COMBITHERM 7•14ES over 7•14ES
Stacked Electric Combitherm
Combination Oven/Steamer
W164 N9221 Water treet • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U. .A.
Phone: [phone].558.8744 U. .A./ Canada Fax: [phone].329.8744 U. .A Only
www.alto-shaam.com
ANSI/NSF 4
team generation:
■■ Boiler-free
■■ Boiler version
Controls:
■■ Standard
■■Deluxe
■■S-Control
Standard features and accessories:
• Four (4) stainless steel shelves (each oven)
• Two (2) stainless steel side racks with
Seven (7) non-tilt pan support rails (each oven)
21-1/16" (535mm) horizontal width between rails
2-5/8" (65mm) vertical spacing between rails
• Four (4) adjustable legs
• One (1) hand-held shower with backflow preventer
(patent pending).
• One (1) flush-mounted rotary door latches with steam
venting position (each oven)
• One (1) single-point detachable temperature probes
(optional on S-Control models) (each oven)
Model 7•14ES over
Model 7•14ES
Short form specifications:
Provide Alto-Shaam Combitherm®Model 7•14ES series over 7•14ES series stacked combination oven/steamer designed with
EcoSmart™technology for reduced energy and water usage and include operational modes for steam, convection, and a combination
of steam and convection heat. Standard features to include patented, automatic steam venting; Gold-n-Brown™browning function;
and a self-adjusting, flush-mounted rotary door handle with a steam venting safety stop. Control to include 2-speed fan, cool-down
function, and automatic decalcification program. Oven cavity is to be constructed of 18 gauge stainless steel, include an attached
spray hose with backflow preventer, and automatic cleaning function. Each oven is to accommodate up to 7 full-size sheet pans or 14
full-size hotel pans, include a removable door gasket for easy replacement, and standard right-hand door hinging.
tandard Control: To include removable quick-connect internal product temperature probe in the oven interior.
Deluxe Control: To include removable quick-connect internal product temperature probe in the oven interior.
and programming capability with Rapid-Touch™operational quick-keys.
-Control: To include removable quick-connect internal product temperature probe in the oven interior as an option.
Product hi hli hts:
• Cook by internal product temperature or time with temperature variable steam,
convection heat, or a combination of both to roast, steam, bake, or oven-fry in a single
piece of equipment.
• Provides increased food quality and expands menu options while increasing
production efficiency and speed by as much as 70% compared to conventional cooking
methods.
• EcoSmart™technology reduces energy cost by using less electricity and water during both
normal operation and the cleaning function.
• Gold-n-Brown™feature provides the operator with the ability to add additional
product color.
• AutoClean™feature simplifies the cleaning process to a single oven function.
• Standard and Deluxe control offers 2-speed fan, a cool-down feature, additional moisture
injection, Delta-T cooking, multiple language display, and other control features.
• Enhanced safety feature includes automatic steam venting immediately before cooking
time expires. (U.S. Pat. #7,282,674)
• The boiler-free version’s flash-steam generation:
— Eliminates steam generating boiler maintenance
— Ends boiler heating element burn-out
— Maintains steam levels without a water reservoir
• Optional patented smoking technology (U.S. Pat. 7,157,668) gives operators the unique
ability to smoke any product, hot or cold, and follow it with a non-smoked item without
any residual smoke flavor. Boiler-free version only.
Series Series
Version Available
Universal Stack options
■■ Stacked ovens with hinged doors and feet [5008331]
■■ Stacked ovens with recessed doors and feet [5008332]
■■ Stacked ovens with hinged doors and mobile base [5008651]
■■ Stacked ovens with recessed doors and mobile base
[contact factory for availability]
Top oven
team generation:
■■ Boiler-free
■■ Boiler version
Controls:
■■ Standard
■■Deluxe
■■S-Control
Bottom oven

Dimensions: (HxWxD)
Exterior: 65-1/8" x 43-7/8" x 42-13/16"
(1654mm x 1114mm x 1087mm)
Exterior with retractable door: 65-1/8" x 47-7/8" x 42-13/16"
(1654mm x 1216mm x 1087mm)
Interior (each oven):20-5/16" x 23-1/2" x 28-7/16"
(515mm x 596mm x 722mm)
Clearance Requirements:
Left: 6" (152mm) plus service access
18" (457mm) recommended
20" (508mm) from heat producing equipment
Right: 4" (102mm)
Top: 20" (508mm) for air movement
Back: 4" (102mm)
Bottom: 5-1/8" (130mm) for legs
Installation Requirements:
Oven must be installed level. Hood installation is required.
Water supply shut-off valve and back flow preventer.
