Ametek 2003RP Owner's manual

March 2011 Document No. 4005-995 Rev N
Model 2003RP
AC Power Source
User and Programming
Manual
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email:
Domestic Sales: [e-mail]
International Sales: [e-mail]
Customer Service: [email protected]
Web: www.programmablepower.com

i
About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design
and manufacture of precision, programmable power supplies for R&D, test and measurement,
process control, power bus simulation and power conditioning applications across diverse
industrial segments. From bench top supplies to rack-mounted industrial power subsystems,
AMETEK Programmable Power is the proud manufacturer of Elgar, Sorensen, California
Instruments and Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromechanical
devices with annualized sales of $2.5 billion. The Company has over 11,000 colleagues working
at more than 80 manufacturing facilities and more than 80 sales and service centers in the United
States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc.
Other trademarks, registered trademarks, and product names are the property of their respective
owners and are used herein for identification purposes only.
Notice of Copyright
AC Power Source, User and Programming Manual © 2010 AMETEK Programmable Power, Inc. All
rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE POWER, INC.
(“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED AMETEK CONTENT
IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION, WHICH IS POSTED AT
WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
March 2011 Revision N
Part Number
4005-995
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email: [e-mail]
[e-mail]
Web: www.programmablepower.com

ii
This page intentionally left blank.

iii
Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your
particular application.
WARNING
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
WARNING
The equipment used contains ESD sensitive ports. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform
installation and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any
cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis.
However, depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO
HUMAN SAFETY may be normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety hazards and that any
inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the
electrical circuits. Even when power is off, capacitors may retain an electrical charge. Use safety
glasses during open cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary
sales organizations can accept any responsibility for personnel, material or inconsequential injury,
loss or damage that results from improper use of the equipment and accessories.
SAFETY SYMBOLS

iv
Product Family: California Instruments Model 2003RP
Warranty Period: One Year
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the
Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in
material or workmanship within the applicable warranty period stated above, then AMETEK may,
at its option: repair or replace the Product; or issue a credit note for the defective Product; or
provide the Buyer with replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in
accordance with the return procedure specified below. AMETEK will, at its expense, deliver the
repaired or replaced Product or parts to the Buyer. Any warranty of AMETEK will not apply if the
Buyer is in default under the Purchase Order Agreement or where the Product or any part
thereof:
is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
is installed or operated contrary to the instructions of AMETEK;
is opened, modified or disassembled in any way without AMETEK’s consent; or
is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty
until the Buyer has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
1. Request a Return Material Authorization (RMA) number from the repair facility (must be
done in the country in which it was purchased):
In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: [phone], ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
Outside the United States, contact the nearest Authorized Service Center
(ASC). A full listing can be found either through your local distributor or our
website, www.programmablepower.com, by clicking Support and going to the
Service Centers tab.
2. When requesting an RMA, have the following information ready:
Model number
Serial number
Description of the problem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to
an evaluation fee and applicable freight charges.

