Alto AU-800P Series User manual

www.altoproaudio.com
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Version 1.0
MODEL: AU-800P
Revised on Jan,2010

CONTENTS
1. Introduction..............................................................................................................................1
2. Specification.............................................................................................................................3
3. Block Diagram..........................................................................................................................4
4. Schematic Diagram................................................................................................................5
5. Wiring Diagram........................................................................................................................7
6. PCB Layout.............................................................................................................................8
7. Test Procedure.......................................................................................................................10
8. Exploded View & Mechanical Parts List.................................................................................12
9. BOM List................................................................................................................................14

The ALTO wireless microphone system AU-800R/800H/800P series is the delicately designed UHF, PLL
synthesized system, with two antennas built inside the receiver for smart switching diversity control, the
higher level RF signals may be fed into the system for greater reliability and coverage, therefore, the risks of
breakdown and interference are to be effectively reduced. By the Auto Scan function provided by the
AU-800R, PLL UHF Diversity Receiver, the operating frequency of the transmitter may be automatically
searched out and locked by the system. Or, you can manually adjust the channel of the transmitter to match
the receiver in case you know about the operating frequency of it. Generally, the AU-800R/800H/800P series
consists of
-AU-800R, PLL UHF Diversity Receiver
-AU-800H, Handheld transmitter
-AU-800P, Body Pack transmitter
S-600
Type: Dynamic Mic.
Frequency response: 50Hz~16kHz( 3dB)
Impedance: 300ȍ+ 20% at 1kHz
Sensitivity: -71dB 3dB
Direction: Omni-directional
For the AU-800P, there are several types of clip microphone are included in this product range, please make
sure that the proper microphone has been selected for your typical sound reinforcement system before
installation.
HM-38, Condenser microphone
Preset impedance: 600ohm;
Freq. response: 80-12KHz;
Sensitivity: -68dB+/-3dB at 1KHz;
Directional: Uni-directional;
Weight: 52g (0.12Ib)
1
. Introductio
n
--- 1 --
-

HM-58, Condenser microphone
Preset impedance: 700ohm;
Freq. response: 200-8KHz;
Sensitivity: -65dB at 1KHz;
Directional: Uni-directional;
Weight: 54g (0.12Ib)
Main features:
-AU-800R, PLL UHF Diversity Receiver,
-Friendly interface of front panel LCD status display;
-Auto Scan function for easy and convenient operation;
-Switching diversity control to receive the RF signal;
-Three output level versions;
-Squelch control;
-AU-800H/800P transmitters,
-Soft touch painting for comfortable use;
-Rechargeable battery design;
-Three RF output power versions;
-Mute function;
-Lock function to avoid the misaction during the live applications;
-Common features,
-PLL synthesized design;
-Consistent operating frequencies to comply with the EMC regulations;
-Up to 12x12, total 144 channel frequency presets;
-Manufactured under ISO9000:2000, ISO/TS16949:2002 quality management system;
--- 2 --
-

MODEL
Channel
Frequency band
Receiver type
Frequency response
Frequency stability
T.H.D.
Modulation mode
S/N Ratio
Dynamic
RF sensitivity
Audio output
Balance output
Power supply
Dimensions
Weight
AU-800H AU-800P
Oscillation mode
Carrier frequency band
Frequency response
Frequency stability
T.H.D.
Modulation mode
RF output power
Dynamic
Tone frequency
Current drain
Max. Deviation
Battery
Optional
Mic. Capsule(optional) Condenser or Dynamic Capsule Condenser or Dynamic Capsule
Dimensions 277 36.5mm (10.9" 1.44") 97mm 68mm 22mm(3.82" 2.68" 0.87")
Weight 0.246Kg 0.009Kg
AU-800R
Multi-channels, up to 144 frequency presets for each frequency bands
UHF 470-900 MHz Dependent on applicable country regulations
PLL UHF SYNTHESIZED
50 Hz-15KHz ( +/-3dB)
+/-0.005% (-10к-50 к)
1KHZІ0.8%
FM (F3E)
Ї90dB
Ї100dB
-100 dBm/30dB SINAD
Unbalanced 6.3mm phone jack 550mV ;+/-35KHz deviation
220mV , 35KHz deviation
DC 15V/ 500mA (AC 115V/230V 50/60Hz adaptor)
210(W) *55 (D)* 44(H)mm; (8.2"* 6.1"*1.7'')
0.99Kg
Nickel hydrogen battery +charger
UHF 470-900 MHz Dependent on applicable country regulations
Ї100dB
5-50mW(adjustable 3 bands)
30-33 KHz
100mA
50 Hz-15KHz ( +/-3dB)
+/-0.005% (-10к-50 к)
1KHZІ0.8%
FM (F3E)
PLL UHF SYNTHESIZED
+/-35KHz
AA type *2
2. Specification
--- 3 --
-
MODEL
Specification

1 2 34
A
B
C D
4
321
D
C
B
A
IC55
AF
COMP
Q8 RF
PA
Q1 Q3
RF
Buffering
Q6 Q7
VCO
IC55
AF
AMP
IC55 2/1
AF
FLITER
IC59
+3.3V
REGULATOR
IC2
+3V
REGULATOR
+3
PIC16F74
Micro controler
U132
LCD
U130
DETE103067BEP
Q2 Q15
CHARGE PUMP
PLL BLOCK
MT GT
Mic IN
RF
B,P,F
IC58
+5V
REGULATOR
+3+3V
IC1
PLL
CONTROL
IC58
Q53
DC
CONVERTER
RF
POWER
LEVEL
DC9V IN PUT
+5 +5 +3
BV.911Q!CMPDL!EJBHSBN/tdi
Ujumf;
Gjmf; Ebuf;
Esbxo!Cz; Tiffu!pg;
Sfwjtjpo;
Npefm!OP/
:.Nbz.3117!
BV.911Q!CMPDL!EJBHSBN
2
WFS171232B5
Tj{f; BV.911Q
D/M
AU-800P BLOCK DIAGRAM
3. Block Diagram
--- 4 --
-

