ALW LIGHTPLANE 2 User manual

A1035 22nd Avenue, Unit 1 nOakland, CA 94606 P510.489.2530 [e-mail] Walwusa.com
INSTALLATION INSTRUCTIONS
LIGHTPLANE 2
LP2 | Suspended | LED

LP2 Suspended Installation Guide 2 of 12 102-000026 - IG121818-A.0
Safety & Warnings!
1. Read all instructions.
2. Install in accordance with national and local electrical code regulations.
3. This product is intended to be installed and serviced by a qualied, licensed electrician.
4. Turn off electrical power before installing or servicing xture in any way.
5. Do not install in wet locations. For dry and damp use only.
6. Turn off electrical power before installing or servicing xture in any way.
7. To reduce the risk of re and overheating, make sure all connections are tight.
8. This product is suitable for continuous row mounting.
1. Lisez toutes les instructions.
2. Installez conformément à la réglementation du code électrique national et local.
3. Ce produit est destiné à être installé et entretenu par un électricien agréé qualié.
4. Coupez l’alimentation électrique avant d’installer ou de réparer le luminaire de quelque manière que
ce soit.
5. Ne pas installer à l’extérieur ou dans des endroits humides. Pour une utilisation en intérieur et sec
seulement.
6. Coupez l’alimentation électrique avant de évoluer le système d’éclairage en aucune façon.
7. Pour réduire le risque d’incendie et de surchauffe, assurez-vous que toutes les connexions sont bien
serrées.
8. Ce produit convient au montage en ligne continue.
Attention!
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior
to installation or servicing.

LP2 Suspended Installation Guide LP2 Suspended Installation Guide 3 of 12 102-000026 - IG121818-A.0
Table of Contents
Troubleshooting 10
Wiring Diagrams 11
Installation 5
Prepare Ceiling 5
Standard Suspension 5
Connecting Multiple Sections 7
Luminaire Overview 4
Diagrams 4
Components 4
Parts (by others) 4
Tools Required 4
Quick Specs 4

LP2 Suspended Installation Guide 4 of 12 102-000026 - IG121818-A.0
LUMINAIRE OVERVIEW
Drill
#2 phillips bit
Tools Required
Wire strippers
Input Voltage / Frequency:
See product label
Rated Power:
See product drawing
Ambient Temperature:
-4° – 120°F (-20° – 50°C)
Environment:
Dry and damp locations
Quick Specs
STANDARD SUSPENSION COMPONENTS
Suspension BulletCanopy Assembly Suspension Cable Ceiling Fitting
J-Box
Ceiling Fitting /
Suspension Bullet
To Building Power
Canopy
Power Cord
Suspension Cables
Cable Gripper
Fixture Body
Integrated LED Driver
Junction Box (Optional)
Parts (by others)
Wood Screws, #10, 1.5”
long
Conduit/NM (non-metallic)
cable (or similar) if not using
J-Box
5/64” Hex Key (for Joining)
1/8” Hex Key (for Joining)

LP2 Suspended Installation Guide 5 of 12 102-000026 - IG121818-A.0LP2 Suspended Installation Guide
Ceiling Fittings may also be mounted using toggle bolts.
3BInstall Ceiling Fitting - Toggle Bolts
Ceiling Fittings may also be mounted on 1/4”-20
Threaded Rods.
3CInstall Ceiling Fitting - 1/4”-20 Threaded Rods
Installation: Prepare Ceiling Installation: Standard Suspension
Ceiling Fittings may be installed directly into framing with
appropriate hardware.
3AInstall Ceiling Fitting - Framing
ELECTRICAL WIRING:
A
T
MUST
See nal/record drawings for mounting locations. Install
framing or strut channels with consideration for alignment
of wiring and suspension mounting locations.
1See Final/Record Drawings for Mounting Locations
SAMPLE DRAWING
ELECTRICAL WIRING:
A
T
MUST
Install Canopy J-Box (if using - sold separately) at power
feed location per nal/record drawing. Otherwise run
conduit/NM cable to powerfeed location.
2Install Canopy J-Box
SAMPLE DRAWING
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior to
installation or servicing.
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON
WIRES while joining sections or reattaching heatsink.

LP2 Suspended Installation Guide 6 of 12 102-000026 - IG121818-A.0
Bring wiring and canopy assembly to J-box. Refer to page
11 and nal/record drawing to make wiring connections.
CAUTION: High Voltage Wire —Ensure Power is OFF prior
to connecting wiring.
9Connect High Voltage Wiring
Route Suspension Cable through Suspension Bullet. Ball
end should sit in Suspension Bullet. Screw Suspension Bullet
to Ceiling Fitting.
4Route Suspension Cable and Attach to Ceiling
Installation: Standard Suspension
(Cont.)
6"
Use wire snips or shears to cut Suspension Cables to
desired length. Keep an extra 6 inches of cable for
adjustments.
5Cut Suspension Cables to Desired Length 8Adjust Suspension Cable Length
Adjust xture until it is level and at desired height. Depress
top of Cable Gripper to lower xture. Keep xture
supported while lowering. Cut excess cable.
Raise xture to Suspension Cables, and attach xture by
inserting Suspension Cable through Cable Grippers.
7Raise Fixture to Suspension Cables
6Connecting Multiple Sections (If Necessary)
Please see steps 12 through 25 for directions on
connecting multiple sections.
SHOCK HAZARD! May result in serious injury or death. Turn
power OFF at circuit breaker prior to installation or servicing.

