ALW LIGHTPLANE 9 User manual

A1035 22nd Avenue, Unit 1 nOakland, CA 94606 P510.489.2530 [e-mail] Walwusa.com
ILLUMINATE THE SOUL
INSTALLATION INSTRUCTIONS
LIGHTPLANE 9
LP9 | Suspended | LED

LP9 Suspended Installation Guide 2 of 11 102-000026 - IG090320-A.0
Safety & Warnings!
1. Read all instructions.
2. Install in accordance with national and local electrical code regulations.
3. This product is intended to be installed and serviced by a qualied, licensed electrician.
4. Turn off electrical power before installing or servicing xture in any way.
5. Do not install in wet locations. For dry and damp use only.
6. Turn off electrical power before installing or servicing xture in any way.
7. To reduce the risk of re and overheating, make sure all connections are tight.
8. This product is suitable for continuous row mounting.
1. Lisez toutes les instructions.
2. Installez conformément à la réglementation du code électrique national et local.
3. Ce produit est destiné à être installé et entretenu par un électricien agréé qualié.
4. Coupez l’alimentation électrique avant d’installer ou de réparer le luminaire de quelque manière que
ce soit.
5. Ne pas installer à l’extérieur ou dans des endroits humides. Pour une utilisation en intérieur et sec
seulement.
6. Coupez l’alimentation électrique avant de évoluer le système d’éclairage en aucune façon.
7. Pour réduire le risque d’incendie et de surchauffe, assurez-vous que toutes les connexions sont bien
serrées.
8. Ce produit convient au montage en ligne continue.
Attention!
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior
to installation or servicing.

LP9 Suspended Installation Guide LP9 Suspended Installation Guide 3 of 11 102-000026 - IG090320-A.0
Table of Contents
Troubleshooting 9
Wiring Diagrams 10
Installation 5
Prepare Ceiling 5
Standard Suspension 5
Connecting Multiple Sections 7
Luminaire Overview 4
Diagrams 4
Components 4
Parts (by others) 4
Tools Required 4
Quick Specs 4

LP9 Suspended Installation Guide 4 of 11 102-000026 - IG090320-A.0
Luminaire Overview
Drill
#2 phillips bit
Tools Required
Wire strippers
Input Voltage / Frequency:
See product label
Rated Power:
See product drawing
Ambient Temperature:
-4° – 120°F (-20° – 50°C)
Environment:
Dry and damp locations
Quick Specs
STANDARD SUSPENSION COMPONENTS
Suspension BulletCanopy Assembly Suspension Cable Ceiling Fitting
J-Box 4x4
Ceiling Fitting /
Suspension Bullet
To Building Power
Canopy
Power Cord
Suspension Cables
Cable Gripper
Fixture Body
Junction Box 4x4(Optional)
Parts (by others)
Wood Screws, #10, 1.5”
long
Conduit/NM (non-metallic)
cable (or similar) if not using
J-Box
5/64” Hex Key (for Joining)

LP9 Suspended Installation Guide 5 of 11 102-000026 - IG090320-A.0LP9 Suspended Installation Guide
Ceiling Fittings may also be mounted using toggle bolts.
3BInstall Ceiling Fitting - Toggle Bolts
Ceiling Fittings may also be mounted on 1/4”-20
Threaded Rods.
3CInstall Ceiling Fitting - 1/4”-20 Threaded Rods
Installation: Prepare Ceiling Installation: Standard Suspension
Ceiling Fittings may be installed directly into framing with
appropriate hardware.
3AInstall Ceiling Fitting - Framing
C
See nal/record drawings for mounting locations. Install
framing or strut channels with consideration for alignment
of wiring and suspension mounting locations.
1See Final/Record Drawings for Mounting Locations
SAMPLE DRAWING
C
Install Canopy J-Box at power feed location per nal/
record drawing. Otherwise run conduit/NM cable to
powerfeed location.
2Install Canopy J-Box
SAMPLE DRAWING
SHOCK HAZARD! May result in serious injury or
death. Turn power OFF at circuit breaker prior to
installation or servicing.
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON
WIRES while joining sections or reattaching heatsink.

LP9 Suspended Installation Guide 6 of 11 102-000026 - IG090320-A.0
Bring wiring and canopy assembly to J-box. Refer to page
10 and nal/record drawing to make wiring connections.
CAUTION: High Voltage Wire —Ensure Power is OFF prior
to connecting wiring.
9Connect High Voltage Wiring
Route Suspension Cable through Suspension Bullet. Ball
end should sit in Suspension Bullet. Screw Suspension Bullet
to Ceiling Fitting.
4Route Suspension Cable and Attach to Ceiling
Installation: Standard Suspension
(Cont.)
6"
Use wire snips or shears to cut Suspension Cables to
desired length. Keep an extra 6 inches of cable for
adjustments.
5Cut Suspension Cables to Desired Length 8Adjust Suspension Cable Length
Adjust xture until it is level and at desired height. Depress
top of Cable Gripper to lower xture. Keep xture
supported while lowering. With xture level and at desired
height, cut excess cable extending from cable gripper.
Raise xture to Suspension Cables, and attach xture by
inserting Suspension Cable through Cable Grippers.
7Raise Fixture to Suspension Cables
6Connecting Multiple Sections (If Necessary)
Please see steps 12 through 20 for directions on
connecting multiple sections. See nal/ record drawing
for more details. Join sections as noted (AA-AA, BB-BB,
etc.)
SHOCK HAZARD! May result in serious injury or death. Turn
power OFF at circuit breaker prior to installation or servicing.

