COMBITHERM®
●Flash-steam generation design makes
conventional steam generator obsolete:
— Eliminates steam generating boiler maintenance
— Ends boiler heating element burn-out
— Maintains steam levels without a water reservoir
●Cook by internal product temperature or time with temperature
variable steam, convection heat, or a combination of both to roast,
steam, bake, or oven-fry in a single piece of equipment.
●Provides increased food quality and expands menu options
while increasing production efficiency and speed by as much
as 70-percent compared to conventional cooking methods.
●EcoSmart™technology reduces energy cost by using less
electricity and water during both normal operation and the
cleaning function.
●Gold-n-Brown™ feature provides the operator with the ability to
add additional product color.
●AutoClean™ feature simplifies the cleaning process to a single
oven function.
●Standard and Deluxe control offers 2-speed fan, a cool-down
feature, additional moisture injection, Delta-T cooking,
multiple language display, and other control features.
●Enhanced safety feature includes automatic steam venting
before door is opened. (U.S. Pat. 7,282,674)
●Optional patented smoking technology (U.S. Pat. 7,157,668)
gives operators the unique ability to smoke any product,
hot or cold, and follow it with a non-smoked item without
any residual smoke flavor.
1018ESi
ELECTRIC COMBINATION OVEN/STEAMER
ANSI/NSF 4
W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A.ONLY
www.alto-shaam.com
ODELS:
■■10•18ESi: STANDARD
■■10•18ESi: DELUXE
■■10•18ESi: S-CONTROL
MODEL 10•18ESiDELUXE
CAPACI Y OF WEN Y (20) FULL-SIZE OR GN 1/1 PANS,
EN (10) FULL-SIZE SHEE OR GN 2/1 PANS
SHOWN WI H OP IONAL MOBILE S AND 5005736
SHORT FOR SPECIFICATIONS:
Provide Alto-Shaam Combitherm®Model 10•18ESi flash-steam combination oven/steamer designed with EcoSmart™ technology for
reduced energy and water usage and include operational modes for steam, convection, and a combination of steam and convection heat.
Standard features to include patented, automatic steam venting; Gold-n-Brown™ browning function; and a self-adjusting, flush-mounted
rotary door handle with a steam venting safety stop. Control to include 2-speed fan and cool-down function. Oven cavity is to be
constructed of 18 gauge stainless steel, include an attached spray hose with backflow preventer, and automatic cleaning function. The
oven is to accommodate up to 10 full-size sheet pans or 20 full-size hotel pans, include a removable door gasket for easy replacement, and
standard right-hand door hinging. The oven is to include the patented smoking function (only if requested with order).
STANDARD CONTROL: To include removable quick-connect internal product temperature probe in the oven interior.
DELUXE CONTROL: To include removable quick-connect internal product temperature probe in the oven interior
and programming capability with Rapid-Touch™ operational quick-keys.
S-CONTROL: To include removable quick-connect internal product temperature probe in the oven interior
and smoking function as an option.
STANDARD FEATURES AND ACCESSORIES
• Five (5) stainless steel shelves
• Two (2) stainless steel side racks with
Ten (10) non-tilt pan support rails
21-1/16" (535mm) horizontal width between rails
2-5/8" (65mm) vertical spacing between rails
• Four (4) adjustable legs
• One (1) hand-held shower with backflow preventer PATENT PENDING
• One (1) flush-mounted rotary door latch with steam venting position
• Single-point detachable temperature probe
(OPTIONAL ON S-CONTROL MODELS)

#441 - 1/08 DUE TO ONGOING PRODUCT IMPROVEMENT, S P E C I F I C A T I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E . www.alto-shaam.com
ELECTRIC COMBINATION OVEN/STEAMER 1018ESi
C A PA C I T Y
FULL-SIZE PANS: 20" x 12" x 2-1/2" Twenty (20) Eighteen (18)
GN 1/1: 530 x 325 x 65mm Twenty (20) Eighteen (18)
GN 2/1: 650 x 530 x 65mm Ten (10) Eight (8)
FULL-SIZE S EET PANS:* 18" x 26" x 1" Ten (10) Nine (9)
ON WIRE SHELVES ONLY
240 lb (109 kg) MAXIMUM
VOLUME MAXIMUM: 150 QUARTS (190 LITERS)
WEIGHT
NET 514 lb EST. (233 kg) EST.
SHIP 754 lb EST. (342 kg) EST.
CRATE 46" X51" X46" EST.
