CLARKE TECHNOLOGY Vision 21i /Vision V
Accessories-11/95
Accessories:
Description PartNo.
Power Wand System Kit 14634A
ESP Recycle System Kit 14633A
SoftCaster(Wheel only) 52127A
SoftTraverseWheel 59952A
LowVoltageShut-off(24v) 14097A
ClarkeTechnologyCareKit 14607A
FrameBumper 821203
Roller Kit (one side per Kit) 14693A
NitrileSqueegeeBlades:
Length Machine PartNo.
28.12" 21i 30938A
32.50" Vision V 30949A
RibbedSqueegeeBlades:
Length Machine PartNo.
29.88" Vision V 30948A
25.88 21i 30942A
BrushAssemblies:
Size Description PartNo.
11" Poly 11442A
11" Grit-Heavy 11443A
11" Grit-Medium11444A
11" Soft-Nylon 11441A
13" Poly 11438A
13" Grit-Heavy 11440A
13" Grit-Medium11439A
13" Soft Nylon 11437A
PadDrivers: Size Part No.
11" 17530A
13" 17531A

Page -26- Clarke Technology Operator's Manual -Vision 21i - Vision V
ClLARKE TECHNOLOGY Vision 21i / Vision V
RearCover AssemblyDrawing 7/99
47
21
4
43
44 45
83
40 84
40
12
35
34
78
42
84
39
81
38
23
22
21
84
4728
23
27
1
77 90 51 53
61
8560
70 23
62
71
67
55 85
18
57
85
48
56
65
23
89
88
87
72
49
48
63
54
30
46
75
15
16
21
59
17
20
13
14
8
82
19
12
10
11
65
23
23
66
64
63
779
6
5
4
350
36
37
33
80
41
26
3179
32
224 25
5
3
42

