Alto-Shaam COMBITHERM CTP6-10e User manual

Installation Manual
Combination Oven/Steamer
WARNING
Improper installation, alteration, adjustment, service,
cleaning, or maintenance could result in property
damage, severe injury, or death.
Read and understand the installation, operating and
maintenance instructions thoroughly before installing,
servicing, or operating this equipment.
WARNING
To prevent personal injury, death or
property damage:
Do not store or use gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
EN
MN-35947
Rev 22
10/22
CTC6-10E
CTC10-10E
CTC7-20E
CTC10-20E
CTC20-10E
CTC20-20E
CTC6-10G
CTC10-10G
CTC7-20G
CTC10-20G
CTC20-10G
CTC20-20G
CTP6-10E
CTP10-10E
CTP7-20E
CTP10-20E
CTP20-10E
CTP20-20E
CTP6-10G
CTP10-10G
CTP7-20G
CTP10-20G
CTP20-10G
CTP20-20G
CT CLASSIC™
CT PROFORMANCE™

2 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Transportation Damage and Claims
All Alto-Shaam equipment
is sold Free on Board
(F.O.B.) shipping point,
and when accepted by the
carrier, such shipments
become the property of the
consignee.
Should damage occur in shipment, do not put the
appliance into service until the damage has been
inspected by an authorized Alto-Shaam service provider.
Shipping damages are a matter between the carrier and
the consignee. In such cases, the carrier is assumed to
be responsible for the safe delivery of the merchandise,
unless negligence can be established on the part of
theshipper.
1. Make an immediate inspection while the appliance is
still in the truck or immediately aer it is moved to the
receiving area. Do not wait until aer the appliance is
moved to a storage area.
2. Do not sign a delivery receipt or a freight bill until
a proper count has been made and inspection of all
appliances are received.
3. Note all damage to packages directly on the carrier’s
delivery receipt.
4. Make certain the driver signs the delivery receipt. If the
driver refuses to sign, make a notation of this refusal
on the receipt.
5. If the driver refuses to allow inspection, write the
following on the delivery receipt: Driver refuses to
allow inspection of containers for visible damage.
6. Contact the carrier’s oce immediately upon nding
damage, and request an inspection. Mail a written
conrmation to the carrier’s oce with the time, date,
and the personcalled.
7. Save any packages and packing material for further
inspection by the carrier.
8. Promptly le a written claim with the carrier and
attach copies of all supporting paperwork.
Alto-Shaam will continue our policy of assisting our
customers in collecting claims which have been properly
led and actively pursued. Alto-Shaam cannot, however,
le any damage claims, assume the responsibility of any
claims, or accept deductions in payment for such claims.
Record the model and serial number of the appliance for easy
reference. Always refer to both model and serial number in
any contact with Alto-Shaam regarding this appliance.
Model: ______________________________________________
Serial Number: ______________________________________________
Date Installed: ______________________________________________
Voltage: ______________________________________________
Purchased From: ______________________________________________
______________________________________________
______________________________________________
Alto-Shaam has established a twenty-four
hour emergency service call center to oer immediat
e
customer access to a local authorized service agency
outside of standard business hours. The emergency
service access is provided exclusively for Alto-Shaam
equipment and is available throughout the United
States through the use of Alto-Shaam’s toll-free
number. Emergency service access is available seven
days a week including holidays.