LP9 Suspended Installation Guide LP9 Suspended Installation Guide 7 of 11 102-000026 - IG090320-A.0
Installation: Standard Suspension
(Cont.)
Turn breaker ON and check if xture operates as
intended and that there are no loose connections.
11 Turn Power On
Installation: Connecting Multiple
Sections
Carefully remove metal cover to expose joiner sections.
12 Remove Cover
Mount Canopy Bracket to J-Box using appropriate
mounting hardware, then secure Canopy over J-Box with
Ceiling Fitting using 1/8” Allen Key. Attach bullet (with ca-
ble) to canopy. CAUTION: Do not pinch wire connections.
10BCombo Canopy Installation
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON WIRES while
installing canopy.
Mount Canopy Bracket to J-Box using appropriate
mounting hardware, then secure Canopy over J-Box with
nial. CAUTION: Do not pinch wire connections.
10AMount Canopy Bracket to J-Box & Secure Canopy
!
DO NOT PINCH OR PUT EXCESSIVE TENSION ON WIRES while
installing canopy.
Loosen set screws on Joining Bar and extend, as shown.
13 Extend Joining Bar
Loosen set screws and slide out joiner bracket halfway
to allow for joining. Join sections together, as shown,
ensuring correct alignment. See nal/record drawing for
more details. CAUTION: Do not pinch wires while joining!
14 Align and Join Sections Together

LP9 Suspended Installation Guide 8 of 11 102-000026 - IG090320-A.0
Installation: Connecting Multiple
Sections (Cont.)
Tighten joiner screws, as shown, using a 1/8” Hex Key.
Ensure each section is properly aligned, and that there
are no gaps between sections
17 Mitered Corners: Tighten Joiner Screws
Align sections and join, as shown. CAUTION: Take care not
to pinch wires.
16 Mitered Corners: Align & Join Sections
Re-install each metal cover. CAUTION: Do not pinch wires
while reattaching!
19 Re-install Cover
Tighten joiner screws, as shown, using a 5/64” Hex Key.
Ensure each section is properly aligned, and that there
are no gaps between sections..
15 Tighten Joiner Screws
Adjust Down-Light aiming, parallel and perpendicular
direction are available, as shown.
20 Downlight direction.
Connect wiring quick-connects between sections. Match
each color, as shown. NOTE: Color combinations may
vary.
18 Connect Wiring Between Sections
SHOCK HAZARD! May result in serious injury or death. Turn
power OFF at circuit breaker prior to installation or servicing.

LP9 Suspended Installation Guide 9 of 11 102-000026 - IG090320-A.0
Troubleshooting
Full Fixture does not illuminate • Ensure all wire connections are made.
• Ensure xture is wired correctly and power is on.
• Check that circuit breaker is on and not off or tripped.
• LED driver may be defective.
Full xture is ickering • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.
• Possible loose low voltage DC + or - connection from driver to LED.
Call customer support.
Only a certied electrician can service and troubleshoot product eld issues. Always turn main power off
before servicing xture.
Fixture section(s) do not
illuminate
• Possible loose low voltage DC + or - connection between LED
boards or from LED driver to LED boards.
• Some xtures contain multiple LED drivers. In this case, it’s possible
one of the drivers is defective, which will cause the LED connected
to the driver not to illuminate. Call tech support.
Fixture section(s) are ickering • Possible loose low voltage DC + or - connection between LED
boards.
Fixture does not dim • 0-10V, DMX, and DALI Dimming Models: Ensure polarity is
correct for DATA + and - connections. Swapping DATA + and -
connections can cause ickering. TEST.
• TRIAC Dimming Models: Ensure a compatible TRIAC Forward
Phase dimmer is connected to xture. Call tech support for further
information.
• Possible loose DATA + and - connections from xture to 0-10V,
DMX, or DALI control.

LP9 Suspended Installation Guide 10 of 11 102-000026 - IG090320-A.0
LP9 Suspended Installation Guide
Wiring Diagrams
Black
White
Green
Ground
Line Voltage (Hot)
Line Voltage (Neutral)
L
N
AC 50/60Hz
Traditional On/Off
Black
White
Green
Blue
Red
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
0-10VDC (Dim-)
0-10VDC (Dim+)
L
N
AC 50/60Hz
DIM-
DIM+
0-10V Dimming
Black
White
Green
Clear
Black
DMX in shield
DMX in -
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
L
N
AC 50/60Hz
DMX In Shield
DMX in -
Red
DMX in +
DMX in +
Clear
Black
DMX out shield
DMX out -
White
DMX out +
DMX Out Shield
DMX out -
DMX out +
DMX
Canopy/Power Feed
Canopy/Power Feed
Canopy/Power Feed

LP9 Suspended Installation Guide 11 of 11 102-000026 - IG090320-A.0
Wiring Diagrams (Cont.)
Black
White
Green
Blue
Red
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
Dali -
Dali +
L
N
AC 50/60Hz
DALI -
DALI +
DALI
Canopy/Power Feed
Black
White
Green
Red
Blue
Line Voltage (Hot)
Line Voltage (Neutral)
Ground
E1
E2
L
N
AC 50/60Hz
E1
E2
Lutron LDE
Canopy/Power Feed
