Alula RE252 PINPad User manual

PINPad is a simple arming station that allows local
control of the security system. It is battery powered
and requires no installation tools. Many can be
installed throughout the home to provide convenient
system control.
Features
• Secure 4 digit disarming
• Small yet comfortable
• 5 year warranty
Enroll by placing the panel into wireless enrollment
mode and then using the specic enrollment
instructions from your Honeywell panel's manual. The
PINPad will be enrolled exactly the same way as a
keyfob.
The default access code is "1234". To change the
access code, complete the following steps within four
seconds:
1.Enter the current 4-digit access code.
2.Press and hold the "1" and "3" buttons
simultaneously. After three seconds, the Red LED
will be lit.
3.Enter new 4-digit access code. After this happens,
the green LED will be lit.
Panel specic enrollment instructions
Lynx Touch 5100: First select "programming". Then
choose "keys" and select "add new".
Key Type
4 Button
User
Master
Serial Number
[Press Stay key to enroll]
Zone
49 (example)
Button Key 1 - Zn 49
Arm Away
Button Key 2 - Zn 50
Disarm
Button Key 3 - Zn 51
Arm Stay
Button Key 4 - Zn 52
24 Hour Auxiliary
Use the panel installation guide to verify proper system setup.
RE252 PINPad™
Honeywell® Compatible
I
N
S
T
A
L
L
G
U
I
D
E
I
Resolution Compatibles
System Programming

Lynx 5100 (Continued)
PINPad
Button
Lynx Touch
Button Key
Lynx Touch
Loop
Should be
Programmed to
Away Button Key 1 Loop 3 ARM AWAY
PIN Code Button Key 2 Loop 2 DISARM
Stay Button Key 3 Loop 4 ARM STAY
Stay + Away Button Key 4 Loop 1 24 HOUR AUX
Lynx Plus 3000 and Vista
To RF Learn: Press each PINPad button (or PIN Code) twice,
more than 5 seconds apart.
Note: be at least 5 feet from the panel, and be sure to
associate Key with a user.
PINPad
Button
Lynx Plus
Zone Number
Lynx Plus
Zone Type
Lynx Plus
Input Type
Lynx Plus
Loop
Away 26 (example) 21 Arm Away BR Loop 3
PIN Code 27 22 Disarm BR Loop 2
Stay 28 20 Arm-Stay BR Loop 4
Stay +
Away
29 07 24 Hr Aud BR Loop 1
Operation
PINPad Button Panel Action LED
Stay ARM STAY Flashes double red
Away ARM AWAY Flashes double red twice
PIN Code DISARM Flashes double green
Stay + Away PANIC ALARM Flashes red eight times
Note: Do not use this product for 2GIG panels, as the panic
alarm will not work on 2GIG panels using the Honeywell
compatible PINPad. For 2GIG panels, use the RE252T.

Install using the 3M VHB® tape on the back of the
PINPad to adhere it to a wall.
• See Pro Tips for recommendations about using
3M VHB tape.
• Two #4 or #6 screws may be used instead of,
or in addition to, the 3M VHB tape.
• The mounting plate can also be rotated 180°
for table top use (See Pro Tips).
Operate using the PINPad buttons. The PINPad LED will
blink when a button is activated.
Disarm by entering a valid 4 digit user code on the
number pad.
Arm Away by pressing the AWAY button until the
PINPad LED ashes red.
Arm Stay by pressing the STAY button until the
PINPad LED ashes red.
Trigger a panic alarm by pressing the STAY &
AWAY buttons together simultaneously until the
Red LED briey ashes repeatedly.
Pro Tips
3M VHB Tape works great if the surface is properly
prepared and rm pressure is applied for over 10
seconds.
Surface Preparation
• Clean the surface
• Ensure the mounting surface temperature is above 50 °F
Reversible mounting plate allows for easy use on a
wall or table. For table top use, remove and reverse
the mounting plate and install the rubber feet
supplied.
To replace the battery insert a screwdriver into the
latch slot on either side of the PINPad and pop the
cover off the wall plate. Replace the battery and
reinstall the cover onto the wall plate.
Mounting Screw Holes
VHB Tape
VHB Tape
Arm Stay Arm Away
LED

Specications
Physical
Housing Dimensions
Weight with Battery
Mounting Fastener
2.28 x 1.97 x 0.40 inches (5.8 x 5.0 x 1.0 cm)
0.70 ounces (20 grams)
3M VHB™ Tape or #4/#6 screws (Mounting screws not provided)
Environmental
Operating Temperature
Maximum Humidity
32 to 120 °F (0 to 49 °C)
85% relative humidity non-condensing
Sensor Specications
Frequency
Replacement Battery
Nominal Battery Life
Battery Voltage
Current Draw
Transmitted Indications
345 MHz
One Panasonic CR2032
4 to 6 years
3.0 VDC (Nominal), 2.2 VDC (Low)
20 mA (Maximum), 1 uA (Quiescent)
Low Battery, Supervision
Certication
RE252 FCC, IC
Specications subject to change without notice.
WARRANTY
Alula will replace non-portable products that are defective in their
rst ve (5) years, and portable products that are defective in their
rst two (2) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE252
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by Alula could void
the user’s authority to operate this equipment.
FCC ID: U5X-RE252
TRADEMARKS
Alula is a trademark owned by Alula Holdings, LLC.
“Honeywell” is a trademark owned by Honeywell International Inc.
Alula products will function with Honeywell systems. However, no
Alula product is produced by, endorsed by, or is ofcially associated
with Honeywell.
Alula recommends verifying proper enrollment and operation, per
control panel installation instructions, at installation.
47-0007-02 • REV A • 2018-04-25