LP2 Suspended Installation Guide LP2 Suspended Installation Guide 7 of 12 102-000026 - IG121818-A.0
Installation: Standard Suspension
(Cont.)
Turn breaker ON and check if xture operates as
intended and that there are no loose connections.
11 Turn Power On
Installation: Connecting Multiple
Sections
Remove heatsink/reector screws that attach to housing.
Set aside.
13 Remove Heatsink/Reector Screws
Remove heatsink/reector and hang over side of xture.
CAUTION: Do not apply excessive tension to wires!
14 Remove Heatsink/Reector
Carefully remove lens using suction cup or similar.
12 Remove Lens
Mount Canopy Bracket to J-Box using provided screws,
then secure Canopy over J-Box with nial. Attach bullet
(with cable) to canopy. CAUTION: Do not pinch wire
connections.
10BCombo Canopy Installation
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON WIRES while
installing canopy.
Mount Canopy Bracket to J-Box using provided screws,
then secure Canopy over J-Box with nial. CAUTION: Do
not pinch wire connections.
10AMount Canopy Bracket to J-Box & Secure Canopy
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON WIRES while
installing canopy.

LP2 Suspended Installation Guide 8 of 12 102-000026 - IG121818-A.0
Connect wiring quick-connects between sections. Match
each color, as shown. NOTE: Color combinations may
vary.
20 Connect Wiring Between Sections
Installation: Connecting Multiple
Sections (Cont.)
Loosen set screws and slide out joiner bracket halfway
to allow for joining. Join sections together, as shown,
ensuring correct alignment. See nal/record drawing for
more details. CAUTION: Do not pinch wires while joining!
15 Align and Join Sections Together
Tighten set screws to secure outer corner bracket to
joined section using a 1/8” hex key. Ensure each section
is properly aligned and that there are no gaps between
sections.
18 Tighten Set Screws on Outer Corner
Tighten joiner screws, as shown. Ensure each section is
properly aligned, and that there are no gaps between
sections.
19 Tighten Joiner Screws on Inner Corner
Tighten joiner set screws, as shown, using a 5/64” hex key
for the sides and a 1/8” hex key for the bottom. Ensure
each section is properly aligned, and that there are no
gaps between sections.
16 Tighten Joiner Set Screws
17 Mitered Corners: Join Sections
Join sections together, as shown, ensuring correct
alignment. See nal/record drawing for more details.
CAUTION: Do not pinch wires while joining!

LP2 Suspended Installation Guide LP2 Suspended Installation Guide 9 of 12 102-000026 - IG121818-A.0
Installation: Connecting Multiple
Sections (Cont.)
Re-install heatsink/reector screws to attach back to
housing.
22 Re-install Heatsink/Reector Screws
Install Diffuser Shim at each joined location to prevent
light leak between lens sections. Re-install at endcap
locations, as necessary.
23 Install Diffuser Shim
Re-install each heatsink/reector section. CAUTION: Do
not pinch wires while reattaching!
21 Re-install Heatsink/Reector
Carefully re-install lens, ensuring lens sits properly within
Lens Clips.
24 Re-install Lens
Ensure the lens is properly installed between the Lens
Clips.
25 Ensure Lens Sits Properly Between Lens Clips
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior to
installation or servicing.
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON
WIRES while joining sections or reattaching heatsink.

LP2 Suspended Installation Guide 10 of 12 102-000026 - IG121818-A.0
Troubleshooting
Full Fixture does not illuminate • Ensure all wire connections are made.
• Ensure xture is wired correctly and power is on.
• Check that circuit breaker is on and not off or tripped.
• LED driver may be defective.
Full xture is ickering • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.
• Possible loose low voltage DC + or - connection from driver to LED.
Call customer support.
Only a certied electrician can service and troubleshoot product eld issues. Always turn main power off
before servicing xture.
Fixture section(s) do not
illuminate
• Possible loose low voltage DC + or - connection between LED
boards or from LED driver to LED boards.
• Some xtures contain multiple LED drivers. In this case, it’s possible
one of the drivers is defective, which will cause the LED connected
to the driver not to illuminate. Call tech support.
Fixture section(s) are ickering • Possible loose low voltage DC + or - connection between LED
boards.
Fixture does not dim • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering. TEST.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.
