Alto Vision V- 00590A User manual

Form No. 78493B 2/00 CLARKE TECHNOLOGY Printed in the USA
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your ALTO
machinecouldresultininjurytoyouortootherpersonnel;damagetothemachineorotherproperty
could occur as well. You must have training in the operation of this machine before using it. If you
oryouroperator(s)cannotreadEnglish,havethismanualexplainedfullybeforeattemptingtooperate
this machine.
Si Ud.osusoperadoresnopuedenleerelInglés,sehaganexplicarestemanualcompletamenteantes
de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
For new books write to: ALTO U.S. INC., 2100 Highway 265, Springdale, Arkansas 72764.
Vision 21i
VisionV
Operator's
Manual
E

Page -2- Clarke Technology Operator's Manual -Vision 21i - Vision V
Table of Contents
OperatorSafetyInstructions ............................................................................................................3
Introduction & Machine Specifications .............................................................................................5
ProceduresForTransporting ............................................................................................................6
Symbols Used On Vision 21i & Vision V..........................................................................................7
Machine Control Panel 21i & Vision V..............................................................................................8
Machine Control Panel 21i & Vision V..............................................................................................9
MachineControlsandFeatures........................................................................................................10
HowToPrepareTheMachineForOperation....................................................................................11
How To Install The Batteries ...............................................................................................11
BatteryMaintenance ..........................................................................................................12
HowToChargeTheBatteries ............................................................................................ 13
How To Install The Brushes Or Pad Drivers .......................................................................14
HowTo RemoveThe BrushesOr PadDrivers....................................................................14
HowToOperateTheMachine.........................................................................................................15
HowToOperateTheSqueegee..........................................................................................15
How To Fill The Solution Tank ...........................................................................................15
HowToClean AFloor ........................................................................................................17
HowTo CorrectProblems InThe Machine ......................................................................................18
Maintenance ...................................................................................................................................20
Accessories....................................................................................................................................25
DrawingsandPartLists
Vision 21i - Vision V Rear Cover Assembly Drawing .......................................................................26
Parts List ...........................................................................................................................27
Vision 21i - Vision V Traverse System Assembly Drawing..............................................................28
Parts List ...........................................................................................................................29
Vision 21i - Vision V Squeegee & Squeegee Arm Assembly Drawing .............................................30
Parts List ...........................................................................................................................31
Vision 21i - Vision V Brush Head Assembly Drawing ...................................................................... 32
Parts List ...........................................................................................................................33
Vision 21i - Vision V Solution/Vacuum System Drawing .................................................................34
Parts List ...........................................................................................................................35
Vision 21i - Vision V Brush Housing Assembly ...............................................................................36
Parts List ...........................................................................................................................37
Vision 21i - Vision V Alternate Brush Motor (44809A) Assembly Drawing and Parts List.................38
Vision 21i - Vision V Alternate Brush Motor (44809A) Drawing and Parts List ................................. 39
Vision 21i - Vision V Brush Motor (45037A) Drawing & Parts List ................................................... 40
Vision 21I - Vision V Traverse Motor (45038A) Drawing & Parts List...............................................41
BatteryCharger Drawing& PartsList..............................................................................................42
Vision 21i - Vision V Vac Motor (44917A) .......................................................................................43
Vision 21i - Vision V Electrical Schematic ......................................................................................44
Vision 21i - Vision V Connection Diagram, Front of Machine........................................................... 45
Vision 21i - Vision V Connection Diagram, Rear of Machine............................................................46
Vision 21i - Vision V Connection Diagram, Inside Rear Cover .........................................................