Wei ht:
Net (est.) 850 lb (386 kg) hip 1,297 lb (588 kg)
Crate Dimensions:
83" x 52" x 52" 2108 x 1321 x 1321mm
Water Requirements (each oven):
One (1) treated water inlet: 3/4" NPT*
One (1) untreated water inlet: 3/4" NPT*
* Can manifold off of one 3/4" line.
Line Pressure: 30 to 90 psi, 2.8 to 6.2 bar
Water drain: 1-1/2" NPT connection with air gap
Water Quality Minimum Standards:
Using a water supply not meeting Alto- haam’s minimum
water quality standards will void this warranty.
t is the responsibility of the purchaser to ensure that
incoming water supply is compliant with the specifications
listed through adequate treatment measures. nstallation of
the CombiGuard™ Water Filtration System is
recommended, but this system may not address all water
quality issues present.
Contaminant Inlet Water Requirements (untreated water)
Free Chlorine Less than 0.1 ppm (mg/L)
Hardness Less than 3 gpg (52 ppm)
Chloride Less than 30 ppm (mg/L)
pH 7.0 to 8.5
Alkalinity Less than 50 ppm (mg/L)
Silica Less than 12 ppm (mg/L)
Total Dissolved
Solids (tds) Less than 60 ppm
7•14ES over
7•14ES
Stacked Electric Combitherm
Combination Oven/Steamer
42-13/16" (1087mm)
43-7/8" (1114mm)
41-7/8" (1064mm)
1-15/16" (50mm)
33-1/16" (840mm) 4-15/16" (125mm)
36-3/4" (934mm)
65-1/8" (1654mm)
57-9/16" (1462mm)
7-9/16" (192mm)
6-1/4" (158mm)
40-1/8" (1019mm)
9/16" (13mm)
8-5/8" (219mm)
25-5/8" (650mm)
Water Drain
(Top Unit)
Water Drain
(Bottom Unit)
TOP VIEW
SIDE VIEWFRONT VIEW
Low Pressure Valve
Untreated Water
Intake (Bottom)
Treated Water
Intake (Bottom)
Electrical
Connection
(Bottom)
Water Drain
(Side Back)
49-1/8" (1247mm)
2" (50mm)
12-3/4"
(323mm)
Steam Vent (Top)
69-3/8" (1761mm)
15-1/2"
(393mm)
22-3/8" (568mm)
4-11/16" (120mm)
2-5/16" (58mm)
30" (760mm)
Series
Series
Electrical: (each oven) 7•14ES 7•14ESi 7•14ESi/sk
Voltage Phase Cycle/Hz AWG Amps kW Amps kW Amps kW
at 208 1* 50/60 2 Wire plus ground 67.0 13.9 67.0 13.9 69.2 14.4
at 240 AWG 3 77.0 18.4 77.0 18.4 79.0 18.9
at 208 3 50/60 3 Wire plus ground 38.5/ph 13.8 38.6/ph 13.9 40.0/ph 14.4
at 240 AWG 6 44.0/ph 18.3 44.3/ph 18.4 45.5/ph 18.9
at 380 3 50/60 4 Wire plus ground 21.5/ph 14.2 21.1/ph 13.9 22.0/ph 14.4
at 415 AWG 10 25.6/ph 18.4 25.6/ph 18.4 26.3/ph 18.9
at 440 3* 50/60 3 Wire plus ground 20.0/ph 15.4 20.0/ph 15.4 21.0/ph 15.9
at 480 AWG 8 22.0/ph 18.4 22.0/ph 18.4 23.0/ph 18.9
* Electrical service charge applies.
Capacity: (each oven) 7•14ES 7•14ESi 7•14ESi/sk
Full-Size Pans: 20" x 12" x 2-1/2" 14 14 12
GN 1/1: 530 x 325 x 65mm 14 14 12
GN 2/1: 650 x 530 x 65mm 775
Full-Size Sheet Pans*: 18" x 26" x 1" 776
Weight capacity: 168 lb (76 kg)
Volume capacity: 105 quarts (133 liters)
*On wire shelves only. Additional wire shelves required for maximum capacity.
#460 - 05/08 Due to ongoing product improvement, specifications are subject to change without notice. www.alto-shaam.com

Standard Control
The Combitherm standard control includes all operational functions shown
to steam, bake, and roast by time or internal product temperature. The
control features the Gold-n-Brown™automatic browning function, a Retherm
Mode for plate regeneration, plus a wide variety of auxiliary functions and
operational settings. This control is offered for operators that do not require
programming capability.
Deluxe Control (optional)
The Combitherm deluxe control includes all the operational functions of
the standard control and adds a programming function. Program memory can
accept up to 250 procedures, each with up to 20 steps in any combination of
cooking modes. The deluxe control also features a set of 8 Rapid-Touch™ keys
to assign frequently used programs to cook at the touch of a single button.
