Alpine PKG-1000 User manual

R
R
DVD Rear Seat Entertainment Package
PKG-RSE1
Rear Seat Entertainment Package
PKG-1000
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda
Shinagawa-ku
Tokyo 141-0031, Japan
Phone [phone]
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place
Torrance, California 90501 U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road
Toronto, Ontario M3J 2M9 Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY, LTD.
161-165 Princess Highway, Hallam
Victoria 3803, Australia
Phone [phone]
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117,
80807 München, Germany
Phone [phone]
ALPINE ELECTRONICS OF U.K., LTD.
ALPINE House
Fletchamstead Highway, Coventry CCV4 9TW, U.K.
Phone [phone]
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. paris Nord II,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone [phone]
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone [phone]
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, España
Phone [phone]
Designed by ALPINE ELECTRONICS OF AMERICA, INC.
Printed In Taiwan
EN
FR
ES
TW_PKG-RSE.indb iTW_PKG-RSE.indb i 4/25/05 4:50:38 PM4/25/05 4:50:38 PM

PKG-RSE1
DVD Rear Seat Entertainment Package
• PKG-1000 (REAR SEAT ENTERTAINMENT PACKAGE)
• DVE-5207 (DVD VIDEO/MP3/WMA/CD PLAYER)
PKG-1000
Rear Seat Entertainment Package
• TMX-R1000 (VGA MOBILE CINEMA MONITOR)
• SHS-N100 (SINGLE SOURCE IR HEADPHONE)
• RUE-4155 (UNIVERSAL REMOTE CONTROL)
• INSTALLATION BRACKET
• TRIM RING
FCC ID: DVUTMX-R1000 (U.S.A.)
IC: 700A-TMXR1000 (CANADA)
Federal Motor Vehicle Safety Standard (FMVSS)
No. 201U: "Occupant Protection in Interior Impact, Upper Interior Head Impact Protection"
No. 207: "Seating Systems" which was used as a guideline for 20G load testing
PKG-RSE1
Système de divertissement DVD pour les sièges arrière
• PKG-1000 (SYSTÈME DE DIVERTISSEMENT POUR LES SIÈGES ARRIÈRE)
• DVE-5207 (LECTEUR DVD VIDEO/MP3/WMA/CD)
PKG-1000
Système de divertissement pour les sièges arrière
• TMX-R1000 (MONITEUR CINÉMA MOBILE VGA)
• SHS-N100 (CASQUE IR À UNE SOURCE UNIQUE)
• RUE-4155 (TÉLÉCOMMANDE UNIVERSELLE)
• SUPPORT DE FIXATION
• BAGUE DE GARNITURE
FCC ID : DVUTMX-R1000 (États-Unis)
IC : 700A-TMXR1000 (CANADA)
Norme fédérale de sécurité automobile (FMVSS)
N° 201U : « Protection des occupants contre les chocs intérieurs, Protection de la tête
contre les chocs intérieurs supérieurs »
N° 207 : « Systèmes de places assises » qui a été utilisée en tant que directive pour un
essai de charge de 20G
PKG-RSE1
Paquete de entretenimiento con DVD para asientos traseros
• PKG-1000 (PAQUETE DE ENTRETENIMIENTO PARA ASIENTOS TRASEROS)
• DVE-5207 (REPRODUCTOR DE DVD/VIDEO/MP3/WMA/CD)
PKG-1000
Paquete de entretenimiento para asientos traseros
• TMX-R1000 (MONITOR VGA DE CINE MÓVIL)
• SHS-N100 (AURICULARES SENCILLOS POR INFRARROJOS)
• RUE-4155 (MANDO A DISTANCIA UNIVERSAL)
• SOPORTE DE INSTALACIÓN
• ANILLO DE COLOCACIÓN
FCC ID: DVUTMX-R1000 (EE.UU.)
IC: 700A-TMXR1000 (CANADÁ)
Norma federal de seguridad de vehículos motorizados (FMVSS)
Núm. 201U: “Protección de ocupantes frente a impactos interiores, protección frente a impactos en la
cabeza por la parte interior de arriba”
Núm. 207: “Sistemas de asientos” que se ha utilizado como directriz para las pruebas de carga 20G
TW_PKG-RSE.indb iiTW_PKG-RSE.indb ii 4/25/05 4:50:44 PM4/25/05 4:50:44 PM

