ALW LIGHTPLANE 9 User manual

A1035 22nd Avenue, Unit 1 nOakland, CA 94606 P510.489.2530 [e-mail] Walwusa.com
ILLUMINATE THE SOUL
INSTALLATION INSTRUCTIONS
LIGHTPLANE 9
LP9WE/LP9WH | Wall End, Wall Horizontal | LED

LP9 Wall Installation Guide 2 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
Safety & Warnings!
1. Read all instructions.
2. Install in accordance with national and local electrical code regulations.
3. This product is intended to be installed and serviced by a qualied, licensed electrician.
4. Only install with a compatible Class 2 LED Driver. This product has not been evaluated for use when
connected to an LED driver that does not comply with Class 2 voltage and energy limited supplies.
5. Do not install in wet locations. For dry and damp use only.
6. Turn off electrical power before installing or servicing xture in any way.
7. To reduce the risk of re and overheating, make sure all connections are tight.
1. Lisez toutes les instructions.
2. Installez conformément à la réglementation du code électrique national et local.
3. Ce produit est destiné à être installé et entretenu par un électricien agréé qualié.
4. Installez uniquement avec un pilote de classe 2 compatible. Ce produit n’a pas été évalué pour une
utilisation lorsqu’il est connecté à un pilote de DEL qui n’est pas conforme aux alimentations de classe
2 à tension et énergie limitées.
5. Ne pas installer à l’extérieur ou dans des endroits humides. Pour une utilisation en intérieur et sec
seulement.
6. Coupez l’alimentation électrique avant de évoluer le système d’éclairage en aucune façon.
7. Pour réduire le risque d’incendie et de surchauffe, assurez-vous que toutes les connexions sont bien
serrées.
Attention!
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior
to installation or servicing.

LP9 Wall Installation Guide LP9 Wall Installation Guide 3 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
Table of Contents
Troubleshooting 8
Wiring Diagrams 9
Installation 5
Prepare Wall 5
Standard Mounting 5
Luminaire Overview 4
Diagrams 4
Components 4
Parts (by others) 4
Tools Required 4
Quick Specs 4
Tie-Backs 6

LP9 Wall Installation Guide 4 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
LUMINAIRE OVERVIEW
Drill
#2 phillips bit
Tools Required
Wire strippers
Input Voltage / Frequency:
See product label
Rated Power:
See product drawing
Ambient Temperature:
-4° – 120°F (-20° – 50°C)
Environment:
Dry and damp locations
Quick Specs
STANDARD WALL MOUNT COMPONENTS
Wall FittingUniversal Adapter
Universal Adapter (Optional)
To Building Power
(High Voltage)
Framing/
Blocking
Fixture Body
Wood Screws, #8, 1.5” long
Parts (by others)
Conduit
J-BOX 4 (By Others)
4” Square or Octagonal
Junction Box
Wall Bullet Cable

LP9 Wall Installation Guide 5 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
LP9 Wall Installation Guide
Installation: Prepare Wall
WALL
See nal/record drawings for mounting locations. Install
framing or strut channels with consideration for alignment
of wiring and Wall mounting locations.
1See Final/Record Drawings for Mounting Locations
SAMPLE DRAWING
Raise entire xture to wall, and connect wiring. Refer to
page 9 and record drawing to make wiring connections.
CAUTION: High Voltage Wiring — Ensure Power is OFF prior
to connecting wiring.
6Raise Fixture to Wall & Connect Wiring
WALL
Install Canopy J-Box ((if using, by others) at power feed
location per nal/record drawing.
2Install Canopy J-Box
SAMPLE DRAWING
Prepare wiring into J-box. Refer to page and nal/
record drawing to make wiring connections. Strain relief
connection. Ensure Power is OFF prior to connecting
wiring.
4Prepare Wiring into J-Box
SHOCK HAZARD! May result in serious injury or death. Turn
power OFF at circuit breaker prior to installation or servicing.
3
1
/
2
”
Install Universal Adapter(provided) using appropriate
hardware screws (by others) to allow Fixture Mount on
Step 7. NOTE: Ensure Universal Adapter (holes) alignment
for Fixture, as shown.
5Install Universal Adapter (If Necessary)
Pushing wires connection into J-Box . Secure xture to wall
J-Box using provided 8-32 screws.
CAUTION: Do not pinch wires connections.
7Secure Fixture
Installation: Standard Mounting

