Alula NanoMax RE322T User manual

NanoMax is the smallest full-featured security transmitter
in the industry. It is typically used to sense opening and
closings of doors and windows, but can secure just about
anything using its Strip & Stick™external contact holes. It will
alarm when the magnet is pulled away from the NanoMax or
when the external contact is opened.
Features
• Quick peel and press mounting
•Small prole for a near invisible look
•Most exible magnet positioning in the industry
• Strip & Stick external contact holes
• 5 year warranty
Enroll by placing the panel into wireless enrollment mode and
removing the battery tab or tripping the sensor three times.
Enrollment Tips
• Program as an RF type (Supervised RF)
• Loop 2 = Door
• Loop 4 = Tamper
• Removing the battery tab, which can be done
without removing the cover, sends the entire
enrollment sequence needed by Honeywell
panels.
• Sensor trips should be spaced by two seconds
when enrolling.
Install by removing the adhesive paper and adhering the
NanoMax and magnet on a door or window. Make sure to
align the alignment marks on the NanoMax and magnet
when mounting. Alternatively, NanoMax can be used with an
external contact instead of using the reed switch.
External Contact (not evaluated by ETL)
• If you are using the external contact then you
cannot use the reed switch.
• Use a normally-closed contact because
NanoMax will transmit an alarm when it sees
the external contact open.
• Do not use end-of-line resistors.
• Connect the contact to NanoMax by inserting
the contact’s wires into the two Strip & Stick
holes on the back of NanoMax.
• Additional wiring information can be found
by searching alula.net for “external contact
wiring”.
Verify proper enrollment and operation using your control panel’s installation manual.
NanoMax™
RE122, RE222, RE322T, RE322, RE622
I
N
S
T
A
L
L
G
U
I
D
E
I
Resolution Compatibles

Pro Tips
3M VHB Tape works great if the surface is properly prepared and rm pressure is applied
for over 10 seconds.
Surface Preparation
• Clean the surface
• Ensure the mounting surface temperature is above 50 °F
Wireless performance is optimized when mounted near the top of the door in a vertical
orientation.
OK BESTWRONG
Accessories
MetalMax™ NanoMax Mounts (RE033-16) can be used for better performance on metal
and narrow mounting situations.
• Improves wireless performance by
moving the internal antenna away from
metal surfaces.
• Provides an alternate mounting
orientation for narrow installs.
• Increases magnet gap distance on
metal surfaces.

Non-Ferromagnetic Surface
Nominal Mounting Distance
X Axis - Make
Break
Y Axis - Make
Break
Z Axis - Make
Break
0.75 inches (2.0 cm)
0.90 inches (2.3 cm)
0.95 inches (2.5 cm)
1.70 inches (4.3 cm)
1.75 inches (4.5 cm)
1.10 inches (2.8 cm)
1.15 inches (3.0 cm)
Ferromagnetic Surface (Using RE033 Mount)
Nominal Mounting Distance
X Axis - Make
Break
Y Axis - Make
Break
Z Axis - Make
Break
0.50 inches (1.2 cm)
0.55 inches (1.4 cm)
0.60 inches (1.5 cm)
1.50 inches (3.8 cm)
1.55 inches (4.0 cm)
0.70 inches (1.8 cm)
0.75 inches (2.0 cm)
Magnet Gap Specications
Z Axis
X Axis
Y Axis

Physical
Housing Dimensions
Weight with Battery
Mounting Fastener
1.80 x 0.77 x 0.39 inches (4.6 x 2.0 x 1.0 cm)
0.53 ounces (15 grams)
3M VHB Tape
Environmental
Operating Temperature
Maximum Humidity
32 to 120 °F (0 to 49 °C)
85% non-condensing relative humidity
Sensor Specications
Frequency
Replacement Battery
Nominal Battery Life
Battery Voltage
Current Draw
Transmitted Indications
345 MHz
One Panasonic CR1632
6 years
3.0 VDC (Nominal), 2.62VDC (Low)
20 mA (Maximum), 0.5uA (Quiescent)
Cover Tamper, Low Battery, Supervision
Certications
RE222 UL634, ULC634, ETL, FCC, IC
Specication subject to change without notice
Specications
47-0006-02 • REV C • 2018-02-28
Tech Support Line • (888) 88-ALULA • [phone]
alula.net
WARRANTY
Alula Holdings, LLC will replace products that are defective in their
rst ve (5) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE222
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the Alula
Holdings, LLC could void the user’s authority to operate this
equipment.
FCC ID: U5X-RE222
TRADEMARKS
Alula and NanoMax are trademarks owned by Alula Holdings, LLC.
“Honeywell” is a trademark owned by Honeywell International, Inc.
Alula Holdings, LLC products will function with Honeywell systems.
However, no Alula Holdings, LLC product is produced by, endorsed
by, or ofcially associated with Honeywell. Alula Holdings, LLC
recommends verifying proper enrollment and operation, per control
panel installation instructions, at installation.
