Amart Furniture SENTINAL MK2 CNR3C2wC User manual


ImportedbyAmartFurniturePtyLtd,Qld,BrisbaneAustralia.
Foranyassistancewithassemblyorformissingpartspleasephone
AmartFurniture,CustomerServiceFreecall1800351084
ASSEMBLYINSTRUCTION
SENTINALMK2CNR3C2wC
ITEMCODE77425
ImportedbyAmartFurniturePtyLtd,Qld,BrisbaneAustralia.
Foranyassistancewithassemblyorformissingpartspleasephone
AmartFurniture,CustomerServiceFreecall1800351084
1
106cm
304cm
327cm

PRE‐ASSEMBLYPREPARATION
Beforeyoustart:
1. Chooseaclean,level,spaciousassemblyarea.Avoidhardsurfacesthatmay
damagetheproduct
2. Takecarewhenlifting.Productshouldbeassembledasnearaspossibleto
thepointofuse
3. Ensurethatyouhaveallrequiredcontentsforcompleteassembly
4. Alwaysreadtheassemblyinstructionscarefullybeforebeginningassembly.
5. Keepallhardwarepartsandpackagingoutofreachofsmallchildren.
6. Donotovertightenthescrewsandboltsasthismaydamagethethreads
40
2
2
WARNING
DoNotallowchildrentoplayonthismechanisedfurniture
oroperatethemechanism.Legrestfoldsdownonclosing
sothatachildcouldpossiblybeinjured.Alwaysleaveinan
uprightandclosedposition.Keephandsandfeetclearof
mechanism.Onlytheoccupantshouldoperateit.

Step1:Locatethelefthandfacingreclinerpowerpackwhichisfixedon
themechanismatthebottomoftherecliner.
Step2:Slidereceiversintosteelmechanismpostsatseatoftheleft
handfacingrecliner,andpressbothsidesofthebackfirmlyintoplace
toensurefullylocked.
3
Transformercable
1pcs
Transformer Powercable
1pcs
1pcs
PowerPartsConnection
Transformer
PowerPack
Transformercable
Powercable
Receiveratbottom
ofbackrest
slidereceiver
intopost
Mechanismpost
atrearofseat

Step3:Connectthecords‘A’and‘B’forpowerconnection
betweenheadrestandseat.Onecordcomesfromthebackand
theotherfromtheseatoflefthandfacingrecliner.
Step4:Slidereceiversintosteelmechanismpostsatseatofthe
righthandfacingchair,andpressbothsidesofthebackfirmly
intoplacetoensurefullylocked.
4
A
B
slidereceiver
intopost
Receiveratbottom
ofbackrest
Mechanismpost
atrearofseat

Step5:Locatereadinglightpowercablewhichisattachedtothe
mechanismpostofthearmlesschair.Keepthepowercabletothe
side.Thenunravelthecable‘E’withaplugontheendofit.The
cableisfromthearmlesschairbackthatneedbepluggedintoa
wallsockettoconnectpowerforchargestationonthedrop‐down
console.
Step6:Slidereceiversintosteelmechanismpostsatseatofthe
armlesschair,andpressbothsidesofthebackfirmlyintoplaceto
ensurefullylocked.
5
E
Receiveratbottom
ofbackrest
slidereceiver
intopost
Mechanismpost
atrearofseat
ReadingLightPowerCable

1pcs
ReadingLight
PowerCable
ChargeStation
PowerCable

Step7:Connectthecords‘C’and‘D’(below)inthearmlesschairto
connectpowerforreadinglights.Onecordcomesfromtheback
andtheotherfromtheseat.
Step8:Locatetherighthandfacingreclinerpowerpackwhichis
fixedonthemechanismatthebottomoftherecliner.
6
C
D
PowerPartsConnection
Transformer
PowerPack
Transformercable
Powercable
Transformercable
1pcs
Transformer Powercable
1pcs
1pcs

