American Standard ClearTap 4665.000 User manual

SINGLE CONTROL WATER FILTERING
KITCHEN FAUCET
MODEL NUMBER:
4665.000 Water Filtering System - Kitchen Faucet
Handspray - Cap provided for less spray application.
4665.003 Water Filtering System - Kitchen Faucet
Handspray through escutcheon.
PRODUCT FEATURES: (cont'd)
Ceramic Disc Valve Cartridge: Assures a lifetime of drip-free
performance.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Filtration Characteristics: Meets NSF 42 and NSF 53. Extra
long - life Capacity - 250 gallons of usage or 90 days before filter
replacement. High Flow Filter capability at .75 GPM/2.8L/min.
Superior Filtration properties. Filter does not remove beneficial
fluoride. Ultra-simple Filter Replacement Technique.
Flexible Installation: (4 Hole, 3 Hole, 2 Hole or 1 Hole options)
Filter can be mounted above or below deck. Faucet installs with or
without deck plate. Faucet installs with or without handspray. Below
deck Filter Housing Bracket provided.
End of Life Indicator: Simple operation and communication with
the user. Easy replacement of the common watch battery. Change
filter and change battery alerts are easily understood.
Choice of Finishes: Choice of Polished Chrome, White, Bone
or Satin.
PRODUCT FEATURES:
Brass and Copper Waterway, Cast Brass Spout: Highest
quality faucet materials for durability and long life. Spout swings
135˚.
Integrated faucet control via patented Ceramic Disc
Valve Cartridge:
Memory Position Valving: Allows user to turn valve on and
off at predetermined temperature setting without readjusting handle
position each time. Large temperature control zone. Simple one-
step filtering with a shift of the metal lever.
SUGGESTED SPECIFICATION:
Single control kitchen Filter faucet shall be constructed of a cast brass body and swing spout. Stamped brass escutcheon
plate and metal lever handle. Shall also feature a washerless ceramic disc valve cartridge that regulates temperature, volume
and diverts the flow of water from the aerator to the Filtered water discharge. Filter life shall be digitally displayed in terms of
"Days of Life Remaining". Fitting shall be American Standard Model # 4665.____.____.
GENERAL DESCRIPTION:
Cast brass body and swing spout, stamped brass escutcheon
and metal lever handle. Washerless 47mm Ceramic Disc valve
cartridge. 1/2" I.P.S. connection will accept standard bull nose
connection. 2.2 GPM/8.3L/min. maximum flow rate @60 PSI
from the aerator and 0.75 GPM/2.8L/min. Filtered water.
Patented American Standard Carbon Matrix Technology Filter.
SMARTELECTRONICS End of Life Indicator utilizes a
standard CR1220 watch battery. Kitchen side spray included.
4665.000 Shown
UP
UP
102mm
(4")
330mm
(13")
min. clearance 15"
51mm
(2") max.
installation
32mm
(1-1/4")
127mm
(5")
226mm
(5")
248mm
(9-3/4")
15˚
206mm
(8-1/8")
32mm
(1-1/4")
270mm
(10-5/8")
152mm
(6")
25mm
(1)
SPRAY FOR
4 HOLE SINK
121mm
(4-3/4)
51mm
(2)
51mm
(2)MAX.
35mm (1-3/8")
Dia. Mounting Hole
35mm (1-3/8")
Dia. Mounting Hole

SINGLE CONTROL WATER FILTERING
KITCHEN FAUCET
4665.000
4665.003
Product
Number Description
Finish Options
Polished
Chrome
White
Heat
002 208
Bone
021 295
Satin
(PVD)
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
Water filtering System - Kitchen Faucet. Handspray - Cap provided for
less spray application.
Water filtering System - Kitchen Faucet. Handspray through escutcheon.
CODES AND STANDARDS
These products meet or exceed the following codes and
standards:
ASME A112.18.1
A117.1
CSA B125
Federal Safe Drinking Water Act
NSF 61 Section 9
NSF 42
Chlorine Reduction Class I 98.9%
Improves Taste
Reduces ParticulateClass I
Eliminates Odor
NSF 53
Reduces Turbidity
Reduces Lead 99.3%
Reduces Live Cysts 99.99% by Filtration
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
