American Dryer Corp. ML-122 User manual

ML-122
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: [phone] / Fax: [phone]
E-mail: [e-mail]
ADC Part No. 450411
070599DMG/cms
Parts Manual

Retain This Manual In ASafe Place For Future Reference
American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is
properly maintained, it will provide many years of safe, efficient, and trouble-free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make
changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or
discontinue models.
Important
For your convenience, log the following information:
DATE OF PURCHASE ____________________________ MODEL NO. __________________________________________
RESELLER’S NAME _______________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory,
you can FAX your order to ADC at [phone] or telephone your order directly to the ADC Parts Department at
[phone]. Please specify the dryer model number and serial number in addition to the description and part number, so
that your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are a composite of the
various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
ML-122
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the instructions
to be followed if the user smells gas. These instructions must be posted in a
prominent location near the dryer.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de yout autre appareil.

Table of Contents
Control DoorAssembly ....................................................................................................................................... 2
Phase 6 Microprocessor Panel Assembly ........................................................................................................... 3
Wrapper Assembly............................................................................................................................................... 4
Front Panel Assembly .......................................................................................................................................... 5
Front Panel Assembly Polymark Option .............................................................................................................. 6
CRS Door Assembly............................................................................................................................................ 7
Main Door Switch Assembly ............................................................................................................................... 8
Lint Screen Assembly .......................................................................................................................................... 9
Microprocessor Temperature Sensor Bracket................................................................................................... 10
Motorized ImpellorAssembly ............................................................................................................................ 11
Tumbler (Basket) Assembly .............................................................................................................................. 12
Tumbler (Basket) Bearing Assembly ................................................................................................................. 13
Drive Wheel Assembly ...................................................................................................................................... 14
Idler Wheel Assembly ........................................................................................................................................ 15
Drive Motor Assembly ....................................................................................................................................... 16
Direct Spark Ignition (DSI) Burner Assembly............................................................................................. 17, 18
Hot Surface Ignition (HSI) Burner Assembly ............................................................................................. 19, 20
Sail Switch Assembly ......................................................................................................................................... 21
Pneumatic Valve Assembly ............................................................................................................................... 22
Steam Damper Assembly ............................................................................................................................ 23, 24
Reversing Relay Panel Assembly
For 60 Hz Model ONLY .................................................................................................................... 25, 26
Reversing Relay Panel Assembly
For 50 Hz Model ONLY .................................................................................................................... 27, 28
Polymark Reversing Relay Panel Assembly
For 50 Hz Model ONLY .................................................................................................................... 29, 30
Air Jet Assembly................................................................................................................................................ 31
Exhaust Adapter ................................................................................................................................................ 32

2
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Control Door Assembly
Illus. No. Part No. Qty. Description
1882277 1White Control Door Assembly Gas Models ONLY
882278 1Cornflower Blue Control Door Assembly Gas Models ONLY
882279 1Coral Blue Control Door Assembly Gas Models ONLY
882280 1White Control Door Assembly Steam Models ONLY
882281 1Cornflower Blue Control Door Assembly Steam Models ONLY
882282 1Coral Blue Control Door Assembly Steam Models ONLY
2112368 1Logo ONLY
3882541 2Spring Turn Latch (2-piece)
4117603 5Noise Suppressor Tape (sold by the foot)
5150309 9#10-16 x 1/2” Hex Head TEK Crimptite Screw
6102603 1Control Door Rod Catch
7102601 1Control Door Retainer Clip
8102505 1Control Door Support Rod

3
Telephone: [phone] Fax: [phone]
Phase 6 Microprocessor Panel Assembly
Illus. No. Part No. Qty. Description
1112537 1Phase 6 OPL Keyboard
112276 1OPL Stick-On Labels
(English Only) ... Not Illustrated
112275 1OPL Stick-On Labels
(Spanish, Italian, and Hebrew) ... Not Illustrated
112277 13 Language OPL Stick-On Labels
(English, Spanish, and Hebrew) ... Not Illustrated
112278 15 Language OPL Stick-On Labels
(Italian, Dutch, French, German, and Chinese) ... Not Illustrated
2842878 1Phase 6 Microprocessor Controller (computer) Panel Only
3137124 1Phase 6 Reversing Microprocessor Controller (computer) with Air Jet
4150005 3#6-32 x 3/4” Phillips Round Head Machine Screw
5153010 3#6 Star Washer
6136048 11/8-Amp (slo blo) Fuse
7136017 13.5-Amp (fast acting) Fuse
8136019 11-Amp (fast acting) Fuse

4
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty. Description
1150309 20 #10-16 x 1/2” Hex Head TEK Crimptite Screw
2859367 1Bottom Right Wrapper
3--------- 1Drive Shaft Assembly
(refer to Drive Wheel Assembly on page 14)
4--------- 1Temperature Sensor Bracket
(refer to Microprocessor Temperature Sensor Bracket on page 10)
5859368 1Bottom Left Wrapper
6--------- 1Idler Shaft Assembly
(refer to Idler Wheel Assembly on page 15)
7122116 124 VAC Lint Door Switch
WrapperAssembly