Clarke Technology Operator's Manual - Vision 21i - Vision V 3
OPERATOR SAFETY INSTRUCTIONS
WARNING AVERTISSEMENT ADVERTENCIA
DANGER: Failure to read and observe all DANGER statements could result in
severe bodily injury or death. Read and observe all DANGER
statements found in your Owner's Manual and on your machine.
WARNING: Failureto read and observe all WARNINGstatementscould result in
injury to you or to other personnel; property damage could occur as
well. Read and observe all WARNING statements found in your
Owner's Manual and on your machine.
CAUTION: Failure to read and observe all CAUTION statements could result in
damage to the machine or to other property. Read and observe all
CAUTIONstatementsfound in our Owner's Manual and on your
machine.
DANGER: Failureto read theOwner's Manualpriorto operatingor attempting anyservice or
maintenanceprocedure to yourClarke Technologymachinecould resultin injury to
you or to other personnel; damage to the machine or to other property could occur
as well. You must have training in the operation of this machine before using it. If
you or your operator(s) cannot read English, have this manual explained fully
beforeattempting to operatethis machine.
DANGER: Operating a machine that is not completely or fully assembled could result in injury
or property damage. Do not operate this machine until it is completely assembled.
Inspectthemachine carefully beforeoperation.
DANGER: Machinescancauseanexplosionwhenoperatednearflammablematerialsand
vapors. Do not use this machine with or near fuels, grain dust, solvents, thinners,
orotherflammablematerials.
DANGER: Lead acid batteries generate gases which can cause an explosion. Keep sparks
and flames away from batteries. Do not smoke around the machine. Charge the
batteries only in an area with good ventilation. Make sure that you unplug the AC
chargerfrom thewall outletbefore diconnecting from the machine.
DANGER: Workingwith batteriescan bedangerous! Always weareye protection and protec-
tive clothing when working near batteries. Remove all jewelry. Do not put tools or
other metal objects across the battery terminals, or the tops of the batteries.
DANGER: Using a charger with a damaged power cord could result in an electrocution. Do
not use the charger if the power cord is damaged.
WARNING: Operating this machine from anywhere other than the back of the machine could result in
injury or damage. Operate this machine only from the rear.
WARNING: This machine is heavy. Get assistance before attempting to transport or move it. Use
two able persons to move the machine on a ramp or incline. Always move slowly. Do
not turn the machine on a ramp. Do not stop and leave the machine on a ramp or
incline. Readthe "Procedures ForTransporting" in thismanual before transporting.
WARNING: Machines can topple over if guided over the edges of stairs or loading docks and cause
injury or damage. Stop and leave this machine only on a level surface. When you stop
the machine, turn the key "OFF".

Page -4- Clarke Technology Operator's Manual -Vision 21i - Vision V
WARNING: Maintenanceandrepairsperformedbyunauthorizedpersonnelcouldresultindamageor
injury. Maintenanceandrepairsmustbeperformed by authorized ClarkeTechnology
personnelonly
WARNING: Any alterations or modifications of this machine could result in damage to the machine or
injury to the operator or other bystanders. Alterations or modifications not authorized by
the manufacturer voids any and all warranties and liabilities.
WARNING: Electrical components of this machine can "short-out" if exposed to water or moisture.
Keep the electrical components of the machine dry. Wipe the machine down after each
use. For storage, keep the machine in a dry building.
WARNING: Operatingamachinewithout observing all labelsandinstructionalinformationcould
result in injury or damage. Read all machine labels before attempting to operate. Make
sure all of the labels and instructional information are attached or fastened to the ma-
chine. Get replacement labels and plates from your Clarke Technology distributor.
WARNING: Wet floor surfaces can be slippery. Water solutions or cleaning materials used with this
type of machine can leave wet areas on the floor surface. These areas can cause a
dangerous condition for the operator or other persons. Always put "Caution" signs
around/neartheareayouarecleaning.
CAUTION: Use of this machine to move other objects or to climb on could result in injury or dam-
age. Do not use this machine as a step or furniture. Do not ride on this machine.
CAUTION: Yourmachinewarrantywill be voided ifanythingotherthangenuine Clarke Technology
parts are used on your machine. Always use Clarke Technology parts for replacement.

