Ameriwood 5945307T User manual

B345945307T00
>> assembly instructions
Mixed Material
4 drawer dresser
style # 5945307T
DPCI # 249-05-0494
TM

Congratulations on your latest Target purchase.
Now what? Don't start sweating over the box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your
room in no time. Good luck--- though we're confident you won't need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order
missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly. Please do not use power tools.
tools needed
2

3
table of contents
introduction
hardware
parts list
how to use the cam lock system
assembly
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number
ready when calling.
2
4-5
6
7
8-27

4
hardware
(1) x20
cam lock
#A22570
(2) x20
cam bolt
#A22510
(3) x14
wood dowel
#A21660
(4) x4
#8 x 1-3/4" flat head screw
#A13410
(5) x32
nail
#A21110
(6) x28
#8 x 7/16" pan head screw
#A12120
(7) x26
#6 x 1-1/4" flat head screw
#A11600
(8) x40
#6 x 7/16" flat head screw
#A11080
(9) x8
8-32 x 7/8" bolt
#A17400
(10) x8
drawer bracket
#A54223
(12) x4
handle
#A50415
(13) x4
slide set
#A56750
(14) x2
metal leg
#A95490
13a
13b
13c
13d

hardware
(15) x1
safety bracket kit
#A80450
5
15a
15b 15c 15d

Parts List DESCRIPTION
PART NUMBER
QTY
ITEM LEFT PANEL
35945307010
1
ARIGHT PANEL35945307020
1B TOP35945307030
1C BOTTOM35945307040
1D BRACE
359453070503
ESTRINGER35945000060
1F UPPER DRAWER FRONT35945307070
1G LOWER DRAWER FRONT359453070803
HLEFT DRAWER SIDE
C1670370331010L
4 RIGHT DRAWER SIDEC1670370331010R
4 DRAWER BACK
C1670704331510B3
DRAWER BOTTOM35945331120
4 DRAWER BRACE
35945000130
4M UPPER DRAWER BACKC1670704331540B
1 DRAWER DIVIDER
35945331150
1
OBACK PANELK594500000
1
Parts shown are the base cabinet of your model. Please
note, most parts are labeled with a sticker or have a letter
stamped on a raw edge.
Parts F & N may not be labeled.
This piece is paper board construction.
It is not made from wood but is
required for the assembly of your unit.
A
B
D
E
E
E
F
M
HG
M
O
6
C
back
panel
drawerback
left
drawer side
drawer bottom
right
drawer side
lower drawer
left
drawer side
upperdrawer back
drawer
bottom
right
drawer side
upper drawer

how to use the cam lock system
2
3
½ turn to fully
lock.
4
Tighten to fully seat. Do not over
tighten. Proper orientation of cam.
1
Lock
Titus
Titus
Titus
7

1
step
8
(2) x4
cam bolt
A
Proper orientation of CAM LOCK
(1) x2
cam lock
1
1
2
2
2
(3) x2
wood dowel (8) x12
#6 x 7/16" screw (13) x4
left cabinet slide
2
8
8
8
88
8
8
8
8
8
8
8
2
8
3
3
13a
13a
13a
13a
13a
marked with an "L"
finished
edge
13a
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.

2
step
9
Proper orientation of CAM LOCK
(1) x2
cam lock (2) x4
cam bolt (3) x2
wood dowel (8) x12
#6 x 7/16" screw (13) x4
right cabinet slide
1
3
1
3
2B
288
8
8
2
2
8
88
8
8
8
8
8
8
2
13b
13b
13b
13b
13b
13b
marked with an "R"
finished edge
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.

3
step
10
(2) x4
cam bolt
C
2
2
2
(15) x1
safety bracket kit
2
15a
15b
finished edge
15a 15b
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.
do not tighten screw (15b)

4
step
Proper orientation of CAM LOCK
E
F
x3
(1) x8
cam lock (3) x8
wood dowel
11
1
1
1
1
3
3
3
3
1. Refer to page 7 for instructions on how to use the cam lock system.

5
step
12
UNLOCKLOCK
A
finished edge
E
F
EE
1. Refer to page 7 for instructions on how to use the cam lock system.
x4

6
step
A
B
E
E
E
F
UNLOCKLOCK
finished edge
13
1. Refer to page 7 for instructions on how to use the cam lock system.
x4

7
step
14
(4) x4
#8 x 1-3/4" flat head screw
finished edge
4
4
4
4
D
B
A
raw surface

8
step
UNLOCKLOCK
15
A
B
C
finished edge
D
1. Refer to page 7 for instructions on how to use the cam lock system.
x4

9
step
and/or serious injury.
Failure to do so could cause instability, product collapse,
All nails must be driven into the parts straight and centered.
Please make sure that the Back Panel is attached securely.
WARNING
Assure that the unit is square.
Distance from corner to corner
must be equal as shown.
Attach the back panel so that the
bottom edge is even with the bottom
(D) and aligned side to side.
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
(5) x32
nail
16
BD
5
back
panel

10
step
17
(6) x12
#8 x 7/16" pan head screw (14) x2
metal leg
D
B
C
6
6
14
14
6

11
step
Bracket Orientation Bracket Orientation
(10) x8
drawer bracket
1. Lay the drawer sides down on a flat surface. Carefully line up the drawer
bracket with the holes in the drawer side as shown. Using a hammer, tap
each drawer bracket stem part way into each hole. Repeat this process until
the drawer bracket is fully seated the drawer side.
18
x4
1010
x4
leftdrawerside
(marked "LEFT")
rightdrawerside
(marked"RIGHT")

12
step
(6) x16
#8 x 7/16" pan
head screw
(2) x8
cam bolt
x3
19
H
G2
6
6
GH
/
2
6
6
GH
/
line up all grooves during assembly
rightdrawerside
(marked"RIGHT")
leftdrawerside
(marked"LEFT")
leftdrawerside
(marked"LEFT")
rightdrawerside
(marked"RIGHT")
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.

13
step
20
(1) x8
cam lock
M
x4
Proper orientation of CAM LOCK
1
M
G
Hx3
M
1. Refer to page 7 for instructions on how to use the cam lock system.
1
UNLOCKLOCK
x8