Table of Contents
1Introduction.....................................................................................................................................1
1.1 General Description...............................................................................................................................1
1.2 Accessory Equipment/Rack Slides........................................................................................................1
2Specifications.................................................................................................................................2
2.1 Electrical................................................................................................................................................2
2.2 Supplemental.........................................................................................................................................5
2.3 Measurements [Option] .........................................................................................................................6
2.4 System Specification.............................................................................................................................7
2.5 Unit Protection.......................................................................................................................................8
2.6 Mechanical ............................................................................................................................................8
2.7 Environmental........................................................................................................................................9
2.8 Regulatory.............................................................................................................................................9
2.9 Front Panel Controls............................................................................................................................10
2.10 Available Options.............................................................................................................................11
3Installation and Functional Test ...................................................................................................12
3.1 Unpacking............................................................................................................................................12
3.2 Power Requirements...........................................................................................................................12
3.3 Input Voltage Range Selection............................................................................................................14
3.4 Mechanical Installation ........................................................................................................................17
3.5 Input Wiring.........................................................................................................................................17
3.6 Output Connections.............................................................................................................................18
3.7 Output Voltage Ranges .......................................................................................................................20
3.8 Functional Test....................................................................................................................................21
3.9 Other Modes of Operation...................................................................................................................22
4Front Panel Operation..................................................................................................................23
4.1 Functional Controls..............................................................................................................................23
4.2 How to examples.................................................................................................................................28
4.3 Setting the Power on Initialization Values ...........................................................................................31
4.4 Current Limit Modes............................................................................................................................32
4.5 Function Strobe [Option]......................................................................................................................32
4.6 Remote Inhibit [Option]........................................................................................................................33
5Principle of Operation...................................................................................................................34
5.1 General................................................................................................................................................34
5.2 Overall Description..............................................................................................................................34
5.3 DC Supply ...........................................................................................................................................34
5.4 Mother Board.......................................................................................................................................39
5.5 Amplifier Modules................................................................................................................................39
5.6 Oscillator Module.................................................................................................................................39
5.7 Range/Relay Board .............................................................................................................................39
5.8 Output Board .......................................................................................................................................40
5.9 IEEE 488/RS232 Interface [Option].....................................................................................................40
6Calibration....................................................................................................................................42
6.1 Calibration Equipment .........................................................................................................................42
6.2 Selecting Calibration Mode..................................................................................................................43
6.3 Routine Calibration..............................................................................................................................44
6.4 Non-Routine Calibration ......................................................................................................................48

7Service......................................................................................................................................... 52
7.1 General ............................................................................................................................................... 52
7.2 Cleaning.............................................................................................................................................. 52
7.3 Basic Operation................................................................................................................................... 52
7.4 Module Removal ................................................................................................................................. 55
7.5 Replaceable Parts............................................................................................................................... 58
8Remote Control............................................................................................................................ 60
8.1 Introduction ......................................................................................................................................... 60
8.2 PGUI32 Program Requirements ......................................................................................................... 60
8.3 IEEE Interface.....................................................................................................................................62
8.4 RS232C Interface................................................................................................................................63
8.5 PGUI32 Setup and Installation............................................................................................................ 65
8.6 Troubleshooting - RS232C.................................................................................................................. 67
8.7 Troubleshooting - IEEE-488 / GPIB .................................................................................................... 70
8.8 PGUI32 Distribution Files....................................................................................................................72
8.9 Software Registration.......................................................................................................................... 73
9Introduction to SCPI..................................................................................................................... 74
9.1 Conventions Used in This Manual ...................................................................................................... 74
9.2 The SCPI Commands and Messages................................................................................................. 74
9.3 Using Queries .....................................................................................................................................76
9.4 Structure of a SCPI Message.............................................................................................................. 76
9.5 SCPI Data Formats.............................................................................................................................79
9.6 Bus Throughput and Timing Considerations.......................................................................................79
10 SCPI Command Reference...................................................................................................... 80
10.1 Subsystem Commands................................................................................................................... 80
10.2 Calibration Subsystem .................................................................................................................... 81
10.3 Measurement Subsystem ...............................................................................................................85
10.4 Instrument Subsystem .................................................................................................................... 88
10.5 Source Subsystem.......................................................................................................................... 89
10.6 Output Subsystem...........................................................................................................................92
10.7 Limit Subsystem.............................................................................................................................. 96
10.8 Display Subsystem.......................................................................................................................... 97
10.9 System Commands......................................................................................................................... 98
10.10 Common Commands .................................................................................................................... 100
11 Programming Examples......................................................................................................... 106
11.1 Introduction ................................................................................................................................... 106
11.2 Bus Throughput and Timing Considerations.................................................................................106
11.3 Making Measurements..................................................................................................................108
12 Status Registers..................................................................................................................... 110
12.1 Power-On Conditions.................................................................................................................... 110
12.2 Standard Event Status Group .......................................................................................................111
12.3 Status Byte Register ..................................................................................................................... 111
12.4 Examples ...................................................................................................................................... 112
Appendix A : SCPI Command tree.................................................................................................... 113
Appendix B : SCPI Conformance Information................................................................................... 114
Appendix C : Error Messages ........................................................................................................... 115
Index.................................................................................................................................................. 116