LP9 Wall Installation Guide 6 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
Installation: Standard Mounting
(Cont.)
Turn breaker ON and check if xture operates as
intended and that there are no loose connections.
10 Turn Power On
Ensure Fixture is properly aligned and leveled.
8Fixture Alignment
Installation: Tie-Back Supports
Wall Fittings may be installed directly into framing with
appropriate hardware.
NOTE: Cables should be installed at a 45° angle.
11A Install Wall Fitting - Framing
45 °
Angle
Please see steps 11 through 16 for direction on Installing
Tie-Back Cable for Wall End-Mount.
NOTE: Tie back support installed at a 45° angle.
9Installing Tie-Backs for Wall End-Mount
Wall Fittings may also be mounted using toggle bolts.
11BInstall Wall Fitting - Toggle Bolts
Wall Fittings may also be mounted on 1/4”-20 Threaded
Rods.
11CInstall Wall Fitting - 1/4”-20 Threaded Rods

LP9 Wall Installation Guide LP9 Wall Installation Guide 7 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
Route Tie-Back Cable through Tie-Back Bullet. Ball end
should sit in Tie-Back Bullet. Screw Tie-Back Bullet to Wall
Fitting.
12 Route Tie-Back Cable and Attach to Wall
Insert Tie-Back Cable through Cable Grippers, as shown.
13 Insert Tie-Back Cable into Gripper
Adjust Tie-Back Cable until Fixture is level. Keep xture
supported while Adjusting. With xture level and support-
ed, cut excess cable extending from cable gripper.
14 Adjust Tie-Back Cable Length
Ensure Fixture is properly aligned and supported.
15 Fixture Alignment
Turn breaker ON and check if xture operates as
intended and that there are no loose connections.
16 Turn Power On
Installation: Tie-Back Supports (Cont.)
Adjust Down-Light aiming, parallel and perpendicular
direction are available, as shown.
17 Downlight direction.

LP9 Wall Installation Guide 8 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
Troubleshooting
Full Fixture does not illuminate • Ensure all wire connections are made.
• Ensure xture is wired correctly and power is on.
• Check that circuit breaker is on and not off or tripped.
• Class 2 LED driver may be defective.
Full xture is ickering • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.
• Possible loose low voltage DC + or - connection from driver to LED.
Call customer support.
Only a certied electrician can service and troubleshoot product eld issues. Always turn main power off
before servicing xture.
Fixture section(s) do not
illuminate
• Possible loose low voltage DC + or - connection between LED
boards or from LED driver to LED boards.
• Some xtures contain multiple LED drivers. In this case, it’s possible
one of the drivers is defective, which will cause the LED connected
to the driver not to illuminate. Call tech support.
Fixture section(s) are ickering • Possible loose low voltage DC + or - connection between LED
boards.
Fixture does not dim • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering. TEST.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.

LP9 Wall Installation Guide 9 of 9 102-000028 - IG090320-A.0
ILLUMINATE THE SOUL
LP9 Wall Installation Guide
Wiring Diagrams
(Colors and driver quantity may vary, consult Final/Record Drawing for more details)
Black
White
Green
Ground
Line Voltage (Hot)
Line Voltage (Neutral)
L
N
AC 50/60Hz
Traditional On/Off
Black
White
Green
Grey
Purple
Hot
Neutral
Ground
Dimming -
Dimming +
Line Voltage
Line Voltage
Ground
0-10V DC
0-10V DC
L
N
AC 50/60Hz
DIM-
DIM+
0-10V Dimming
Black
White
Green
Clear
Black
DMX in shield
DMX in -
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
L
N
AC 50/60Hz
DMX In Shield
DMX in -
Red
DMX in +
DMX in +
Clear
Black
DMX out shield
DMX out -
White
DMX out +
DMX Out Shield
DMX out -
DMX out +
DMX
Black
White
Green
Purple
Grey
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
Dali +
Dali -
L
N
AC 50/60Hz
DALI +
DALI -
DALI
Black
White
Green
Purple
Grey
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
E1
E2
L
N
AC 50/60Hz
E1
E2
Lutron Ecosys