5
Telephone: [phone] Fax: [phone]
Front Panel Assembly
Illus. No. Part No. Qty. Description
1-------- 1CRS Main Door Assembly
(refer to CRS Door Assembly on page 7)
2150443 2Socket Cap Screw
3881441 1White Bottom Hinge Block
882306 1Cornflower Blue Bottom Hinge Block
882283 1Coral Blue Bottom Hinge Block
4153031 1Nylon Washer
5150443 2Socket Cap Screw
6881440 1White Top Hinge Block
882307 1Cornflower Blue Top Hinge Block
882284 1Coral Blue Top Hinge Block
7882285 1White Front Panel Assembly
882286 1Cornflower Blue Front Panel Assembly
882287 1Coral Blue Front Panel Assembly
882288 1White Front Panel Assembly Complete
(includes illus. nos. 2 through 11)
882289 1Cornflower Blue Front Panel Assembly Complete
(includes illus. nos. 2 through 11)
882290 1Coral Blue Front Panel Assembly Complete
(includes illus. nos. 2 through 11)
8-------- 1Main Door Switch Assembly
(refer to Main Door Switch Assembly on page 8)
9150201 210-32 x 1/4” Phillips Pan Head Tap Zinc
10 170330 1Friction Door Latch
11 154215 25/32”Rivet

6
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Front Panel Assembly Polymark Option
Illus. No. Part No. Qty. Description
1-------- 1CRS Main Door Assembly
(refer to CRS Door Assembly on page 7)
2150443 2Socket Cap Screw
3881441 1White Bottom Hinge Block
882306 1Cornflower Blue Bottom Hinge Block
882283 1Coral Blue Bottom Hinge Block
4153031 1Nylon Washer
5150443 2Socket Cap Screw
6881440 1White Top Hinge Block
882307 1Cornflower Blue Top Hinge Block
882284 1Coral Blue Top Hinge Block
7882452 1White Front Panel Assembly
882453 1Cornflower Blue Front Panel Assembly
882454 1Coral Blue Front Panel Assembly
882455 1White Front Panel Assembly Complete
(includes illus. nos. 2 through 15)
882456 1Cornflower Blue Front Panel Assembly Complete
(includes illus. nos. 2 through 15)
882457 1Coral Blue Front Panel Assembly Complete
(includes illus. nos. 2 through 15)
8-------- 1Main Door Switch Assembly
(refer to Main Door Switch Assembly on page 8)
9150201 210-32 x 1/4” Phillips Pan Head Tap Zinc
10 170330 1Friction Door Latch
11 154215 25/32”Rivet
12 122351 1“Emergency Stop” Push/Pull Button
13 122419 1“Emergency Stop” Nameplate
14 132395 1N.C. Contact Block w/Base
15 132387 1N.C. Contact Block

7
Telephone: [phone] Fax: [phone]
CRS Door Assembly
Illus. No. Part No. Qty. Description
1881689 1White CRS Main Door Assembly
(includes illus. nos. 2 through 10)
882308 1Cornflower Blue CRS Main Door Assembly
(includes illus nos. 2 through 10)
882292 1Coral Blue CRS Main Door Assembly
(includes illus. nos. 2 through 10)
881684 1White CRS Main Door Ring
882309 1Cornflower Blue CRS Main Door Ring
882305 1Coral Blue CRS Main Door Ring
2102214 130” Door Glass
170730 1Door Glass Adhesive (10.3 oz. cartridge)
3881685 1White Main Door Hinge
882310 1Cornflower Blue Main Door Hinge
882296 1Coral Blue Main Door Hinge
4881740 61/4-20 x 5/8” White Carriage Bolt
882311 61/4-20 x 5/8” Cornflower Blue Carriage Bolt
882294 61/4-20 x 5/8” Coral Blue Carriage Bolt
5881688 1White Main Door Handle
882312 1Cornflower Blue Main Door Handle
882295 1Coral Blue Main Door Handle
6881806 61/4-20 White Free Spin Wash Nut
882313 61/4-20 Cornflower Blue Free Spin Wash Nut
882293 61/4-20 Coral Blue Free Spin Wash Nut
7152008 1#10-32 Hex Nut
8150120 1Door Latch Screw
9882411 1Door Gasket
10 151012 4#10-32 White Nylon Acorn Nut

8
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Main Door Switch Assembly
Illus. No. Part No. Qty. Description
1150006 2#6-32 x 7/8” Phillips Pan Head Machine Screw
2152013 2#6-32 Hex Nut
3153010 2#6 Star Washer
4137005 1Door Switch
5881702 1White Main Door Switch Housing Assembly
(includes illus. nos. 1 through 5)
882314 1Cornflower Blue Main Door Switch housing Assembly
(includes illus. nos. 1 through 5)
882298 1Coral Blue Main Door Switch housing Assembly
(includes illus. nos. 1 through 5)
881687 1White Main Door Switch Housing ONLY
882315 1Cornflower Blue Main Door Switch Housing ONLY
882291 1Coral Blue Main Door Switch Housing ONLY
6150201 210-32 x 1/4” Phillips Pan Head Tap Zinc