Step9:Slidereceiversintosteelmechanismpostsatseatofthe
righthandfacingrecliner,andpressbothsidesofthebackfirmly
intoplacetoensurefullylocked.
Step10:Connectthecords‘A’and‘B’forpowerconnection
betweenheadrestandseat.Onecordcomesfromthebackandthe
otherfromtheseatofrighthandfacingrecliner.
7
slidereceiver
intopost
Receiveratbottom
ofbackrest
Mechanismpost
atrearofseat
A
B

Step11:Slidereceiversintosteelmechanismpostsatseatofthe
lefthandfacingchair,andpressbothsidesofthebackfirmlyinto
placetoensurefullylocked.
Step12:Locatetheknockdownconsolebackandfittingsthatare
placedinsidethezipperpocketonthebottomofconsole.
8
Receiveratbottom
ofbackrest
slidereceiver
intopost
Mechanismpost
atrearofseat
pocket
Consoleback
2pcs
Bolt Nut
2pcs
1pcs

Step13:Screwtheshortendsoftheboltsintotheholesonthe
bottomofconsoleback.
Step14:Poketheconsolebackintoholesontherearofconsoleand
thenfixthebackbytwonutsscrewedinsidetheconsole.
9

Step15:LocateandremovetheWedgeSofaFeetandSoundPowerCable
fromthezipperpocketunderneaththeWedgebase.Keepthepowercableto
theside.
Step16:Securethe6xplasticfeetprovidedtothebottomofthewedgepiece,
turninginclockwisedirectiontotighten.
10
With2people,
carefullyturn
loungeontobackofa
pieceofcardboard
orcarpettoprotect
covering
PlasticFoot

6pcs
Turntheplastic
roundfeet
clockwiseto
tighten
pocket
SoundPowerCable
1pcs

Step17:Removeprotectivepackagingfromthewedgeback
packagedwithfittingsindividually.Thenscrewtheshortendsofthe
boltsintotheholesonthebottomofwedgeback.
Step18:Pokethewedgebackintoholesontherearofwedgebase
andthenfixthebackbyfournutsscrewedinsidethewedgebase.
11
WedgeBack
1pcs 4pcs
Bolt Nut
4pcs

Step19:Connectthecordsoftwospeakersbeingoutfromthe
wedgebackwithcordswhichareoutfromthehubboxinsidethe
wedgebase.
Step20:Connectthe3Seaterand2Seaterwithconsolerespectivelyfrom
righttoleft.For3Seater,beginwiththerighthandfacingchair,thenarmless
chair,thenlefthandfacingrecliner.Andfor2Seater,beginwiththeright
handfacingrecliner,thenconsole,thenlefthandfacingchair.Slidethebase
clipstogetherthenpressthefrontandrearsidestoensuretheclipsare
connectedallthewaytothebottom.
12

Step21:Unfoldconnectionclipstopokeoutfrombottomoftheleft
handfacingchairandplaceslidewaypartsatbottomofwedgeinto
theclips.Then,unfoldconnectionclipstopokeoutfrombottomof
thewedgeandplaceslidewaypartsatbottomofrighthandfacing
chairintotheclips.
Step22:Attherearandbaseoflounge,connectthecordsforthe
lightstripbetweeneachpieceof3Seater,2Seaterwithconsoleand
Wedge.
13
SlidewayParts
atwedge
ConnectionClipsatleft
handfacingchair
SlidewayParts
atrighthand
facingchair
ConnectionClips
atwedge
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAROF
THEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVERYOUR
POWERCORDRESULTINGINSERIOUSINJURYORDEATH.

Step23:Plugthelefthandfacingreclinerpowercableintothebacksocket
ofthelefthandfacingrecliner.
Step24:Plugtherighthandfacingreclinerpowercableintothebacksocket
oftherighthandfacingrecliner.
14
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.

Step25:Plugthereadinglightpowercableintothebacksocketofthe
armleeschair.
Step26:Plugthesoundpowercableintothebacksocketofthewedge.
15
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.

