Ametek Sorensen XFR 1200 Watt Series User manual

TM-F1OP-C1XN Rev C www.programmablepower.com
XFR 1200 Watt Series
Programmable DC
Power Supply
Operation Manual
XFR 6-200
XFR 7.5-140
XFR 12-100
XFR 20-60
XFR 35-35
XFR 40-30
XFR 60-20
XFR 100-12
XFR 150-8
XFR 300-4
XFR 600-2

About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design
and manufacture of precision, programmable power supplies for R&D, test and measurement,
process control, power bus simulation and power conditioning applications across diverse
industrial segments. From bench top supplies to rack-mounted industrial power subsystems,
AMETEK Programmable Power is the proud manufacturer of Elgar, Sorensen, California
Instruments and Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromechanical
devices with annualized sales of $2.5 billion. The Company has over 11,000 colleagues working
at more than 80 manufacturing facilities and more than 80 sales and service centers in the United
States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc. Sorensen is a trademark owned by AMETEK,
Inc. Other trademarks, registered trademarks, and product names are the property of their
respective owners and are used herein for identification purposes only.
Notice of Copyright
XFR 1200 Watt Series Programmable DC Power Supply Operation Manual © 2007 AMETEK
Programmable Power, Inc. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE POWER, INC.
(“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED AMETEK CONTENT
IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION, WHICH IS POSTED AT
WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
February 2009 Revision C
Part Number
TM-F1OP-C1XN
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email: [e-mail]
[email protected]
Web: www.programmablepower.com
i

This page intentionally left blank.
ii

Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your
particular application.
WARNIN
G
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
WARNIN
G
The equipment used contains ESD sensitive parts. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform
installation and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any
cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis.
However, depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO
HUMAN SAFETY may be normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety hazards and that any
inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the
electrical circuits. Even when power is off, capacitors may retain an electrical charge. Use safety
glasses during open cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary
sales organizations can accept any responsibility for personnel, material or inconsequential injury,
loss or damage that results from improper use of the equipment and accessories.
SAFETY SYMBOLS
iii

This page intentionally left blank.
iv

Product Family: XFR 1200 Watt Series Programmable DC Power Supply
Warranty Period: Five Years
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the
Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in
material or workmanship within the applicable warranty period stated above, then AMETEK may,
at its option: repair or replace the Product; or issue a credit note for the defective Product; or
provide the Buyer with replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in
accordance with the return procedure specified below. AMETEK will, at its expense, deliver the
repaired or replaced Product or parts to the Buyer. Any warranty of AMETEK will not apply if the
Buyer is in default under the Purchase Order Agreement or where the Product or any part
thereof:
• is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
• is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
• is installed or operated contrary to the instructions of AMETEK;
• is opened, modified or disassembled in any way without AMETEK’s consent; or
• is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty
until the Buyer has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
1. Request a Return Material Authorization (RMA) number from the repair facility (must be
done in the country in which it was purchased):
• In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: [phone], ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
• Outside the United States, contact the nearest Authorized Service Center
(ASC). A full listing can be found either through your local distributor or our
website, www.programmablepower.com, by clicking Support and going to the
Service Centers tab.
2. When requesting an RMA, have the following information ready:
• Model number
• Serial number
• Description of the problem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to
an evaluation fee and applicable freight charges.
v

This page intentionally left blank.
vi

TM-F1OP-C1XN-01 vii
Important Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - v
1 Introduction
Description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–2
Features and Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–3
Front Panel Controls- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–3
Rear Panel Connectors and Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–5
Rear Panel SW1 Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–7
Resetting the Switches - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–8
Rear Panel J2 Connector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–8
Making J2 Connections - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1–10
Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–11
2 Installation
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–2
Basic Setup Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–2
Inspection, Cleaning, and Packaging- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–3
Initial Inspection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–3
Periodic Cleaning - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–3
Returning Power Supplies to the Manufacturer- - - - - - - - - - - - - - - - - - - - - - - - - -2–3
Return Material Authorization Policy - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–3
Packaging for Shipping or Storage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–5
Location, Mounting, and Ventilation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–6
Rack Mounting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–6
Ventilation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–6
AC Input Power Connection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–7
AC Input Connector and Voltage Selection - - - - - - - - - - - - - - - - - - - - - - - - - -2–7
Auto Range Select - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–7
AC Fail LED - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–8
AC Input Cord - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–8
AC Input Wire Connection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–9
Functional Tests - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–11
Equipment Required - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–11
Contents
TM-F1OP-C1XN-01.book Page vii Thursday, October 25, 2007 9:04 PM