Clarke Technology Operator's Manual - Vision 21i - Vision V 5
Introduction & Machine Specifications
Introduction&MachineSpecifications
Clarke Technology’s newly designed Vision 21i & Vision V automatic scrubbers are efficient and
superior floor cleaning machines. The Vision 21i uses two brushes or pads to scrub a path 21 inches
wide. The Vision V uses two brushes or pads to scrub a path 26 inches wide. A squeegee wipes the
floor while the vacuum motor removes the dirty solution from the floor - all in one pass.
The Vision 21i or Vision V automatic scrubbers come complete with four - 6 volt batteries or two - 12
voltbatteries, onebattery charger, either two brushes or two pad drivers, and oneoperator’s manual.
SPECIFICATIONS:
Model VisionV- 00590A Vision21i-00610A
Motor,Vac ¾ HP three ¾HP three
stagetangential stagetagential
discharge - 21 Amp discharge - 21 Amp
PowerSupply 24volt*24 volt *
195AH,250AH 195AH,250AH
SolutionTank 20gallon(76 liter) 20gallon(76 liter)
RecoveryTank 20gallon (76 liter) 20gallon (76 liter)
ParabolicSqueegee 37inches (94 cm) 27 inches (69 cm)
Motors, Brush (2) .5 hp PM (.37 kw) 23 amp .5 hpPM (.37 kw) 23 amp
MotorTraction .5 hp PM (.37kw) 23 amp .5 hp PM (.37kw) 23 amp
DriveTrain DirectDrive,Roller Chain DirectDrive,RollerChain
Brushes(2) 13 inch (33cm) 11inch (28cm)
BrushSpeed 320rpm 320rpm
BrushPressure 100lbs. 100 lbs
Speed,Forward 3speedsto 220ft/min. 3speedsto 220ft/min.
Speed,Reverse 2 speeds to 170ft/min. 2 speedsto 170ft/min.
DriveWheel 12"x6"(30x15cm) 12"x6"(30x15cm)
Charger 24V,25A,115V/60hz 24V,25A,115V/60hz
Length 58inches (147cm) 57inches(145cm)
Width 27inches(70cm) 23inches(58cm)
Height 42inches (106cm) 42 inches(106cm)
CleaningRate 29,000sqft/hr 23,000 sq ft/hr
(2,694sq. m/hr) (2,136 sq. m/hr)
CleaningSwath 26 inch (66cm) 21 inch(53cm)
GradeCleaning 5°Incline 5°Incline
Weight 492lbs. 462lbs.
ShippingWeight 602lbs. 572lbs.
BatteryWeight(4-250AH) 264 lbs. 264lbs.
(2-195 AH) 224lbs. 224lbs.
NOTE: * 24V (4-6v batteries or 2-12v batteries)

Page -6- Clarke Technology Operator's Manual -Vision 21i - Vision V
PROCEDURES FOR TRANSPORTING
How To Put The Machine In A Van Or Truck
WARNING: The machine is heavy. Make sure you use two able persons to assit
the machine in climbing the ramp.
1. Make sure the loading ramp is at least eight (8) feet long, and strong enough to support the machine.
2. Make sure the ramp is clean and dry.
3. Put the ramp in position.
4. Removesqueegeeassembly,brush housings,&brushesor paddriversbeforeloading.
5. Turn key switch "ON".
6. Align the machine on a level surface ten (10) feet in front of the ramp.
7. Put the traverse speed switch in the "HI" position.
8. Push the control handles toward the machine all the way.
9. Push the machine to the top of the ramp.
10. Engagetheparkingbrake.
11. Turn the key switch "OFF".
12. Fasten the machine to the vehicle.
How To Remove The Machine From A Van Or Truck
1. Make sure there are no obstructions in the area.
2. Make sure the unloading ramp is at least eight (8) feet long and strong enough to support the machine.
3. Make sure the ramp is clean and dry.
4. Put the ramp in position.
5. Unfastenthemachine.
WARNING: The machine is heavy. Make sure you use two able persons to assist in
moving the machine down the ramp.
6. Turn the key switch "ON".
7. Releasetheparkingbrake.
8. Put the traverse speed switch in the "HI" position.
9. Carefully and slowly, pull the machine to the top of the ramp.
10. As the machine begins to travel down the ramp, push the control handles toward the machine to
maintainaslowdownwardspeed.
11. Replace squeegee assembly, brush housings, & brushes or pad drivers after the machine is unloaded
and ready to use.

Clarke Technology Operator's Manual - Vision 21i - Vision V 7
SYMBOLS USED ON VISION 21i & Vision V
Warning
Power
On/OffKeySwitch
TraverseSpeed
SolutionControl
BrushUp/Down