1-EN
ENGLISH
Contents
Operating Instructions
WARNINGntents
WARNINGS ...............................................2
CAUTION...................................................3
PRECAUTIONS .........................................3
Monitor Features
Features ............................................................. 4
Overhead Monitor ............................................. 4
Remote Control ................................................. 4
Overhead Monitor Control
Screen Display ON/OFF ................................... 5
Audio Mute Function ........................................ 5
Adjusting the Volume........................................ 5
Switching the Source......................................... 5
Setting the Backlight Brightness....................... 5
Adjusting Picture............................................... 6
Adjusting Brightness ................................ 6
Adjusting Color Density........................... 6
Adjusting Tint ........................................... 6
Adjusting Contrast.................................... 6
Adjusting Sharpness ................................. 7
Resetting the Picture Adjustment ............. 7
Switching Display Mode................................... 7
Visual EQ Operation ......................................... 8
System Setup Operation.................................... 9
DVD Player Control
Playing and Pausing ........................................ 10
Stopping .......................................................... 10
Skipping Forward ............................................ 10
Skipping Backward ......................................... 10
Selecting Menu................................................ 10
DVD Setup Operation ..................................... 10
TV Tuner Control
Selecting Preset Channel................................. 11
Seeking Channel Manually ............................. 11
Memorizing Channel....................................... 11
Wireless Headphone
Headphone Receivers...................................... 11
Operation......................................................... 11
Battery Installation.......................................... 11
Information
In Case of Difficulty........................................ 12
Remote Control Battery Replacement ............ 12
Accessories ..................................................... 13
Specifications ................................................. 13
Installation and Connections
WARNINGntents
WARNINGS .............................................14
CAUTION................................................. 14
PRECAUTIONS .......................................14
Installation and Connections........................... 14
Power Connections .......................................... 15
Dome Light Connection.................................. 16
System Connections ........................................ 17
Limited Warranty ............................................ 18
TW_PKG-RSE.indb EN1TW_PKG-RSE.indb EN1 4/25/05 4:50:46 PM4/25/05 4:50:46 PM

2-EN
WARNINGS
WARNING
This symbol means important instructions.
Failure to heed them can result in serious
injury or death.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking
ahead of the vehicle and cause an accident.
DO NOT OPERATE ANY FUNCTION THAT TAKES
YOUR ATTENTION AWAY FROM SAFELY DRIVING
YOUR VEHICLE.
Any function that requires your prolonged attention
should only be performed after coming to a complete
stop. Always stop the vehicle in a safe location before
performing these functions. Failure to do so may result in
an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN
STILL HEAR OUTSIDE NOISE WHILE DRIVING.
Failure to do so may result in an accident.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking
ahead of the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in
fire, electric shock or other injury.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF
THE REACH OF CHILDREN.
Swallowing them may result in serious injury. If
swallowed, consult a physician immediately.
DO NOT PLACE HANDS, FINGERS OR FOREIGN
OBJECTS IN INSERTION SLOTS OR GAPS.
Doing so may result in personal injury or damage to the
product.
USE THE CORRECT AMPERE RATING WHEN
REPLACING FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result
in fire.
INSTALL THE PRODUCT CORRECTLY SO THAT THE
DRIVER CANNOT WATCH TV/VIDEO UNLESS THE
VEHICLE IS STOPPED AND THE EMERGENCY BRAKE
IS APPLIED.
It is dangerous (and illegal in many states) for the driver to
watch the TV/Video while driving the vehicle. The driver
may be distracted from looking ahead and an accident
could occur. If the product is not installed correctly, the
driver will be able to watch the TV/Video while driving
the vehicle and may be distracted from looking ahead
causing an accident. The driver or other people could be
severely injured.
Operating Instructions
TW_PKG-RSE.indb EN2TW_PKG-RSE.indb EN2 4/25/05 4:50:47 PM4/25/05 4:50:47 PM