Clarke Technology Operator's Manual - Vision 21i - Vision V 27
CLARKE TECHNOLOGY Vision 21i / Vision V
RearCoverAssembly Parts List 7/99
Ref# PartNo. Description Qty
1 49720A MainHarness 1 x x
2 66533A HandlePin 2 x x
3 85390A Screw,¼-20 x 1¼ PN 2 x x
4 980657 Washer, Lock 1/4 2 x x
5 24308A ControlHandle 1 x x
6 34608A ControlHandleGrip 2 x x
7 962262 Screw, 8-32 x ¼ Set 2 x x
8 47380A Key Switch, W/Key 1 x x
9 55502A Knob 1 x x
10 47381A Switch(HeadUp/Down) 1 x x
11 47383A Switch(3SpeedTrav.) 1 x x
12 962966 Screw, 10-24 x ¾ PN 6 x x
13 34264A Gasket 2 x x
14 69339B ConsolePanel 1 x x
15 80011A Screw, 3/8-16 x 3 CR 2 x x
16 85395A Screw, ¼-20 x ½ PN 1 x x
17 64462A StationaryHandle 2 x x
18 980666 Washer,Starlock3/81xx
19 77208A WiringLabel 1 x x
20 64508A CoverHinge 1 x x
21 85391A Screw, ¼-20 x 5/8PN 8 x x
22 77211B WiringLabel 1 x x
23 81104A Nut, ¼-20 ESNA 20 x x
24 61651A ControlSwitchCollar 1 x x
25 60662A CenteringBracket 1 x x
26 53038A Spring 2 x x
27 83302A Stud 2 x x
28 854849 Insulator 2 x x
29 61652A SolutionControl 1 x x
30 30024A RearCover 1 x
31 962304 Screw, 5/16-18 x ½ Set 4 x x
32 69507A CoverSupport,LH 1 x x
33 980652 Washer,Lock5/16 4xx
34 920296 Nut,10-24ESNA 2 x x
35 46318A Relay- .12 Sec. (F/N/R) 1 x x
36 81301A Nut,3/8-16Jam 2 x x
37 85813A Screw,5/16-18x 3/4HX 4 x x
38 10052A ToggleSwitch(Traverse) 1 x x
39 41810A Solenoid,BrushMotor 1 x x
40 878514 Solenoid, Vac, Speed Ctrl 3xx
41 69506A CoverSupport,RH 1 x x
42 41811A Solenoid,For./Rev. 2 x x
Vision 21i Vision V
Vision 21i Vision V
Ref# PartNo. Description Qty
43 831105 Tank stop Brushing 2 x x
44 836707 Pin 2 x x
45 920280 Nut,5/8-18 2 x x
46 73714A WarningPlate 1 x x
47 63342A FrameWeldment 1 x x
48 61653A SqueegeeLiftCable 1 x x
49 856702 Hairpin 2 x x
50 902731 NylinerBushing 2 x x
51 41448A Circuit Breaker, 30A (Vac) 1 x x
53 41423A Circuit Breaker, 5A (
Hd. Act.) 1xx
54 85518A Screw, ¼-20 x 3/4PN 5 x x
55 64490A Handle 1 x x
56 47388A Switch Asm., Vac 1 x x
57 85389A Screw,3/8-16 x 5/8PN 1 x x
59 87029A Washer, Flat 3/41xx
60 80028A Bolt 1 x x
61 438360 Spring 1 x x
62 65619A SqueegeeLiftLever 1 x x
63 920056 Nut, 6-32 ESNA 4 x x
64 60676A Power,Conn.Bracket 1 x x
65 962980 Screw, 6-32 x 1 PN 4 x x
66 41146A ConsoleCableAssembly 1 x x
67 61260A SqueegeeLiftBracket 1 x x
70 608210 Spacer 1 x x
71 962285 Screw, ¼-20 x 1 Flat 1 x x
72 Pg.28 Pin Bracket ref. #25 1 x x
74 980651 Washer,Flat5/16 1xx
75 930093 Rivet 2 x x
77 41431A Circuit Breaker 35A (Br.Mtr.) 1xx
78 46317A Relay, 3 sec. (HSD) 1 x x
79 87202A Washer,Lock 1 x x
80 980205 Washer 4 x x
81 42404A Diode Asm. 1 x x
82 55413A Key 1 x x
83 51867A Clamp,Cable 1 x x
84 170915 Screw, ¼-20 x 3/4Hex 16 x x
85 87026A Washer, Flat ¼ 8 x x
86 85700A Screw ¼-20 x 1 Hex 2 x x
87 962546 Screw, #10-24 X ½ 2 x x
88 980675 Washer 2 x x
89 68643A Plate,Wear 1 x x
90 41444A CircuitBreaker30A (Trav.) 1xx

Page -28- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
TraverseSystemAssemblyDrawing 2/00
16
17
15
19
13
7
14
12
11
32
25
18
25
4
10
5
89
45
6
7
7
24
3
2
1
22
21
23
41
42
40
39
38 24
37 35
36 34
30
43
26
16
33
29
19 30
16
31
27
28
2
20