Page -8- Clarke Technology Operator's Manual -Vision 21i - Vision V
MACHINE CONTROL PANEL (Vision 21i & Vision V)
Key Switch (See Figure #1, Item "A")
The key switch turns "ON" the power to the control panel. "0" is "OFF" and "1" is "on".
Traverse Speed Switch (See Figure #1, Item "B")
The speed switch has three positions: High, Medium, and Low speeds.
Brush Position Switch (See Figure #1, Item "C")
The brush switch has two positions: "Up" positions the brushes up; "Down" positions the brushes on the floor. The
brush motors start when the brushes are down.
Solution Control Knob (See Figure #1, Item "D")
The solution control knob regulates the flow of cleaning solution to the floor. To increase the flow turn the knob
clockwise. To decrease the flow, turn the knob counter-clockwise.
Control Handles (See Figure #1, Item "E")
The control handles are located at the rear of the machine. They control the direction of the machine. Push forward to
go forward. (See Figure #2, page 7). Pull back to move in reverse. (See Figure #3, page 7).
Circuit Breakers (See Figure #1, Item "F"-"J")
The circuit breaker reset buttons are located on the rear cover, below the control handle. The breakers are located as
follows: Item F & G - Brush Motors (35A)
Item H - Traverse Motor (30A)
Item I - Vac Motor (30A)
Item J - Actuator Motor, Brush Head (5A)
If a circuit breaker trips, determine which motor is not operating and turn the key switch "OFF". Wait five minutes and
push the reset button back in. Turn the key switch "ON", and try again. An authorized service person should be
contacted if the breaker trips again.

Clarke Technology Operator's Manual - Vision 21i - Vision V 9
MACHINE CONTROL PANEL (Vision 21i & Vision V)
Figure #2 Figure #3
Figure #1
C
D
E
B
A
FG HIJ

Page -10- Clarke Technology Operator's Manual -Vision 21i - Vision V
MACHINE CONTROLS & FEATURES
Squeegee Lift Handle. See Figure #4a & #4b.
The squeegee lift handle is located below the control
handles on the right side. It is used to raise or lower
the squeegee. The vac motor is turned on when the
handleislowered.
Float Shut Off. See Figure #5.
The shut-off switch for the vac motor is located in the
recovery tank. It automatically turns off the vac
motor when the recovery tank is full.
Parking Brake. See Figure #6a & #6b.
The parking brake prevents movement of the ma-
chine. It is located at the rear lower left side of the
machine. Toengage the brake, push thepedal down
(Figure #6a). To release the brake, lift pedal up
(Figure#6b).
CAUTION: Do notactivatethebrake
while the machine is moving.
Figure #4a
Figure #4b.
Figure #5.
Figure #6b.
Figure #6a.

Clarke Technology Operator's Manual - Vision 21i - Vision V 11
HOW TO PREPARE THE MACHINE FOR OPERATION
HowTo Install The Batteries
The Vision 21i and Vision V machines use four 6-volt
or two 12-volt batteries. The batteries are located in
the battery compartment under the recovery tank.
To Install the batteries, follow this procedure:
1. Set the parking brake.
2. Make sure both tanks are empty.
3. Disconnect the hoses from the recovery tank
(upper tank) & unplug the vac motor.
Remove the recovery tank.
4. Remove the two screws that attach the
solution tank (lower tank) to the back of the
frame, leaving the two angle brackets
attached to the tank.
5. Disconnect the two hoses under the right
side and remove the solution tank.
6. Place the batteries in the tray as shown in
figure #7a, #7b, or #7c.
WARNING: Liftingbatterieswithout
help could result in an
injury. Get help to lift the
batteries. Thebatteriesare
heavy.
WARNING: Workingwithbatteriescan
bedangerous. Always
weareyeprotectionand
protectiveclothingwhen
workingnearbattiers.
NOSMOKING!
7. Connectthebatterycablesbetween
batteries and install long battery cable
assembly as indicated. See figure #7.
8. Join the connector from the battery pack to
the connector on the control panel. See
figure#8.
9. Install the tank, reconnecting hoses and
replace the two screws attaching the
solution tank to the rear of the frame.
NOTE: Charge the batteries before using the
machine.
Figure #7a
Figure #7b
Figure #7c
Figure #8
12 Volt 195 AH
All 6 Volt
Poly Case Batteries
330 AH, 6 Volt
BlackRubber CaseBattery