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •3
Delivery
DELIVERY
This Alto-Shaam appliance has been thoroughly tested and
inspected to ensure only the highest quality unit is provided.
Upon receipt, check for any possible shipping damage and
report it at once to the delivering carrier. See Transportation
Damage and Claims section located in this manual.
This appliance, complete with unattached items and
accessories, may be delivered in one or more packages. Ensure
all standard items and options have been received with each
model as ordered.
Save all the information packed with the appliance. Register
online at www.alto-shaam.com to ensure prompt service in the
event of a warranty parts and labor claim.
This manual must be read and understood by all people using
or installing the equipment model. Contact the Alto-Shaam
Tech Team if you have any questions concerning installation,
operation, or maintenance.
1-800-558-8744; [email protected]
UNPACKING
• Carefully remove the appliance from
the carton or crate.
NOTICE: Do not discard the carton
and other packaging
material until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
• Read all instructions in this manual carefully
before installing this appliance, using the appliance, or
performing routine maintenance. Following procedures
other than those indicated in this guide to use and clean
the appliance is considered inappropriate and may cause
damage, injury, or fatal accidents, in addition to invalidating
the guarantee and relieving Alto-Shaam of all liability.
• DO NOT DISCARD THIS MANUAL.
This manual is considered part of the appliance and
is provided for the owner or manager of the business
and for training personnel. Additional manuals are
available from the Alto-Shaam Tech Team, or online at
www.alto-shaam.com.
• Remove all protective plastic film, packaging materials,
and accessories from the appliance before connecting
electrical power. Store any accessories in a convenient
place for future use.
CAUTION
Appliance and accessories may be heavy.
To prevent injury, always use a sufficient
number of trained and experienced workers
when moving or leveling appliance and
handling accessories.
OPERATIONAL ENVIRONMENTAL CONDITIONS
• Unit must acclimate to room temperature in the environment it is
placed. 24 hours is recommended.
• Ambient temperature range of 60°F to 110°F (16°C to 43°C).
• Relative humidity of less than 95% non-condensation.
• Atmospheric pressure range of 50KPa to 106KPa.
The serial number is required for all inquiries.
Always include both model and serial number(s) in any
correspondence regarding the appliance.
Model: ______________________________________________
Serial number: ______________________________________________
Purchased from: ______________________________________________
Date installed: ____________________ Voltage: _____________

4 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
DANGER
Explosion hazard. Before starting the
appliance, make certain you do not detect
the odor ofgas.
If you smell gas:
• Shut o the gas supply immediately.
• Do not attempt to light any appliance.
• Do not touch any electrical elements.
• Extinguish any open flame.
• Evacuate the area.
• Use a telephone outside the property and
immediately contact your gas supplier.
• If unable to contact your gas supplier,
contact the fire department.
Please post the following instructions in a prominent location
in the event the user smells gas.
This manual covers the following CTC and CTP series models:
Control Type Boiler-Free Models Steam Generator Models
CTP
CTC
CT PROformance™ with
PROtouch™ control
CT Classic with Classic
manual control
6-10E, 6-10G
10-10E, 10-10G
7-20E, 7-20G
10-20E, 10-20G
20-10E, 20-10G
20-20E, 20-20G
6-10EB
10-10EB
7-20EB
10-20EB
20-10EB
20-20EB