List of Figures
Figure 2-1: Available RMS Current as function of Output Voltage and Frequency..............................4
Figure 2-2: Rack Mount Slides (-RMS option) position.......................................................................11
Figure 3-1: Model 2003RP AC Power Source....................................................................................12
Figure 3-2: Rear Panel View ..............................................................................................................13
Figure 3-3: Internal Jumper Location, Input Line Voltage 107/115 ....................................................15
Figure 3-4: Internal Jumper Location, Input Line Voltage 208/230 .....................................................16
Figure 3-5: Rack Mount Slides (-RMS option) position.......................................................................17
Figure 3-6: Input and Output Wiring....................................................................................................19
Figure 3-7: Test Setup 2003RP...........................................................................................................22
Figure 4-1: Front Panel View...............................................................................................................23
Figure 4-2: Voltage Auto Range Switch Over Points..........................................................................25
Figure 4-3: Control Knob....................................................................................................................26
Figure 5-1: AC Power System Block Diagram ...................................................................................35
Figure 6-1: Test Equipment Hookup for Routine Output and Voltage Measurement Calibration ......44
Figure 6-2: Test Equipment Hook-up for Current and Power Measurement Calibration ...................45
Figure 6-3: Internal Adjustments ........................................................................................................50
Figure 7-1: Assembly Location...........................................................................................................56
Figure 8-1: Rear Panel View ..............................................................................................................61
Figure 8-2: GPIB Address Selection Switch.......................................................................................62
Figure 8-3: RS232C Interface Cable Wiring Diagram........................................................................65
Figure 8-4: System Properties Dialog Box .........................................................................................68
Figure 8-5: COM Port Properties Dialog Box .....................................................................................68
Figure 8-6: Advanced Port Settings Dialog Box.................................................................................68
Figure 8-7: NI AT-GPIB/TNT Settings................................................................................................70
Figure 8-8: NI AT-GPIB/TNT Advanced Settings Dialog....................................................................70
Figure 9-1: Partial Command Tree.....................................................................................................75
Figure 9-2: Command Message Structure.........................................................................................77
Figure 12-1: AC Source Status System Model.................................................................................110

List of Tables
Table 1-1: Available models.................................................................................................................. 1
Table 3-1: Maximum Output Wiring Lengths ...................................................................................... 19
Table 4-1: Factory Default Power on Settings.................................................................................... 31
Table 6-1: Load Resistors and Current.............................................................................................. 42
Table 6-2: CAL Mode Status LED Indicators ..................................................................................... 43
Table 7-1: Basic Symptoms ............................................................................................................... 52
Table 7-2: Poor Output Voltage Accuracy.......................................................................................... 52
Table 7-3: Poor Output Voltage Regulation ....................................................................................... 53
Table 7-4: Distorted Output................................................................................................................ 53
Table 7-5: Unit Shuts Down After 3-5 Seconds ................................................................................. 53
Table 7-6: No Output and No Lights on Front Panel.......................................................................... 53
Table 7-7: No Output But "Display" Is On ......................................................................................... 54
Table 7-8: Replaceable Parts............................................................................................................. 58
Table 7-9: Fuses ................................................................................................................................ 59
Table 10-1: Mode Command Encoding ............................................................................................. 97
Table 10-2: Bit Configuration of Standard Event Status Enable Register........................................ 101
Table 10-3: Bit Configuration of Standard Event Status Register.................................................... 102
Table 10-4: *RST Default Parameter Values................................................................................... 104
Table 10-5: Status Registers - Power on Conditions ........................................................................ 104
Table 10-6: Bit Configuration of Status Byte Register...................................................................... 105
Table 12-1: Bus Error Messages ..................................................................................................... 115