Clarke Technology Operator's Manual - Vision 21i - Vision V 29
CLARKE TECHNOLOGY Vision 21i - Vision V
Traverse System Assembly Parts List 2/00
Ref# PartNo. Description Qty
1 63342A Frame 1 x x
2 85727A Screw, 3/8-16 x 1 Hex 12 x x
3 848302 BrakeSpring 1 x x
4 81104A Nut, ¼-20 Hex ESNA 4 x x
5 87026A Washer, Flat ¼ 5 x x
6 438360 Spring 1 x x
7 920110 Nut, 5/16-18,ESNA 3 x x
8 838214 Brake Arm Spacer 1 x x
9 60412A Brake Arm 1 x x
10 848508 Brake RodSwivel 1 x x
11 67147A BrakeRod 1 x x
12 925004 Cotter Pin 2 x x
13 85814A Screw, 5/16-18 x 1.25 Hx 1 x x
14 16703A BrakeLever 1 x x
15 67877A BrakePedalSpacer 1 x x
16 85811A Screw,5/16-18x 3/4Hex 5 x x
17 60663A Brake Pedal Bracket 1 x x
18u60246A Guard 1 x x
19 980651 Washer,Flat5/16 3xx
20 85816A Screw, 5/16-18 x 1.5 Hx 1 x x
21 915102 Key 1 x x
22 45038A TraverseMotor 1 x x
23 51828A Strap 1 x x
24 81105A Nut, 3/8-16ESNA 12 x x
25u170892 Washer, Lock ¼ 7 x x
26 170915 Screw, ¼-20 x 3/44xx
27 899769 Caster Assembly 2 x x
28 980638 Washer, Lock 3/88xx
29 962593 Screw, ¼-20 x 3/8set 2 x x
30 980652 Washer,Lock5/16 5xx
31 980205 Washer 1 x x
32u85395A Screw, ¼-20 x ½ 3 x x
33 52202A Chain 1 x x
34 898550 DriveSprocket 1 x x
35 895158 Master Link 1 x x
36 838506 DrivenSprocket 1 x x
37u980475 SpacerWasher 3 x x
38 69009A Axle Strap 2 x x
39 60154A Shaft 1 x x
40 883351 GreaseFitting 1 x x
41 59944R WheelAssembly 1 x x
42u30063A Sheild,WheelGuard 1 x x
NIu77266B Label,ParkingBrake 1 x x
Vision V Vision 21i
NOTE: uindicates a change has taken place
since last publication of this manual

Page -30- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
Squeegee&Squeegee Arm AssemblyDrawing 1/97
34 11 ref.
45
42 33 34
35
21
37 23
22
21
20 18
19
38
39
11
12
14
10
26
15
16
46
26
11
36
1
23
40
4
6
5
8
7
13
41
26 17 25
27
28
44
43
29
30
32
31
24
9

Clarke Technology Operator's Manual - Vision 21i - Vision V 31
Ref# PartNo. Description Qty
1 80011A Screw, 3/8-16 x 3 CR 2 x x
2 62712A Duct 1 x x
3 62430A ClampWeld 1 x
62424A ClampWeld 1 x
4 62421A EndClamp 2 x x
5 86004A Screw, ¼-20 x 1.50 Hx 2 x x
6 30946A OuterBlade 1 x
30931A OuterBlade 1 x
7 38719A Spacer 2 x
38713A Spacer 2 x
8 30947A InnerBlade 1 x
30930A InnerBlade 1 x
9 81301A Nut,3/8-16JAM 6 x x
10 69613A SqueegeeWeld. 1 x
69059A Sq. Weld. 1 x
11 980687 Washer3/8ID 11 x x
12 59950A GuideWheel 2 x x
13 962522 Screw,3/8-16x1.50Hex 2 x x
14 25201A Knob 2 x x
15 34260B SqueegeeGasket 1 x x
16 419702 Wheel 2 x x
17 61242A TubeBracket 1 x x
18 170915 Screw, ¼-20 x 3/4Hex 4 x x
19 87026A Washer, Flat ¼ 5 x x
20 920256 Nut,5/16-18Hex 2 x x
21 81104A Nut, ¼-20 Hex ESNA x x
22 60659A SqueegeeSpringBrkt. 2 x x
23 68013A SqueegeeAdj.Stud 2 x x
24 60417A RearArm 1 x x
25 61249A Pin Bracket 1 x x
26 81105A Nut, 3/8-16ESNA 5 x x
27 962269 Screw, ¼-20 x 2.50 Hex 1 x x
28 82505A SqueegeeActuatorPin 1 x x
29 63009A SqueegeeLiftBar 1 x x
30 80015A ShoulderBolt 1 x x
31 920056 Nut, 6-32 ESNA 4 x x
32 962920 Screw, ¼-20 x 3.4 Soc. 1 x x
33 60420A Front Arm 1 x x
34 920110 Nut,5/16-18ESNA 5 x x
35 56493A SqueegeePress.Spring 2 x x
36 18810A SqueegeAsm. 1 x
18807A SqueegeeAsm. 1 x
37 836711 Hairpin 3 x x
38 85727A Screw, 3/8-16 x 1 Hwx 1 x x
39 85704A Screw,3/8-16x2¼ 2 x x
40 37016A Pad 1 x x
41 67899A Washer, Flat 3/8 S.S. 1 x x
42 85811A Screw 5/16 - 18 x .75 2 x x
43 66531A Swing Arm Pin 1 x x
44 836711 HairPin 1 x x
45 60416A Arm, Pivot 1 x x
46 81207A Nut,3/8-16SS 2 x x
CLARKE TECHNOLOGY Vision 21i - Vision V
Squeegee & Squeegee Arm Assembly Parts List 1/97
Vision21i VisionV

