American Dryer Phase 7 AD-360X2RD User manual

American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: [phone] / Fax: [phone]
E-mail: [e-mail]
www.amdry.com
AD-360X2RD
Phase 7
Parts Manual
081803MGOLDSTEIN/tcosta ADC Part No. 450248

Retain This Manual In A Safe Place For Future Reference
American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is
properly maintained, it will provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following FOR YOUR SAFETY caution must e posted near the dryer in a prominent location.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make
changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or
discontinue models.
Important
For your convenience, log the following information:
DATE OF PURCHASE ____________________________ MODEL NO. __________________________________________
RESELLERS NAME _______________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory,
you can FAX your order to ADC at (508 678-9447 or telephone your order directly to the ADC Parts Department at (508
678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that
your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer e actly. The illustrations are a composite of the
various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
IMPORTANT NOTE TO PURCHASER
Information m st be obtained from your local gas supplier on the instructions
to be followed if the user smells gas. These instructions m st be posted in a
prominent location near the dryer.
FOR YOUR SAF TY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
POUR VOTR SÉCURITÉ
Ne pas entreposer ni utiliser dessence
ni dautres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
AD-360X2RD Phase 7

Parts Reference Diagram

Front Panel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Coin Computer Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Coin Vault Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Coin Panel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Main Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Main Door Switch Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Basket (Tumbler)/Support Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Top Locking Lint Basket Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Bottom Locking Lint Basket Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Separator Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Rotational Sensor/Sail Switch and Teflon® Backup Washer Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Lint Coop and Adjustment Wheel Bracket Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Left Rear Wheel Bracket (3 Bolt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Right Rear Wheel Bracket (3 Bolt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Microprocessor Temperature Sensor Bracket Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Top Burner Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18, 19
Bottom Burner Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 21
Blower Motor Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Top Rear lectrical Panel 120v 1ø 50/60 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Bottom Rear lectrical Panel 120-240v 1ø 50/60 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Drive Motor/Motor Mount Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Upper xhaust Duct Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Lower xhaust Duct Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Rear Back Guard Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Wrapper Assembly and Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
S.A.F. . System Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table of Contents

3
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 883945 1 White Front Panel Assem ly
(includes illus. nos. 1, 8, and 9)
883946 1 Bisque Front Panel Assem ly
(includes illus. nos. 1, 8, and 9)
2 150517 10 #10-16 x 1-1/4 Hex Head TEK Screw
3 800453 2 Main Door Switch Assem ly
4 150311 2 #10-16 x 3/4 TEK Screw
5 854117 1 Kick Plate
6 150311 2 #10-16 x 3/4 Head TEK Screw
7 150309 8 #10-16 x 1/2 Hex Head TEK Screw
8 881987 2 Friction Door Latch Kit
(includes illus. nos. 8 and 9)
9 154215 4 5/32 x 1/4 Rivet
10 102317 10 Foam Block
11 116329 1 Upper Front Panel Insulation
12 116330 1 Lower Front Panel Insulation
Front Panel Assembly

4
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty.Description
1 112583 1 Phase 7 Coin Key oard (touch pad)
2 117603 1 1/8 x 9/16 Noise Suppression Tape
3 152001 1 #8-32 x 3/8 Hex Nut
4 153010 6 #6 External and Internal Star Washer
5 360161 1 Control Panel Support Bracket
6 153012 1 #8 Internal Star Washer
7 150001 6 #6-32 x 1/2 Phillips Round Head Machine Screw
8 354227 1 Computer Cover
9 137260 1 Phase 7 Dual Coin Board with S.A.F.E.
10 182621 1 Computer Panel Lock Assem ly
11 860071 1 Phase 7 Control Panel
12 860025 1 Control Lock Base Assem ly
Coin Computer Panel

5
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 860022 1 Coin Vault
Coin Vault Assembly

6
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty.Description
1 182621 1 Computer Panel Lock Assem ly
2 803612 1 Hanke 25¢ U.S. Coin Acceptor Assem ly
3 860027 1 Coin Panel
4 117603 1 1/8 x 9/16 Noise Suppression Tape
5 860028 1 Coin Panel Lock Assem ly
6 153010 4 #6 Internal and External Star Washer
7 152102 4 M3 Hex Nut
Coin Panel Assembly