S-Control (optional)
The Combitherm S-Control includes all basic combination oven operational
modes with the use of rotary dials. The S-Control also features the
Gold-n-Brown™ automatic browning function, an automatic cleaning setting, an
oven cool-down function, and a half-speed fan position. S-Control models can
also be furnished with a Core Temperature option package.
Standard
Control
Deluxe
Control
S-Control
Steam Mode
• Automatic steaming at 212°F (100°C).
• Quick steaming between 213°F and 248°F (101°C and
120°C).
• Low temperature steaming between 86°F and 211°F (30°C
and 99°C) – for poaching or proofing.
Combination Mode
• Combines steam and convection modes for faster
preparation and better moisture retention.
• mproves yield, quality and shelf life.
• Automatic humidity control.
• Temperature range of 212°F to 482°F (100°C to 250°C).
Convection Mode
• Cooking, roasting, baking and finishing applications at a
temperature range of 86°F to 482°F (30°C to 250°C).
Retherm Mode
• Bulk food or plated meal reheating with automatic
steam injection.
• Automatic humidity control.
• Temperature range of 248°F to 320°F (120°C to 160°C).
Core Temperature Mode
• Removable single-point probe monitors cooking time and
core food temperature.
Gold-n-Brown™
• An automatic browning function to be set or programmed
as needed to add additional product color in the
combination or convection mode of operation.
Smokin Function (optional on ESi ver ion only)
• Patented Alto-Shaam technology (U.S. Pat. 7,157,668)
• Smoke any product, hot or cold, utilizing real wood chips.
• Full mode function without smoke or residual
smoke flavor.
• Functions in both combination and convection mode.
• Function can programmed into deluxe model
operating procedure.
7•14ES over
7•14ES
Stacked Electric Combitherm
Combination Oven/Steamer
Series
Series
#460 - 05/08 Due to ongoing product improvement, specifications are subject to change without notice. www.alto-shaam.com
Factory Installed Options:
(may require additional lead time)
Smokin Function (U.S. Pat. 7,157,668)
■■ Top Oven
■■ Bottom Oven
ESi models only. No charge when requested at the time of
order. ncludes a sample bag of wood chips.
Recessed Door
■■ Top Oven
■■ Bottom Oven
ncreases oven width by 4" (102mm)
■■ Left-Hand Door Swin
Sin le-point removable temperature probe [5005679]
■■ Top Oven
■■ Bottom Oven
Optional on S-Control ovens, included on Standard
and Deluxe control ovens.
Multi-point, hard-wired internal product
temperature probe [5005678] Not available on
S-control ovens
■■ Top Oven
■■ Bottom Oven
Computer Software Options [5005676]
Not available on S-Control Models. Refer to HACCP
specification sheet #9015 for applicable part numbers
■■ HACCP Documentation
■■ HACCP Documentation with Kitchen
Mana ement
■■ Wireless HACCP Documentation with Kitchen
Mana ement
IEEE 802.11b STANDARDS

Options & Accessories
■
■Chicken Grease Tray with drain: 1-1/2" (38mm) deep 4758
■■Chicken Grease Tray with drain: 2-3/4" (70mm) deep 14475
Chicken Roasting Racks:
■
■6 chicken capacity — fits full-size pan: 4 racks per oven SH-23000
■■8 chicken capacity — fits full-size pan: 4 racks per oven SH-23619
■■10 chicken capacity — fits in side racks: 4 racks per oven SH-22634
■
■CombiGuard™ Triple-Guard Water Filtration System (includes 1 cartridge) F -23014
■■CombiGuard™ Replacement Filter F -26356
■■Fry Basket, 12" x 20" (325mm x 530mm) BS-26730
■■Grilling Grate, 12" x 20" (325mm x 530mm) SH-26731
■■Oven Cleaner — specially formulated for Combitherm ovens. Twelve containers/case, 1 quart (c. 1 liter) each CE-24750
■■Scale Free™ — citrus based, non-corrosive deliming product CE-27889
■■Service Start-Up Check — Available through an Alto-Shaam Fasteam Center SPEC FY AS REQU RED
■■Shelf, Stainless Steel Wire SH-22584
#460 - 05/08 Due to ongoing product improvement, specifications are subject to change without notice. www.alto-shaam.com
Fry Basket BS-26730 Grillin Grate SH-26731
Ten Chicken Roastin Rack
SH-22634
Six Chicken Roastin Rack
(pan not included) SH-23000
7•14ES over
7•14ES
Stacked Electric Combitherm
Combination Oven/Steamer
Series
Series