Page -32- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
BrushHeadAssemby Parts List 9/98
59
46
47
46
45
22 51 66
54
53
52
44
48
14
58
57
28 65
8
31 67
5
28
13 10
7
29
62
30
68
21
17
11
12
61
49
12
15
70
21
19
18
20
16
40
25
26
69 27
32
36 3538
60 36437
43 42
36
1
9
36
1239
1
65
36
33
5
1
50 366
9
41
34
SqueegeeArm
StopAsm.
56
55
71

Clarke Technology Operator's Manual - Vision 21i - Vision V 33
Ref# PartNo. Description Qty
37 66530A HeadPressurePin 1 x x
38 69100B HeadPressureTube 1 x x
39 49720A Harness,Wiring 1 x x
40 61658A GimbalCollar 2 x x
41 50204A Actuator 1 x x
42 53400A HeadPressureSpring
(ref. to pages 36 and 37) 1 x x
43 69006A SpringSeat 1 x x
44 63342A MainFrame 1 x x
45 39007B Battery Tray 1 x x
46 871334 Battery, 12 Volt, 195 AH 2 x x
881317 Battery, 6 Volt, 250 AH 4 x x
47 842406 SeriesCable-9" 1 x x
41206A SeriesCable-16" 2 x x
48 41211A BatteryCable 1 x x
49 838301 BrushHolderSpring 2 x x
50 77091A Label,Warning-Moving 3 x x
51 77210A Label, Wiring 1 x x
52 77209A Label,BatteryConnect. 1 x x
53 77092A Label,Warning-Battery 2 x x
54 77093A Label,Warning-Falling 2 x x
55 56941A CenterLokAsm.
(PadDriveronly) 2xx
56 962737 Screw#10-16x7/8 (paddriveronly) 6xx
57 80011A Screw 3/8-16 x 3 CR 2 x x
58 81301A Nut, 3/8 -16 JAM 4 x x
59 67887A Spacer, 12V Bat. 2 x x
60 925006 Cotter Pin 1 x x
61 962989 Screw, ¼-20 x 1½ 2 x x
62 962850 Screw, ½-13 x 1½ Hx 4 x x
63 59856A Washer,Rubber 2 x x
64 60509A Activator 1 x x
65 81105A Nut,3/8-16ESNA 4 x x
66 85727A Screw 3/8-16 x 1 4 x x
67 980673*Washer 8 x x
68 85735A Screw, Special Hd 2 x x
69 81216A Nut,Spacer 2 x x
70 170892 Washer, Lock ¼ 8 x x
71 70065A Label26v 1 - x
70066A Label,21i 1 x -
Ref# PartNo. Description Qty
1 962980 Screw, 6-32 x 1 PN 4 x x
2 47374A LeverSwitch
(ScrubLmt.) 1xx
3 920056 Nut, 6-32 ESNA 6 x x
4 47405A Switch,Brush(HeadUp) 1 x x
5 85519A Screw, ¼-20 x 3/8PN 4 x x
6 69434A Switch Bracket 1 x x
7 81104A Nut, ¼-20 ESNA 2 x x
8 46508A Resistor(TraverseRes.) 1 x x
9 82501A Pin 2 x x
10 68661A Brush Plate 1 x
68670A Brush Plate 1 x
11 782002 Clamp 2 x x
12 34705A Brush Hose L.H.& R.H. 2 x
34704A Brush Hose L.H.& R.H. 2 x
13 722030 HoseClamp 1 x x
14 980638 Washer, Lock 3/88xx
15 170915 Screw, ¼-20 x 3/48xx
16 962714 Screw, 5/16-18 x 3/4Soc 2 x x
17 82508A Pin 1 x x
18 833802 Gimbal 2 x x
19 962495 Screw, ¼-20 x 1 Pn 6 x x
20 Pg23 Brushes & Pads 2 x x
21 34400B Gimbal 2 x x
22 836711 Hairpin 3 x x
23 838502 Splitter,Water 1 x x
25 915102 Key 1 x x
26 45037A Motor, Brush
(ref. to pages 36 & 37) 2 x x
27 41601A Connector 2 x x
28 920365 Nut, ½-13 ESNA 8 x x
29 63058A LinkageBar 4 x x
30 962344 Screw, ½-13 x 1¼ HX 2 x x
31 67705B SleeveBearing 8 x x
32 41602A ConnectorHousing 2 x x
33 Pg. 33 Solution Hose ref. #4 1 x x
34 38708A NylonWasher 2 x x
35 67703A HeadPressureSleeve 1 x x
36 82404A Spirol Pin, 3/16 3xx
CLARKE TECHNOLOGY Vision 21i - Vision V
BrushHeadAssemby Parts List 9/98
Vision 21i Vision V
*NOTE: #67 used with screws #62 only as needed to square
uplinkagebars#29.
Vision 21i Vision V