Contents
viii TM-F1OP-C1XN-01
Power-on Check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–11
Voltage Mode Operation Check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–12
Current Mode Operation Check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–12
Front Panel Function Checks - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–13
Load Connection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14
Load Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14
Insulation Rating - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14
Current Carrying Capacity - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14
Load Wiring Length for Operation with Sense Lines - - - - - - - - - - - - - - - 2–15
Noise and Impedance Effects - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–16
Making Load Connections - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–16
6 V to 40 V Models - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–17
60 V to 600 V Models - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–19
Inductive Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–20
Connecting Single Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–21
Connecting Multiple Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–22
Parallel Power Distribution - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–22
Radial Power Distribution Method - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–22
Local and Remote Sensing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–24
Sense Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–24
Local Sensing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–25
Using Remote Sensing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–26
3 Local Operation
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Standard Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Operating Modes and Automatic Crossover - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Constant Voltage Mode Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Constant Current Mode Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Automatic Mode Crossover - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Shipped Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–5
Setting Output Voltage and Current Limit - - - - - - - - - - - - - - - - - - - - - - - - - - 3–6
Using Over Voltage Protection (OVP) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Front Panel OVP Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Resetting the OVP Circuit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–8
Using the Shutdown Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–9
STANDBY Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–9
TM-F1OP-C1XN-01.book Page viii Thursday, October 25, 2007 9:04 PM

Contents
TM-F1OP-C1XN-01 ix
Controlling the Shutdown Function via the J2 Connector - - - - - - - - - - - - - - - -3–9
Using Multiple Supplies - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3–11
Configuring Multiple Supplies for Series Operation - - - - - - - - - - - - - - - - - - -3–12
Configuring Multiple Supplies for Parallel Operation - - - - - - - - - - - - - - - - - -3–13
Sensing for Parallel Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3–13
Configuring Multiple Supplies for Split Supply Operation - - - - - - - - - - - - - -3–14
Over Temperature Protection (OTP) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3–16
4 Remote Operation
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -4–2
Remote Analog Programming of Output Voltage and Current Limit - - - - - - - - - - -4–3
Remote Programming Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -4–3
Remote Analog Programming Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - -4–3
Remote Monitoring of Output Voltage and Current- - - - - - - - - - - - - - - - - - - - - - -4–7
Readback Signals - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -4–7
5 Calibration and Troubleshooting
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–2
Calibration Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–2
Service Environment and Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–2
Equipment Required - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–2
Accessing Calibration Potentiometer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–3
Removing Option Card - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–3
Calibrating for Programming Accuracy - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–5
Voltage Programming Circuit Calibration - - - - - - - - - - - - - - - - - - - - - - - - - - -5–5
Current Limit Programming Circuit Calibration - - - - - - - - - - - - - - - - - - - - - - -5–6
Calibrating for Readback Accuracy- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–6
Output Voltage Monitor Circuit Calibration - - - - - - - - - - - - - - - - - - - - - - - - -5–7
Output Current Monitor Circuit Calibration - - - - - - - - - - - - - - - - - - - - - - - - -5–8
User Diagnostics - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–9
Emergency Shutdown - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–9
Unusual or Erratic Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–9
Troubleshooting for Operators - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5–10
TM-F1OP-C1XN-01.book Page ix Thursday, October 25, 2007 9:04 PM

Contents
x TM-F1OP-C1XN-01
A Specifications
Electrical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–2
Additional Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–6
Input Conditions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–6
Additional Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–8
Remote Programming and Monitoring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–9
Environmental Specification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A–10
Mechanical Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A–11
Warranty and Return Information - - - - - - - - - - - - - - - - - - - - - - - - - - - WA–1
TM-F1OP-C1XN-01.book Page x Thursday, October 25, 2007 9:04 PM

TM-F1OP-C1XN-01 xi
Figure 1-1 Power Supply Front Panel- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4
Figure 1-2 Power Supply Rear Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–5
Figure 1-3 Programming and Monitoring SW1 Switch - - - - - - - - - - - - - - - - - - - - - 1–7
Figure 1-4 Programming and Monitoring J2 Connector- - - - - - - - - - - - - - - - - - - - - 1–9
Figure 2-1 Shipping or Storage Carton Label- - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–6
Figure 2-2 AC Input Cover and Strain Relief- - - - - - - - - - - - - - - - - - - - - - - - - - - 2–10
Figure 2-3 Maximum Load Wire Length for 1 V Line Drop- - - - - - - - - - - - - - - - - 2–15
Figure 2-4 Bus Bar Shield - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–17
Figure 2-5 Typical Load Connection Hardware - - - - - - - - - - - - - - - - - - - - - - - - - 2–18
Figure 2-6 Output Voltage Connector with Shield - - - - - - - - - - - - - - - - - - - - - - - 2–20
Figure 2-7 Single Load with Local Sensing (Default) - - - - - - - - - - - - - - - - - - - - - 2–21
Figure 2-8 Single Load with Remote Sensing - - - - - - - - - - - - - - - - - - - - - - - - - - 2–21
Figure 2-9 Multiple Loads with Local Sensing - - - - - - - - - - - - - - - - - - - - - - - - - 2–23
Figure 2-10 Multiple Loads with Remote Sensing- - - - - - - - - - - - - - - - - - - - - - - - 2–23
Figure 2-11 J10 Sense Connector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–25
Figure 2-12 Connecting Remote Sense Lines - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–27
Figure 3-1 Operating Modes- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Figure 3-2 Series Operation of Multiple Supplies- - - - - - - - - - - - - - - - - - - - - - - - 3–12
Figure 3-3 Parallel Operation of Multiple Supplies- - - - - - - - - - - - - - - - - - - - - - - 3–13
Figure 3-4 Split Supply Operation of Multiple Supplies - - - - - - - - - - - - - - - - - - - 3–14
Figure 3-5 Split Supply Operation of Multiple Supplies - - - - - - - - - - - - - - - - - - - 3–15
Figure 4-1 Connecting Programming Sources to J2 Connector- - - - - - - - - - - - - - - - 4–5
Figure 5-1 Programming and Monitoring Calibration Locations- - - - - - - - - - - - - - - 5–4
Figure A-1 Typical Input Current Characteristics, 85-130 Vac Range - - - - - - - - - - - A–7
Figure A-2 Typical Input Current Characteristics, 190-264 Vac Range- - - - - - - - - - - A–7
Figure A-3 Current Derating for Rack Mounted 6 V Models - - - - - - - - - - - - - - - - A–10
Figure A-4 Dimensional Drawings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–12
Figures
TM-F1OP-C1XN-01.book Page xi Thursday, October 25, 2007 9:04 PM

