Tri Power X33 HE 30-125KVA
User Manual

Page 1to 52
Introduction
Thank you for choosing our product.
Alpha and Outback Energy is specialised in the design, development and production of Uninterruptible Power
Supplies (UPS)
The TRI POWER X33 HE described in this manual is a high quality, meticulously designed product, built to
guarantee the best performance.
This manual contains detailed instructions on how to use and install this product.
For information on how to use this equipment and obtain the best performance, this manual must be
carefully kept near the TRI POWER X33 HE and it must be READ BEFORE OPERATING IT.
© Reproduction of this manual or any portion thereof without the manufacturer’s consent is prohibited.
The manufacturer reserves the right to revise or make improvements to its product at any time without prior notice.

Page 2to 52
Contents
Overview.......................................................................................................................................4
Tri Power X33 HE 30 –40........................................................................................................................4
Front views of the Tri Power X33 HE........................................................................................................5
Views of the TRI POWER X33 HE connections........................................................................................7
Rear view of the Tri Power X33 HE..........................................................................................................8
View of the control panel..........................................................................................................................9
Separate bypass input (optional)..............................................................................................................9
Installation............................................................................................................................................................... 10
Storage of the Tri Power X33 HE ............................................................................................................................ 10
Preparation for installation......................................................................................................................10
Preliminary information............................................................................................................................................ 10
Electromagnetic compatibility.................................................................................................................................. 11
Installation environment........................................................................................................................................... 11
Removing the Tri Power X33 HE from the pallet..................................................................................................... 12
Preliminary check of contents.................................................................................................................................. 14
Positioning the Tri Power X33 HE ........................................................................................................................... 14
Operations to access the terminals of the Tri Power X33 HE................................................................................. 14
Electrical connections ............................................................................................................................15
Diagrams of connections to the electrical system ................................................................................................... 15
Tri Power X33 HE internal protections .................................................................................................................... 18
External protection devices ..................................................................................................................................... 19
Cross section of the cables ..................................................................................................................................... 20
Connections............................................................................................................................................................. 20
Connections of the model with separate bypass..................................................................................................... 21
R.E.P.O..................................................................................................................................................21
External Sync.........................................................................................................................................22
Remote maintenance bypass connection...............................................................................................22
Connecting the Tri Power X33 HE to the Battery Box (optional).............................................................24
Setting the nominal battery capacity –software configuration................................................................................ 25
External temperature probe....................................................................................................................25
Remote synoptic panel (optional)...........................................................................................................25
USE.............................................................................................................................................. 26
Description.............................................................................................................................................26
Preliminary operations and first start-up.................................................................................................27
Mains start-up........................................................................................................................................29
Battery start-up ......................................................................................................................................29
Switchingoff the Tri Power X33 HE.........................................................................................................29
Graphic display ......................................................................................................................................30
Menu display..........................................................................................................................................31
Operating mode .....................................................................................................................................32
Maintenance bypass (SWMB)................................................................................................................32
Redundant auxiliary power supply for automatic bypass........................................................................33
Auxiliary “power share” and “power out” sockets (optionals)...................................................................33
Power walk-in.........................................................................................................................................33
Power reduction for 200/208V phase-neutral loads................................................................................34
CONFIGURING THE TRI POWER X33 HE ...........................................................................................35

Page 3to 52
Communication ports.............................................................................................................................37
RS232 AND USB CONNECTORS.......................................................................................................................... 37
Communication Slot................................................................................................................................................. 38
AS400 PORT........................................................................................................................................................... 38
Buzzer....................................................................................................................................................40
Software.................................................................................................................................................41
Monitoring and control software .............................................................................................................................. 41
Configuration software............................................................................................................................................. 41
Troubleshooting.........................................................................................................................42
Status / alarm codes ..............................................................................................................................46
Technical data............................................................................................................................50