Page -34- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
Solution/VacuumSystemDrawing9/98
4
56
78
2
9
3
5
612
16
1314 15 5
16 18
19
20
21
22
23
27
20
26
24
25
43
28
55 34
27
17
54
30
17
31
32
29
24
42 2
8
2
8
2
2
8
8
47
3632
24
40
41
50
51 52
53
17
56
39
38
48
35 37 34 33

Clarke Technology Operator's Manual - Vision 21i - Vision V 35
CLARKE TECHNOLOGY Vision 21i - Vision V
Solution/Vacuum System Parts List 9/98
Ref# PartNo. Description Qty
2 920296 Nut,10-24ESNA 6 x x
3 820823 Bracket 1 x x
4 35199A SolutionHose 1 x x
5 722030 HoseClamp 6 x x
6 822802 Elbow 2 x x
7 61652A SolutionControl 1 x x
8 962798 Screw, 10-24 x ½ Pan 6 x x
9 849401 Solution Valve 1 x x
10 678215 Spacer 1 x x
11 832102 CableClip 1 x x
12 81104A Nut, ¼-20 ESNA 1 x x
13 830214 Connector 1 x x
14 838517 FilterScreen 1 x x
15 50335A HoseAdapter 1 x x
16 30412A Hose 2 x x
17 872010 HoseClamp 5 x x
18 85702A Screw, ¼-20 x 13/41xx
19 35102A DrainHose,Recovery 1 x x
20 832002 Clamp 2 x x
21 839401 DrainValve 2 x x
22 833407 DrainGasket 2 x x
23 833901 DrainValveHandle 2 x x
24 52206A Chain 4 x x
25 962987 Screw, 10-24 x 3/8PN 2 x x
26 962943 Screw, 8-18 x 1/2 PN 2 x x
27 30405A DrainHose,Solution 1 x x
28 85391A Screw, ¼-20 x 5/8PN 4 x x
Ref# PartNo. Description Qty
29 60659A Bracket 1 x x
30 30409B SqueegeeHose 1 x x
31 30123A SqueegeeAdapter 1 x x
32 837304 O-Ring 2 x x
33 85728A Screw, ¼-20 x 4.00 Hex 3 x x
34 87026A Washer, Flat ¼ 5 x x
35 58533A Vac Motor Spacer 3 x x
36 59319A Stand,Tube 1 x x
37 643418 Gasket 1 x x
38 44917A Vac Motor 1 x x
39 41809A Contact 4 x x
43401A Housing Black - Vac 2 x x
43402A HousingBlue-Float 2 x x
40 832322 Lid 2 x x
41 34256A Lid Gasket 2 x x
42 38984C SolutionTank 1 x x
43 69443A Bracket, Solution Tank LH 1 x x
47 58012A VacuumStrainer 1 x x
48 920797 Nut 1 x x
50 14092A Float Switch 1 x x
51 56459A StrainRelief 1 x x
52 87612A Seal 1 x x
53 170686 Locknut 1 x x
54 38985D RecoveryTank 1 x x
55 170915 Screw, ¼-20 x 3/4hex 1 x x
56 30410A Hose, Vac Motor 1 x x
Vision 21i Vision V
Vision 21i Vision V