7
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 170336 1 Cold Rolled Steel (CRS) Main Door Ring
2 102354 1 Extruded Steel Door Gasket
3 170329 1 Top Hinge Block
4 150445 2 1/4-20 x 3/4 Socket Head Cap Screw
5 153031 1 1/4 Nylon Washer
6 170331 1 Bottom Hinge Block
7 150445 2 1/4-20 x 3/4 Socket Head Cap Screw
8 152014 3 1/4-20 Free Spin Wash Nut
9 151010 1 #10-32 Black Hex Acorn Nut
10 150120 1 #10-32 x 7/16 Door Latch Screw
11 816656 1 Cold Rolled Steel (CRS) Main Door Handle Assem ly
12 152014 3 1/4-20 Free Spin Wash Nut
13 102211 1 Door Glass with Notch
Main Door Assembly

8
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Main Door Switc Assembly
Illus. No. Part No. Qty.Description
1 153566 2 #6-32 x 7/8 Clinch Stud
2 152013 2 #6-32 Hex Nut
3 153010 2 #6 Star Washer
4 137005 1 Door Switch
5 122636 2 Flag Terminal
6 881211 1 Black Main Door Switch Housing ONLY
881153 1 Black Main Door Switch Housing Complete
(includes illus. nos. 1 through 4 and 6)
7 150301 2 #8-18 x 7/16 Phillips Pan Head TEK Screw

9
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 154210 40 5/32 x 3/16 Pop Rivet
2 354217 1 Spacer Plate
3 153048 1 Inner Friction Teflon® Pad
4 116332 1 Felt Collar
5 882765 1 One Arm Basket (tum ler) Support Assem ly
(includes illus. nos. 2, 3, and 5)
6 882766 1 Basket (tum ler) Assem ly for One Arm Basket (tum ler) Support
(includes illus. nos. 1, 4, and 9)
882990 1 One Arm Basket (tum ler) and Support Assem ly Complete
(includes illus. nos. 1 through 7 and 9)
7 154210 6 5/32 x 3/16 Pop Rivet
8 100191 1 12 Ri 105 Long (J) High Temperature Belt
9 115992 1 Inner Ring Felt Collar
401010 1 #847 Adhesive for Felt Collar (5 oz. tu e)
Basket (Tumbler)/Support Assemblies

10
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Top Locking Lint Basket Assembly
Illus. No. Part No. Qty.Description
1 115904 1 Lint Basket Felt
2 154210 5 5/32 x 3/16 Pop Rivet
3 160140 1 Key ONLY for XX4451
4 882787 1 Top Locking Lint Basket with Lock (white)
(includes illus. nos. 1 through 5)
882794 1 Top Locking Lint Basket with No Lock ( isque)
(includes illus. nos. 1, 2, and 4)
5 160038 1 Lint Basket Lock with Cam (no key)
160050 1 Lint Basket Lock (no cam and key) for Stainless Steel ONLY
6 117605 4 1/4 x 3/8 Neoprene Sponge Tape (sold y the foot)

11
Telephone: [phone] Fax: [phone]
Bottom Locking Lint Basket Assembly
Illus. No. Part No. Qty.Description
1 115904 1 Lint Basket Felt
2 154210 5 5/32 x 3/16 Pop Rivet
3 160140 1 Key ONLY for XX4451
4 882797 1 Bottom Locking Lint Basket Assem ly with Lock ( lack)
(includes illus. nos. 1 through 6)
882796 1 Bottom Locking Lint Basket Assem ly with No Lock ( lack)
(includes illus. nos. 1, 2, 4, and 6)
5 160038 1 Lint Basket Lock with Cam (no key)
6 117604 4 1/8 x 3/8 Neoprene Sponge Tape (sold y the foot)

12
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty.Description
1 152014 23 1/4-20 Free Spin Wash Nut
2 154210 4 5/32 x 3/16 Pop Rivet
3 152002 2 1/4-20 Hex Nut
4 115903 1 Basket (tum ler) Separation Felt with Elastic
5 860039 1 Separator Bracket
 883938 1 Inner Ring Separator Assem ly
(includes illus. nos. 1 through 5)
Separator Assembly

