Ametek DMS-3K User manual

1088-351 Rev B
DMS-3K
Distributed Monitoring System
Installation & Operation Manual
Document no. 1088-351

TOC Page i
Table of Contents
Table of Contents...................................................................................................................................i
Scope.....................................................................................................................................................i
Chapter 1 Product Overview.................................................................................................................1
Features and Functions.....................................................................................................................1
Inputs..............................................................................................................................................1
Outputs...........................................................................................................................................1
Annunciator Logic...........................................................................................................................1
Sequence of Events Recording (SER) ...........................................................................................1
Power Supply Options....................................................................................................................1
Time Synchronization.....................................................................................................................2
Communications.............................................................................................................................2
System Configuration.....................................................................................................................2
Alarm Display and Notification........................................................................................................2
DMS 3K System Components...........................................................................................................4
Logic Card Racks...........................................................................................................................5
Power Supply Regulators...............................................................................................................8
CPU-200.........................................................................................................................................9
I/O Modules..................................................................................................................................10
Annunciator Displays....................................................................................................................13
Model Number Codes / Ordering Information..................................................................................15
DMS-3K System Configuration........................................................................................................17
Safety and Agency Approvals..........................................................................................................18
Chapter 2. Installation & Setup ...........................................................................................................19
Safety ..............................................................................................................................................19
Mounting..........................................................................................................................................21

Page ii TOC
Wiring ..............................................................................................................................................22
Terminal Blocks............................................................................................................................22
IDC Connectors............................................................................................................................22
Protective Earth Connection.........................................................................................................22
Power Input and Field Contact Voltage........................................................................................22
External Power Supply Wiring......................................................................................................31
Input / Output Wiring.....................................................................................................................32
Communication and Time Sync Ports..........................................................................................46
IRIG-B ..........................................................................................................................................48
Chapter 3. DMS-3K Web Browser Configuration...........................................................................49
DMS-3K Home Page.......................................................................................................................50
Systems with CR Option (Combined Master)...............................................................................51
Home Page Editable Fields..........................................................................................................52
WEB Browser Navigation.............................................................................................................53
WEB Browser System Configuration...............................................................................................54
Alarm Inputs Configuration..............................................................................................................56
Input .............................................................................................................................................56
Enable/Disable.............................................................................................................................57
Input Filter: ...................................................................................................................................57
Input Filter / Debounce Time:.......................................................................................................57
Automatic Delete From Scan:.......................................................................................................58
Contact State:...............................................................................................................................58
Control / Sequence Group:...........................................................................................................58
Inhibit Group:................................................................................................................................58
Alarm Legend:..............................................................................................................................59
Normal Legend:............................................................................................................................59
Set all Inputs.................................................................................................................................59

TOC Page iii
Import / Export Legends...............................................................................................................59
Control Inputs Configuration............................................................................................................60
Input Terminal: .............................................................................................................................60
Function:.......................................................................................................................................61
Control/Sequence Group:.............................................................................................................62
Inhibit Group:................................................................................................................................62
Channel:.......................................................................................................................................62
Operating Sequence Configuration:.............................................................................................62
Control Interlock:..........................................................................................................................62
Flash Type Settings:.....................................................................................................................63
Analog Inputs Configuration ............................................................................................................64
Module Type:...................................................................................................................................64
Analog Input Trip Settings:...........................................................................................................64
Alarm Outputs Configuration ...........................................................................................................66
Output No:....................................................................................................................................66
Output Type:.................................................................................................................................67
Input Assignments:.......................................................................................................................69
Serial Communications Configuration (optional)..............................................................................73
Serial Communication Set-up:......................................................................................................73
Modbus RTU................................................................................................................................74
Systems with CR Option...............................................................................................................77
DNP Protocol (option)...................................................................................................................78
ASCII Protocol (option).................................................................................................................78
Ethernet Communications Configuration (optional) .........................................................................80
DNP Protocol (option)...................................................................................................................81
Combined Rack (CR).......................................................................................................................82
CR Operation – Connection Status..............................................................................................82

