24" TOWEL SHELF with TOWEL BAR
M968248A
8040.300
1
24" TOWEL SHELF with TOWEL BAR
Install 24" TOWEL SHELF (2) and TOWEL BAR (1) onto front of MOUNTING PLATES (5) (see Figure A). Secure and tighten the HEX BOLTS (7),
from back of MOUNTING PLATES (5) to secure.
The 24" TOWEL SHELF (2) with TOWEL BAR (1) works best if secured to a wall stud or cross brace within the wall, using the SCREWS ( )
supplied.
Determine desired height and location (optional) and mark a center line. For the 24" TOWEL BAR (2) mark a centerline 24" horizontally
from the first location. Using the MOUNTING PLATE (5) as a template mark the two spots for the ANCHORS (4). Repeat for the other
MOUNTING PLATE (5). If MOUNTING PLATE (5) is secured to a stud or cross brace drill small pilot holes for SCREWS ( ).(see Figure B).
For installations on drywall, use ANCHORS (4) and SCREWS ( ) for securing MOUNTING PLATE (5) to wall. Drill two 1/4" dia. holes
then press into drywall until it is seated flush with the wall. Place MOUNTING PLATE (5) over ANCHORS (4) and insert SCREWS ( ) provided
with #2 Phillips screwdriver. See illustration below. Secure MOUNTING PLATE (5) to wall with SCREWS ( ).
10'
For installations on tiled walls, If ANCHORS (4) and SCREWS ( ) are used for securing MOUNTING PLATE (5) drill two 1/4" dia.
holes a minimum of 1-1/4" deep. Insert the two ANCHORS (4) flush with face of the finished wall. Secure MOUNTING PLATE (5) to wall
with SCREWS ( ).
Thank you for selecting American-Standard...the benchmark of fine
quality for over 1 years.
To ensure that your installation proceeds smoothly--
please read these instructions carefully before you begin.
Installation
Instructions
Regular Screwdriver
Recomme ded Tools
Phillips Screwdriver
Drill
Tape Measure
Hex Wrench
Figure B
5
3
2
1
USE MOUNTING
PLATE AS TEMPLATE
4
CENTER LINE
4
FRONT
Figure A
BACK SIDE
2
1
5
7
7
Figure C
23-3/4"
CENTER LINE
6-3/8"
1"
1"
48" TO 68"
(OPTIONAL)
4
FINISHED
WALL
5
2
1
3
3
CARE INSTRUCTIONS:
DO: SIMPLY RINSE THE PRODUCT CLEAN WITH CLEAR
WATER. DRY WITH A SOFT COTTON FLANNEL CLOTH.
DO NOT: CLEAN THE PRODUCT WITH SOAPS, ACID,
POLISH, ABRASIVES, HARSH CLEANERS, OR A CLOTH
WITH A COARSE SURFACE.
ACCESSORIES

M919209-YYY0A
24" TOWEL BAR M907546-YYY0A
MOUNTING PLATE
M923092-YYY0A
24" TOWEL SHELF
8040.300
24" TOWEL SHELF with TOWEL BAR
CHROME
POLISHED BRASS 002 099
Replace the "YYY" with
appropriate finish code
M968248A
ACCESSORIES
24" TOWEL SHELF
WITH TOWEL BAR
MODEL NUMBERS
8040.300
HOT LINE FOR HELP
For toll-free information and answers to your questions, call:
1-800 442-1902
Weekdays 8:00 a.m. to 8:00 p.m. EST
IN CANADA 1-800- 87-0 69 (TORONTO 1-905- 06-109 )
Weekdays 8:00 a.m. to 7:00 p.m. EST
Product names listed herein are trademarks of American Standard Inc.
© American Standard Inc. 2002
M918985-0070A
WOOD SCREW
M918309-0070A
SCREW