Page 4to 52
Overview
Tri Power X33 HE 30 - 40
The TRI POWER X33 HEs in the 30 –40 series have been designed using state-of-the-art technology, in order to
ensure the best performance for the user. The use of the new control boards based on microprocessor architecture
(DSP + µP inside), together with the adoption of specific circuit solutions that use last-generation components, have
allowed to reach high performances such as:
ZERO IMPACT SOURCE: ensures low input distortion, a power factor close to 1, and maximum generator
set compatibility.
BATTERY CARE SYSTEM: allows a customised management for different battery types and their
continuous monitoring, therefore enhancing battery efficiency and durability.
SMART INVERTER: guarantees an extraordinary efficiency even at a low-load percentage. Moreover, it
ensures a stable low-distortion output tension even in extreme operating conditions.
Thanks to these and other features, and thanks to its ease of use, the 30 –40 series presents itself as a reference
point among three-phase UPSs.

Page 5to 52
Front views of the Tri Power X33 HE
Control panel with graphic display Wheels for moving the TRI POWER X33 HE
Front door with lock Brake rod
Ventilation grid

Page 6to 52
Slot for auxiliary communication board
From the left:
Input isolator / Separate bypass isolator (optional) /
Manual bypass isolator / Output isolator
From the left:
Battery start button (COLD START) /
R.E.P.O. (Remote Emergency Power Off)
connector / Contact holder for AS400 /
USB communication port / RS232
communication port
Terminal cover
Battery fuse holder isolator

Page 7to 52
Views of the Tri Power X33 HE connections
Power connections: EXTERNAL BATTERY, INPUT, SEPARATE BYPASS (optional), OUTPUT
Connection for external synchronization signal
Connection for remote maintenance bypass command
Connection for external Battery Box temperature probe

Page 8to 52
Rear view of the Tri Power X33 HE
Parallel board slot (optional)
Power board fans
Powershare socket / Power out socket
Battery charger fan
Power relay board slot (optional)

Page 9to 52
View of the control panel
Mains power LED
Low battery LED
Battery power LED
ECO mode LED
Load on bypass LED
Graphic display
Stand-by / alarm LED
F1, F2, F3, F4 = FUNCTION KEYS. The function of each key is indicated at the bottom of the display and it varies
according to the menu.
Separate bypass input (optional)
THE OPTIONAL DI VERSION OF THE TRI POWER X33 HE SERIES HAS SEPARATE BYPASS AND INPUT
LINES.
The TRI POWER X33 HE series with Separate Bypass allows a separate connection between the input and the
bypass lines. The TRI POWER X33 HE output is synchronised with the bypass line, in order to avoid incorrect
voltage changeovers during the alternate phases, in case an automatic bypass or a maintenance isolator closure
occurs.

Page 10 to 52
INSTALLATION
ALL OPERATIONS DESCRIBED IN THIS SECTION MUST BE CARRIED OUT BY QUALIFIED
PERSONNEL ONLY.
The company assumes no responsibility for any damage caused by flawed connections or by
operations that are not described in this manual.
Storage of the Tri Power X33 HE
The storage area must respect the following characteristics:
Temperature: 0°÷40°C (32°÷104°F) Relative humidity degree: 95% max
Preparation for installation
Preliminary information
TRI POWER X33 HE Models
30
40
Nominal power
30kVA
40kVA
Operating temperature
0 ÷ 40 °C
Max. relative humidity during operation
90 % (no condensation)
Max. installation height
1000 m at nominal power rating
(-1% power for every 100 m over 1000 m)
max 4000 m
Dimensions W x D x H
440 x 850 X 1320 mm
Weight with no batteries
135kg
145kg
Weight with batteries
335kg
345kg
Dissipated power with nominal resistive
load (pf=0.9) and buffer battery (1)
1.4 kW
1205 kcal/h
4780 B.T.U./h
1.5 kW
1290 kcal/h
5120 B.T.U./h
Dissipated power with nominal distorting
load (pf=0.7) and charged battery (1)
1.34 kW
1150 kcal/h
4565 B.T.U./h
1.35 kW
1160 kcal/h
4605 B.T.U./h
Flow rate of the fans to remove heat from
the installation area (2)
750mc/h
800 mc/h
Current dispersion to earth (3)
< 50 mA
Protection level
IP20
Cable input
On the rear from the bottom
(1) 3,97 B.T.U./h = 1 kcal/h
(2) The following formula can be used to calculate the air flow rate: Q [mc/h] = 3,1 x Pdiss [kcal/h] / (ta - te) [°C]
Pdiss is the power expressed in kcal/h dissipated by all the devices installed in the installation environment.
ta= ambient temperature, te=external temperature. In order to take leaks into account, it is necessary to
increase the value obtained by 10%.
The table shows an example of a flow rate with (ta - te) =5°C and a rated resistive load (pf=0.9).
(Note: This formula is applicable only if ta>te. If not, the TRI POWER X33 HE installation requires an air-
conditioning system).
(3) The dispersion current of the load is added to that of the TRI POWER X33 HE on earth wire.