1 2 3 4 56
A B C D
6
54321
D
C B A
IN
G
OUT
IC59
3.0V XC62FP3002MR
GND
C98
22uF/10V
R91
NC
R63 22K
R55 4.7K
Q54
2SC2412
+3V
+5
BAT
R135 15K
GND
C131 104P
GND X130
16MHZ
C134
22P
GND GND
C135 22P
+3V
+3V
POWER LEVEL1
LE DA
CLK
POWER ON/OFF POWER LEVEL2
CHG
TONE CONTROL
BATTERY
+3V
C133 104P GND
C132 104P
GND
+3V
RC6/TX
44 RC5
43 RC4/SDA
42 RD3
41 RD2
40 RD1
39 RD0
38 RC3/SCL
37 RC2
36 RA2/AN2 21
RA1/AN1 20
RA5/AN4
24
RE0/AN5
25
RE1/AN6
26
RE2/AN7
27
VDD
28
VSS
29
OSC1
30
OSC2
31
RC1
35 NC
34
NC 13
RB4 14
RB5 15
RB6/PGC 16
RB7/PGD 17
MCLR 18
RA0/AN0 19
NC 12
RC0
32
NC
33
RB2 10
RA3/AN3 22
RC7/RX 1
RD4 2 RD5 3 RD6 4 RD7 5
VSS 6
VDD 7
RB0 8 RB1 9
RB3/PGM 11
RA4
23
U132
PIC16F74
RC0 RC2 RC3 RC4 RC5 RE0 RE1 RE2 RA0
RD0 RD1 RD2 RD3 RD4 RD5 RD6 RD7 RB0
RB1 RB2 RB3 RB4 RB5 SEG1
5
SEG2
6
SEG3
7
SEG4
8
SEG5
9
SEG6 10 SEG7 11 SEG8 12 SEG9 13
SEG10 14 SEG11 15 SEG12 16 SEG13 17 SEG14 18
COM1
4COM2 3COM3 2COM4 1
U130 RF_SMALL_LCD
1
122
T8
MLB-160808-0080A-N2
VIN
D3 1SS355
R13282K
R13382K
R13482K
R13182K
R139 4.7K R140 22K
+3V
R13647K
R13747K
R13847K
R10447K
GND
C130 105P
BAT
R35 4.7K
R36 4.7K
+3V
C146 102P
GND
GND
GND GND
C123 22uF/10V
R143 100K
R144 100K
GND
GND
R45 10K
D2 1SS355
R32 22K
5
2
4
1 3
U131 24LC08B
GND
R41 10K
Q62
2SC2412 CHG
SW1 SW-PB SW2 SW-PB
C53 104P
1 2 3 4 5 6 7 8
CN1 HC00824
1 2 3 4 5 6 7 8
CN2 HC00824
GND
BAT
+5
LED1 SG00067
LED2
SG00067
+3V
GND
CHG
Z1
BUZZER
GND GND GND
R33 47K
11 22 33CN9
3PIN
11 22 33
CN10 3PIN
Titel Size File: Date:
Drawn By: Sheet
RevisionModel No:
of
A3
UP-8P-A.SCH(AU-800P)
2006/10/16
XIANG
UP-8P-A.SCH(AU-800P)
AU-800P VER061016
11
AU-800P(1/2)
15`2
4. Schematic Diagram
--- 5 --
-