13
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 353283 1 Rotational Sensor Bracket
2 319202 1 Sail Switch Flat Damper
3 154004 1 Tinnerman Twin Speed Nut
4 154002 1 1/8 Push On Fastener
5 153528 1 8/32 x 1/2 Self-Clinching Stud
6 152014 2 1/4-20 Free Spin Wash Nut
7 150303 2 Phillips Pan Head Screw
8 122200 1 Sail Switch
9 105550 1 Sail Switch Rod
883934 1 Teflon® Backup Washer and Magnet Assem ly
(includes illus. nos. 10 through 12, 17, and 18)
10 353282 1 Thrust Bearing Backup Washer
11 353281 1 Backup Washer Rivet Spacer
12 154218 1 1/8 Diameter Aluminum Rivet
13 153053 1 5/16 Lock Washer
14 150640 1 5/16-18 X 7/8 Hex Bolt
15 354217 1 Plate Spacer
16 153048 1 Inner Friction Pad
17 153047 1 Outer Teflon® Friction Pad
18 102102 1 1 x 3/4 x 0.197 Door Magnet
19 822735 1 Phase 7 Rotational Sensor Switch
Rotational Sensor/Sail Switc and Teflon® Backup Was er Plate

14
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty.Description
1 354067 1 Thrust Wheel Mount
2 150682 4 1/4-20 x 5/8 Stainless Steel Carriage Bolt
3 154284 2 Basket (tum ler) Wheel Spacer
4 154267 2 M10 x 25 mm Shoulder Screw
5 154013 2 M8 Hex Nut
6 153002 2 5/16 Split Lock Washer
7 180032 2 Duratred Idler Wheel
8 122002 1 Arcolectric Door Switch
9 150309 2 #10-16 x 1/2 Hex Head TEK Screw
10 354156 1 Lint Switch Bracket
11 152014 6 1/4-20 Free Spin Wash Nut
12 154210 20 5/32 x 3/16 Pop Rivet
13 854029 1 Lint Coop
14 152001 2 #8-32 x 3/8 Hex Nut
15 354171 1 Harness Stiffener
Lint Coop and Adjustment W eel Bracket Assembly

15
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 153002 1 5/16 Split Lock Washer
2 154013 1 M8 Hex Nut
3 180032 1 Duratred Idler Wheel
4 154284 1 Basket (tum ler) Wheel Spacer
5 154267 1 M10 x 25 mm Shoulder Screw
6 354253 1 Left Roller Wheel Bracket
7 153007 3 1/4 Split Lock Washer
8 150510 3 1/4-20 x 3/4 Hex Head Machine Bolt
Left Rear W eel Bracket (3 Bolt)

16
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Illus. No. Part No. Qty.Description
1 153002 1 5/16 Split Lock Washer
2 154013 1 M8 Hex Nut
3 154284 1 Basket (tum ler) Wheel Spacer
4 180032 1 Duratred Idler Wheel
5 154267 1 M10 x 25 mm Shoulder Screw
6 150510 3 1/4-20 x 3/4 Hex Head Machine Bolt
7 153007 3 1/4 Split Lock Washer
8 354252 1 Right Roller Wheel Bracket
Rig t Rear W eel Bracket (3 Bolt)

17
Telephone: [phone] Fax: [phone]
Illus. No. Part No. Qty.Description
1 882682 1 Temperature Sensor Bracket Assem ly Complete
(includes illus. nos. 1 through 6, 8, and 12 through 14)
354117 1 Sensor Bracket ONLY
2 152013 2 #6-32 Hex Nut
3 153010 2 #6 Star Washer
4 150005 2 #6-32 x 1/4 Phillips Round Head Machine Screw
5 883025 1 Microprocessor Temperature Sensor Pro e Assem ly
(includes illus. nos. 5, 6, and 12 through 14)
6 154007 2 1/4 Push On Fastener
7 152014 2 1/4-20 Free Spin Wash Nut
8 130119 1 Temperature Sensor
9 121494 2 3/16 Push Mount Wire Tie
10 122700 4 Pin Terminal ONLY
11 122604 1 4-Position Connectors (male)
12 121028 2 1/4 Push On Terminal
13 122701 4 Socket Terminal ONLY
122801  Pin/Socket Extraction ToolNot Illustrated
14 122605 1 4-Position Connectors (female)
Microprocessor Temperature Sensor Bracket Assembly

18
American Dryer Corporation 88 C rrant Road / Fall River, MA 02720-4781
Top Burner Box Assembly