DI ENSIONS:(1168 x 1295 x 1168mm)
E L E C T R I C A L 1 0 • 1 8 E S i 1 0 • 1 8 E S i / s k
VOLTAGE PHASE CYCLE/HZ AWG A PS kW A PS kW
at 208 3 50/60 3 Wire plus ground 61.1/ph 22.0 62.5/ph 22.5
at 240 AWG 2 70.3/ph 29.2 71.5/ph 29.7
at 380 3 50/60 4 Wire plus ground 33.5/ph 22.0 34.2/ph 22.5
at 415 AWG 8 40.7/ph 29.2 41.4/ph 29.7
at 440 3* 50/60 3 Wire plus ground 35.7/ph 27.2 36.4/ph 27.7
at 480 AWG 8 43.5/ph 36.1 44.0/ph 36.6
* ELECTRICAL SERVICE CHARGE APPLIES
208-240
380-415
440-480
30"
(760mm)
4-11/16" (120mm)
2-5/16" (58mm)
22-3/8"
(568mm)
15-1/2"
(393mm)
12-3/4"
(323mm)
Electrical Connection
(Bottom)
2" (50mm)
46-7/8" (1190mm)
43-7/8"
(1114mm)
41-15/16"
(1064mm) 40-1/8"
(1019mm)
25-5/8"
(650mm)
8-11/16"
(219mm)
6-1/4" (158mm)
Water Drain
(Bottom)
42-13/16"
(1087mm)
33-1/8"
(840mm)
4-15/16"
(125mm)
Steam
Vents
(Top)
Water Drain
(Side Back)
69-3/8" (1761mm)
7-9/16" (192mm)
40-7/16" (1026mm)
32-7/8"
(834mm)
Treated Water
Intake (Bottom)
Untreated Water
Intake (Bottom)
Low Pressure
Valve (Top)
D I M E N S I O N S : x W x D
EXTERIOR:
40-7/16" x 43-7/8" x 42-13/16" (1026mm x 1114mm x 1087mm)
EXTERIOR WITH RETRACTABLE DOOR:
40-7/16" x 47-7/8" x 42-13/16" (1026mm x 1216mm x 1087mm)
INTERIOR:
30-3/4" x 23-1/2" x 28-7/16" (781mm x 596mm x 722mm)
*ADDITIONAL WIRE S ELVES REQUIRED FOR MAXIMUM CAPACITY
I N S TA L L AT I O N R E Q U I R E M E N T S
Oven must be installed level.
ood installation is required.
Water supply shut-off valve and back-flow
preventer.
C L E A R A N C E R E Q U I R E M E N T S
LEFT: 6" (152mm) PLUS SERVICE ACCESS: 18" (457mm) R ECOMMENDED
20" (508mm) F R O M H E AT P R O D U C I N G E Q U I P M E N T
RIGHT: 4" (102mm) TOP: 20" (508mm) FOR AIR MOVEMENT
BACK: 4" (102mm) BOTTO : 5-1/8" (130mm) FOR LEGS
COUNTER-TOP INSTALLATIONS MUST MAINTAIN 4" (102mm) MINIMUM
CLEARANCE FROM COUNTER SURFACE.
WAT E R R E Q U I R E M E N T S
TWO (2) COLD WATER INLETS - DRINKING QUALITY
ONE (1) TREATED WATER INLET: 3/4" NPT
ONE (1) UNTREATED WATER INLET: 3/4" NPT
LINE PRESSURE:30 to 90 psi
2.8 to 6.2 bar
WATER DRAIN: 1-1/2" FERNCO CONNECTION WIT AIR GAP
WAT E R Q U A L I T Y M I N I M U M S TA N D A R D S
USING A WATER SUPPLY NOT MEETING ALTO-S AAM'S
MINIMUM WATER QUALITY STANDARDS WILL VOID T IS
WARRANTY. It is the responsibility of the purchaser to ensure
that incoming water supply is compliant with the specifications
listed through adequate treatment measures. Installation of the
CombiGuard™ Water Filtration System is recommended, but this
system may not address all water quality issues present.