1 2 3 4 5 6 78
A
B C
D
8
7654321
D
C B
A
GND
C114 102P
R76 22K
GND
GND
84
IC55C ST33078
C91 10uF/10V(T)
R100 10K
C113 47P
C103
104P
3 2
1
IC56A NJR4580
GND
VR55 B50K
GND
R84 22K
C106 47P C104 104P
GND
R81 12K
C71 100P
C134
10uF/10V
5 6
7
IC55B ST33078
GND
R99 220K
R101 15K
R83 47K
R95
47K
R97 10K
R74 10K
R98 470K
C109 472P
C107 472P
C108 470P
CPU-30KHz-35KHz
C110 470P
GND
GND
Njd!,
R79 1K
R70 10K
C85
10uF/10V(T)
GND
GND
R75 12K
L65 1uH
C78
100P
GND
1 2 3 4
CN54
ྤற
R58 56K
R72 22K
GND
GND
GND
L68
100uH
D5 FS1J3 1A/30V
C116 102P
R102 100K
R78
20K
GND
GND
C121
22uF/10V
C118 10uF/10V
C122
104P
C119 100uF/7V(T) 5
2
4
1 3
IC58
XC9103D
GND
11
2
2
T10
MLB-160808-0080A-N2
C117 104P
GND
GND
C125
104P
GND
C137
104P
AF IN
+5
+5
+5E
C115 104P
GND
5 6
7
IC56B NJR4580
84
IC56C NJR4580
BATE
CPU-30KHz-35KHz
BATV
BAS
CPU1 CPU2
CLK
DA
LE
1
122
T7 MLB-160808-0080A-N2
+5
C136
104P
GND
+5
R130 2.2K
C124 103P
G
DS
Q53 XP151A
C140 100P
1
122
T11
MLB-160808-0080A-N2
C141
104P
C142 104P C143 47uF/7V(T)
GND GND
GND
C144 47uF/7V(T)
GND
C145 104P
GND
C147 330P
GND
GND
1
3
2
BAT54
ྤற
TONGOUT
R34 2.2K
C112 470P
Q60 RTR030P02
Q61
2SC2412
GND GND
R77 47K
VR56 B50K
GNDTONGOUT
C45 470P C44 225P
C86 105P
power on
POWER ON
Q2 2SC2412
R42
22K
R43 8.2K
R44 4.7K
D4
FS1J3 1A/30V
GND
D6
S07ATHRUS07M GND
CHG
C48 104P
GND
GND
11
2
2
T1
MLB-160808-0080A-N2
GND
D7 1SS355
BATV
3 1 2
CN5 PHONEJACK2
C54 103P
GND
GND
BATE
+5
1 2 3 4 5 6 7 8
CN3 HC00819
1 2 3 4 5 6 7 8
CN4 HC00819
3
2
1
4
5
IC3
AD8541
L7
1uH
R52 120K
R25 220K
R51 1K
C66 220P
GND
C84 225P
GND
+5
C69 104P
GND
VR2 B50K
VR1 B50K
R27 10K R30 12K
GND
Q15
2SA1797Q
R59 12K
RF POWER
RF OFF
RF OFF
CHG
C51 225P
D1
S07ATHRUS07M
R20 4.7K
12
L56
18nH
1 2
L57
100nH
R69
2K
R56 1K
GND
GND
GND
R88 2.2K
GND
Q9
2SK2731
GND
2-POWER 3-POWER
CPU1 CPU2
R60 200R
Q10
DTC614TU
GND
GND
GND
R89 47R
R65
100R
GNDGND
GND
L60 10nH
L61
10nH
GND GND
L58 10nH
L59 10nH
GND GND
GND
1
GND
GND GND
GND
ANTENNA
L62
6.8nH(W)
BATE
C47 3.5P
C56
1P
C61 47P
C57 56P
C58 102P
C70 56P
C76 10P
C73 1.5P
C79 2.7P
C80NC
C77 3.5P
C81 1P
C82 1P
C75 4.7P
C74 3.3P
C59 100P
C65 56P
C63 102P
C62 47P
C120 15P
C138 15P
C139 100P
GNDGND
GND
R26 3.3K
L54
15nH
C43 472P
GND
R15 4.7K
R3 4.7K
R1 270R
R6 1K
R5 4.7K
R7 1K
R8 22K
R2 1K
R12 8.2K
R14 300R
C11
224P
C12
104P
VC1 V20P
C8 1.8P
C4 47P
C7 104P
C5 47P
+5
C38
10uF/10V(T)
C39
10uF/10V(T)
OUT
G
IN
IC2 XC62FP3002
+3VT
C27
104P
C28
104P
GND
OUTPUT3.3V
C17 22uF/10V
C10 103P
C16 4.7P
C3 47P
C2 10P
C1 47P
C19 472P
R4 4.7K
CLK DA LE
X1
12MHZ SC00398
+3VT
+3
GND
GND
GND
LE DA CLK
GND
VCO 794-805MHz
GND
+3
GND GND
GND
R17 18R
R21 430R
C20 1.8P
R23 100R
R28 1.8K
C33 56P
C34 2P
C36 472P
C29 1P
C21 4.7P
C25 56P
GND
VD1
BB142
C6 102P
C22
47uF/7V(T)
GND
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