Page -12- Clarke Technology Operator's Manual -Vision 21i - Vision V
Battery Maintenance
The electrical power to operate the machine comes from
the storage batteries. Storage batteries need preventive
maintenance.
WARNING:Workingwithbatteriescanbedanger-
ous. Always wear eye protection
andprotectiveclothingwhenwork-
ingnearbatteries.
NOSMOKING!
To maintain the batteries in good condition, follow these
instructions:
1. Keeptheelectrolyteatthe correct level. Thecorrect
levelis between1/4" belowthe bottom of the tube in
eachcellandabovethetopsoftheplates. Checkthe
level of the electrolyte each time you charge the
batteries. See figure #9.
NOTE: Checkthelevelofelectrolytepriortochargingthe
batteries. Besuretheplatesineachcellarecoveredwith
electrolyte . Do not top off the cells prior to charging the
battery. Electrolyteexpandsduringcharging. Asaresult,
the electrolyte could overflow from the cells. Always top
off the cells with distilled water after charging.
CAUTION: Irreversible damage will occur to
the batteries if the electrolyte level
doesnotcovertheplates. Keepthe
electrolyteatthecorrectlevel.
CAUTION: Machine damage and discharge
acrossthetopsofthebatteriescan
occurifthebatteriesarefilledabove
the bottom of the tube in each cell.
Do not fill the batteries up to the
bottom of the tube in each cell.
Wipeany acid from the machine or
thetopsofthebatteries. Neveradd
acidto a battery after installation.
CAUTION: Tap water may contain contami-
nants that will damage batteries.
Batteriesmustbere-filledwithdis-
tilled water only.
2. Keep the tops of the batteries clean and dry.
Keep the terminals and connectors clean. To clean
the top of the batteries, use a damp cloth with a
weaksolution ofammonia orbicarbonate ofsoda
solution. To clean the teminals and connectors,
use a terminal and connector cleaning tool. Do
not allow ammonia or bicarbonate of soda to get
intobatteries.
3. Keepthebatteriescharged.
Figure #9
HOW TO PREPARE THE MACHINE FOR OPERATION
CorrectFillLevel

Clarke Technology Operator's Manual - Vision 21i - Vision V 13
Figure #12
How To Charge The Batteries
WARNING: Chargingthe batteries in an area
without adequate ventilation
could result in an explosion. To
preventanexplosion,chargethe
batteries only in an area with
goodventilation.
WARNING: Lead acid batteries generate
gaseswhichcouldexplode. Keep
sparksandflamesawayfrombat-
teries. NOSMOKING!
WARNING: FailuretodisconnecttheACplug
from the wall receptacle before
connectingordisconnectingthe
DC connector on the charger
could result in an explosion. Al-
ways disconnect the AC plug
from the wall receptacle before
connectingordisconnectingthe
DCconnectoronthecharger.
Tocharge thebatteries, followthis procedure:
1. Put the charger on a flat surface. Make sure the
ventsonthesidesareatleasttwoinchesawayfrom
walls and other objects. Make sure there are no
objectsneartheventsonthebottomofthecharger.
2. Set the parking brake by putting it into the down
position. Seefigure#10. Makesurethekeyswitch
is “OFF” position.
3. Disconnect the battery pack connector from the
control housing connector. See figure # 11.
4. Connect the DC connector on the charger to the
battery pack connector. See figure #12.
5. Connectthechargertoaproperlygroundedsingle
phase(3-wire)wallreceptaclehavingthevoltage,
frequency, and ampere capacity specified on the
nameplateofthecharger.
Formoreinstructionontheuseofthecharger,readthe
instructionbook supplied withthe charger.
HOW TO PREPARE THE MACHINE FOR OPERATION
Figure # 10
Figure #11

Page -14- Clarke Technology Operator's Manual -Vision 21i - Vision V
How To Install The Brushes Or Pad Drivers
To install the brushes or pad drivers on the machine,
followthisprocedure:
1. Engagetheparkingbrake.
2. Turn the key switch "ON".
3. Put the brush switch in the "UP" position.
4. Turn the key switch "OFF".
5. Go to the front of the machine.
6. Pull out the brush housing pin and remove the
right and left brush housings.
7. Putabrushorpaddriverunderthebrushmotorplate.
Seefigure#13.
8. Alignthelugsonthemotorgimbalwiththeslotsinthe
brushgimbal.
9. Pull the brush up until the gimbal locks.
10. Repeat steps 7, 8, and 9 to install the second brush
orpaddriver.
How To Remove The Brushes Or Pad Drivers
To remove the brushes or pad drivers from the
machine,followthisprocedure:
1. Engagetheparkingbrake.
2. Turn the key switch "ON".
3. Put the brush switch in the "UP" position.
4. Turn the key switch "OFF".
5. Go to the front of the machine.
6. Pushdownontwosidesofthebrushorpaddriveruntil
thegimbalsrelease.
HOW TO PREPARE THE MACHINE FOR OPERATION
Figure # 13

