Altinex DA103-301 User manual

400-0542-002 Operating Instructions
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will , for 3 years, which
starts with the date of original purchase ("Limited Warranty period"), at its option
either(a) repair your product with new or refurbished parts, or (b) replace it with a
new of a refurbished product. The decision to repair or replace will be made by the
warrantor.
This Limited Warranty is extended only to the original purchaser and only covers
product purchased as new. A purchase receipt or other proof of original purchase
date is required for Limited Warranty service.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and provide
a day time phone and/or email address where you can be reached. Return
Merchandise Authorization is required. Items shipped to the company without an
RMA will be rejected.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The
Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or
failures which are caused by products not supplied by warrantor , or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration,
faulty installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, or service by anyone
other than a Factory Service center or other Authorized Servicer, or damage that is
attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED
WARRANTY COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING
OUT OF ANY BREACH OF THIS WARRNTY. (As examples, this excludes damages for lost
time, cost of having someone remove or re-install an installed unit if applicable,
travel to and from the service, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE
YOUR RESPONSIBILITY.
4
400-0542-002 Operating Instructions
DA103-301 HDMI Splitter
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
FEATURES
One input signal can be split to 2 signal sink devices
Maintains 480p,720p,1080i and 1080p video formats
Maintains highest HDMI single link video resolution and digital audio signal
Supports HDCP compliant devices
HDMITM (with deep color )
Supports digital audio format, such as LPCM/Dolby-AC3/DTS7.1/DSD
NOTICE
Our company reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
1

400-0542-002 Operating Instructions
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product Service
Warranty
SPECIFICATIONS
Operating Temperature range ..........................................-15 to +55 (-41 to +95°F)
Operating Humidity range ......................................... 5 to 90%RH (No Condensation)
Video Amplifier Bandwidth........................................................................... 140 MHz
Input Video signal.........................................................................5.0 Volts P-P (TTL)
Single LinkRange .......................................................................... 1920x1200,1080p
Output Video ......................................................................................... HDMI+HDCP
Vertical Frequency Range.................................................................................. 60Hz
Date transfer speed .................................................................................2.25Gbpsx3
Power supply......................................................................................................5VDC
Dimension (L×W×H) ............................................................................ 88x47x25mm
Weight ............................................................................................................... 110g
Note: Specifications are subject to change without notice. Mass and dimensions are
approximate.
PACKING CONTENTS
1) Main Unit. HDMI splitter
2) 5VDC 2A Power Supply
3) Operating Instructions
PANEL DESCRIPTIONS
Front Panel
①②
2
400-0542-002 Operating Instructions
Left Panel
③
1) Power input.
2) HDMI output ports
3) HDMI input port
Connecting and Operating
1) Connect the HDMI signal sources(Such as PS3,STB etc) into DA103-301 input.
2) Connect the HDMI display device (such as :HD-LCD,HD-DLP) into HDMI output.
3) Plug the 5VDC power supply into DA103-301 and the unit is ready to use .
Attention:Insert/Extract cable gently.
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to
clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described in
these operating instructions. Refer all other servicing to authorized servicing
personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks to
confirm that the unit is in proper working condition.
3