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •5
Table of Contents
Transporation Damage and Claims. . . . . . . . . . . . . . 2
Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Procedures and Precautions . . . . . . . . . . . . . 6
Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation Codes and Standards . . . . . . . . . . . . . . 15
Site Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installation Codes and Standards . . . . . . . . . . . . . . . . . 15
Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . 15
Sound Pressure Measurements. . . . . . . . . . . . . . . . . . . 15
Technical Specications . . . . . . . . . . . . . . . . . . . . . . 16
General Specications. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Oven Specications. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Liing Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Positioning on Site – Countertop Models . . . . . . . . . . . 21
Positioning on Site – 20-10 & 20-20 Models. . . . . . . . . . 22
Electrical Safety Regulations. . . . . . . . . . . . . . . . . . . . . 23
Electrical Connection for Gas Models . . . . . . . . . . . . . 24
Electrical Connection for Electric Models . . . . . . . . . . 24
Electrical Kit Installation – 50 Hz
(Rear Panel with Cover Plates) . . . . . . . . . . . . . . . . . . . 25
Electrical Kit Installation – 50 Hz . . . . . . . . . . . . . . . . . 26
Electrical Kit Installation – 60 Hz
(Rear Panel with Cover Plates) . . . . . . . . . . . . . . . . . . . 27
Electrical Kit Installation – 60 Hz . . . . . . . . . . . . . . . . . 28
Ventilation Requirements for Gas Models . . . . . . . . . . 29
Gas Supply & Installation . . . . . . . . . . . . . . . . . . . . . . . 30
Water Quality Requirements. . . . . . . . . . . . . . . . . . . . . 35
Water Supply & Installation . . . . . . . . . . . . . . . . . . . . . 36
Water Drainage – For Single Oven . . . . . . . . . . . . . . . . 37
Water Drainage – For Single Oven
(Rear Panel with Louver). . . . . . . . . . . . . . . . . . . . . . . . 38
Water Drainage – For Stacked Ovens . . . . . . . . . . . . . . 39
Water Drainage – For Stacked Ovens
(Rear Panel with Louver). . . . . . . . . . . . . . . . . . . . . . . . 40
Mobile Equipment Restraint. . . . . . . . . . . . . . . . . . . . . 41
For Gas Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
For Electric Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Special Conditions for Units Installed
within the City of New York . . . . . . . . . . . . . . . . . . . . . 42
Liquid Cleaner Hook-Up (If Equipped
with this Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Grease Collection Installation
(If Equipped with this Option) . . . . . . . . . . . . . . . . . . . 44
CT PROformance™ Start-Up Procedures . . . . . . . . 45
How To Turn On the Appliance . . . . . . . . . . . . . . . . . . 45
How To Start a Manual Calibration. . . . . . . . . . . . . . . . 45
How To Calibrate the Touchscreen . . . . . . . . . . . . . . . . 45
How To Turn O the Appliance . . . . . . . . . . . . . . . . . . 45
How To Run a Cycle Test of the Appliance . . . . . . . . . . 46
CT Classic™ Start-Up Procedures . . . . . . . . . . . . . . 47
How To Turn On the Appliance . . . . . . . . . . . . . . . . . . 47
How To Run a Cycle Test of the Appliance . . . . . . . . . . 47
Inspection Checklist . . . . . . . . . . . . . . . . . . . . . . . . . 48
Troubleshooting – Error Codes . . . . . . . . . . . . . . . . 54
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Touch Motor Control Error Codes. . . . . . . . . . . . . . . . . 59

6 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Safety Procedures and Precautions
• This appliance is intended to cook, hold, or process foods
for the purpose of human consumption. No other use for
this appliance is authorized and is therefore considered
dangerous. The appliance must not be used to cook food
containing flammable materials (such as food with alcohol).
Substances with a low flash point can ignite spontaneously
and cause a fire.
• This appliance is intended for use in commercial
establishments where all operators are familiar with
the purpose, limitations, and associated hazards of this
appliance. Operating instructions and safety alerts must
be read and understood by all operators and users. We
recommend regular training of your staff to avoid the risk of
accident or damage to the unit. Operators must also receive
regular safety instructions.
• Any troubleshooting guides, component views, and parts
lists included in this manual are for general reference
only and are intended for use by qualified and trained
technicians.
• This manual should be considered a permanent part of
this appliance. This manual and all supplied instructions,
diagrams, schematics, parts lists, notices, and labels must
remain with the appliance if the item is sold or moved to
another location.
NOTICE: For equipment delivered for use in
any location regulated by the following
directive: 2012/95/EC WEEE
DO NOT dispose of electrical or
electronic equipment with other
municipal waste.
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury.
NOTICE: Indicates information considered important,
but not hazard-related (e.g., messages
relating to property damage).
Knowledge of proper procedures is essential to the safe operation
of electrically and/or gas energized equipment. The following
signal words and symbols may be used throughout this manual.
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •7
Safety Procedures and Precautions
• To prevent serious injury, death, or property damage,
your appliance should be inspected and serviced at
least every twelve (12) months by an authorized service
partner or trained technician.
• ONLY allow an authorized service partner or trained
technician to service or to repair your appliance.
Installation or repairs that are not performed by an
authorized service partner or trained technician, or
the use of non-factory authorized parts, will void the
warranty and relieve Alto-Shaam of all liability.
• When working on this appliance, observe precautions in
the literature, on tags, on labels attached to or shipped
with the appliance, and other safety precautions that
may apply.
• If the appliance is installed on casters, freedom of
movement of the appliance must be restricted so that
utility connections (including gas, water, and electricity)
cannot be damaged when the unit is moved. If the
appliance is moved, make sure that all utility connections
are properly disconnected. If the unit is returned to its
original position, make sure that any retention devices
and utility connections are properly connected.
• ONLY use the appliance when it is stationary. Mobile
oven racks, mobile plate racks, transport trolleys, and
appliances on casters can tip over when being moved
over an uneven oor or threshold and cause serious
injury.
• ALWAYS apply caster brakes on mobile appliances or
accessories when these are not being moved. These
items could move or roll on uneven oors and cause
property damage or serious injury.
• Be extremely careful when moving appliances because
the food trays may contain hot uids that may spill,
causing serious injury.
• ALWAYS open the appliance door very slowly. Escaping
hot vapors or steam can cause serious injury or death.
• If your gas appliance is installed under an exhaust
hood, the hood must be switched ON when the oven
is in use to avoid the buildup of combustion gases.
Failure to do so may result in serious injury, death, or
property damage.
• NEVER place objects near the oven exhaust vents. This
area is hot and could be a potential ignition source for
a re.
• Do not allow objects to block or obstruct the area
below the oven base. This may result in re, damage
to the equipment, or serious injury.
• Do not use the attached hand-held hose to spray
anything other than the interior of the oven
compartment.
• Do not use the attached hand-held hose on the
surface of a hot cooking compartment. The sudden
temperature change can damage the oven interior.
Allow the oven to cool to a minimum of 150°F (66°C).
Failure to observe this precaution can void the
warranty.
WARNING
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
concerning use of the appliance by person
responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
WARNING
DO NOT obstruct or block exhaust flues
or attach any flue extension that may
impede proper burner operation, restrict
the exhaust fumes and cause negative
backdra or the appliance to shut down.
Failure to do so may result in serious injury
or death.