Step27:Plugallpowercablesintopowersource/wall.Theleftrecliner
powercable,rightreclinerpowercable,readinglightpowercable,
chargestationpowercableandsoundpowercable.
16
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM.AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.

READTHESEINSTRUCTIONSTHOROUGHLYBEFOREUSE:
DANGER:TOREDUCETHERISKOFELECTRICSHOCK:
Alwaysunplugfromelectricoutletbeforecleaning.
WARNING:RISKOFINJURY
Keepchildrenawayfromextendedfootrestandanymovingparts.
CAUTION:
•Donotallowchildrentoplayonthiselectricreclineroroperatethepoweredmechanism.
Thelegrestfoldswhenclosingandcouldpossiblycauseinjurytoachild.Alwaysleavethe
reclinerinanuprightandclosedpositionwhennotinuse.Keephandsandfeetclearof
mechanism.Onlytheoccupantshouldoperateit.
•Doensurefullyenterthenormalsittingpositionbeforeusingoftherecliner.Improper
sitting,suchassittinginthefrontofreclinermayresultindamagetobothmechanismand
motordrivebar.
POWERCORDSAFETY
WARNING:Unplugandremovepowercordfromwallwhennotinuseandstoreoutofreach
ofchildren.
Takecarewhenmovingreclinerthatwallandtransformercordsarenotunderthebaseor
theymaygetdamaged.
‐NEVEROPERATEELECTRICRECLINERIFITHASADAMAGEDCORDORPLUG.
WARNING:TOREDUCERISKOFBURNS,FIRE,ELECTRICSHOCKORPERSONALINJURYTO
PERSONS:
•Useonlyforitsintendedpurpose
•Neverpressoractivatecontrolswitchifyouarenotseatedinrecliner
•Onlytheoccupantshouldactivatethecontrolswitch
•Neveroperatewithmorethanonepersonoccupyingseat
•Neversitorstandonthefootrest
17
YES NO

18

SpeakerControlPanelManual
Bluetooth
•BluetoothName:Cassius
•HowtoConnect:
1) Holddownthepowerbuttonfor3seconds.
2) Whenthebluelight(BT)startsflashing,connectyourdevice.Ensureyourdevice
iswithinrange.
3) Oncesuccessfullyconnectedthebluelight(BT)willstaylit.
SpeakerControlPanel
•Howtouse:
1) Holdthepowerbuttonfor3secondstoturnon/off.
2) Pressthe“replay”and“skip”buttonstonavigate.
3) Pressthe“+volume”and“‐volume”buttonstocontrolthesound.
WirelessCharge:
•Howtouse:
1) Placethedeviceinthecenteroftheredwirelesschargingpanel.Whenthegreen
lightison,wirelesschargeissuccessfullyinoperation.
NOTE:
•Toindicatethattheconsoleisconnectedtopower,theredlight(power)willstaylit.
•Whenthephoneispairedandyoureceiveacallortext,thesoundwillpause.
•ThespeakerswillonlyworkthroughBluetoothconnection,notUSBorWireless
connection.
SpeakerInstruction:
+Volume
‐Volume
Replay
Skip
USBPort
WirelessCharger
Power/Play/Pause
USBPort
19

SpeakerSpecifications
•Reproductionsystem
•Woofer∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙φ104mm
Magnet:370g
•Tweeter∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙φ78mm
•Nominalimpedance∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6Ω‐4Ω‐4Ω
•Sensitivity∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙92±3dB82±3dB
•Frequencyresponse∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙F0～10KHZF0‐12KHz
•Nominalpower∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙20W
•Maximummusicpower∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙32W
•Grillematerial∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙Steelnet,ABS
•Weight(perspeakerincludingaccessoryparts)∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1377g/198g
•Grossweight(2speakersincludingpackaging)∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1774g
IMPORTANTINFORMATION
•DONOTplaythespeakersformorethan6hourscontinuously.
Indoingsomaycausedamagetoyourspeakers.
20