Page -36- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
BrushHousingAssembly Drawing 7/96
3
4
5
2
14
6
7
8
9
1
11 12
10

Clarke Technology Operator's Manual - Vision 21i - Vision V 37
CLARKE TECHNOLOGY Vision 21i - Vision V
Brush Housing Assembly Parts List 7/96
Ref# PartNo. Description Qty
1 64729A BrushHousing,L.H. 1 x
64727A BrushHousing,L.H. 1 x
2 64728A BrushHousing,R.H. 1 x
64726A BrushHousing,R.H. 1 x
3 81105A Nut, 3/8-16 ESNA 1 x x
4 980687 Washer 1 x x
5 419702 Guide,Wheel 1 x x
6 85704A Scr., 3/8-16 x 2¼ 1 x x
7 69089A Strap, R.H. 1 x
69079A Strap, R.H. 1 x
8 38235A Skirt, R.H. 1 x
38234A Skirt, R.H. 1 x
9 50449A Pin 1 x x
10 38236A Skirt, L.H. 1 x
38233A Skirt, L.H. 1 x
11 69090A Strap, L.H. 1 x
69078A Strap, L.H. 1 x
12 81104A Nut, 1/4-20 ESNA 9 x
81104A Nut,1/4-20ESNA 11 x
13 85737A Scr., 1/4-20 x 5/8 Hex 9 x
85737A Scr., 1/4-20 x 5/8 Hex 11 x
14 81301A Nut, 3/8-16 Jam 1 x x
Vision 21i Vision V

Page -38- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
AlternateBrushMotorAssembly#44809A 5/95
Ref. Part No. Description Qty.
1 980638 Washer, Lock 3/8 8
2 962244 Screw, 3/8-16 x 3/4 8
3 44809A Motor,Brush 2
4 53412A Head Pressure Spring 1
NOTICE: If yourVisionV orVision 21i has brush motor #44809A,shown
below,use the parts on this page. Refer to pages 30 and 31 in this
manual for other parts.

Clarke Technology Operator's Manual - Vision 21i - Vision V 39
CLARKE TECHNOLOGY Vision 21i - Vision V
AlternateBrushMotor#44809A 5/95
Item Part No. Description Qty
1 56478A Stator Frame Assembly (w/Magnets & Clips) 1
2 50142A Armature Assembly (w. B.E. & F.E. Bearings) 1
3 902654 Bearings B.E. 1
4 902550 Bearing F.E. 1
5 51840A Commutator Bracket Assembly 1
(w/Brush BRD Assembly Leads)
6 50520A Commutator Bracket 1
7 56480A Strain Relief 2
8 962546 Brush Board Screw 2
9 50517A Brush Board Assembly (w/ Springs & Brushes) 1
10 448396 Brush Spring 4
11 40826A Brush Assembly 4
12 55657A Lead Assembly 1
13 55656A Lead Assembly 1
14 59805A Helical Washer 1
15 50515A Thru Bolt 2
16 44809A Shaft Key 1
17 54238A B.E. Bracket Assembly (Gear Box) 1
Flam Location