8 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Labels
Made in U.S.A.
WARNING
Hot surface
WARNING
Electric shock hazard
LA-39123
WARNING / ADVERTENCIA / AVERTISSEMENT
Burn hazard. Always load liquids, or foods that can become liquid
when heated, at an eye level where they can be seen.
Peligro de quemaduras. Siempre coloque líquidos, o alimentos que
se puedan volver líquidos cuando se calientan, a nivel de los ojos
donde se puedan ver.
Risque de brûlure. Toujours charger les liquides, ou les aliments qui
deviennent liquides au chauffage, à hauteur des yeux où ils peuvent
être vus.
WARNING
Burn hazard
Always load liquids, or foods that can become liquid
when heated, at an eye level where they can be seen.
LA-39155
Every Alto-Shaam product is precision calibrated prior to
release from the factory to ensure accurate temperature
control.

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •9
Labels
LA-36443-L1
Line 1 supply terminal
LA-36443-L2
Line 2 supply terminal
LA-36443-L3
Line 3 supply terminal
LA-36443-L2/N
Neutral
LA-36443-G
Ground terminal
LA-36443-E
Equipotential terminal
LA-38911
Drain water connection point.
LA-38910
Untreated, drinkable water connection point.
LA-38909
Treated, drinkable water connection point.

10 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Labels
LA-38940
kg max. liter max. GN 1/1
6-10 33 57 6
10-10 54 95 10
7-20 76 133 14
10-20 109 190 20
20-10 109 190 20
20-20 218 380 40
kg
∑ ∑ ∑
Capacities
Fire hazard
This unit is only for use with factory-supplied legs,
casters, or base.
Read the installation manual.
LA-39336

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •11
Labels
Warning
Steam. Open door carefully.
LA-39126
Warning
Failure to follow cleaning instructions can cause injury
or equipment damage. Clean oven only with Combitherm
cleaner. Cleaner is caustic. Avoid contact with skin or
eyes. Wear PPE. Read and understand the Combitherm
cleaner safety data sheet and the operator’s manual
before cleaning.
LA-39149
CombiTabs

12 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Labels
Warning
Electric Shock Hazard
Appliances with permanent electrical connection that
are mounted on casters must be secured to building
structure. Read installation instructions.
LA-39148
Warning
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing the
equipment.
Water and waste connection shall comply with the
basic plumbing code of the Building Officials and Code
Administrators International, Inc. (COCA) and the
Food Service Sanitation Manual of the Food and Drug
Administration (FDA).