Page 11 to 52
Electromagnetic compatibility
This TRI POWER X33 HE product conforms to the current electromagnetic compatibility (EMC) regulations (C2
class). It may cause radio interference in the home environment. The user may have to adopt supplementary
measures.
This product is for professional use in industrial and commercial environments. Connections to USB and RS232
connectors must be made with the cables provided, or at least with shielded cables less than 3 metres long.
Installation environment
As for the installation area of the TRI POWER X33 HE, and, if necessary, of the Battery Box, follow carefully the
following instructions:
Avoid dusty environments
Make sure that the floor is level and that it is able to withstand the weight of the TRI POWER X33 HE (and of
the Battery Box)
Avoid environments which are too narrow, as they could impede normal maintenance operations
The relative humidity should not exceed 90% with no condensation
Make sure that the ambient temperature remains between 0 and 40°C while the TRI POWER X33 HE is
operatingThis TRI POWER X33 HE can operate with an ambient temperature between 0 and 40°C. The
recommended working temperature for the TRI POWER X33 HE and the batteries is between 20
and 25°C. In fact, with a working temperature of 20°C, a battery has an average operating life of 5
years, whilst with a working temperature of 30°C the operating life is halved.
Avoid positioning the TRI POWER X33 HE in places exposed to direct sunlight or hot air
To maintain the temperature in the installation area within the above mentioned range, there must be a system to
dispose of the dissipated heat (the kW / kcal/h / B.T.U./h values dissipated by the TRI POWER X33 HE are shown in
the table in the previous page). The methods that can be used are the following:
Natural ventilation
Forced ventilation, recommended when the external temperature is lower (e.g. 20°C) than the temperature at
which the TRI POWER X33 HE or the Battery Box has to be operated (e.g. 25°C)
Air-conditioning system, recommended when the external temperature is higher (e.g. 30°C) than the
temperature at which the TRI POWER X33 HE or the Battery Box has to be operated (e.g. 25°C)

Page 12 to 52
Removing the TRI POWER X33 HE from the pallet
CAUTION! TO AVOID HARMING PEOPLE AND/OR DAMAGING THE EQUIPMENT, FOLLOW
CAREFULLY THE FOLLOWING INSTRUCTIONS.
SOME OF THESE INSTRUCTIONS NEED TO BE CARRIED OUT BY TWO PEOPLE.
Cut the straps and remove the
cardboard box by sliding it upwards.
Remove the packaging material.
Remove the accessory box.
NOTE: the accessory box can be either
inside the packaging, or behind the USP
door.
Remove the 2 brackets securing the TRI POWER X33
HE to the pallet by unscrewing the screws marked A
and B in the figure.
The previously removed brackets can also be used as slides. Secure the slides to the pallet by using the
type A screws, making sure they are aligned with the wheels.