Contaminant Inlet Water Requirements (untreated water)
Free Chlorine Less than 0.1 ppm (mg/L)
ardness Less than 3 gpg (52 ppm)
Chloride Less than 30 ppm (mg/L)
p 7.0 to 8.5
Alkalinity Less than 50 ppm (mg/L)
Silica Less than 12 ppm (mg/L)
Total Dissolved
Solids (tds) Less than 60 ppm

#441 - 1/08 D U E T O O N G O I N G P R O D U C T I M P R O V E M E N T, S P E C I F I C AT I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E . www.alto-shaam.com
Seam Mode
A
utomatic steaming at 212°F (100°C)
Quick steaming between 213°F and
248°F (101°C and 120°C)
Low temp steaming between 86°F and
211°F (30°C and 99°C)
Combina ion Mode
Steam and convection cooking with a
temperature range of 212°F to 482°F
(100°C to 250°C)
Convec ion Mode
Cooking without steam at a
temperature range of 86°F to 482°F
(30°C to 250°C)
Re herm Mode
Food or plated meal reheating with
automatic steam injection at a
temperature range of 248°F to 320°F
(120°C to 160°C)
Core Tempera ure Mode
Cooking by sensing internal
product temperature in any
selected cooking mode
Gold-n-Brown
™
An automatic browning function
to be set or programmed as needed
to add additional product color in
the combination or convection mode
of operation.
Smoking Func ion (op ion)
Patented Alto-Shaam technology
(U.S. Pat. 7,157,668) provides the ability to
smoke any product, hot or cold,
utilizing real wood chips. The oven
also provides full mode function
without smoke or residual smoke
flavor. The smoking feature functions
in both combination and convection
mode and can be programmed into
deluxe model operating procedure.
1018ESi
ELECTRIC COMBINATION OVEN/STEAMER
S - C o n t ro l
The Combitherm S-Control
includes all basic combination
oven operational modes with the
use of rotary dials. The S-Control
also features the Gold-n-Brown™
automatic browning function, an
automatic cleaning setting, an
oven cool-down function, and a
half-speed fan position. S-Control
models can also be furnished with
a Smoker, which includes the Core
Temperature option package.
S t a n d a r d C o n t r o l
The Combitherm standard control
includes all operational functions
shown to steam, bake, and roast by
time or internal product temperature.
The control features the Gold-n-
Brown™automatic browning
function, a Retherm Mode for plate
regeneration, plus a wide variety of
auxiliary functions and operational
settings. This control is offered for
operators that do not require
programming capability.
D e l u x e C o n t r o l
(PICTURED)
The Combitherm deluxe control
includes all the operational functions
of the standard control and adds a
programming function. Program
memory can accept up to 250
procedures, each with up to 20 steps
in any combination of cooking
modes. The deluxe control also
features a set of 8 Rapid-Touch™
keys to assign frequently used
programs to cook at the touch of a
single button.

#441 - 1/08 DUE TO ONGOING PRODUCT IMPROVEMENT, S P E C I F I C A T I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E . www.alto-shaam.com
1018ESi
ELECTRIC COMBINATION OVEN/STEAMER
FA C T O RY I N S TA L L E D O P T I O N S
(MAY REQUIRE ADDITIONAL LEAD TIME)
■■ Smoking Function (U.S. PAT. 7,157,668)
NO C ARGE W EN REQUESTED AT TIME OF ORDER.
SAMPLE BAG OF WOOD C IPS INCLUDED.
■■ Recessed Door [5005761]
INCREASES OVEN WIDT BY 4" (102mm)
■■ Le t-Hand Door Swing [5005762]
Single-point removable temperature probe (PATENT PENDING)
INCLUDED ON STANDARD AND DELUXE OVENS
■■ OPTIONAL ON S-CONTROL OVENS [5005679]
■■ Multi-point, hard-wired internal product temperature probe [5005678]
NOT AVAILABLE ON OVENS WIT S-CONTROL
■■ Security Devices [5005680]
FOR CORRECTIONAL FACILITY USE
INCLUDES CONTROL SECURITY PANEL, DOOR LOCK, TAMPER-PROOF SCREW PACKAGE,
FLANGED LEGS FOR FLOOR OR COUNTER BOLTING (PADLOCKS NOT INCLUDED)
■■ Ventless Hood VHES-10 [5005690]
NOT AVAILABLE ON SMOKER MODELS OR STACKED COMBINATIONS
■■ Stacking Combinations
MUST BE SPECIFIED AT TIME OF ORDER
SEE INDIVIDUAL STACKING COMBINATION SPECIFICATIONS S EETS
■■6•10ESiOVER 10•18ESi, STATIONARY
■■6•10ESiN OVER 10•18ESi, STATIONARY
■■ADDITIONAL MOBILE STACKING STAND [5006473]
■■ Computer So tware Options [5005676]
Not available on S-Control Mod els.
