American Standard Colony Soft 3875.509 User manual

C61
© 2008 AS America Inc.
COLONY SOFT
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
WITH LEVER HANDLES
GENERAL DESCRIPTION:
Cast brass valve bodies with reinforced flexible hose
connections for 6" to 12" (152mm to 305mm) installations.
1/4 turn washerless ceramic disc valve cartridges. Cast
brass spout. One-half inch brass male inlets with brass
coupling nuts. 20" (500mm) long flexible stainless steel drain
cable is pre-assembled to faucet body. Metal Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece, (3875.509).
Non-Metallic Speed Connect®drain body with 1-1/4 inch
(32mm) tail piece, (3875.503). 1.5 gpm/5.7L/min. maximum
flow rate.
PRODUCT FEATURES:
Brass Construction: Durable. Ideal for prolonged contact
with water.
Ceramic Disc Valve Cartridges: Smooth handle
operation and assures a lifetime of drip-free performance.
Exclusive Speed Connect Metal Drain:
• Fewer Parts - installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in
tight spaces.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Choice of Finishes
MODEL NUMBER:
3875.503 Colony Soft Widespread
Non-metallic Speed Connect®Pop-up drain
3875.509 Colony Soft Widespread
Metal Speed Connect Pop-up drain.
SUGGESTED SPECIFICATION:
Two handle widespread lavatory faucet shall feature cast brass valve bodies with reinforced flexible hose connections for
6" to 12" installations. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a drain body
with stainless steel cable actuation. Fitting shall be American Standard Model # 3875.__.__.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B 125
NSF 61/Section 9
51mm
(2)DIA.
64mm
(2-1/2)
DIA.
115mm
(4-1/2)
152mm - 305mm
(6 TO 12)
FLEXIBLE
29mm
(1-1/8)
DIA.
80mm
(3-1/8)
51mm
(2)
FLEXIBLE
HOSE
FLEXIBLE
HOSE
3875.503
Product
Number Description
Colony Soft Widespread. With Lever Handles. Non-Metallic Speed Connect®drain.
3875.509 Colony Soft Widespread. With Lever Handles. Metal Speed Connect Pop-up drain.
Finish Options
Polished
Chrome
002
PVD
Satin
Nickel
295
FOR GROUND JOINT
OR 1/2" O.D. SLIP
CONNECTION
35mm
(1-3/8)DIA.
MOUNTING
HOLES
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
38mm
(1-1/2)
MAX.
32mm OD
(1-1/4 OD)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
10080604020

C62
© 2008 AS America Inc.
COLONY SOFT
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
WITH LEVER HANDLES
GENERAL DESCRIPTION:
Cast brass valve bodies with reinforced flexible hose
connections for 6" to 12" (152mm to 305mm) installations.
1/4 turn washerless ceramic disc valve cartridges. Cast
brass spout. One-half inch brass male inlets with brass
coupling nuts. 20" (500mm) long flexible stainless steel drain
cable is pre-assembled to faucet body. Metal Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece, (3875.509).
Non-Metallic Speed Connect®drain body with 1-1/4 inch
(32mm) tail piece, (3875.503). 1.5 gpm/5.7L/min. maximum
flow rate.
PRODUCT FEATURES:
Brass Construction: Durable. Ideal for prolonged contact
with water.
Ceramic Disc Valve Cartridges: Smooth handle
operation and assures a lifetime of drip-free performance.
Exclusive Speed Connect Metal Drain:
• Fewer Parts - installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in
tight spaces.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Choice of Finishes
MODEL NUMBER:
3875.503 Colony Soft Widespread
Non-metallic Speed Connect®Pop-up drain
3875.509 Colony Soft Widespread
Metal Speed Connect Pop-up drain.
SUGGESTED SPECIFICATION:
Two handle widespread lavatory faucet shall feature cast brass valve bodies with reinforced flexible hose connections for
6" to 12" installations. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a drain body
with stainless steel cable actuation. Fitting shall be American Standard Model # 3875.__.__.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B 125
NSF 61/Section 9
51mm
(2)DIA.
64mm
(2-1/2)
DIA.
115mm
(4-1/2)
152mm - 305mm
(6 TO 12)
FLEXIBLE
29mm
(1-1/8)
DIA.
80mm
(3-1/8)
51mm
(2)
FLEXIBLE
HOSE
FLEXIBLE
HOSE
3875.503
Product
Number Description
Colony Soft Widespread. With Lever Handles. Non-Metallic Speed Connect®drain.
3875.509 Colony Soft Widespread. With Lever Handles. Metal Speed Connect Pop-up drain.
Finish Options
Polished
Chrome
002
PVD
Satin
Nickel
295
FOR GROUND JOINT
OR 1/2" O.D. SLIP
CONNECTION
35mm
(1-3/8)DIA.
MOUNTING
HOLES
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
38mm
(1-1/2)
MAX.
32mm OD
(1-1/4 OD)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
10080604020