Page 13 to 52
Screw the brake rod completely, so to separate it from the pallet
Make sure that the door is firmly closed.
CAUTION! Push the TRI POWER X33 HE from the rear with great care. Given the weight of the
equipment, this operation needs to be carried out by two people.
NOTE: It is recommended to keep all parts of the packaging for further use

Page 14 to 52
Preliminary check of contents
Once the package has been opened, proceed to checking the contents:
metal slides, guarantee document, user manual, cd-rom containing the TRI POWER X33 HE management software,
serial connecting cable, 4 battery fuses (to be inserted in the "SWBATT" fuse holders), door key.
Positioning the Tri Power X33 HE
When positioning the equipment, the following points should be taken into account:
The wheels are intended for accurate positioning, therefore for small movements only.
The plastic parts and the door are not suitable for pushing or gripping the TRI POWER X33 HE.
Sufficient space should be left in front of the equipment, for it to be switched on and off and in order to allow
carrying out maintenance operations on it (≥ 1,5 metres).
The rear part of the TRI POWER X33 HE should be placed at least at 30 cm from the wall, to allow the air
blown by the ventilation fans to outflow correctly.
No objects should be placed on its upper surface.
Once the equipment has been positioned, secure it with the apposite brake rod (see "Front views of the TRI
POWER X33 HE ").
In earthquake-prone zones or in mobile systems it is possible to use the brackets securing the TRI POWER X33 HE
to the pallet to anchor the machine to the ground (see figure below). In normal conditions the brackets are not
necessary.
Operations to access the terminals of the TRI POWER X33 HE
To carry out the following operations, the TRI POWER X33 HE must be disconnected from the
mains power supply, switched off, and with all the equipment switches and fuse holders open.
Follow the instructions provided below to open the TRI POWER X33 HE:
Open the door using, if necessary, the key provided
Remove the terminal cover in correspondence with the switches (see "Front views of the TRI POWER X33
HE" )
Once the installation operations inside the equipment have been completed, replace the terminal cover and close the
door.

Page 15 to 52
Electrical connections
WARNING: a 4-wire three-phase distribution system is required.
The TRI POWER X33 HE must be connected to a power supply line made up of 3 phases + neutral + PE
(protective earth) of TT, TN or IT type. Therefore, the phase rotation must be respected.
Optional TRANSFORMER BOXES to convert the distribution systems from 3 wires to 4 wires are available.
Diagrams of connections to the electrical system
TRI POWER X33 HE with no modification of the neutral regime
TRI POWER X33 HE with input galvanic isolation
TRI POWER X33 HE with output galvanic isolation

Page 16 to 52
TRI POWER X33 HE with no modification of the neutral regime and with separate bypass input
TRI POWER X33 HE with input galvanic isolation and with separate bypass input
TRI POWER X33 HE with output galvanic isolation and separate bypass input

Page 17 to 52
Separate bypass on separate lines:
When the separate bypass option is present, protective devices should be placed on both the main power supply line
and the bypass line.
Note: The neutral of the input line and that of the bypass are commoned inside the equipment, therefore they must
refer to the same potential. In case the two power supplies were different, an isolation transformer would be
necessary on one of the inputs.
TRI POWER X33 HE with no modification of the neutral regime and with separate bypass input connected to
an independent power supply line
TRI POWER X33 HE with separate bypass input connected to an independent power supply line and with
input galvanic isolation
TRI POWER X33 HE with separate bypass input connected to an independent power supply line and with
output galvanic isolation

