American Standard Cadet 3 Round Front Total Toilet 2880.000 Operating and safety instructions

K100
© 2008 AS America Inc. Revised 2/08




THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
 Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.

❑ 
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• 12" Rough-in (305mm)
• EverClean® surface inhibits the growth of stain
and odor causing bacteria, mold and mildew on
the surface
• Features the 
• Space saving round front siphon action
jetted bowl
• Fully-glazed 2-1/8" trapway with 2" ball pass
• Generous 9" x 8" water surface area
• Close-coupled tank with at tank cover for
superior storage
• Oversized 3" ush valve with chemical
resistant apper
• Chrome trip lever
• Speed Connect® tank-to-bowl coupling system
• Sanitary dam on bowl with four point
tank stabilization
• 2 color-matched bolt caps
• Color matched solid plastic seat and cover
with EverClean® surface
• Wax ring gasket with closet bolts
• 100% factory ush tested
• 5 year warranty

718 x 438 x 733mm
(28-1/4" x 17-1/4" x 28-7/8")


• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability

❏ Color: ❏ White
❏ Supply with stop:
FINISHED WALL
FINISHED
FLOOR
C/L OF OUTLET
SUPPLY
AS
REQ'D.
216mm
(8-1/2)
718mm
(28-1/4)
25mm ± 6mm
(1 ± 1/4)
102mm
(4)
416mm
(16-3/8)
438mm
(17-1/4)
733mm
(28-7/8)
*381mm
(15)
*203mm
(8)
305mm
(12)
333mm
(13-1/8)
216mm
(8-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
352mm
(13-7/8)
*152mm
(6)
235mm
(9-1/4)