Clarke Technology Operator's Manual - Vision 21i - Vision V 15
HOW TO OPERATE THE MACHINE
How To Operate the Squeegee
Thesqueegee wipesthe floorwhile thevacuum motor
removes the dirty solution from the floor. Use your right
handto loweror raisethe squeegee handle. To operate the
squeegee,followthisprocedure:
1. To lower the squeegee and start the vac motor move
the squeegee lever to the right and down. See figure
#14a.
2. To raise the squeegee, lift the squeegee lever up.
Seefigure#14b.
Note: The center position lets the vac motor continue to
run with the squeegee off the floor to avoid drips.
How to Fill The Solution Tank
CAUTION: Makesurewaterorsolution
does not enter the opening for
the vacuum motor. See figure
#15.
The solution tank lid is at the front. To fill the solution tank
followthisprocedure:
1. Remove the solution tank lid.
2. Fill the solution tank with water.
3. Add a cleaning chemical to the water. for the
correct amount, follow the directions shown on the
container.
4. Replace the solution tank lid.
Figure#14a
Figure#14b
Figure#15

Page -16- Clarke Technology Operator's Manual -Vision 21i - Vision V
WARNING: Watersolutionsorcleaningmateri-
als used with this type of machine
can leave wet areas on the floor
surface. These areas can cause a
dangerousconditionfortheopera-
tor or other persons. Always put
CAUTION signs near the area you
arecleaning.
WARNING: Machinescanigniteflammablema-
terialsandvapors. Donotusewith
or near flammables such as gaso-
line, grain dust, solvents and
thinners. Onlyuse a cleaning con-
centrate recommended by the
chemicalmanufacturer.
NOTE:Putthemachineinthe"LO"traversespeed. Use
themachineinanareathathasnofurnitureandobjects
until you can do the following:
1. Movethemachineinastraightdirection,forwardand
backward.
2. Stop the machine safely.
3. Movethemachineinastraightdirectionafteryouturn
themachine.
To move the machine, follow this procedure:
1. Releasetheparkingbrake.
2. Turn the key switch “ON” position.
3. Put the brush switch in the "UP" position.
4. Raisethesqueegee.
5. To go forward, push the control handles toward the
machine. See figure #16.
6. To stop the machine, put the handles in the center
position.
7. To go backward, pull the handles away from the
machine. See figure #17.
8. Toturn the machine,push therear ofthe machineto
the side.
9. When you stop the machine, turn the key switch
"OFF".
Figure # 16
Figure#17
HOW TO OPERATE THE MACHINE (cont.)

Clarke Technology Operator's Manual - Vision 21i - Vision V 17
HOW TO OPERATE THE MACHINE (cont.)
HOWTOCLEANA FLOOR
WARNING: Watersolutionsorcleaningmateri-
als used with this type of machine
can leave wet areas on the floor
surfaces. Theseareascancausea
dangerousconditionfortheopera-
tor or other persons. Always put
CAUTION signs near the area you
arecleaning.
To clean a floor, follow this procedure:
1. Set the parking brake.
2. Put the water and a cleaning chemical in the clean
solution tank.
3. Releasetheparkingbrake.
4. Turn the key switch "ON".
5. Lowerthesqueegee.
6. Put the brush switch in the "DOWN" position.
NOTE: Keep the machine moving when the brushes are
rotating on the floor. (I models only)
7. Turnthesolutionknobtotherighttoactivatetheflow
of solution. Adjust the flow of clean solution to the
flowdesired.
8. Move the machine across the floor in the forward
direction.Seefigure#18(1).
9. Whenthemachineisonemachinelengthfromtheend
of the area to be cleaned (figure #18 (2)), rotate the
solution knob to the left.
10. Make a 1800turn. See figure #18 (3).
NOTE: Whenyoumakemorepassesacrossthefloor,let
the brushes clean approximately 2 inches of the
areaalready cleaned bythe brushes. Seefigure
#18(4).
NOTE: Duringmostcleaningprocedures,applyand
removethesolutioninone operation.
HOW TO CLEAN A VERY DIRTY FLOOR
To clean a very dirty floor, follow this procedure:
1. Apply solution to the floor.
2. Donotlowerthesqueegee.
3. Do not activate the vacuum motor.
4. Lowerthe brushes and scrub thefloor.
5. Leave the solution on the floor long enough for the
solution to begin cleaning the floor.
6. Scrubtheflooragainwithadditionalsolution,picking
up all the solution with the squeegee
Figure #18
1
2
4
3