3-EN
CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized ALPINE dealer or the
nearest ALPINE Service Center for repairing.
KEEP FINGERS OR ANY OBJECT AWAY WHEN CLOSING THE
MONITOR.
Failure to do so may result in personal injury or damage to the
product.
DO NOT MIX NEW BATTERIES WITH OLD BATTERIES. INSERT
WITH THE CORRECT BATTERY POLARITY.
When inserting the batteries, be sure to observe proper polarity (+
and –) as instructed.
Rupture or chemical leakage from the battery may cause fire or
personal injury.
PRECAUTIONS
Temperature
Be sure the temperature inside the vehicle is between
+60°C (+140°F) and -10°C (+14°F) before turning your unit on.
Fuse Replacement
When replacing the fuse(s), the replacement must be of the same
amperage as shown on the fuse holder. If the fuse(s) blows more
than once, carefully check all electrical connections for shorted
circuitry. Also have your vehicle’s voltage regulator checked.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your ALPINE dealer or the nearest ALPINE Service
Station for servicing.
Installation Location
Make sure the TMX-R1000 will not be exposed to:
• Direct sun and heat • Excessive dust
• High humidity • Excessive vibrations
Characteristics of LCD Panel
• After turning the system off, a slight ghost of the image
will remain temporarily. This is an effect peculiar to LCD
technology and is normal.
• Under cold temperature conditions, the screen may lose
contrast temporarily. After a short warm-up period, it will
return to normal.
• The LCD panel is manufactured using an extremely high
precision manufacturing technology. Its effective pixel ratio
is over 99.99%. This means that 0.01% of the pixels could be
either always ON or OFF.
Using Wireless Headphones
If ACC or the monitor's power source is turned off, a loud noise is
produced through the headphones. Be sure to remove the wireless
headphones from your ears before you turn the monitor off.
TW_PKG-RSE.indb EN3TW_PKG-RSE.indb EN3 4/25/05 4:50:48 PM4/25/05 4:50:48 PM

4-EN
Monitor Features
Features
The ALPINE TMX-R1000 provides the following
• 10.2 inch Wide VGA TFT Active Matrix Color LCD
(800 x 480)
• 3 AUX In / 1 AUX Out
• 1 Remote In / 2 Remote Out
• Front Panel Controls (OHM / DVD / DVD-HU / TV
Tuner)
• Visual EQ (FLAT, NIGHT MOVIE, SOFT, SHARP,
CONTRAST)
• Independent parameter setting on each AUX input
(Picture/Visual EQ/Audio Input Level/Display Mode)
• 3 Level Dimmer (HIGH/MID/LOW)
• CH Selectable IR Transmitter for IR Headphones
(A/B/OFF)
• Built-in Wireless FM Transmitter
• DVD Power Control
• Customized OSD Source Name
• White LED Dome Light
Overhead Monitor
White LED Dome Light
Infrared Wireless
Headphone Transmitter
LCD Monitor Panel
Back-Lit Function
Button
Aux 3 Input
Monitor Open Button
Dome Light Switch
LCD Monitor Panel
This is a 10.2 inch, Wide VGA, Active Matrix LCD. In
addition, an Infrared Wireless Headphone Transmitter is
located on top of the LCD panel.
• The power state of the monitor is memorized when
Ignition/ACC is turned off. When Ignition/ACC is
turned back on, the monitor returns to the power state
memorized (either ON or OFF).
Monitor Open Button
Press Monitor Open Button to release the Monitor Panel.
The Panel will drop down slightly allowing you to fully
open to its 90 degree or greater position. To close, firmly
press the LCD Monitor Panel back up into the housing
until a click is heard.
White LED Dome Light
White LED Dome Light connection has polarity. Be
cautious when installing the monitor. Refer to Dome Light
Connection (Page 16).
Back-Lit Function Buttons
Blue, back-lit function button illuminates when the
overhead monitor main power is on. Overhead monitor,
DVD player, DVD-HU and TV tuner can be controlled by
using these buttons.
Remote Control
TMX-R1000 Overhead
Monitor Control
ALPINE DVD Player
Control
(Refer to DVA-5210 or
DVE-5207 Owner’s Manual)
ALPINE TV-Tuner Control
(Refer to ALPINE TV-Tuner
Owner’s Manual)
When you use Remote Control for the first time, pull the
plastic tape before using the remote control.
TW_PKG-RSE.indb EN4TW_PKG-RSE.indb EN4 4/25/05 4:50:48 PM4/25/05 4:50:48 PM

