American Standard Cadet 4098.100 Operating and safety instructions

M44
© 2008 AS America Inc. Revised 2/08
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Linen
❏ Silver ❏ Fawn Beige ❏ Black
❏ Seat: American Standard #5324.019 “Rise and
Shine” (with easy to clean lift-off hinge system)
solid plastic closed front seat with cover.
❏ Seat: American Standard #5311.012 “Laurel”
molded closed front seat with cover.
❏ Alternate Seat:
❏ Supply with Stop:
* Flushmate III tank system by Flushmate® Div. of Sloan Valve Co
GLENWALL™ PRESSURE-ASSISTED
WALL-MOUNTED TOILET
VITREOUS CHINA
GLENWALL™ PRESSURE-ASSISTED TOILET
❏ 2093.100
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• Wall-mounted, back-outlet toilet
• Elongated bowl
• Fully-glazed 2" ballpass trapway
• 10" x 12" water surface area
• Pressure-assisted siphon jet action
• Side-mounted chrome trip lever
• Close-coupled ushometer tank*
• Speed Connect® tank/bowl coupling system
• Sanitary bar on bowl
❏ 3402.016 Elongated bowl
❏ 4098.100 Tank complete with coupling
components
Nominal Dimensions:
749 x 495 x 762 mm
(29-1/2" x 19-1/2" x 30")
Fixture only, seat and supply by others
Required working pressure range 25 psi - 80 psi
Alternate Congurations Available:
❏ 4098.700 Tank and tank cover only
with tank cover locking device
❏ 4098.800 Tank and tank cover only
with right hand trip lever
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2 for Vitreous China Fixtures
NOTES:
WASTE OUTLET SEAL RING MUST BE NEOPRENE OR GRAPHITE-
FELT (WAX RING NOT RECOMMENDED)
SUGGEST 1/16" CLEARANCE BETWEEN FACE AT WALL AND BACK OF
BOWL.
CARRIER FITTING AS REQUIRED TO BE FIGURED AND FURNISHED BY
OTHERS.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
FOR ADDITIONAL INFORMATION REFER TO INSTALLATION
INSTRUCTIONS SUPPLIED.
IMPORTANT: Dimensions of xtures are nominal and may vary within
the range of tolerances established by ANSI Standard A112.19.2. These
measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
14-3/4
(375mm)
9
(229mm)
29-1/2
(749mm)
9
(229mm)
18-1/2
(470mm)
C/L OF SEAT POST HOLES
5-1/2 (140mm CENTERS)
7-1/2
(191mm)
191mm
(7-1/2)
C/L OF WASTE
OUTLET
(4) 7/8
(22mm) DIA. HOLES
SUPPLY AS
REQUIRED
*
5/8
(16mm)
3-1/4
(83mm)
1-1/2
(38mm)
5-1/4
(133mm)
3-7/8
(98mm)
FINISHED WALL
FIN.
FLOOR
3-1/4
(83mm)
3/4 (19mm)
REF.
6
(152mm)
8-1/2
(216mm)
19-1/2
(495mm)
3/4 ±1/4
(19mm ±6mm)
C/L
30
(762mm)
OR
32
(813mm)
14-1/2
(368mm)
OR
16-1/2
(419mm)
4-1/8
(105mm)
OR
6-1/8
(156mm)
When installed so top of seat is 432 to 483mm (17" to 19") from the
finished floor.
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES AND
ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND USEABLE
BUILDING FACILITIES-CHECK LOCAL CODES.
BARRIER FREE