Page -18- Clarke Technology Operator's Manual -Vision 21i - Vision V
There is no solution flow.
The solution flow does not stop.
The machine does not remove all the
water from the floor.
The batteries do not give the normal
running time.
Open the solution valve.
Remove the obstruction from the hose and the
filter.
Repair or replace the valve and the linkage.
Fill the solution tank.
Close the solution valve.
Repair or replace the valve and the linkage.
Clean the solution valve.
Replace the seat and washer.
Clean and lubricate valve stem.
Lower the squeegee.
(See Figure 27)
Drain the tank.
Clean the screen filter.
Remove the obstruction or repair the damage.
Check for tripped breaker. Have an autho-
rized service person make repairs.
Connect the hose.
Turn or replace the squeegee blade.
Correctly install the squeegee blade.
Adjust the pressure of the squeegee.
Replace the gaskets.
Clean the terminals and connectors. Replace
the damaged cables. Charge the batteries.
Add distilled water to each cell and charge the
batteries.
Charge the batteries for a full 16 hour charge.
Have an authorized service person repair the
charger.
Check voltage of each cell while discharging.
Connect the batteries.
PROBLEM CAUSE ACTION
The solution valve is closed.
There is an obstruction in the solution hose
or filter.
The solution valve or linkage is damaged.
The solution tank is empty.
The solution valve is open.
The solution valve or linkage is damaged.
The solution valve is dirty
There is a damaged seat and washer in the
solution valve.
The valve stem is dirty
The squeegee is up
The squeegee tilt is not correct.
The vacuum tank is full.
The screen filter is dirty.
There is an obstruction or damage in the
squeegee, squeegee hose or standpipe.
The vacuum motor is not running.
The squeegee hose is disconnected.
The squeegee blade is damaged, worn, or
incorrectly installed.
The squeegee pressure is not correctly
adjusted.
The gaskets on the cover of the recovery
tank are damaged.
The battery terminals are dirty or damaged.
The electrolyte level is too low.
The batteries are not fully charged.
The charger is damaged.
The battery is defective.
The batteries are disconnected.
HOW TO CORRECT PROBLEMS IN THE MACHINE

Clarke Technology Operator's Manual - Vision 21i - Vision V 19
Check the battery connections.
NOTE: If the problem continues consult
an authorized service person.
PROBLEM CAUSE ACTION
The cleaning is not even. The scrub brushes or pads are worn.
There is damage to the brush assembly,
casters or the solution valve.
The brush motors are not running
The solution level is low.
The machine does not run. The machine loses power. Reset the circuit breaker.
Check wire connection to traverse motor.
NOTES
Replace the scrub brushes or pads.
Have an authorized service person make
the needed repairs.
Check for tripped breaker, reset. Check
for loose connections.
Fill the solution tank.
NOTE: If the problem continues consult
an authorized service person.

Page -20- Clarke Technology Operator's Manual -Vision 21i - Vision V
WARNING: Maintenance and repairs must be
donebyauthorizedpersonnelonly.
WARNING: Alwaysemptythesolutiontankand
recovery tank before doing any
maintenance.
WARNING: Keepallfastenerstight.
TheseMaintenanceProceduresMustBeDoneEvery
Day
Keep the machine clean, it will need fewer repairs and
havelongerlife.
Do These Procedures When You Begin Your Work
Period
NOTE: Always engage the parking brake before
servicingthemachine.
1. Disconnect the plug on the charger from the
connector on the back of the machine. See
figure #19
2. Join the connector from the batteries (1) to the
control panel cable connection. See figure #19.
3. Make sure the recovery tank lid is on correctly.
See figure #20, Item A.
4. MakesuretheScreenfilteroverthevacuummotor
is clean and in position. See figure #21, Item B.
5. Makesurethevalvesonthedrainhosesareclean.
Tightly close the valves.
6. Make sure brush housings and skirts are in
position on the brush head.
7. Make sure the brushes are in position and
installed correctly
8. Check the installation of the squeegee and
squeegeehose.
MAINTENANCE
Figure #19
Figure #20
Figure #21