Page iv TOC
Combined TCP/IP Port:................................................................................................................83
Access Control Configuration..........................................................................................................84
User Account can:........................................................................................................................84
Admin Account can:......................................................................................................................84
Trusted IPs/hostnames.................................................................................................................84
Ports.............................................................................................................................................84
HTTPS..........................................................................................................................................84
Basic Authentication.....................................................................................................................85
Network Configuration.....................................................................................................................86
Date / Time Configuration................................................................................................................87
Email Configuration .........................................................................................................................88
Save and Restore Configuration......................................................................................................89
Firmware Configuration ...................................................................................................................90
Option Upgrade...............................................................................................................................92
Color Selection ................................................................................................................................94
Logon as User.................................................................................................................................95
Documentation ................................................................................................................................95
Chapter 4-WEB Browser Alarm and Events Display Option ...............................................................97
Active Alarms Page .........................................................................................................................98
Download File (.csv)...................................................................................................................101
Erase the log (only for administrators)........................................................................................101
Print Events................................................................................................................................101
Maximum events to retrieve .......................................................................................................102
Event Sorting and Filtering.........................................................................................................102
Chapter 5-System Hardware.............................................................................................................105
Logic Box Diagram ........................................................................................................................106
Logic Box Motherboard Outline..................................................................................................107

TOC Page v
3U Logic Box Motherboard Schematic (Front View)...................................................................108
CPU-200 Details............................................................................................................................110
REG-90 (REG-91) .........................................................................................................................112
REG-92 (REG-93) .........................................................................................................................114
REG-94 (REG-95) .........................................................................................................................117
REG-96 (REG-97) .........................................................................................................................121
I/O Modules...................................................................................................................................124
I/O System Addressing...............................................................................................................125
8I/O-9xB 8 Ch. Digital Input / Output Module Data Sheet......................................................127
16I-9XB 16 Ch. Digital Input Module Data Sheet (Terminal Block Connection)...................130
16I-9xB 16 Ch. Digital Input Module Data Sheet (IDC Ribbon Connection).........................133
16O-9xB 16 Ch. Digital Output Module Data Sheet (Terminal Block Connection).................136
8 IAM – 90B 8 Ch. Analog Input Module Data Sheet..............................................................139
I/R Module..................................................................................................................................142
8 RR Module ..............................................................................................................................144
16 RR Module ............................................................................................................................146
5 PR-9xB 5 Channel Relay Output Module.............................................................................148
8 PR-9xB 8 Channel Relay Output Module.............................................................................151
I/R Module Switch Settings.........................................................................................................154
8 RR Module Switch Settings.....................................................................................................155
16 RR Module Switch Settings...................................................................................................156
DMS-3K SPECIFICATIONS..........................................................................................................157
System Capacity ........................................................................................................................157
I/O Card Rack Capacity..............................................................................................................157
INPUTS......................................................................................................................................157
Sequence of Events Recording..................................................................................................158
Time Synchronization.................................................................................................................158

Page vi TOC
OUTPUTS..................................................................................................................................159
COMMUNICATIONS..................................................................................................................160
OPERATING VOLTAGES..........................................................................................................161
MECHANICAL............................................................................................................................161
EMC Compliance .......................................................................................................................162
ENVIRONMENTAL.....................................................................................................................162
Chapter 6-Service & Maintenance....................................................................................................163
-Firmware Upgrade (Firmware Configuration Page) ..........................................................................163
Real Time Clock (RTC) battery......................................................................................................163
Reset Password & IP Address.......................................................................................................164
Appendix A MODBUS Protocol.....................................................................................................166
Modbus Operation.........................................................................................................................166
Modbus Master and Slave Modes.................................................................................................167
Modbus Alarms Data Mapping (Status).........................................................................................168
Modbus Event Data Mapping (Status + Time Stamp)....................................................................171
Appendix B DNP Protocol.............................................................................................................172
Device Profile Document...............................................................................................................172
Implementation Table....................................................................................................................173
DMS-3K DNP Data Map................................................................................................................174
Binary Inputs ..............................................................................................................................174
Binary Input Change with Time ..................................................................................................174
Time and Date............................................................................................................................175
Appendix C Browser Compatibility....................................................................................................177
Appendix D Notes on saving the event file as .csv ...........................................................................180
Appendix E Default Settings .............................................................................................................183
Appendix F Diagnostic Events..........................................................................................................185
Appendix G Legend Format for CSV Import..................................................................................188

TOC Page vii
Appendix H Operating Sequence Tables ......................................................................................189
LEGEND........................................................................................................................................189
CONTACT LIST & WARRANTY.......................................................................................................193
Telephone / Fax Number List ........................................................................................................193
MAIN OFFICE................................................................................................................................193
FAR EAST OFFICE....................................................................................................................193
UK OFFICE................................................................................................................................193
Procedures for Factory Repair and Return....................................................................................194
Warranty........................................................................................................................................194

Page i
Scope
This manual describes the functions, features, installation, and configuration of DMS-3K. This
includes usage of the Web browser interface.