Page -40- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
BrushMotor#45037A 3/95
Ref# PartNo. Description Qty
1 832315 Com. BracketCover 1
2 980076 Washer-Helical 1
3 902547 Bearing 1
4 50156A ArmatureAssembly 1
5 902550 Bearing 1
6 897655 Seal - Oil 1
7 830846 Bracket 1
8 962955 Screw ¼-20 x 5¾ Hex 2
9 50577A Bracket Assembly 1
10 833102 Field Asm. w/Mag Clips 1
11 55133A Brush Holding Asm. 1
12 448396 Spring-Brush 4
13 40807A Brush Assembly 4

Clarke Technology Operator's Manual - Vision 21i - Vision V 41
CLARKE TECHNOLOGY Vision 21i - Vision V
TraverseMotor#45038A 8/94
Ref# PartNo. Description Qty
1 52776A Cover, Bracket, Com. 1
2 980076 Washer-Helical 1
3 902547 Bearing 1
4 50156A ArmatureAssembly 1
5 902550 Bearing 1
6 897655 Seal - Oil 1
7 830845 Bracket 1
8 962955 Screw ¼-20 x 5¾ Hex 2
9 50577A Bracket Assembly 1
10 833102 Field Asm. w/Mag Clips 1
11 912206 Housing-MaleTerminal
Connector 1
12 912207 Terminal-Male 1
13 55133A BrushHoldingAssembly 1
14 448396 Spring-Brush 4
15 40807A Brush Assembly 4

Page -42- Clarke Technology Operator's Manual -Vision 21i - Vision V
CLARKE TECHNOLOGY Vision 21i - Vision V
BatteryCharger
Drawing & Parts List 8/94
WARNING: All electrical repairs must be performed by qualified personnel only.
Charger #40512A: 24 volt, 25 amp D.C., 115 volt, A.C., 60 Hz
Charger #40513A: 24 volt, 25 amp D.C., 230 volt, A.C., 50 Hz
Charger Model Number
40512A 40513A
Ref# Description Part # Part#
1 ChargerCase 41129A 41128A
2 Transformer 48413A 48409A
3 Electronic Controller Kit 47500A 48200A
4 Capacitor, 660V.A.C. 912132 912132
5 Heat Sink Assembly 912212 912212
6 Ammeter 40200A 40200A
7 FuseHolder 912382 912382
8 Strain Relief,A.C.Cord 837525 837525
9 StrainRelief,D.C.Cord 747553 747553
10 D.C. Cord Assembly 51986A 51986A
11 A.C. Cord Assembly 51974A 908947
12 Housing 911470 911470
13 D.C. Plug Lock Key 795020 795020

Clarke Technology Operator's Manual - Vision 21i - Vision V 43
Clarke Technology Vision 21i - Vision V
Vacuum Motor Model
Drawing 8/94
Form#44917A
Ref# PartNo. Description Qty
1 51913A Clip(optional) 2
2 54809A HousingVent 1
3 Fan 1
4 85303A Screw - 8x32 - 3/8 P.N. 4
5 40817A Brush,Mechanism 2
6 51914A Clamp 2
7 50618A Bracket,CommutatorE. 1
8 Bearing 1
9 672714 Disc 1
10 Bearing 1
11 59803A Washer,Neoprene 1
12 Bracket, Fan End 1
13 58500A Spacer 1
*
*
*
*
*
*
*
Ref# PartNo. Description Qty
14 53914A Fan,Rotating 2
15 658201 Spacer 2
16 Fan,Stationary 1
17 Shell, Fan 1
18 638313 Spring,Load 1
19 Fan, Air Seal 1
20 Fan,Stationary 1
21 Fan,Rotating 1
22 Washer 1
23 Nut 1
*NOTE: #'s 3, 8, 10, 12, 16, 17, 19, 20, 21, 22, & 23
are not available at this time.
*
*
*
*