1 Introduction
This instruction manual contains information on the installation, operation, calibration and
maintenance of the 2003RP AC power source.
1.1 General Description
The 2003RP AC source is a high efficiency, lightweight, three-phase, 2000 VA,
programmable AC power source. In addition to the standard 2003RP model, several options
are available that may change the voltage and frequency ranges of the power source. This
user manual covers the following models:
Model
Voltage ranges
No. of
Outputs
Max.
Current
Frequency range
2003RP
135 VRMS
270 VRMS
3
5 ARMS
2.5 ARMS
16 Hz –5000 Hz
2003RP-AV1
Avionics version
115 VRMS
230 VRMS
3
5.9 ARMS
2.9 ARMS
360 Hz –5000 Hz
2003RP-HV
156 VRMS
312 VRMS
3
4.3 ARMS
2.1 ARMS
16 Hz –5000 Hz
Table 1-1: Available models
The output voltage terminals for each output phase are isolated from the chassis (earth)
ground. The nominal input can be either 107/115 VAC or 208/230 VAC at 50/60/400 Hz line
frequency.
Simple front panel controls enable the voltage, phase selection, current limit, and frequency
to be changed. An optional RS232C and IEEE 488 interface is available for applications that
require remote control and measurements. Settings are displayed for one output phase at a
time. The selected phase can be toggled between A, B, and C using the phase select key.
1.2 Accessory Equipment/Rack Slides
General Devices Company Model C300S-120-B308 rack slides may be attached to the sides
of the power source using 10-32 X 3/8 flat head screws.
12003RP-AV models may be factory configured with a single voltage range and fixed frequency output.

2 Specifications
All specifications at 25 5 C and 400 Hz output unless noted otherwise.
2.1 Electrical
Input
Parameter
Specification
Line Voltage:
107/120 VAC ± 10%
208/230 VAC ± 10%
Line Current:
35 ARMS maximum, line voltage = 96 VAC, full-load,
PF = 0.6, Efficiency = 75%, (typical)
Inrush Current:
185 APK at 253 VAC input line
Input power factor:
0.6 at full-load and 120 VAC input
Line Frequency1:
50/60 Hz ± 5%
Efficiency:
75% typical (depending on line and load)
Hold-Up Time:
10 ms (with no effect on output)
Isolation Voltage:
1350 VAC, input to chassis
2300 VAC, input to output
Output
Parameter
Specification
Outputs
Phases:
3
Mode:
AC
Coupling:
AC
Voltage
2003RP:
0 to 135 V or 0 to 270 V
(see Section 3.7)
2003RP-AV:
0 to 115 V or 0 to 230 V
or
0 to 115 V only (factory set)
2003RP-HV:
0 to 156 V or 0 to 312 V
(see Section 3.7)
Resolution:
0.1 volt
Accuracy1:
± 0.1% of full scale, 16 Hz - 100 Hz
± 0.2% of full scale, 100 Hz - 2000 Hz
Applies from 10 to 100% of voltage range.
1Supplementary specification applies outside indicated frequency ranges.

Parameter
Specification
Load Regulation1:
± 0.1% of full scale, 16 Hz - 500 Hz
External Sense:
Will compensate for up to 7% of voltage drop up to 2
kHz
Line Regulation:
± 0.02% of full scale
Settling time:
From start of voltage change from 5.0 VRMS or
higher voltage to within 2% of final value:
No load: 16 ms
Full load: 300 ms
(16 ms to within 15% of final value)
Distortion (THD
into linear load):
0.5% typical, 1.0% maximum below 100 Hz
1.0% typical, 2.0% maximum 100 Hz - 2000 Hz
DC Offset voltage:
AC coupled transformer output
Output noise:
< 0.1 VRMS typical
( 20 kHz to 1 MHz at full load )
Temperature
coefficient:
± 0.02% of full scale per degree C
Stability:
(24 hours)
± 0.015% of full scale under constant load, line and
temperature
Total Power:
2000 VA maximum at full scale voltage, either range
Current per Output Phase
2003RP:
2003RP-AV:
2003RP-HV
Volt Range
135
270
115
230
156
312
ARMS
5.0
2.5
5.9
2.9
4.3
2.1
APEAK
15.0
7.5
17.6
8.8
12.9
6.3
Adjustable Limit:
0.0 to Maximum available RMS current for selected
voltage range. Maximum current is available for
output voltage from 50% to 100% of range. Current
derates below 50% of range setting. See derating
chart.