Page 1
Chapter 1 Product Overview
DMS-3K is an advanced distributed alarm management system that accepts a variety of digital and
analog inputs and provides outputs to remote Annunciator displays and other devices used for Alarm
Management. The DMS-3K provides advanced communication outputs via serial and Ethernet ports
using various non-proprietary protocols. Each DMS-3K product can work as a stand-alone system
monitoring up to 128 digital inputs or multiple DMS-3K units can be networked together to form a
larger system with all alarms consolidated to a single master unit for common output and display.
Features and Functions
Inputs
Each DMS-3K card rack can accommodate up to 128 digital contact inputs or 32 analog inputs (or
combinations of both digital and analog). In addition, there are up to 64 control inputs which can be
assigned as functions to test, acknowledge, reset the lamp displays or inhibit specific inputs. Up to 16
card racks can be combined to form a system with maximum capacity of 2,048 digital inputs or 512
analog inputs (or combinations of both).
Outputs
Each DMS-3K card rack can accommodate up to 240 outputs which can consist of relay contacts or
solid state outputs. The outputs can be used to drive a remote Annunciator display, retransmit an
alarm input or group of inputs, and connect to a horn or other device.
Annunciator Logic
The DMS-3K system has logic to assign how an input or group of inputs drives an output. This is
used to assign an input or group of inputs to an Annunciator window, retransmit relay, alarm horn,
common alarm relay etc. The logic can be used with AND / OR functions to group multiple inputs to a
single output. In addition, you can apply ‘Voting Logic’ which will require scenarios like 2 of 3 or 3 of 4
inputs in alarm before activating an output. The Logic is also used to assign the control pushbuttons
(Test, Acknowledge, Reset, etc) to specific groups of inputs. All logic is confined to I/O contained in a
single Logic Card Rack.
Sequence of Events Recording (SER)
The DMS-3K provides timestamping of alarms to the millisecond for quick determination of root cause
and verification that control systems responded in an appropriate manner. Up to 40,000 events per
Logic Card Rack are stored in non-volatile RAM.
Power Supply Options
The DMS-3K logic card rack has a built in power supply regulator for 24VDC and 48VDC power
inputs. These regulators can provide a non-isolated 24 VDC or 48 VDC field contact voltage for
wetting the ‘dry’ field contact inputs. The regulators can also connect to an isolated external field
contact voltage supply of 24, 48 or 125 VDC for distribution to field inputs. Other input power options
(125VDC, 120/240VAC) are available through external power supplies which can be provided in a
redundant fashion, or different voltages for the Primary Power and Back Up Power.

2
Time Synchronization
The DMS-3K can be synchronized externally via IRIG-B and NTP time formats. This is used for
applying a time stamp to the digital and analog inputs synchronized to real time via GPS
synchronized time clocks.
Communications
Each DMS-3K unit has a built-in RS-232/485 Serial Port (DB9) and RJ45 Ethernet Port. The ports
can be used to retransmit the alarm status to other devices using Modbus, DNP or ASCII Protocols.
In addition, the multi-user Ethernet port can be used for time sync, networking multiple card racks
together to form a system and connect to a web browser for configuration and display of alarms and
events.
System Configuration
The DMS-3K System is configured using a WEB Browser connected to the CPU Ethernet Port. The
PC with WEB Browser (Internet Explorer, Mozilla Firefox, etc) can be connected directly to the DMS-
3K CPU or via the LAN where the DMS-3K is installed. The DMS-3K I/O Modules have switches or
jumpers for some configuration items. The configuration is flexible so that any single input or group of
inputs can operate any number of outputs configured as lamp outputs (for remote Annunciator
Display), Alarm Relay Outputs, Horn Outputs, etc. In addition, inputs can be retransmitted using
Modbus and DNP protocols.
Alarm Display and Notification
The DMS-3K WEB Browser will display the alarms as they occur graphically using an ‘Annunciator
style’ display and in list format showing the alarm details and timestamp. The DMS can also generate
an email for selected alarms.