IC1 MB15E03SLPFV
C37 3P
GND
L69 10nH L70 10nH
C83 3.3P
R19 10K
R31 10K
AF IN
C72 3.3P
GND
L4
2.2uH
GND
GND
C52 472P
GND
L71
10nH
C67 15P
C46 104P
GND
R9 10R
C9 56P
GND
B
CE1
E2
Q6
BFG425W
Q7 BFG425W
GND
R10 18R
R11 18R
Q8 BFG425W
C14 1P
C13 3.5P
C23 3.3P
VC2 V6P
R16 4.7K
R18 10R
C26 47P
C32 472P
C30 472P
C35 56P
R29 22R
B
CE1
E2
Q3 BFG425W
L3
15nH
GND
VC3 V6P
R38 22K R40 5.6K
GND
R33 330R
R39 1K
C42 4.7P
C41 56P
GND
C18 47P
GND
C50 104P
GND
R48 2.2uH
R24 1K
GND
C31 1.8P
GND
C87
10uF/10V(T)
GND
L8
5.6nH(W)
GND
RF POWER
C60 102P
GND
G
DS
Q4
XP151A
R47 10K
Q5
2SC2412
GND
L2
5.6nH(W)
L6
15nH
L9 15nH
C40 102P
GND
C53 102P
GND
GND GND
GND
C15 103P
GND 1
122
T4
MLB-160808-0080A-N2
R13 0R
C64 104P
GND
C90 103P
GND
1 2 3
4MODUL
ሶᠦᆝ
GND GND
GND GND
BATE
R32 10R
+4
+3 GND VD2
1SV270
C68 0.5P
GND GND GND
+3
11
2
2
T5
MLB-160808-0080A-N2
C100
10uF/10V(T)
GND
1
122
T2 2.2uH
C98 47uF/7V(T)
GND
GND
GND
C126 47P
C123 104P
GND
R35 10K
GND
Q1
2SC4226
Q11
2SC4226
R41 22R
R36 4.7K
R45 47R
R49 47R
Q12
BFG425W
R46 47R
GND
C89 1P
AUDIO +
Titel Size File: Date:
Drawn By: Sheet
RevisionModel No:
of
A3
D2 5.1V
GND
1 2 3
4MODUL-1
ሶᠦᆝ
GND GND
GND GND
C101 220P
R90 15K
C24 47P
R22 22K
C55 390P
C128 102P
AUDIO +
R64 10K
R57 10K
R71 33K
GND GND
GND GND
C127 225P
19 18
17
IC4D
SA575-2/1
Q13 DTC614TU
LD
LD
R62
1K
C132 33P C131 33P
GND GND
C133
4.7uF/10V(T)
R63 5.6K
GND
R82 2.2K
GND
C99 1uF/10V(T)
C93
10uF/10V
GND
C95
22uF/10V
GND
R93 4.7K
C105 680P
C111 225P
C102 225P
R87 33K
R86 33K
C92
10uF/10V(T)
C97 225P 3
2
1
IC55A
ST33078
C146 105P
C96 103P R67
330R
R55 22K
R50 100K
R66 1K
R37 1K
6
97
4
10 5
20
8
IC4A
SA575
12 13 16
14 11
15
IC4B SA575
GND
GND
+5
1 2
3
IC4C
SA575-2/1
R85 12K
R92 12K
C151 330P
C150 105P
GND
C135 104P
R80 2.2K
R96 5.6K
C152 102P
GND
C49 47P
GND
R54 120K
AUDIO -
C129
10uF/10V
R53 10K
R68 10K
GND
C130
47P
GND
C148 100P
C88 225P
+5
C153 100P
GND
TP2
COM-TP
MOD-TP
AMP-TP
TP4
Q14
2SA1036K
GND
GND
L1
180nH
C154 220P
L67
180nH
L66
180nH
+5E
C149
104P
GND
L5
22uH
R61 100K
GND
UP-8P-B.SCH(AU-800P)
2006/09/20
XIANG
UP-8P-B.SCH(AU-800P)
AU-800P
D8
1SS355
D9
1SS355
C94 47P
GND
L10 1uH
R73 10K
1KHz 65mvଃᙰᙁԵ
1KHz 100mvଃᙰᙁԵ
250mv-350mv
GND GND GND GND
SG00040
R91 22K
+5
VER061016
11
AU-800P(2/2)
15`3
--- 6 --
-

1 2 34
A
B
C D
4
321
D
C
B
A
LCD
દۥ ႕ۥ ֚ᒵ
ՂՀኙ༺ ՂՀኙ༺
CN1 CN2
CN3
CN4
૤ᄕᐘׂ إᄕᐘׂ
AU-800P
٤ᖲ಻ᒵቹ
BV.911Q!٤ᖲ಻ᒵቹ/Tdi
Ujumf;
Gjmf; Ebuf;
Esbxo!Cz; Tiffu!pg;
Sfwjtjpo;
Npefm!OP/
:.Nbz.3117!
BV.911Q!٤ᖲ಻ᒵቹ
2
WFS171232B5
Tj{f; BV.911Q
D/M
UP-8P-A(AU-800P)
UP-8P-B
AU-800P WIRING DIAGRAM
AU-800P WIRING DIAGRAM
AU-800P WIRING DIAGRAM
Antenna
+ spring tab
- spring tab
RED BLACK
AU-800P WIRING DIAGRAM
AU-800P WIRING DIAGRAM
AU-800P WIRING DIAGRAM
Antenna
+ spring tab
- spring tab
RED BLACK
5. Wiring Diagram
--- 7 --
-