5-EN
Overhead Monitor
Control
POWER SELECT DIMMER
Front Panel Controls
POWER
DIMMER
Remote Control
Screen Display ON/OFF
Front Panel Controls
1Press POWER to turn ON.
2To turn off the power, press and hold POWER
again.
• While the power is ON, press POWER to activate the
Mute function.
Remote Control
1Press POWER to turn ON.
2To turn off the power, press POWER again
Audio Mute Function
Front Panel Controls
1While the power is ON, press POWER to
activate the Mute function.
2Press POWER again turn it OFF the Mute
function.
Remote Control
Press MUTE to turn it ON and OFF.
Adjusting the Volume
Volume can be controlled from the headphone or your
own radio volume function.
1Turn on POWER on the headphone.
2Adjust the volume level by turning clockwise
for louder and counter-clockwise for lower on
the headphone.
Refer to Wireless Headphone (Page 11)
Switching the Source
1Press SEL on the remote control or SELECT
on the Front Panel Controls to change each
source.
2Press SEL/SELECT to switch to the different
sources.
• Inside ( ) is default setting. The source name is
selectable. When it is OFF, the source will be skipped.
• OSD (On Screen Display) will be turned off
automatically, when not operating more than 10
seconds.
Setting the Backlight Brightness
The brightness of the LCD panel’s backlighting is
adjustable to more closely match the vehicle’s interior
lighting. This makes the screen easier to view.
1Press DIMMER.
2Press DIMMER to cycle through the OSD as
HIGH, MID, LOW and HIGH. (Default: HIGH)
SELECT
MUTE
TW_PKG-RSE.indb EN5TW_PKG-RSE.indb EN5 4/25/05 4:50:52 PM4/25/05 4:50:52 PM

6-EN
Adjusting Picture
Brightness, color, tint, contrast and sharpness can be
adjustable.
• Each source can be adjustable individually.
• Adjusting should be made within 10 seconds, otherwise
OSD (On Screen Display) will be automatically turned
off.
• When the adjustment is made, “FLAT” setting in Visual
EQ changes to “CUSTOM”. After reset, “CUSTOM”
changes back to “FLAT”
1Press and hold the SELECT button for at
least 2 seconds to open SETUP screen. Make
sure the PICTURE display mode is selected.
SELECT
Front Panel Controls
SELECT
Remote Control
Adjusting Brightness
2Press ▲or ▼ and select BRIGHT.
3Press or to adjust the brightness.
Brightness can be adjusted from –15 (MIN) to
+15 (MAX).
4Press the ENT button to finish adjustments
or wait 10 seconds until OSD disappears; the
adjustment will be saved automatically.
Adjusting Color Density
2Press ▲or ▼ and select COLOR.
3Press or to adjust the color density.
Change depth can be adjusted from –15 (MIN)
to +15 (MAX).
4Press ENT to finish adjustments or wait
10 seconds until OSD disappears; the
adjustment will be saved automatically.
Adjusting Tint
2Press ▲or ▼ and select TINT.
3 Press or to adjust the tint. Tint tone can
be adjusted from G15 (G MAX) to R15 (R
MAX).
4Press ENT to finish adjustments or wait
10 seconds until OSD disappears; the
adjustment will be saved automatically.
Adjusting Contrast
2Press ▲or ▼ and select CONTRAST.
3Press or to adjust the contrast. Contrast
can be adjusted from –15 (LOW) to +15
(HIGH).
4Press ENT to finish adjustments or wait
10 seconds until OSD disappears; the
adjustment will be saved automatically.
TW_PKG-RSE.indb EN6TW_PKG-RSE.indb EN6 4/25/05 4:50:56 PM4/25/05 4:50:56 PM