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •13
Labels
Warning
Fire Hazard
For use only on noncombustible surfaces. Maintain the
correct clearances to combustibles.
Read the installation instructions.
City of New York Fire Department condition of
acceptance number.
Notice
For trained personnel only: The installation manual and
the wiring diagram for this appliance can be found inside
the oven attached to the opposite side of this panel.

14 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Labels
LA-38950
WARNING/ADVERTENCIA/AVERTISSEMENT
Electric Shock Hazard
To reduce the risk of electric shock, do not remove or
open cover. No user-serviceable parts inside.
Refer servicing to qualified personnel.
Qualified personnel: Disconnect power before servicing.
Danger de décharge électrique
Pour réduire le risque de décharge électrique, ne par
ouvrir ni retirer le capot. Ne contient pas de pièces
réparables par l’utilisateur. Confier les réparations à du
personnel qualifié.
Personnel qualifié : Sectionnez l’alimentation avant
toute intervention.
Peligro de descarga eléctrica
Para reducir el riesgo de descarga eléctrica, no retire ni
abra la cubierta. No hay piezas en el interior a la que se
les pueda realizar mantenimiento. Derive el mantenimiento
a personal calificado.
Personal calificado: Desconecte la energía antes de
realizar mantenimiento.
Warning
Electric shock hazard.
To reduce the risk of electric shock, do not remove or
open cover. No user-serviceable parts inside. Refer
servicing to qualified personnel.
Qualified personnel: Disconnect power before servicing.
Use ______AWG for supply connecons.
Use only copper wires suitable for temperatures ≥ 90°C.
For use on individual branch circuits only.
Do not connect to a circuit operang at
more than 150 VAC to ground.
Use AWG ______ para las conexiones de suministro.
Use solo cables de cobre aptos para temperaturas mayores que 90 °C.
Para su uso en circuitos derivados individuales solamente.
No conecte a un circuito que funcione a más de 150 V CA a erra.
Uliser du calibre ______AWG pour les raccordements électriques.
Uliser exclusivement des conducteurs en cuivre qui conviennent à des
températures ≥ 90 °C.
Uliser exclusivement sur des circuits de dérivaon propres.
Ne pas raccorder à un circuit fonconnant sous plus de
150 VCA par rapport à la terre.
LA-38852
90°C
AWG
Use ______AWG for supply connections.
Use only copper wires suitable for temperatures ≥90°C.
Do not connect to a circuit operating at more than 150
VAC to ground.
For use on individual branch circuits only.
LA-25784
NOTICE: Use only factory-supplied casters when needed. When
this appliance includes casters, the following must also be installed:
• a connector complying with ANSI Z21.69 / CSA 6.16;
• a quick-disconnect device complying with ANSI Z21.41 / CSA 6.9;
• a restraining device to guard against transmission of strain to the
connector as specified in the manual.
AVISO:Solo use ruedas proporcionadas de fábrica cuando sea
necesario. Si este equipo incluye ruedas, también se debe instalar
lo siguiente:
• un conector que cumpla con las normas ANSI Z21.69 y CSA 6.16;
• un dispositivo de desconexión rápida que cumpla con las normas
ANSI Z21.41 y CSA 6.9;
• un dispositivo de sujeción para proteger contra la transmisión de
tensión al conector como se especifica en el manual.
AVIS :S’il y a lieu, utiliser uniquement les roulettes fournies par
le fabricant. Si cet appareil comporte des roulettes, les articles
suivants doivent également être installés :
• un connecteur conforme à ANSI Z21.69 / CSA 6.16;
• un raccord découpleur rapide conforme à ANSI Z21.41 / CSA 6.9;
• un moyen de retenue pour empêcher la transmission de la
contrainte au connecteur comme indiqué dans le manuel.
NOTICE: Use only factory-supplied casters when needed.
When this appliance includes casters, the following must
also be installed:
• a connector complying with ANSI Z21.69 / CSA 6.16;
• a quick-disconnect device complying with
ANSI Z21.41 / CSA 6.9;
• a restraining device to guard against transmission of
strain to the connector as specified in the manual.