ˣ˖˕ˍ˨ˣˀˋˣˀ˔ʳʳ˕ʳ˟˴˸ʳʳ˕ʳˢ˸˿˴ʳ˕ʳʳ˦˿˷˸ ˣ˖˕ˍ˨ˣˀˋˣˀ˔ʳʳ˧ʳ˟˴˸ʳʳ˧ʳˢ˸˿˴ʳ˧ʳ˦˿˷˸
6. PCB Layou
t
--- 8 ---

ˣ˖˕ˍ˨ˣˀˋˣˀ˕ʳ ˣ˸ʳˣ˿˴˸
ˣ˖˕ˍ˨ˣˀˋˣˀ˕ʳ ˚˷ʳˣ˿˴˸
ˣ˖˕ˍ˨ˣˀˋˣˀ˕ʳ ˕ʳ˟˴˸ʳ ˕ʳˢ˸˿˴ʳ ˕ʳ˦˿˷˸
ˣ˖˕ˍ˨ˣˀˋˣˀ˕ʳ ˧ʳ˟˴˸ʳ ˧ʳˢ˸˿˴ʳ ˧ʳ˦˿˷˸
--- 9 ---

AU-800P Finished Product Test Procedure
Test Instruments
1. Signal Generator: 8903B
2. Oscilloscope: LS8106
3. Modulation Meter: JMM-2200
4. Frequency counter: EFC-3203A
5. DC Power Supply: 3303A.
6. Digital Multi-meter
7. Frequency Spectrum: E4403B
Settings
1. Signal Generator: 1kHz/65mV.
2. Modulation Meter:
2.1. Tone setup: H: Pass: 3K L: Pass: 50K RANGE: 10
2.2. AF setup: H: Pass: 25 L: Pass: 15K RANGE: 50
Test Procedures and Specifications
1. Switch on power supply (press and hold the key ON/OFF for 2 seconds). LED
indicator turns on, LCD displaysbattery volume and frequency, then LEDturns off.
2. Test CH1, CH6, CH12:
PL2 response power above 5dBm;
PL1response power above 2dBm;
PL0 response power above -4.5dBm;
Harmonic: below -45 dBm.
(Remark: powers on PL1/PL2/PL0 must vary obviously)
3. Input signal (speaking) to MIC jack input, the modulation meter should have output.
4. Tone testing:
Tone signal: 3KHZ±0.5KHZ;
Frequency: 31~34KHZ.
5. Transmitting frequency:
compliant with criterion range
Tolerance: within ±2KHZ.
6. Function Test
7. Test Procedure
--- 10 -
--

6.1. Switch the key CH/ON and adjust to proper position, then switch SELECT to
check if there’ s any change.
6.2. Switch the key CH/On to “ LOCK” , SELECH key invalid. Then switch CH/On to
“ UNLOCK” , SELECT key can function normally.
6.3. When in status “ ready” , press SELECT key for 2 seconds, it will enter into
MUTE mode, then all the function keys are out of control, no output from
TONE. Press SELECT function key for a few seconds to release to press
CH/ON to switch off the machine.
7. Display Test: LCD will display differently when switch function keys and check if
there should no be any letter lacked or overwritten on the LCD.
8. Low voltage test: when voltage at 2.0V±0.1V, LCD displays “ Low voltage” ;
When voltage below 2V, it will automatically power off.
9. Total current consumption: current drain 125mA when power @ PL2
10. Switch off power supply (press and hold ON/OFF for 2 seconds), LED turns on.
LED will turn off after LCD displays CH.
11. Recharging Test
11.1. Charge current (when recharging): 160mA±40mA;
11.2. Battery sign (when recharging) in LCD display jumps up & down;
11.3. During the charging process, the "Remaining battery life display" flashes;
11.4. Transmitter stops transmitting power (when recharging)
11.5. LED indicator will flash if recharging completed.
Remark
1. Battery must be loaded when recharging;
2. Only charger (supplied by manufacturer) available.
~Test Completed~
--- 11 -
--

MODEL No: AU-800P
8. Exploded View & Mechanical Parts List
--- 12 -
--

S/N Part No Description Specification Qty
1 NI04125 LCD cover-transparent PC MOD-16P 7*43*67.82_V1.0 1
2 NI04304 ZC-top cover-ABS AU-800P ALTO_V1.0 1
3 HF00052 Antenna-RS YH940805 ij4*82.4mm 2
4 MK00114 Spring tab-battery point UP-8P 0.3t*17*12*1.6 (+)_V1.0 1
5 MK00113 Spring tab-battery point UP-8P 17*12*10 (-)_V1.0 1
6 MK00112 Spring tab-battery point UP-8P 25.5*10.5*10*1.6 ±_V1.0 1
7 MH01488 Plug-RS-Stainless steel card ij1.0*10mm SAMSON-T-V1.1 2
8 NI04193 ZB-compartment cover UP-8P 20.7*32.5*68.5_V1.1 1
9 NI03587 Compartment cover SW UP-8P 2*12*19 black_V1.0 1
10 NI04198 ZB-compartment cover SW UP-8P 4.5*10.7*14.5_V1.0 1
11 NI04126 Key-ABS MOD-16P 5.4*9*24 black_V1.0 1
12 HK07070 K-PCB P-UP-8P-A-DIP(AU-800P) 1
13 HK05770 K-PCB P-UP-8P-B_F7-DIP 1
14 MI03098 ZD-separating shade-UP8P-13 UP-8P 0.2t*2.8*14.2*14.3_V1.4 1
15 MI03096 Zd-separating shade top cover-UP8P-12 UP-8P 0.2t*2.8*14.2*14.3_V1.4 1
16 MI03458 ZD-separating shade-UP8P-16 UP-8P 0.2t*5*30*31.8_V1.0 1
17 MI03457 ZD-separating shade top cover-UP8P-15 UP-8P 0.2t*2*30*31.8_V1.0 1
18 NI04232 Cover light board UP-8P 14.6*27.8*0.3t_V1.0 1
19 HB01944 PCB-RS-FR4/2L?11.5*12*1.2 UP-8P-BAL_VER051116 1
20 HC00801 Mini balanced MIC jack TQ-4MC(male) 1
21 NI04194 ZB-fix piece- UP-8P 1*16.9*19.5_V1.0 1
22 MG00695 Copper column ij3.7*ij4.7*4.8_V1.0 1
23 MG00417 Black screw M2*6 Type B 1
24 NI04191 ZB-bottom cover UP-8P 12*69*91.1_V1.0 1
25 MG00626 Black screw M2*10_V1.0 2
26 NE15894 ZC-spec mark39.5*23.5mm AU-800P(F7 798-827)ALTO_V1.0 1
27 MK00105 ZE-spring clip UP-8P ij1.5*11*48.2*68.5mm_V1.0 1
Mechanical Parts List
--- 13 -
--