REFER TO ACCP SPECIFICATION S EET #9015
FOR APPLICABLE PART NUMBERS
■■ HACCP Documentation
■■ HACCP Documentation with Kitchen Management
■■ Wireless HACCP Documentation with Kitchen Management
IEEE 802.11b STANDARDS

Fry Basket BS-26730 Grilling Grate S -26731
Stationary Stand with Shelf
5005731
Mobile Stand with Shelf
5005735
Stationary Stand with Pan Slides & Shelf
5005732
Mobile Stand with Pan Slides & Shelf
5005736
Stationary Stand with Shelf & Skirt
5005733
Mobile Stand with Shelf & Skirt
5005737
1018ESi
ELECTRIC COMBINATION OVEN/STEAMER
#441 - 1/08 D U E T O O N G O I N G P R O D U C T I M P R O V E M E N T, S P E C I F I C AT I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E . www.alto-shaam.com
Ten (10) Chicken Roasting Rack
S -22634
Six (6) Chicken Roasting Rack
(PAN NOT INCLUDED) S -23000

OPTIONS & ACCESSORIES
■■CHICKEN GREASE TRAY WIT DRAIN: 1-1/2" (38mm) DEEP 4758
■■CHICKEN GREASE TRAY WIT DRAIN: 2-3/4" (70mm) DEEP 14475
CHICKEN ROASTING RACKS:
■■6CICKEN CAPACITY — FITS FULL-SIZE PAN: 6 RACKS PER OVEN S -23000
■■8C ICKEN CAPACITY — FITS FULL-SIZE PAN: 6 RACKS PER OVEN S -23619
■■10 C ICKEN CAPACITY — FITS IN SIDE RACKS: 6 RACKS PER OVEN S -22634
■■CO BIGUARD™ TRIPLE-GUARD WATER FILTRATION SYSTE (INCLUDES 1 CARTRIDGE) FI-23014
■■CO BIGUARD™REPLACE ENT FILTER FI-26356
■■FRY BASKET, 12" X20" (325mm x 530mm) BS-26730
■■GRILLING GRATE, 12" X20" (325mm x 530mm) S -26731
■■OVEN CLEANER — SPECIALLY FORMULATED FOR COMBIT ERM OVENS
➥TWELVE (12) CONTAINERS/CASE, 1 QUART (C. 1 LITER) EAC CE-24750
■■SCALE FREE™(CITRUS BASED, NON-CORROSIVE DELIMING PRODUCT) CE-27889
■■SERVICE START-UP CHECK AVAILABLE THROUGH AN ALTO-SHAA FASTEA CENTER SPECIFY AS REQUIRED
■■SHELF, STAINLESS STEEL WIRE S -22584
STAND, STAINLESS STEEL (HXWXD):
■■➥STATIONARY WIT S ELF
28-15/16" X35-7/16" X28" (735mm x 900mm x 710mm) 5005731
■■➥STATIONARY WIT PAN SLIDES & S ELF
28-15/16" X35-7/16" X28" (735mm x 900mm x 710mm) 5005732
■■➥STATIONARY WIT S ELF & SKIRT
28-15/16" X35-7/16" X28" (735mm x 900mm x 710mm) 5005733
■■➥STATIONARY WIT PAN SLIDES, S ELF, & SKIRT
28-15/16" X35-7/16" X28" (735mm x 900mm x 710mm) 5005734
■■➥MOBILE WIT S ELF
33-7/8" X35-7/16" X28" (859mm x 900mm x 710mm) 5005735
■■➥MOBILE WIT PAN SLIDES & S ELF
33-7/8" X35-7/16" X28" (859mm x 900mm x 710mm) 5005736
■■➥MOBILE WIT S ELF & SKIRT
33-7/8" X35-7/16" X28" (859mm x 900mm x 710mm) 5005737
■■➥MOBILE WIT PAN SLIDES, S ELF, & SKIRT
33-7/8" X35-7/16" X28" (859mm x 900mm x 710mm) 5005738
■■➥STATIONARY 37" X35-7/16" X28" (940mm x 900mm x 710mm) 5006170
WOOD CHIPS — BULK PACK 20 lb (9 kg)
■■➥Apple . . .WC-22543 ■■➥Cherry . . .WC-22541 ■■➥ickory . . .WC-2829 ■■➥Maple . . .WC-22545
1018ESi
ELECTRIC COMBINATION OVEN/STEAMER
D U E T O O N G O I N G P R O D U C T I M P R O V E M E N T, S P E C I F I C AT I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E .P R I N T E D I N U .S.A. #441 - 1/08
W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaam.com