xii
TM-F1OP-C1XN-01.book Page xii Thursday, October 25, 2007 9:04 PM

TM-F1OP-C1XN-01 xiii
Table 1-1 Available Voltage and Current Ranges - - - - - - - - - - - - - - - - - - - - - - - - 1–2
Table 1-2 Rear Panel SW1 Switch Assignments - - - - - - - - - - - - - - - - - - - - - - - - - 1–7
Table 1-3 Rear Panel J2 Connector Terminals and Functions - - - - - - - - - - - - - - - - 1–9
Table 2-1 Basic Setup Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Table 2-2 Operational AC Input Voltage Ranges and Frequency - - - - - - - - - - - - - - 2–8
Table 2-3 AC Wire Specification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–8
Table 2-4 Current Carrying Capacity for Load Wiring- - - - - - - - - - - - - - - - - - - - 2–15
Table 2-5 Rear Panel J10 Sense Connector Terminals and Functions - - - - - - - - - - 2–25
Table 3-1 Shipped Configuration (Local Control Mode) - - - - - - - - - - - - - - - - - - - 3–5
Table 3-2 Switch Settings for Shutdown Circuit Logic- - - - - - - - - - - - - - - - - - - - 3–10
Table 3-3 Switch Settings for Over Temperature Recovery Options- - - - - - - - - - - 3–16
Table 4-1 Remote Programming Options- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–3
Table 4-2 Power Supply Settings for Different Programming Sources - - - - - - - - - - 4–6
Table 4-3 Settings for Remote Monitoring of Readback Signals - - - - - - - - - - - - - - 4–7
Table 5-1 User Diagnostics - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5–10
Table A-1 Electrical Specifications for 6 V to 35 V Models - - - - - - - - - - - - - - - - - A–2
Table A-2 Electrical Specifications for 40 V to 600 V Models- - - - - - - - - - - - - - - - A–4
Tables
TM-F1OP-C1XN-01.book Page xiii Thursday, October 25, 2007 9:04 PM

xiv
TM-F1OP-C1XN-01.book Page xiv Thursday, October 25, 2007 9:04 PM

1Introduction
Chapter 1 describes the XFR 1200 Watt Series
Programmable DC Power Supply and lists the features.
TM-F1OP-C1XN-01.book Page 1 Thursday, October 25, 2007 9:04 PM

Introduction
1-2 TM-F1OP-C1XN-01
Description
This series of power supplies provides low-noise, precisely regulated,
variable DC output at 1200 Watts of output power. Over voltage
protection (OVP) and thermal shutdown are standard. Front panel
controls and indicators are extensive. Select from several remote control
choices: standard analog programming, optional isolated programming or
readback, and optional GPIB programming or RS-232 control. Remote
monitoring of output voltage and currents is a standard feature. Use this
power supply either on your bench or in a standard 19 in. (483 mm) rack:
the power supply occupies only 1.75 in. (1 U) of vertical rack space.
Designed for continuous use in standalone or systems applications, this
power supply is typically used to power DC equipment, control magnets,
or burn in components. See Table 1-1 for the list of available models.
Table 1-1 Available Voltage and Current Ranges
Model Voltage Range Current Range
6–200 0–6 V 0–200 A
7.5–140 0–7.5 V 0–140 A
12–100 0–12 V 0–100 A
20–60 0–20 V 0–60 A
35–35 0–35 V 0–33 A
40–30 0–40 V 0–30 A
60–20 0–60 V 0–20 A
100–12 0–100 V 0–12 A
300–4 0–300 V 0–4 A
600–2 0–600 V 0–2 A
TM-F1OP-C1XN-01.book Page 2 Thursday, October 25, 2007 9:04 PM
