filter
※ ※Maintenance and Repair
WARNING! Be sure to turn off the power before for maintenance to avoid accidents !

-10-
DEHUMIDIFIERS
Seller warrants the equipment to be free from defects in workmanship and
materials for a period of 12 months after shipment (60 months/5 years on compressor,
evaporator and condenser). This warranty is limited, however, to the repair or
replacement of defective equipment. If it is necessar y to return unit for service,
customer is solely responsible for proper packaging, transportation costs. Customer
must initiate warranty process by contacting factor y. Do not send any component or
product back to factory without Return Material Authorization.
This limited warranty does not apply to any part or component that is damaged in
transit or when handling, has been subject to misuse, corrosion, chemicals, acts of God
has not been installed, operated or serviced according to the Seller's instructions, or
has been operated beyond the factory-rated capacity or has been altered in any way.
Routine maintenance is not covered by this warranty.
Seller's liability is limited to replacement of defective parts or components and
does not include any cost of labor (including, but not limited to, labor to remove
and/or reinstall any defective part), refrigerant or piping. Customer may elect to have
unit fixed locally in which case required replacement parts will be sent to customer at
customer's expense.
ALORAIR shall not be responsible for loss of use of any product, loss of time
inconvenience, or damage to other equipment, or any other indirect or consequential
damage with respect to property whether as a result of breach of warranty, neglect, or
otherwise.
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL
OTHERWARRANTIES EXPRESSED OR IMPLIED, IN LAW OR IN FACT, INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR
PURPOSE.
ALORAIR's total liability, regardless of nature of claim shall not exceed original
purchase price of the product. If a product or component is replaced while under
warranty, the applicable warranty period shall not be extended beyond the original
warranty time period.
The foregoing shall constitute the total liability of seller in the case of defective
performanceof all or any of the equipment or services provided to Buyer. Buyer agrees
to accept and hereby accepts the foregoing as the sole and exclusive remedy for any
breach or alleged breach of warranty by Seller.
※ Warranty※
