American Standard Bathing Pool with Integral Apron 2083.102 Operating and safety instructions

H101
© 2008 AS America Inc. Revised 12/99
To Be Specied - Required:
❏ Color: (White only)
❏ Bath Filler*: (specify nish)
❏ Drain: 1501.170 (specify Chrome or Satin)
To Be Specied - Optional:
❏ Bath Caddie: 9533.100 (in Chrome only)
For color/nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
Standard Collection® BATHING POOL
with INTEGRAL APRON
❏ 2083.102 Bathing Pool, Right Hand Outlet
❏ 2083.202 Bathing Pool, Left Hand Outlet
Product Features:
• Acrylic with berglass reinforcement
• Integral apron design
• Integral three-sided, tiling/water retention ange
• Generous back rest
• End drain outlet
• Design coordinated to the Standard Collection
of accessories, faucets and xtures
Nominal Dimensions:
1524 x 813 x 508mm
(60" x 32" x 20")
Compliance Certications -
Meets or Exceeds the Following Specications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
Standard Collection®
BATHING POOL
HIGH GLOSS

H102
© 2008 AS America Inc. Revised 12/99
Standard Collection®
BATHING POOL
HIGH GLOSS
60 x 32 x 20 In.
(1524 x 813 x 508mm)
100 Lbs. (45 Kg.)
551 Lbs. (250 Kg.)
54 Gal. (204 L)
18 x 42 In. (457 x 1067mm)
25 X 54 In. (635 x 1372mm)
14 In. (356mm)
41 Lbs./Sq.Ft. (202 Kgs./Sq.m)
20.8
35.3
GENERAL SPECIFICATIONS FOR 2083 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
1-1/2 N.P.T. THREADS
1-1/2 O.D. TAILPIECE
19-3/4"
(502mm)
2"
(51mm)
4-5/8"
(117mm)
ROUGH
FLOOR
4"
(102mm)
20"
(508mm)
1"
(25mm)
16"
(406mm16)
OPTIONAL
TO FLOOR
USUALLY
BETWEEN
65 & 78
(1651 & 1981mm)
C/L OF CURTAIN ROD
USUALLY 76"(1930mm) FROM
FINISHED FLOOR
C/L OF
VALVES
4"
(102mm)
4"
(102mm)
SPOUT-
1/2 N.P.T.
FINISHED
WALL
SHOWER ARM- 1/2 N.P.T.
1-1/4"(32mm) DIA. HOLE
SEE
NOTE
3-1/2"
(89mm)
32"
(813mm)
60"
(1524mm)
3/4"
(19mm)
70mm
(2-3/4)
7-3/4"
(197mm) FINISHED
WALL
4"
(102mm)
4"
(102mm)
C/L OF 1/2
SUPPLIES
AS REQ'D
C/L OF
DRAIN
229mm x 305mm
(9 x 12)
FLOOR
CUTOUT
15-3/8"
(391mm)
4-1/2"
(114mm)
25mm
(1)
(2) 2-1/8"(54mm)
DIA. HOLES
2-3/8" 13mm
+
(2-3/8) (1/2)
+
BATH SUPPORT MATERIAL
TOP OF DECK
NOTES:
BATH TO BE INSTALLED ABOVE FLOOR LINE AS A RECESS INSTALLATION.
■REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS (2083.202).
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standards Z124.1 and
A112.19.7. These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.
