Alpine MAGICAL POND FOGGER User manual

ALPINE (3 Head) MAGICAL
POND FOGGER W/ LED LIGHTS
INSTALLATION AND INSTRUCTIONS.
The Alpine Magical Pond Fogger with LED Lights will enhance the beauty and
atmosphere of any small pond or large water feature. The Magical Pond
Fogger is Fish Safe, and will create a mystical pond fog within seconds.
Simply place the Alpine Magical Pond Fogger into the floating ring and watch
it marvel! Try using it in a Halloween decoration. Children will marvel at
its mystical effect.
This Alpine Magical Pond Fogger has been specifically manufactured to our
specifications to produce the optimal amount of Super Fog with the finest
quality of products. The parts and materials used for this unit are all superior
parts to allow optimal operating performance and longevity of your Super
Power Pond Fogger. If it doesn’t say Alpine, it’s not an Alpine Fogger.
This package includes:
1. 3 Head Magical Pond Fogger Unit with NEW LED Lights
2. Floating Ring
3. Outdoor Transformer
CAUTION! Before Assembly or Operating Please Read.
1. Use the specified transformer supplied.
2. Do not put your hand above the fogger while it is operating. The high
vibration could cause injury.
3. Disconnect power supply before removing fogger or during
maintenance.
Assembly and Operating Instructions
1. Place the Magical Pond Fogger into the floating ring (included).
2. Place the unit (including the floating ring) into the pond or large water
feature.
3. Plug the Magical Pond Fogger into the output socket of the
transformer.
4. Plug transformer into AC power socket, indicators of Super Power
Pond Fogger unit will light up, which means the unit is now running.
General Instructions for Optimal Usage
1. Suggested usage of the Magical Pond Fogger is no more than 8 hours
per day. Connecting a timer to your transformer will insure your
pond fogger to be used only when needed. Clean water is
recommended.
2. Clean the Magical Pond Fogger with a soft cloth approximately twice
per month.
3. When cleaning the Magical Pond Fogger do not use chemical cleaners.
4. Take care of the water level sensor switch, do not hold it to move the
unit around, scratch it, or bump it with anything hard. It will damage
the sensor level switch if it is not properly maintained.
Maintenance and Service
(Ceramic Disk Replacement Tool Kit Sold Separately)
1. Ceramic Disks must be cleaned at least one time per month (twice
recommended). Use of a cotton swab to clean the dirt on the surface is
recommended.
2. Take special care not to scratch the ceramic disc or water switch of the
Super Power Pond Fogger.
3. After using the Pond Fogger for about 3000 hours, the quantity of the
fog will start to decline or the unit may even stop working. Replacing
the ceramic disc (sold separately) will insure continued operation.
Please refer to replacing the disk on the drawing.
4. Replacement discs, and tools are available from your local dealer.
Refer to drawing number 1 for replacing disks instructions.
a. Unplug the unit and remove from water container.

Best Water Depth: 30 to 45mm
b. Using the Alpine tool kit, insert the key into the winding ring
and turn counter clockwise.
c. Remove the filler piece (washer) and ceramic. IMPORTANT,
note that there is a front and back of the ceramic disk. Be sure
to reinstall the correct side facing up. (The washer should not
be faced up)
d. Clean chemical deposits on the ceramic with a soft cloth and
reinstall or proceed to install a new ceramic disk in the reverse
order above. Refer to illustrated instructions below. (Drawing
No. 1)
e. The inside of the unit cavity must be completely dry before the
parts are installed.
f. Using new ceramic disks is needed if they cannot produce fog
normally after cleaning.
Parameters of The Super Pond Fogger Unit:
TECHNICAL DATA
Working Voltage
(VAC) Working Electric Current (A) Ultrasonic Frequency(KHz) Ceramic disc spec. (mm)
36 2.6 ~ 2.9 1700±40 Φ20
Generate mist
(ml/h) Water temp.
Range ( ℃) Ceramic disc
plated material Lifespan of Ceramic Disc ( hour)
≥900 0 ~ 50 Nickel or
Titanium >3000
Alpine 1-Year Guarantee
If this product becomes unserviceable or defective within one year of the date
of purchase from your dealer, after your dealer has been contacted, it will be
repaired or replaced at Alpine’s option – free of charge (less shipping charges).
Unless in the dealers or Alpine’s opinion it has been damaged or misused the
guarantee will be void. To obtain the benefits of this guarantee send the
Magical Pond Fogger with LED Lights back along with proof of purchase
direct toAlpine.
Note: This guarantee does not include the replacements of the tool kits. Be
sure to pour clean water and replace water in the glass bowl timely.
Drawing No. 1
Drawing No. 2
Water Lever
Sensor Switch
LED Lamp
Mist Cavity
Sealing Washer
Ceramic Disc
Winding Ring
Tool
Tarpaulin
Front Of
Ceramic Disc Behind Of
Ceramic Disc