7-EN
Adjusting Sharpness
2Press ▲or ▼ and select SHARPNESS.
3Press or to adjust the screen quality.
Screen quality can be adjusted from -15
(SOFT) to +15 (HARD).
– +
4 Press ENT to finish adjustments or wait
10 seconds until OSD disappears; the
adjustment will be saved automatically.
Resetting the Picture Adjustment
2Press ▲or ▼ and select RESET.
3Press ENT to reset the picture adjustments.
• If you do not press ENT within 10 seconds, OSD
disappears and the reset adjustments will not be saved.
Switching Display Modes
Display mode on the screen can be adjusted to Wide,
Zoom, Cinema and Normal.
• Each source can be adjustable individually.
• Adjusting should be made within 10 seconds,
otherwise OSD (On Screen Display) will be
automatically turned off.
SELECT
Front Panel Controls
SELECT
Remote Control
1Press and hold SELECT for at least 2
seconds to show the SETUP menu.
2Press SELECT to switch to DISP MODE from
PICTURE. To change each mode, press ▲
or ▼.
Each press changes the display modes as follows:
WIDE
Normal images are expanded uniformly in the
horizontal direction and are displayed over the entire
screen.
ZOOM
Normal images are expanded in the horizontal
direction and are displayed over the entire screen. The
expansion ratio increases towards the right and left
edges of the screen.
CINEMA
Normal images are expanded in the horizontal and
vertical directions. The top and bottom of the image
are cut off. This mode is suited for 16:9 cinema size
images.
NORMAL
Normal image (4:3)
3Press the ENT button to finish adjustments
or wait 10 seconds until OSD disappears; the
adjustment will be saved automatically.
TW_PKG-RSE.indb EN7TW_PKG-RSE.indb EN7 4/25/05 4:51:03 PM4/25/05 4:51:03 PM

8-EN
VISUAL EQ Operation
You can select a mode suitable for the subject image.
• Each source can be adjustable individually.
• Adjusting should be made within 10 seconds,
otherwise OSD (On Screen Display) will be
automatically turned off.
DIMMER
Front Panel Controls
DIMMER
Remote Control
1Press and hold DIMMER for at least 2
seconds to show the VISUAL EQ OSD.
2To change VISUAL EQ, press DIMMER or
press ▲or ▼ to cycle through the OSD as
FLAT, NIGHT MOVIE, SOFT, SHARP, HIGHT
CONT, and FLAT. (Default: SHARP)
VISUAL EQ mode (manufacturer’s settings) selection
(VISUAL EQ MODE)
FLAT: Normal Setting (Visual EQ OFF)
NIGHT MOVIE: Suitable for movies in which dark
scenes frequently appear.
SOFT: Suitable for CGs and animated
films.
SHARP: Suitable for old movies where
images are not clearly shown.
CONTRAST: Suitable for recent movies.
• “FLAT” will change to “CUSTOM”, when any of the
picture mode (Brightness, Color, Tint, Contrast and
Sharpness) has been adjusted
• NIGHT MOVIE, SOFT, SHARP and CONTRAST
are fixed values. They cannot be set manually. If the
picture mode is changed, they automatically change to
CUSTOM mode.
• To return FLAT mode, press RESET on the picture
mode, or change values of BRIGHT, COLOR, TINT,
CONTRAST and SHARPNESS to 0 manually.
3 Press ENT to finish adjustments or wait
10 seconds until OSD disappears; the
adjustment will be saved automatically.
TW_PKG-RSE.indb EN8TW_PKG-RSE.indb EN8 4/25/05 4:51:12 PM4/25/05 4:51:12 PM
