Altronix R2432UL Series User manual

Rev. 020504 More than just power.TM
R2432300UL
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Thirty-Two (32) Fuse Protected Outputs.
R2432600UL
- 24VAC @ 25A (600VA) or
28VAC @ 20A (560VA).
- Thirty-Two (32) Fuse Protected Outputs.
R2432300ULCB
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Thirty-Two (32) PTC Protected Outputs.
R2432600ULCB
- 24VAC @ 25A (600VA) or
28VAC @ 20A (560VA).
- Thirty-Two (32) PTC Protected Outputs.
R2432UL Series
UL Listed Rack Mount
CCTV Power Supplies
Installation Guide
Models Include:

- 2 - R2432UL Series
Overview:
Altronix R2432UL Series Rack Mount CCTV Power Supplies provide 24VAC or 28VAC distributed via thirty-
two (32) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories.
Thirty-Two (32) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
Output Voltage (VAC) Total Output Current (Power) Number of Outputs PTC Protected auto-resettable Outputs (Class 2 power-limited for Dry locations, Class 3 for Wet locations) Fuse Protected Class 1 Outputs Individual Output Current (max per output, not to exceed total output current) Fuse Ratings 115VAC 50/60Hz Input Current Agency Listings
R2432300UL 24VAC 12.5A 32 – P3.5A 3.5A 3A
28VAC 10A
R2432300ULCB 24VAC 12.5A 32 P– 2.5A – 3A
28VAC 10A
R2432600UL* 24VAC 25A 32 – P3.5A 3.5A 6A
28VAC 20A
R2432600ULCB* 24VAC 25A 32 P– 2.5A – 6A
28VAC 20A
*24VAC models: Outputs 1-16 provide 12.5A (300VA) max. Outputs 17-32 provide 12.5A (300VA) max.
*28VAC models: Outputs 1-16 provide 10A (280VA) max. Outputs 17-32 provide 10A (280VA) max.
Specifications:
Installation Instructions:
1. The unit is factory set for 24VAC operation.
For 28VAC operation adjust unit prior to mounting and applying power as follows:
a. Open bottom of the unit by removing six (6) screws (Rack Mechanical Drawing & Dimensions, pg. 4).
b. Change the wire position so that the black wire [28V] is connected to the terminal marked [P] and
the yellow wire [24V] is connected to the terminal marked [S] (Fig. 1d, pg. 3).
c. After securing all wires for proper voltage place bottom panel back on the unit and fasten with the
six (6) screws.
2. Mount unit in the desired rack location (Space unit at least 3” from any video monitors).
Do not obstruct side air vents.
3. Set power disconnect circuit breaker to the OFF position (Fig. 1c, pg. 3).
4. Plug power cord into a grounded 115VAC 50/60 Hz receptacle (Fig. 1b, pg. 3), ground should be connected
as indicated in (Fig. 1e, pg. 3).
5. Set power disconnect circuit breaker to the RESET (ON) position and measure output voltage before
connecting devices (Fig. 1c, pg. 3). This helps avoiding potential damage. All terminals with common
suffix (P) “1P, 2P...” are the same polarity.
6. Set power disconnect circuit breaker to the OFF position (Fig. 1c, pg. 3).
7. Connect devices to the removable terminal blocks marked [1P & 1N] through [8P & 8N] (Fig. 1a, pg. 3).
When wiring is completed on the terminal blocks, they can be locked down by tightening screw flanges.
8. Upon completion of the wiring, set power disconnect circuit breaker to the RESET (ON) position
(Fig. 1c, pg. 3).
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL2044).
cUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
CE - European Conformity
Input:
• 115VAC, 50/60Hz.
Output:
• Thirty-two (32) fuse or PTC protected outputs.
• 24VAC or 28VAC supply current.
• Outputs are rated @ 3.5A (fused) or 2.5 (PTC).
• Surge suppression.
Visual Indicators:
• Thirty-two (32) individual power LED indicators.
• Illuminated master power disconnect circuit
breaker with manual reset.
Features:
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
• Spare fuses provided.
Mechanical:
• 2U rack mount chassis for use in a standard
EIA 19” rack.
• Enclosure Dimensions (H x W x D approx.):
3.26” x 19.125” x 8.5” (83mm x 486mm x 216mm).

R2432UL Series - 3 -
9. Green power LEDs on faceplate will illuminate when AC power is present. When an output is in a trouble
condition (blown fuse or tripped PTC) the corresponding LED will not be illuminated (Fig. 1, pg. 3):
a. Blown fuse (R2432300UL and R2432600UL) - Set power switch on the back of the unit to the OFF
position (Fig. 1c, pg. 3). Remove faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA
(Altronix model # Fuse1).
b. Tripped PTC (R2432300ULCB and R2432600ULCB) - to reset PTC, set power switch on the back of
the unit to the OFF position. After approximately 30 sec. set power switch to the ON (RESET) position
(Fig. 1c, pg. 3).
10. Power switch with built-in circuit breaker:
OFF position - Switch not illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not illuminated. Power LEDs on faceplate are not illuminated.
Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position (Fig. 1c, pg. 3).
Note: Do not exceed units electrical load ratings as indicated in reference chart (pg. 2).
Do not place mechanical load on unit. Data racks should always be properly ventilated.
Unit is designed optimally for normal data room office installations.
CAUTION: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to
the National Electrical Code and all local codes.
NPS
PN
S
NPS
PN
S
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
AC Power
LEDs
S P N S P N
24VAC Output
(Factory Set) 28VAC Output
28VAC (Black) 24VAC (Yellow) COM (Brown) 28VAC (Black) 24VAC (Yellow) COM (Brown)
PTC1
Used
on PTC
Models
Removable
Terminal
Block
Strain Relief
Line Cord Power Switch
XFMR*XFMR*
Green Wire
Earth GND
Fig. 1 Fig. 1a Fig. 1b Fig. 1c
Fig. 1e
Fig. 1d

- 4 - R2432UL Series
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
IIR2432ULSeries D19R MEMBER
Rack Mechanical Drawing and Dimensions:
3.26” x 19.125” x 8.5” (83mm x 486mm x 216mm)
30
32
N P N PN PN P N P N PN PN P N P N PN PN P N P N PN PN
PN
P N PN PN PN P N PN PN PN P N PN PN PN P N PN PN P
OFF
31
RESET
2427
29 28 25
26 23 22 21 20 19 18 17 16 15 14 13 12 11 10 98 7 654 3 21
Bottom View
Rear View
Front View
17.5” (444.5mm)
19.125” (486mm)
2.95”
(75mm)
3.26”
(83mm)
8.5”
(215.9mm)
1.0”
(25.4mm)
0.65” (16.5mm)
2.52”
(64mm)
1.5”
(38mm)
For fuse protected models:
Replace fuses with the same type and rating 3.5A/250V.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may
be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside. Refer servicing
to qualified service personnel.
3.5A 250V