Parameter
Specification
Frequency
2003RP:
2003RP-HV:
16.0 - 5000 Hz (see Figure 2-1)
Maximum output voltage available from 45 Hz and
up. Maximum voltage derates from 100% at 45 Hz
to 35% at 16 Hz.
2003RP-AV:
360.0 - 5000 Hz (see Figure 2-1)
Resolution:
0.01 Hz from 16.00 to 80.00 Hz
0.1 Hz from 80.1 Hz to 800.0 Hz
1 Hz from 801 Hz to 5000 Hz
Accuracy:
0.02% of programmed value
Temperature
coefficient:
± 5 ppm per degree Celsius
Stability:
± 15 ppm per year
Impedance
Steady State:
(voltage range * 0.0005) / load current.
Figure 2-1: Available RMS Current as function of Output Voltage and Frequency.

2.2 Supplemental
Note: Specifications listed below are typical and not guaranteed.
Parameter
Supplemental Specification
Line Frequency:
63 - 300 Hz (derate maximum output power 5%)
300 - 440 Hz (derate maximum output power 10%)
Output Voltage Accuracy
(versus output frequency):
± 1% of full scale (2000 - 4000 Hz),
± 5% of full scale (4000 - 5000 Hz)
Output Load Regulation
(versus output frequency):
± 2% (500 - 1000 Hz),
± 5% (1000 - 2000 Hz),
± 10% (2000 - 4000 Hz)
± 20% (4000 - 5000 Hz)
Measurement Accuracy:
Stated ± 5% of full scale (16 - 300 Hz),
Stated ± 1% of full scale (500 - 5000 Hz)

2.3 Measurements [Option]
Note: Specifications listed below apply from 300 Hz to 500 Hz. Refer to Supplemental
Specifications for frequencies outside this range.
Parameter
Specification
Unit
True RMS Current
Available on standard unit.
Ranges
0.000 - 4.000
0.00 –6.00
ARMS
ARMS
Accuracy
0.2 % FS + 0.3 % reading
Resolution
0.001
0.01
ARMS
ARMS
Peak Current
Ranges
(Remote only) 0.00 –12.00
0.0 –20.0
APEAK
APEAK
Accuracy
0.5 % FS + 0.5 % reading
Resolution
0.01
0.1
APEAK
APEAK
Crest Factor
Available over bus only. Requires interface option
Range
0.00 - 4.00
Accuracy
0.05
Resolution
0.01
True RMS Voltage
Range
0.0 - 320.0
VRMS
Accuracy
0.1 % FS + 0.05 % reading
Resolution
0.1
VRMS
Real Power
Range
0 - 800.0
W
Accuracy
0.2 % FS + 0.5 % reading
Resolution
0.2
W
Apparent Power
Available over bus only. Requires interface option
Range
0 - 800.0
VA
Accuracy
0.3 % FS + 0.8 % reading
Resolution
0.1
VA

Parameter
Specification
Unit
Power Factor
Range
0.00 - 1.00
Accuracy
0.05
Resolution
0.01
2.4 System Specification
Parameter
Specification
Setup storage
Eight non-volatile front panel setup registers available through
interface. Power-on setting register available from front panel.
Interface
(Option package -OP1 required)
RS-232C
Bi-directional serial interface
Handshake:
CTS, RTS
Data bits:
8
Stop bits:
1
Parity:
None
Baud rate:
19200
Command syntax:
IEEE 488.2 commands and SCPI
IEEE-488
GPIB Interface
IEEE address:
set using dip switch on rear panel from
0 to 31
IEEE functions:
SH1, AH1, T6, L3, RL2
Terminators:
LF, CRLF, EOI
Command syntax:
IEEE 488.2 commands and SCPI
Remote Inhibit
(Option package -OP1 required)
Input
Contact closure to ground or logic low TTL
signal required to turn off output.
Automatic recovery when RI signal is
removed.
Function Strobe
(Option package -OP1 required)
Output
Active low TTL signal. Signal driven low
for approximately 400 sec any time
output voltage or frequency programmed
value changes. Signal level may be
changed by removing jumpers to open
collector.