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •15
Installation Codes and Standards
SITE INSTALLATION
INSTALLATION CODES & STANDARDS
The following codes and standards are required for
installation of this oven:
AIR SUPPLY, ELECTRICAL CONNECTIONS, WATER
CONNECTIONS, AND WASTE WATER DISCHARGE.
Gas oven installations shall comply with local codes
required for gas appliances. In the absence of local codes,
installation shall comply with the latest edition of:
• USA: National Fuel Gas Code, ANSI Z223.1 (NFPA 54).
And OSHA Regulations
• Canada: Natural Gas and Propane Installation Code,
CAN/CSA-B149.1-15
• EU: European Standard EN203
• Australia/New Zealand: AS 5601
Adherence to code by a qualied installer is essential for
the following: gas plumbing, gas appliance installation,
commercial cooking ventilation, water and plumbing.
WARNING
Improper installation, alteration, adjustment, service,
cleaning, or maintenance could result in property
damage, severe injury, or death.
Read and understand the installation, operating and
maintenance instructions thoroughly before installing,
servicing, or operating this equipment.
SOUND PRESSURE MEASUREMENTS
The A-weighted sound pressure level without ventless
hood operating is less than 70dBA.
WARNING
Electric shock hazard.
Perform lockout/tagout procedures before
cleaning or servicing this appliance.
VENTILATION REQUIREMENTS
A steam ventilation hood is mandatory for the operation
of the oven. In addition, a single gas Combitherm oven
requires a minimum of 28 CFM (793 LPM) make-up air
for both natural and propane gas. Authorities having
jurisdiction should be consulted as to the requirements
for this equipment with respect to ventilation and re
extinguishing systems to ensure conformity with any
Federal, State, or local installation codes.
See the section titled Gas Exhaust
INSTALLATION TEMPERATURE REQUIREMENTS
Malfunctions may occur if the oven is put into service
too soon aer having been stored or transported in cold
temperatures. Therefore, allow the oven to acclimate to
room temperature at the installation site for at least 24
hours before use. If this is impractical, install the oven
as directed and immediately run it in convection mode
at 450°F (232°C) for 25–30 minutes. Then proceed with
completing all remaining functional tests.
NOTICE: ALWAYS remove the electronic control boards
BEFORE welding any stainless steel components
on this appliance. Failure to do so will damage
the control boards and may void thewarranty.

16 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Technical Specications
GENERAL SPECIFICATIONS
Installation must be performed by a qualied technician. Strict adherence to local codes and standards is required for
installation of this oven. Code requirements apply, but are not limited, to:
• Air supply
• Electrical connections
• Water connections
• Waste water discharge
• Natural gas / LP supply (gaseous ovens only)
Water Requirements and Standards
Water requirements (per oven)
• Two cold water inlets - drinking quality
• One treated water inlet: 3/4” NPT connection.
Line pressure 30 psi minimum dynamic and 90 psi
maximum static (200-600 kPa) at a minimum ow
rate of 0.26 gpm (1 L/min).
• One untreated water inlet: 3/4” NPT connection.
Line pressure 30 psi minimum dynamic and 90 psi
maximum static (200-600 kPa) at a minimum ow
rate of 2.64 gpm (10 L/min).
• Water drain: 1-1/2” (40mm) connection with a
vertical vent to extend above the exhaust vent.
Materials must withstand temperatures up to 200°F
(93°C).
Clearance requirements for water ltration system
Do not install a water ltration system behind unit.
CLEARANCE
WATER
Water Quality Standards
It is the sole responsibility of the owner/operator/purchaser
of this equipment to verify that the incoming water supply
is comprehensively tested and, if required, a means of
“water treatment” provided that would meet compliance
requirements with the published water quality standards
shown below. Non-compliance with these minimum
standards will potentially damage this equipment and/or
components and void the original equipment manufacturer’s
warranty. Alto-Shaam recommends using the Alto-Shaam
Reverse Osmosis System to properly treat your water.
Inlet Water Requirements
Contaminant Treated Water Untreated Water
Free Chlorine Less than 0.1 ppm (mg/L) Less than 0.1 ppm (mg/L)
Hardness 30-70 ppm 30-70 ppm
Chloride Less than 30 ppm (mg/L) Less than 30 ppm (mg/L)
pH 7.0 to 8.5 7.0 to 8.5
Silica Less than 12 ppm (mg/L) Less than 12 ppm (mg/L)
Total Dissolved Solids (tds) 50-125 ppm 50-360 ppm