Class Part No Description Specification Insert location Remark
PE02297 MICROPHONE AU-800P(LV)_F7_ALTO
ѥ0001 NI04125 acrylic panel-RS MOD-16P 7*43*67.82_V1.0
ѥ0002 NI04304 top cover AU-800P ALTO_V1.1
ѥ0003 NI04191 bottom cover UP-8P 12*69*91.1_V1.0
ѥ0004 MK00112 spring piece-RS UP-8P 25.5*10.5*10*1.6 ±_V1.0
ѥ0005 MK00113 spring piece-RS UP-8P 17*12*10_V1.1
ѥ0006 MK00114 spring piece-RS UP-8P 0.3t*17*12*1.6 _V1.0
ѥ0007 MH01488 bolt ij1.0*10mm SAMSON-T_V1.1
ѥ0008 NI04193 battery cover UP-8P 20.7*32.5*68.5_V1.1
ѥ0009 NI03587 battery cover switch-RS-C UP-8P 2*12*14.3 black_V1.2
ѥ0010 NI04198 battery cover UP-8P 4.5*10.7*14.5_V1.0
ѥ0011 NI04126 key-RS MOD-16P 5.4*9*24 black_V1.0
ѥ0012 NI04194 fixed piece UP-8P 1*16.9*19.5_V1.0
ѥ0013 MG00417 screw M2*6 B type
ѥ0014 MG00626 screw-RS M2*10_V1.1
ѥ0015 MG00695 copper pillar ij3.7*ij4.7*4.8_V1.0
ѥ0016 NI04232 caushion-RS UP-8P 14.6*27.8*0.3t_V1.1
ѥ0017 HF00052 antenna-RS YH940805 ij4*82.4mm
ѥ0018 NE15894 lable AU-800P(F7 798-827)ALTO_V1.0 transmitter
ѥ0019 NE15893 lable AU-800P ALTO_V1.0 blister, warranty card.
ѥ0020 MK00105 spring-RS UP-8P ij1.5*11*48.2*68.5mm_V1.0
ѥ0021 MI03457 separating shade top cover-RS UP-8P 0.2t*2*30*31.8_V1.2
ѥ0022 MI03096 separating shade top cover-RS UP-8P 0.2t*2.4*14.6*14.7_V2.0
ѥ0023 NE12052 label-RS PE_V1.2 transmitter, blister,
warranty card
ѥ0024 HK07070 PC board P-UP-8P-A-DIP(AU-800P)
ѨΓѥ0001 SC00004 crystal oscillator 16.00MHZ X130
ѨΓѥ0002 HG00176 buzzer PB-09N23P-03 Z1
ѨΓѥ0003 HE00070 LCD module DTE103067BEP U130
ѨΓѥ0004 HC00148 connector 2.0 180° 3P(gold-plated) 3.8/8.5mm CN9,CN10
ѨΓѥ0005 HH00055 back light 50*25.5*3.0mm DB5025503CY
ѨΓѥ0006 AC00603 lead free soldering bar S100
ѨΓѥ0007 HK07071 PC board P-UP-8P-A-SMD(AU-800P)
ѨΓѨΓѥ0001 RD00116 SMD fixed resistor 1/10W 100Kȍ±5% 0603 R143,R144
ѨΓѨΓѥ0002 CI00228 SMD ceramic capacitor 0603 0.001uF/50V C0G±5%(C1608C0G1H102JT)/TDK C146
ѨΓѨΓѥ0003 CI00185 SMD ceramic capacitor 0603 0.1uF/50V X7R±10%(C1608X7R1H104KT)/TDK C53,C131,C132,C133
ѨΓѨΓѥ0004 CI00175 SMD ceramic capacitor 0603 1.0uF/16V X7R±10%(C1608X7R1C105KT)/TDK C130
ѨΓѨΓѥ0005 RD00101 SMD fixed resistor 1/10W 10Kȍ±5% 0603 R41,R45,R91
ѨΓѨΓѥ0006 RD00103 SMD fixed resistor 1/10W 15Kȍ±5% 0603 R135
ѨΓѨΓѥ0007 SE00061 SMD rectifier diode 1SS355-TE17/(ROHM) D2,D3
ѨΓѨΓѥ0008 RD00105 SMD fixed resistor 1/10W 22Kȍ±5% 0603 R32,R63,R140
ѨΓѨΓѥ0009 CI00177 SMD ceramic capacitor 1206 22uF/10V Y5V +80;-20% C98,C123
ѨΓѨΓѥ0010 SF00010 SMD transistor-RS 2SC2412K(SC59)/(ROHM) Q54,Q62
ѨΓѨΓѥ0011 SF00020 voltage stabilized transistor-RS 3.0V XC62FP3002MR(SOT23)/(TOREX) IC59
ѨΓѨΓѥ0012 RD00093 SMD fixed resistor 1/10W 4.7Kȍ±5% 0603 R35,R36,R55,R139
ѨΓѨΓѥ0013 RD00111 SMD fixed resistor 1/10W 47Kȍ±5% 0603 R33,R104,R136,R137,R138
ѨΓѨΓѥ0014 RD00115 SMD fixed resistor 1/10W 82Kȍ±5% 0603 R131,R132,R133,R134
ѨΓѨΓѥ0015 CO00097 SMD inductance-RS 80ȍ±25%(MLB-160808-0080A-N2)/(MALA) T8
ѨΓѨΓѥ0016 SG00315 integrated circuit-RS PIC16F74-I/PT(TQFP44)/(MICROCHIP) U132
ѨΓѨΓѥ0017 HL00005 push button switch-RS 4.5*4.5*3.8mm TRAVEL=0.2 SW1,SW2
ѨΓѨΓѥ0018 SG00207 SMD integrated circuit-RS 24LC00T/OT(SOT23)/(MICROCHIP) U131
ѨΓѨΓѥ0019 CI00051 SMD ceramic capacitor 0603 22PF/50V C0G±5%(C1608C0G1H220JT)/TDK C134,C135
ѨΓѨΓѥ0020 AE00553 SenJu solder paste M705-GRN360-K2-V 0.5KG/bottle
ѨΓѨΓѥ0021 SE00067 SMD L.E.D blue 12-215/BHC-AN1P2/3C LED1,LED2
ѨΓѨΓѬ0022 HB01803 PCB-RS UP-8P-A(1*4)_VER050928
ѨΓѬ0008 HC00819 connector-RS 2.0 90° 8P 1.5/9.7mm CN1,CN2
ѥ0025 HK05770 PC board-RS P-UP-8P-B_F7-DIP
ѨΓѥ0001 SC00398 crystal oscillator 12.000MHZ X1
ѨΓѥ0002 HC00714 DC jack LD-0211-1.3 CN5
ѨΓѥ0003 HK05771 PC board-RS P-UP-8P-B_F7-SMD
ѨΓѨΓѥ0001 SF00005 SMD transistor-RS-ACT 2SA1797Q(SC62)/(ROHM) Q15
ѨΓѨΓѥ0002 SF00042 transistor XP151A13A0MR(SOT23)/(TOREX) Q4,Q53
ѨΓѨΓѥ0003 SF00010 SMD transistor-RS 2SC2412K(SC59)/(ROHM) Q2,Q5,Q61
ѨΓѨΓѥ0004 SF00004 SMD transistor-RS-ACT 2SA1036K(SC59)/(ROHM) Q14
ѨΓѨΓѥ0005 SF00050 transistor XC9103D093MR(SOT25)/(TOREX) IC58
ѨΓѨΓѥ0006 SF00020 voltage stabilized transistor-RS 3.0V XC62FP3002MR(SOT23)/(TOREX) IC2
ѨΓѨΓѥ0007 SG00373 SMD integrated circuit SA575DTBR2(TSSOP20)/(ON) IC4
ѨΓѨΓѥ0008 RD00068 SMD fixed resistor 1/10W 100ȍ±5% 0603 R23,R65,R13
ѨΓѨΓѥ0009 RD00062 SMD fixed resistor 1/10W 18ȍ±5% 0603 R10,R11,R17
ѨΓѨΓѥ0010 RD00076 SMD fixed resistor 1/10W 330ȍ±5% 0603 R33,R67
9. BOM Lis
t
--- 14 -
--