2.5 Unit Protection
Parameter
Specification
Input Overcurrent:
Circuit breaker
Transients:
Surge protection to withstand EN61000-4,-5 levels
Output Overcurrent:
Constant current operation (standard)
0.1 second shutdown (constant voltage mode option)
Output Short Circuit:
Peak current limit
Shutdown (constant voltage mode Option)
Overtemperature:
Automatic shutdown
2.6 Mechanical
Parameter
Specification
Dimensions:
Height
Width
Depth
Unit
13.26
48.26
56.62
cm
5.22
19
22.29
inch
Unit Weight:
2003RP
2003RP-AV
39 kg / 85 lb
34 kg / 76 lb
Material:
Steel chassis and panels
Aluminum cover
Finish:
Painted semi-gloss polyurethane
Cooling:
Fan cooled with air intake on sides and exhaust to rear
Internal Construction:
Modular subassemblies
Chassis Slides:
–RMS Option
General Devices Model C300S-120-B308 (CI P/N 211045)
Rear Panel Mounted Connectors:
Line Input
Marathon Special Products 985 GP 03
Output/Sense
Cinch 8-140Y
RS232C
9 pin D-subminiature
IEEE-488
GPIB standard 24 pin
Remote Inhibit
Isolated BNC (requires -OP1 option package)
Function Strobe
Isolated BNC (requires -OP1 option package)

2.7 Environmental
Parameter
Specification
Operating Temp:
0 to +40 C
Storage Temp:
-40 to +85 C
Humidity:
Maximum relative humidity 80% for temperatures up to 31 C
decreasing linearly to 50% relative humidity at 40 C
Altitude:
2000 m maximum
Pollution Degree:
2
Installation Category
(Overvoltage Category) :
II
indoor use only
Vibration:
Designed to meet NSTA 1A transportation levels
Shock:
Designed to meet NSTA 1A transportation levels
2.8 Regulatory
Parameter
Specification
Electromagnetic
Emissions and
Immunity:
Designed to meet EN50081-1 and EN50082-1 Emissions and
Immunity standards as required for CE marking
Acoustic Noise:
65 dBA maximum at 0% to 50% load
75 dBA maximum greater than 50% load to 100% load
(measured at one meter)
Safety:
Designed to meet EN61010-1 safety standard as required for CE
marking
Remote Control

2.9 Front Panel Controls
Parameter
Specification
Controls:
Knobs:
Two knobs allow continuous change of voltage, frequency and
current limit for all three phase outputs. Voltage change is
inactive on single voltage range configuration units.
Function keys:
Keys control output state, voltage range, 7 segment LED Display
mode and selected phase for liquid crystal display.
Displays:
Two, 4 digit, 0.5” 7 segment LED:
For viewing programmed voltage, frequency, current limit for all
phases or for displaying measured current on selected phase.
Status Indicators:
13 LED‟s:
HIGH (voltage range)
AUTO (voltage range)
FREQ (frequency display)
I RMS (rms current display)
I PK (peak current display)
PWR (power display)
PF (power factor display)
A (phase selected for display)
B (phase selected for display)
C (phase selected for display)
FAULT (of output voltage)
REMOTE (interface active)
OUTPUT (on, relay closed)
(refer also to paragraph 4.1.1)
Phase Selection:
The phase selection and indication applies to the measurement
readouts only. Settings of voltage, frequency and current made
using the rotary knobs apply to all three phases.