Page 3

4
DMS 3K System Components
The DMS-3K System Components consist of:
•Logic Card Racks – Holds I/O modules, CPU and Power Supply
•Power Supplies – Internal and external power supply combinations
•CPU – Used for system configuration, Annunciator Logic, communications
•I/O Modules – Modules that accept digital and analog inputs and provide solid state and
relay contact outputs
•Annunciator Displays – Remote mounted displays that connect to logic card racks
The quantity of card racks, modules and displays is configurable to the application and defined in the
model number.
Logic Card Rack
Power Supply Regulator
I/O Modules
CPU
Annunciator Display
External Power Supply

Page 5
Logic Card Racks
The DMS-3K I/O is housed in a 3U card rack (type LBM or LBW) that can accept up to 10 I/O
modules or a 6U card rack (type LB2M or LB2W) that can accept 23 I/O Modules. Each Card Rack
has it’s own CPU and Power Supply.
LOGIC BOX: Type LBM OR LBMW
This is a standard 19"- 3U single euro-crate which will house the CPU and REG units plus 10
usable slots for input/output modules. The mounting angles are easily moveable to give front
or rear mounting.
LBM - 3U Front Mounting
LBMW - 3U Rear (Wall) Mounting
EB16 EB16 EB1 6
EB16 EB16
CPU
3U LOGI C BOX FRONT VIEW
SIDEVIEW
POSITION OF MOUNTING ANGLES ON
REAR MOUNTI NG LOGI C BOXES ( LBMW)
POSI TI ON OF MOUNTI NG ANGLES ON
FRONT MOUNTI NG LOGI C BOXES ( LBM)
ACCESS TO CARDS AND CARD WITHDRAWAL
IS VI A FRONT OF LOGI C BOX
REGULATOR
10 SLOTS FOR INPUT/ OUTPUT
AND RELAY CARDS ETC.
NOTE: Both types can be 19” rack mounted so that terminals / card withdrawal is either
outwards or inwards to cubicle.

6
LOGIC BOX: Type LB2M OR LB2MW
This is a standard 19"- 6U double euro-crate which will house the CPU and REG units plus 23
usable slots for input/output boards. The mounting angles are easily moveable to give front or
rear mounting.
LB2M - 6U Front Mounting
LB2MW - 6U Rear (Wall) Mounting
EB12
CPU
REGULATOR
SUPPLY
PANEL
POSITION OF MOUNTING ANGLES ON
REAR MOUNTI NG LOGIC BOXES ( LB2 MW)
POSITION OF MOUNTING ANGLES ON
FRONT MOUNTI NG LOGI C BOXES ( LB2 M)
ACCESS TO CARDS AND CARD WITHDRAWAL
IS VIA FRONT OF LOGIC BOX
23 SLOTS I N TOTAL AVAILABLE FOR
INPUT/ OUTPUT AND RELAY CARDS ETC.
6U LOGIC BOX FRONT VI EWSIDEVIEW
EB16 EB16 EB1 6
EB16 EB16

Page 7
Logic Box Diagram

8
Power Supply Regulators
Power Supply Regulators are used for direct power inputs of 24 or 48VDC. In systems with
120/240VAC and 125VDC Power Input, an external power supply is required to provide a 24 VDC
output to the Power Supply Regulator. The Power Supply Regulators may be used to provide an
internal Field Contact Voltage of 24 or 48 VDC or accept an external isolated customer supplied field
contact voltage of 24, 48 or 125 VDC. The field contact voltage is bussed to several terminals for
connection to the field inputs. The Power Supply Regulator also provides an internal horn relay which
is driven from a digital output (8 I/O or 16 O Module) assigned as a horn output. In systems with
external Annunciator Displays, the Power Supply Regulator provides a 24V Supply for the
Annunciator Lamps (LED’s). The Power Supply Regulators may have a suffix of A depending on the
version. Ex. REG-90A
The different types of Power Supply Regulators are shown below:
REGULATOR Type REG-90 and REG-91
This unit is used in 3U logic boxes where the system supply is 24V DC.
It provides the 5V supply necessary for the 10 usable slots plus the CPU, which equates to 128
inputs and 160 outputs maximum.
An auxiliary horn relay is mounted within.
REG-90 (STANDARD) Intended for use where the initiating contacts are being powered from
the 24 V supply voltage.
REG-91 (ISOLATED) Intended for use where the initiating contacts are being powered from a
supply other than the system supply. This isolated supply would be connected to "+VIN" and
“OV IN” terminals.
All connections to the above units are by screw type terminals.
REGULATOR Type REG-92 and REG-93
This unit is used in 6U logic boxes where the system supply is 24V DC.
It provides the 5V supply necessary for the 23 usable slots plus the CPU which equates to 128
inputs and 240 outputs including auxiliary cards to box capacity. Otherwise they are generally
as per REG-90/91.
REG-92 -(STANDARD)
REG-93 -(ISOLATED)