Page 18 to 52
Tri Power X33 HE internal protections
The table below shows the sizes of the TRI POWER X33 HE isolators and the battery fuses (SWBATT) which are all
accessible from the front of the TRI POWER X33 HE. Moreover, the table shows the maximum input and the
nominal output currents.
Fuses must be replaced with ones of the same type and of the same rating, as shown in the table.
Isolators and currents
Tri
Power
X33 HE
Mod.
Non-automatic switches
Battery isolator
Currents
[kVA]
TRI POWER X33 HE input
/ Separate bypass
TRI POWER X33 HE output /
Maintenance
Battery fuse
Input
current [A]
Output
current [A]
SWIN / SWBYP (optional)
SWOUT / SWMB
SWBATT
Max *
Nominal
30
63A(4P)
63A(4P)
80A gG 400V (22x58)
54A
46A
40
100A(4P)
100A(4P)
100A gG 400V
(22x58)
70A
61A
* The maximum input current refers to a nominal load (PF = 0,9), to a 346V+ input voltage, and battery charger
under a 7A charge.
Short circuit
If a fault occurs on the load, the TRI POWER X33 HE protects itself by limiting the value and the duration of the
current supplied (short circuit current). These values also depend on the TRI POWER X33 HE operating status at the
time of the fault, which can be either:
TRI POWER X33 HE in NORMAL OPERATION: the load is instantly commutated to the bypass line (TRI
POWER X33 HE 30kVA I2t=20000A2s; TRI POWER X33 HE 40kVA I2t=25000A2s): the input line is
connected to the output with no internal protection (locked after t>0.5s)
TRI POWER X33 HE in BATTERY OPERATION: the TRI POWER X33 HE protects itself by supplying an
output current which is about 1.5 the nominal current for 0.5s, after which it shuts down.
Backfeed
This TRI POWER X33 HE is also equipped with an internal protection against backfeed through metal separation
devices.
An optional output on the relay board is available for activating a release device to be installed Tri Power X33 HE
tream from the TRI POWER X33 HE.
This TRI POWER X33 HE has an internal device (redundant bypass power supply) which, in case a fault
occurs, activates the bypass automatically, thus maintaining the load powered with no internal protection
and with no limit on the power supplied to the load.
Under such emergency conditions, any disturbance on the input line will affect the load.
Please see the paragraph “Redundant auxiliary power supply for automatic bypass”, in the “USE” section.

Page 19 to 52
External protection devices
Magnetothermal
In order to set up the power line, install a magnetothermal switch Tri Power X33 HEtream from the TRI POWER X33
HE with intervention curve B or C. Please follow the indications in the table below:
Automatic external protections
TRI POWER X33
HE Mod.
Mains input
Separate bypass input (optional)
30kVA
100A
100A
40kVA
100A
100A
If the protection device Tri Power X33 HEtream of the TRI POWER X33 HE interrupts the neutral
conductor, it must also interrupt all the phase conductors at the same time (quadripolar switch).
Output protections (recommended selectivity values)
Normal fuses (gL-gG)
In (Nominal current)/7
Magnetothermal switches (C curve)
In (Nominal current)/7
Ultrarapid fuses (GF)
In (Nominal current)/3
Differential
In the absence of an input separating transformer, the neutral from the mains power supply is connected to the
neutral of the TRI POWER X33 HE output. This way the neutral regime of the equipment is not modified.
THE INPUT NEUTRAL IS CONNECTED TO THE OUTPUT NEUTRAL
THE DISTRIBUTION SYSTEM THAT POWERS THE TRI POWER X33 HE IS NOT MODIFIED BY THE TRI
POWER X33 HE
WARNING: make sure that the equipment is connected correctly to the input neutral, or else
damages to the TRI POWER X33 HE may be caused.
The neutral regime is modified only in presence of an isolation transformer or when the TRI POWER X33
HE operates with a neutral isolated Tri Power X33 HEtream.
When operating from mains power, a differential switch located at the input can intervene as the output circuit is not
isolated from the input circuit. Anyhow, other differential switches can be inserted at the output, possibly coordinated
with the switches at the input.
The differential switch located Tri Power X33 HEtream must have the following features:
Differential current adjusted to the sum of the TRI POWER X33 HE load. It is strongly recommended to keep
an adequate margin in order to avoid delayed interventions (100mA min. - 300mA recommended)
type B or type A
delay greater than or equal to 0,1s