Class Part No Description Specification Insert location Remark
ѨΓѨΓѥ0011 SF00078 transistor DTC614TU(UMT3)/(ROHM) Q10,Q13
ѨΓѨΓѥ0012 SF00067 transistor-RS-ACT BFG425W/(PHI) Q3,Q6,Q7,Q8,Q12
ѨΓѨΓѥ0013 SF00068 transistor 2SK2731-T146/(ROHM) Q9
ѨΓѨΓѥ0014 SF00062 transistor-RS-ACT 2SC4226-T1B(R25)(SC70)/(NEC) Q1,Q11
ѨΓѨΓѥ0015 SF00069 transistor RTR030P02-TL(TSMT3)/(ROHM) Q60
ѨΓѨΓѥ0016 SF00073 transistor AD8541ART(SOT23)/(ADI) IC3
ѨΓѨΓѥ0017 SE00006 SMD varactor 1SV270 VD2
ѨΓѨΓѥ0018 SG00007 SMD integrated circuit MB15E03SLPFV-ER(SOP16)/(FUJTTSU) IC1
ѨΓѨΓѥ0019 SE00016 SMD zener diode-RS-ACT 1/2W 5.1V(RLZ5.1B) LL-34 D2
ѨΓѨΓѥ0020 SG00122 SMD integrated circuit-RS-ACT NJM4580M-TE3(SOP8)/(JRC) IC56
ѨΓѨΓѥ0021 SE00045 SMD Schottky barrier diode-RS-ACT 1A/30V FS1J3 D4,D5
ѨΓѨΓѥ0022 SE00070 SMD Schottky barrier diode-RS-ACT 0.7A/400V S07G D1,D6
ѨΓѨΓѥ0023 SE00061 SMD rectifier diode 1SS355-TE17/(ROHM) D7,D8,D9
ѨΓѨΓѥ0024 SG00040 SMD integrated circuit MC33078DT/MC33078D(SO8)/(ST/MOTOROLA) IC55
ѨΓѨΓѥ0025 RF00001 SMD semi-fixed resistor EVN5ES X50B54-50K VR1,VR2,VR55,VR56
ѨΓѨΓѥ0026 RD00306 SMD fixed resistor 1/10W 20Kȍ±5% 0603 R78
ѨΓѨΓѥ0027 RD00061 SMD fixed resistor 1/10W 10ȍ±5% 0603 R9,R18,R32
ѨΓѨΓѥ0028 RD00063 SMD fixed resistor 1/10W 22ȍ±5% 0603 R29,R41
ѨΓѨΓѥ0029 RD00075 SMD fixed resistor 1/10W 300ȍ±5% 0603 R14
ѨΓѨΓѥ0030 RD00065 SMD fixed resistor 1/10W 47ȍ±5% 0603 R45,R46,R49,R89
ѨΓѨΓѥ0031 RD00508 SMD fixed resistor 1/10W 430ȍ±5% 0603 R21
ѨΓѨΓѥ0032 RD00227 SMD precise resistor 1/8W 200ȍ±1% 0805 R60
ѨΓѨΓѥ0033 RD00083 SMD fixed resistor 1/10W 1.0Kȍ±5% 0603 R2,R6,R7,R24,R37,R39,R51,R56,R62,
R63,R66,R79
ѨΓѨΓѥ0034 RD00103 SMD fixed resistor 1/10W 15Kȍ±5% 0603 R90,R101
ѨΓѨΓѥ0035 RD00095 SMD fixed resistor 1/10W 5.6Kȍ±5% 0603 R40,R96
ѨΓѨΓѥ0036 RD00099 SMD fixed resistor 1/10W 8.2Kȍ±5% 0603 R12,R43
ѨΓѨΓѥ0037 RD00101 SMD fixed resistor 1/10W 10Kȍ±5% 0603 R19,R27,R31,R35,R47,R53,R57,R64,R68,
R70,R73,R74,R97,R100
ѨΓѨΓѥ0038 RD00087 SMD fixed resistor 1/10W 2.0Kȍ±5% 0603 R69
ѨΓѨΓѥ0039 RD00091 SMD fixed resistor 1/10W 3.3Kȍ±5% 0603 R26
ѨΓѨΓѥ0040 RD00093 SMD fixed resistor 1/10W 4.7Kȍ±5% 0603 R3,R4,R5,R15,R16,R20,R36,R38,R44,R93
ѨΓѨΓѥ0041 RD00119 SMD fixed resistor 1/10W 220Kȍ±5% 0603 R99,R25
ѨΓѨΓѥ0042 RD00111 SMD fixed resistor 1/10W 47Kȍ±5% 0603 R77,R83,R95
ѨΓѨΓѥ0043 RD00117 SMD fixed resistor 1/10W 120Kȍ±5% 0603 R52,R54
ѨΓѨΓѥ0044 RD00105 SMD fixed resistor 1/10W 22Kȍ±5% 0603 R8,R22,R42,R55,R72,R76,R84
ѨΓѨΓѥ0045 RD00086 SMD fixed resistor 1/10W 1.8Kȍ±5% 0603 R28
ѨΓѨΓѥ0046 RD00088 SMD fixed resistor 1/10W 2.2Kȍ±5% 0603 R34,R80,R82,R88,R130
ѨΓѨΓѥ0047 RD00108 SMD fixed resistor 1/10W 33Kȍ±5% 0603 R71,R86,R87
ѨΓѨΓѥ0048 RD00123 SMD fixed resistor 1/10W 470Kȍ±5% 0603 R98
ѨΓѨΓѥ0049 RD00102 SMD fixed resistor 1/10W 12Kȍ±5% 0603 R30,R59,R75,R81,R85,R92
ѨΓѨΓѥ0050 RD00074 SMD fixed resistor 1/10W 270ȍ±5% 0603 R1
ѨΓѨΓѥ0051 RD00116 SMD fixed resistor 1/10W 100Kȍ±5% 0603 R50,R102
ѨΓѨΓѥ0052 CI00082 SMD ceramic capacitor 0603 3.3PF/50VC0G±0.25PF(C1608C0G1H3R3CT)TDK C72,C74,C83
ѨΓѨΓѥ0053 CI00089 SMD ceramic capacitor 0603 0.5PF/50VC0G±0.25PF(C1608C0G1H0R5CT)TDK C68
ѨΓѨΓѥ0054 CI00031 SMD ceramic capacitor 0805 2.2uF/16V Y5V-0805(2012) C44,C51,C84,C88,C97,C102,C111,C127
ѨΓѨΓѥ0055 CO00007 SMD chip inductance-RS-ACT 22uH(NLV32-220J-PF)/(TDK) L5
ѨΓѨΓѥ0056 CO00076 SMD chip inductance-RS 18nH±5%(MLG1608B18NJT)/(TDK) L56
ѨΓѨΓѥ0057 CO00067 SMD chip inductance-RS 10nH±5%(MLG1608B10NJT)/(TDK) L58,L59,L60,L61,L69,L70,L71
ѨΓѨΓѥ0058 CO00069 SMD chip inductance-RS 15nH±5%(MLG1608B15NJT)/(TDK) L3,L6,L9,L54
ѨΓѨΓѥ0059 CO00051 SMD chip inductance 1uH (NLV25T-1R0J)/(TDK) L7,L65
ѨΓѨΓѥ0060 CO00088 SMD chip inductance-RS 1.0uH±10%(MLF1608A1R0K)/(TDK) L10
ѨΓѨΓѥ0061 CI00132 SMD ceramic capacitor 0603 2PF/50V C0G±0.25PF(C1608C0G1H020CT)/TDK C34
ѨΓѨΓѥ0062 CI00131 SMD ceramic capacitor 0603 3.5PF/50VC0G±0.25PF(C1608C0G1H3R5CT)TDK C13,C77
ѨΓѨΓѥ0063 CI00177 SMD ceramic capacitor 1206 22uF/10V Y5V +80;-20% C17,C95,C121
ѨΓѨΓѥ0064 CI00175 SMD ceramic capacitor 0603 1.0uF/16V X7R±10%(C1608X7R1C105KT)/TDK C146,C150
ѨΓѨΓѥ0065 CI00176 SMD ceramic capacitor 1206 10uF/10V Y5V +80;-20% C118
ѨΓѨΓѥ0066 CI00185 SMD ceramic capacitor 0603 0.1uF/50V X7R±10%(C1608X7R1H104KT)/TDK C7,C12,C27,C28,C46,C48,C50,C64,C69,C103,C104,
C115,C117,C122,C123,C125,C135,C136,C137,C141,
C142,C145,C149
ѨΓѨΓѥ0067 CI00179 SMD ceramic capacitor 0603 0.22uF/25V X7R±10%(C1608X7R1E224KT)/TDK C11
ѨΓѨΓѥ0068 CI00180 SMD ceramic capacitor-RS-ACT 10uF/10V Y5V +80;-20% C93,C129,C134
ѨΓѨΓѥ0069 CI00047 SMD ceramic capacitor 0603 10PF/50V C0G±0.25PF(C1608C0G1H100CT)TDK C2,C76
ѨΓѨΓѥ0070 CL00007 SMD tantalum capacitor-RS-ACT 10uF/10V case A C98,C38,C39,C85,C87,C91,C92,C100
ѨΓѨΓѥ0071 CK00010 SMD half-adjustment capacitor 4.5-20PF N750 TZY2R200A001R00 VC1
ѨΓѨΓѥ0072 CO00094 SMD inductance 6.8nH±0.2nH(LQW18AN6N8C00D)/(MURATA) L62
ѨΓѨΓѥ0073 CI00188 SMD ceramic capacitor 0603 3PF/50V C0G±0.25PF(C1608C0G1H030CT)/TDK C37
ѨΓѨΓѥ0074 CK00005 SMD adjustment capacitor V6P TZVY2Z060A110 VC2,VC3
ѨΓѨΓѥ0075 CL00004 SMD tantalum capacitor-RS-ACT 4.7uF/20V case A(ELNA) C133
ѨΓѨΓѥ0076 CL00008 SMD tantalum capacitor 47uF/10V case B2 C143,C144,C22
--- 15 -
--