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •17
Technical Specications
OVEN SPECIFICATIONS
Specication sheets for Combitherm ovens are available at www.alto-shaam.com. You can also view and download
PDFs by scanning the QR codes on this and the following pages with the camera on your mobile device or tablet.
CTC6-10E CTC6-10G CTC6-10E with Ventech Hood Stacked CTC6-10E with
Ventech Hood
Stacked CTC6-10E over CTC10-10E
w/Ventech Hood
CTC6-10E over Vector F CTP6-10E CTP6-10G
CTP6-10E with Ventech Hood Stacked CTP6-10E Stacked CTP6-10E with
Ventech Hood
Stacked CTP6-10E over
CTP10-10E
Stacked CTP6-10E over CTP10-10E
w/Ventech Hood
CTP6-10E over Vector F Stacked CTP6-10G

18 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Technical Specications
OVEN SPECIFICATIONS (Continued)
CTC7-20E CTC7-20G CTC7-20E with Ventech Hood Stacked CTC7-20E
Stacked CTC7-20E with
Ventech Hood
Stacked CTC7-20G CTC7-20E over Vector F CTP7-20E
CTP7-20G Stacked CTP7-20G CTP7-20E with Ventech Hood Stacked CTP7-20E
Stacked CTC7-20E with
Ventech Hood
CTP7-20E over Vector F CTC10-10E CTC10-10G
CTC10-10E with Ventech Hood CTP10-10E CTP10-10GE CTP10-10E with Ventech Hood

MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual •19
Technical Specications
OVEN SPECIFICATIONS (Continued)
Stacked CTP10-10E over
CTP7-20E
CTC10-20E CTC10-20G CTC10-20E with Ventech
CTP10-20E CTP10-20G CTP10-20E with Ventech Hood CTC20-10E
CTC20-10G CTP20-10E CTP20-10G CTC20-20E
CTC20-20G CTP20-20E CTP20-20G

20 •MN-35947 •Rev 22 •10/22 •Combitherm® CT PROformance™ and CT Classic Series Installation Manual
Installation
components
protrude below
oven
SITE INSTALLATION
WARNING
To prevent serious injury, death, or property damage:
• Always keep appliance on top of a pallet when using a
fork li or a pallet li truck to move appliance.
• Always use a suicient number of trained and
experienced workers to place the appliance on floor,
stand, or counter.
INSTALLATION
To ensure proper operation, the installation of this oven must
be completed by qualied technicians in accordance with
the instructions provided in this manual. Failure to follow
the instructions provided may result in damage to the oven,
building, or cause personal injury to personnel.
      
     
  
LIFTING INSTRUCTIONS
Remove banding before liing. Li the unit from the
front only, never from the side.
Adjust the forks so that they do not damage any of the
components under the unit. Note that the control side
of the oven is the heaviest portion. Li the unit just
high enough to remove the wooden pallet. Lower the
unit as close to the oor as possible and no more than
2" (50mm) above the oor. Secure hoses and dangling
cords to avoid tangling or damage. When moving the
unit, drive slowly, keep it low to the ground, and use
extreme caution.
Grease Collection Pump
NOTICE: To prevent PROPERTY DAMAGE:
Check the dimensions of the doorways and
aisles before attempting to move the oven and
pallet to the installation site.
Do not tilt the oven. Transport the oven in an
upright and level position only.
Slide the preheat strip into place before using
a forkli or pallet jack in between the trolley
guides to avoid damaging the preheat strip
when liing.
