Altos BrainSphere P10 F7 User manual

Altos
BrainSphere P10 F7
User Guide

System setup
System notes
Thank you for purchasing yourAltos Workstation. This user guide is intended as a
reference for experienced Workstation technicians and helps detail many of the features
available in Altos Workstations. For more detailed information about any particular
component or software solution, you may consult the technical specifications or the user
manual for that application.
Note: Before opening or removing any components
please contact your local certified Altos service
representative
Warning: Any parts or components damaged
during replacement by a non-certified technician
are not covered by the warranty. For details,
please consult the warranty guide from your system.

38L ATX Chassis
28L Micro ATX Chassis
System component identification
Altos BrainSphere P10 F7 Front configuration:
編號
說明
1
USB 3.2 Gen 1 Port x 2
2
USB 2.0 Port x 2
3
Audio jacks (In/Out)
4
USB 3.2 Gen1 Port (Type C)
5
Power Button
6
DVD CD-ROM (Optional)

Specification introduction
CPU
Processor type
Intel®11th/10th Core™ i9/i7/i5/i3 series Processors, TDP Up to
125W
Number of processors
1
On-board Devices
Chipset
Intel®H570 Chipset
SATA
4 SATA3 (6 Gb/s) ports
SATA RAID
Intel onboard software RAID 0, 1, 5, 10 (only supports Windows
OS)
Graphics
Intel® UHD Graphics Support (by CPU)
Network controller
Audio controller
1 Gb/s (10/100/1000) BASE-T LAN port (Intel®I219V)
Realtek ALC897
Memory
Memory slot
4 DIMM slots (Dual channel)
Memory type
Up to 128GB, Non ECC UDIMM, DDR4 3200 MHz
Expansion slots
PCIe
1 PCI-E 4.0 x16 slot (by CPU)
1 PCI-E 3.0 x4 slot
1 PCI-E 3.0 x1 slot
M.2
1 M.2 2280 PCI-E 4.0 slot (by CPU)
1 M.2 2280 PCI-E 3.0 slot
1 M.2 2230 PCI-E 3.0, E Key for Wi-Fi & Bluetooth
I/O ports
Front I/O ports
1 USB 3.2 Gen1 port(Type C)
2 USB 3.2 Gen1 ports
2 USB 2.0 ports
Audio jacks (In/Out)
Option: Multi-Card Reader
Rear I/O ports
1 Display Port 1.4
1 HDMI Port
2 USB 3.2 Gen2 ports(Type-A)
Option: Thunderbolt™ 4
1 Gigabit LAN port (RJ-45)
4 USB 3.2 Gen1 ports
3 Audio jacks (In/Out/Mic)
Management & Security
Option: TPM v2.0 module
Option: Altos Smart Server Management software
Drive Bays
Media bay
28L(mATX) SKU: 2 x 5.25" bay, 1 x 3.5” bay
38L(ATX) SKU: 3 x 5.25" bay, 1 x 3.5” bay
Storage bay
28L(mATX) SKU: 2 x 3.5” bays
38L(ATX) SKU: 4 x 3.5” bays
Power supply
28L(mATX) SKU: 500W 80 PLUS Bronze
38L(ATX) SKU: 750W 80 PLUS Gold
Form factor
Form factor
Micro ATX Tower / ATX Tower
Dimensions (D x W x
H)
28L(mATX) SKU : 425 (D) x 190 (W) x 350 (H) mm
38L(ATX) SKU : 483 (D) x 190 (W) x 416 (H) mm

Motherboard Layout

I/O Panel

Installing the CPU

Installing Memory Modules (DIMM)

Installing Memory Modules (DIMM)

Expansion Slots (PCI Express Slots)

Jumpers Setup

Onboard Headers and Connectors

M.2_SSD Module Installation Guide