Class Part No Description Specification Insert location Remark
ѨΓѨΓѥ0077 CI00049 SMD ceramic capacitor 0603 15PF/50V C0G±5%(C1608C0G1H150JT)/TDK C67,C120,C138
ѨΓѨΓѥ0078 CO00093 SMD inductance 5.6nH±0.2nH(LQW18AN5N6C00D)/(MURATA) L2,L8
ѨΓѨΓѥ0079 CO00095 SMD inductance 100nH±5%(SWI0603CTR10J)/(AOBA) L57
ѨΓѨΓѥ0080 CL00011 SMD tantalum capacitor-RS-ACT 100uF/10V case C C119
ѨΓѨΓѥ0081 CO00097 SMD inductance-RS 80ȍ±25%(MLB-160808-0080A-N2)/(MALA) T1,T4,T5,T7,T10,T11
ѨΓѨΓѥ0082 CI00055 SMD ceramic capacitor 0603 47PF/50V C0G±5%(C1608C0G1H470JT)/TDK C1,C3,C4,C5,C18,C24,C49,C61,C62,
C106,C113,C126,C130
ѨΓѨΓѥ0083 CI00081 SMD ceramic capacitor 0603 2.7PF/50VC0G±0.25PF(C1608C0G1H2R7CT)TDK C79
ѨΓѨΓѥ0084 CI00084 SMD ceramic capacitor 0603 4.7PF/50VC0G±0.25PF(C1608C0G1H4R7CT)TDK C21,C42,C75,C14,C47,C26
ѨΓѨΓѥ0085 CI00076 SMD ceramic capacitor 0603 1PF/50V C0G±0.25PF(C1608C0G1H010CT)/TDK C29,C56,C81,C82,C89
ѨΓѨΓѥ0086 CI00078 SMD ceramic capacitor 0603 1.5PF/50VC0G±0.25PF(C1608C0G1H1R5CT)TDK C73
ѨΓѨΓѥ0087 CO00111 SMD inductance-RS-ACT 100uH±20%(VLCF4020T-101MR26)/(TDK) L68
ѨΓѨΓѥ0088 CI00079 SMD ceramic capacitor 0603 1.8PF/50VC0G±0.25PF(C1608C0G1H1R8CT)TDK C8,C20
ѨΓѨΓѥ0089 CI00201 SMD ceramic capacitor 0603 0.01uF/50V ±10%(C1608X7R1H103KT)/TDK C10,C15,C54,C90,C96,C124
ѨΓѨΓѥ0090 CI00198 SMD ceramic capacitor 0603 0.0047uF/50V ±10%(C1608X7R1H472KT)/TDK C19,C30,C32,C36,C43,C52,C109
ѨΓѨΓѥ0091 CI00217 SMD ceramic capacitor 0603 100PF/50V C0G ±5%(C1608C0G1H101JT)/TDK C59,C71,C78,C139,C140,C148,C153
ѨΓѨΓѥ0092 CI00223 SMD ceramic capacitor 0603 390PF/50V C0G ±5%(C1608C0G1H391JT)/TDK C55
ѨΓѨΓѥ0093 CI00226 SMD ceramic capacitor 0603 680PF/50V C0G ±5%(C1608C0G1H681JT)/TDK C105
ѨΓѨΓѥ0094 CI00224 SMD ceramic capacitor 0603 470PF/50V C0G ±5%(C1608C0G1H471JT)/TDK C45,C108,C107,C110,C112
ѨΓѨΓѥ0095 CI00214 SMD ceramic capacitor 0603 56PF/50V C0G ±5%(C1608C0G1H560JT)/TDK C9,C25,C33,C35,C41,C57,C65,C70
ѨΓѨΓѥ0096 CI00228 SMD ceramic capacitor 0603 0.001uF/50V C0G±5%(C1608C0G1H102JT)/TDK C6,C40,C53,C58,C60,C63,C114,C116,C128,C152
ѨΓѨΓѥ0097 CI00222 SMD ceramic capacitor 0603 330PF/50V C0G ±5%(C1608C0G1H331JT)/TDK C147,C151
ѨΓѨΓѥ0098 CO00124 SMD chip inductance-RS 0603 180nH±5%(MLG1608SR18JT)/(TDK) L1,L66,L67
ѨΓѨΓѥ0099 RD00112 SMD fixed resistor 1/10W 56Kȍ±5% 0603 R58
ѨΓѨΓѥ0100 CO00105 SMD chip inductance-RS 2.2uH±5%(MLF1608A2R2J)/(TDK) L4,T2,R48
ѨΓѨΓѥ0101 CL00002 SMD tantalum capacitor-RS-ACT 1.0uF/16V case A C99
ѨΓѨΓѥ0102 MI03098 separating shade-RS-ACT UP-8P 0.2t*2.8*14.2*14.3_V2.0
ѨΓѨΓѥ0103 MI03458 separating shade-RS UP-8P 0.2t*5*30*31.8_V1.2
ѨΓѨΓѥ0104 AE00553 SenJu solder paste M705-GRN360-K2-V 0.5KG/bottle
ѨΓѨΓѥ0105 CI00220 SMD ceramic capacitor 0603 220PF/50V C0G ±5%(C1608C0G1H221JT)/TDK C66,C101,C154
ѨΓѨΓѥ0106 SE00102 SMD varactor-RS BB143(SOD323)/(PHI) VD1
ѨΓѨΓѥ0107 HB01804 PCB-RS UP-8P-B(1*4)_VER060121
ѨΓѨΓѥ0108 CI00053 SMD ceramic capacitor 0603 33PF/50V C0G±5%(C1608C0G1H330JT)/TDK C131,C132
ѨΓѨΓѥ0109 CI00083 SMD ceramic capacitor 0603 3.9PF/50VC0G±0.25PF(C1608C0G1H3R9CT)TDK C23
ѨΓѨΓѥ0110 CI00030 SMD ceramic capacitor 0805 1uF/16V Y5V-0805(2012) C86
ѨΓѨΓѥ0111 CI00190 SMD ceramic capacitor 0603 5PF/50V C0G±0.25PF(C1608C0G1H050CT)/TDK C16
ѨΓѨΓѬ0112 CI00077 SMD ceramic capacitor 0603 1.2PF/50VC0G±0.25PF(C1608C0G1H1R2CT)TDK C31
ѨΓѥ0004 AC00603 lead free soldering bar S100
ѨΓѬ0005 HC00824 row-pin header(single) 2.0 180° 8P(gold-plated) 4.2mm CN3,CN4
ѥ0026 HK08512 MIC LM-10(4B) UP/UB
ѨΓѥ0001 NI01120 top cover VXM-168LTS
ѨΓѥ0002 NI01274 MIC shassis VXM-168LTS
ѨΓѥ0003 NI00536 wire jacket-RS ij2.7*20 MIC_V1.2
ѨΓѥ0004 NI00551 MIC clip L34*W10*H5.9
ѨΓѥ0005 NI00550 MIC clip-RS L34*W10*H7.1
ѨΓѥ0006 NI01003 MIC fixed bracket VXM-103TS
ѨΓѥ0007 ND00089 dustproof shade-No.1 ij17*24.5 VXM-168LTS
ѨΓѥ0008 MK00026 MIC spring clip piece L10*W5.2*H7.8
ѨΓѥ0009 MG00152 screw M2*5
ѨΓѥ0010 HG00050 condenser MIC-RS TSB-55A02
ѨΓѥ0011 HC00041 XLR MIC plug (mini) 92M-502-4P
ѨΓѥ0012 HA01898 signal wiring-RS ij2.5*ij0.12*1C*3FT
ѨΓѥ0013 NE17585 lable-RS LM-80 PLL SERIES_V1.0
ѨΓѬ0014 CI00228 SMD ceramic capacitor 0603 0.001uF/50V C0G±5%(C1608C0G1H102JT)/TDK PWR + &- polarity
ѥ0027 HB02570 PCB-RS UP-8P-4P_VER070906
ѥ0028 HA01847 wire-RS 37mm red L3R3
ѥ0029 HA01837 wire-RS 40mm black L3R3
ѥ0030 ND00872 EV foam-RS UP-88P 3.5t*40*18 black_V1.1
ѥ0031 MK00132 spring-RS UP-8P 0.5t*15.95*1.9*7.75_V1.0
ѥ0032 HC00801 balance MIC jack TQ-4MC Insert on HB02570 board
ѥ0033 NE18498 label-RS F7(798~827)_V1.0 paste on MCU
ѥ0034 HA02773 wire-RS 14mm L3R3
ѥ0035 HA02771 wire-RS 14mm L3R3
Ѭ0036 HA02770 wire-RS 14mm L3R3
--- 16 -
--
