Ametek SDT User manual

www.ametekusg.com
Ametek Model SDT
Submersible Pressure Transmitter
Installation and Operation Manual
K796471 REV B 9/15

User Manual
2
Model SDT Submersible Level Transmitter
AMETEK MODEL SDT
SUBMERSIBLE PRESSURE TRANSMITTER
INSTRUCTIONS FOR INSTALLATION, SERVICE AND PARTS
K796471 REV A 01/10/07
SPECIFICATIONS
PRESSURE CODE 0001 0-1PSI (0-0.07BAR), 2.31 ft WATER (0.7 m)
0002 0-2PSI (0-0.14BAR), 4.62 ft WATER (0.14 m)
0003 0-3PSI (0-0.21BAR), 6.92 ft WATER (2.1 m)
0004 0-4PSI (0-0.27BAR), 9.23 ft WATER (2.8 m)
0006 0-6PSI (0-0.4BAR), 13.8 ft WATER (4.2 m)
0015 0-15PSI (0-1BAR), 34.6 ft WATER (10.5 m)
0030 0-30PSI (0-2BAR), 69.2 ft WATER (21.1 m)
0060 0-60PSI (0-4BAR), 138.4 ft WATER (42.2 m)
0100 0-100PSI (0-7BAR), 230.7 ft WATER (70.3 m)
0150 0-150PSI (0-10BAR), 346.1 ft WATER (105.5 m)
PRESSURE RANGE UP TO 150 PSIG 0-1 PSI 0-2 PSI 0-3 PSI 0-4 PSI 0-6 PSI
ACCURACY AT 25º C INCLUDING
LINEARITY (BFSL), HYSTERESIS,
REPEATABILITY
±0.2% FS
TYPICAL;
±0.3% FS MAX
±1% FS MAX ±0.5% FS MAX ±0.5% FS MAX ±0.5% FS MAX ±0.5% FS MAX
1 YR. STABILITY <0.25% FS <1% FS <1% FS <1% FS <0.75% FS <0.5% FS
LOAD LIMITATION 50K OHM MIN (ALL VOLTAGE OUTPUTS) 600 OHM MAX (4-20MA)
OPERATING TEMPERATURE -25 TO 60º C (-13 TO 140º F)
COMPENSATED TEMPERATURE -25 TO 60º C (-13 TO 140º F)
TOTAL ERROR BAND
(INCLUDES TEMPERATURE
EFFECTS, ZERO & SPAN SET)
±1% FS ±2.5% FS ±2.5% FS ±2.5% FS ±2% FS ±1.5% FS
BURST PRESSURE 3XFS
VIBRATION 10G, 55 – 2000 HZ
SHOCK 30G
WETTED MATERIALS 316L STAINLESS STEEL, CABLE & SEAL AS SELECTED BELOW, DELRIN
PROCESS CONNECTION 1/4 – 18 NPT MALE WITH DELRIN THREAD PROTECTOR
ELECTRICAL CONNECTION 24 AWG, 6 CONDUCTOR CABLE, (SPECIFY LENGTH)
(CABLE MUST BE VENTED TO DRY ENVIRONMENT)
TEMPERATURE MEASUREMENT LM335AZ (BLUE-CATHODE; BROWN-ANODE)
SELECT TEMPERATURE OPTION CODE "T"
Specications

User Manual
3
TEMPERATURE MEASUREMENT OPTION
T = YES
LEAVE BLANK = NO
CABLE SEAL
V = VITON
N = NEOPRENE
FILL FLUID
S = SILICONE OIL (STANDARD)
DIAPHRAGM MATERIAL
L = 316L STAINLESS STEEL
ELECTRICAL CONNECTION OPTION
N = POLYURETHANE CABLE (K515136)/NUT
R = POLYURETHANE CABLE (K515136)/NUT/CABLE SUPPORT BRACKET
C = POLYURETHANE CABLE (K515136)/CONDUIT ADAPTER
E = POLYURETHANE CABLE (K515136)/EMI/NUT
F = POLYURETHANE CABLE (K515136)/EMI/CABLE SUPPORT BRACKET
G = POLYURETHANE CABLE (K515136)/EMI/CONDUIT ADAPTER
O = POLYOLEFIN CABLE (K515101)/NUT
Y = POLYOLEFIN CABLE (K515101)/NUT/CABLE SUPPORT BRACKET
W = POLYOLEFIN CABLE (K515101)/CONDUIT ADAPTER
T = TEFLON CABLE (K515075)/NUT
S = TEFLON CABLE (K515075)/NUT/CABLE SUPPORT BRACKET
V = TEFLON CABLE (K515075)/CONDUIT ADAPTER
X = TEFLON CABLE (K515075)/EMI/CONDUIT ADAPTER
PRESSURE CODE
XXXX = PRESSURE RANGE (PSI)
BXXX = PRESSURE RANGE (BAR)
INPUT/OUTPUT
B = 11-30 VDC / 4-20 MA
C = 9-30VDC / 1-6VDC
D = 9-30VDC / 1-5VDC
E = 9-30VDC / 0.5-4.5VDC
F = 9-30VDC / 0-5VDC
G = 5VDC / 0.8-3.2VDC (RATIOMETRIC FROM 4.75 TO 5.25VDC INPUT)
H = 5VDC / 1-6VDC (RATIOMETRIC FROM 4.75 TO 5.25VDC INPUT)
J = 9-30VDC / 0.25-2.75VDC
R = 5VDC / 1-6VDC (RATIOMETRIC FROM 4.75 TO 5.25VDC INPUT)
SENSING PORT
S = DELRIN SNUBNOSE
SDT - SUBMERSIBLE DIGITAL TRANSDUCER
SDT S B 0015 N L S V T
Model Number And Ordering Information
EXAMPLE: To specify the Model SDT Submersible Transmitter with 11-30V Input
and 4-20mAOutput, having to measure 15psi (34.6 Ft water), with a standard nut
and polyurethane cable & electrical connection, 316 stainless steel diaphragm,
silicone oil fill, Viton grommet and 100 feet of cable: SDTSB0015NLSV (100ft cable)
NOTES:
1) Cable Termination side should be located in a dry termperature
stable environment.
2) Damage will result if submerged in frozen liquid.
3) A fused or crrent limited DC power source is recommended
to prevent damage during fault conditions.
4) Shield is tied to case on EMI versions only
5) Additional pressure ranges are available, consult factory.
Notes:
1) Cable Termination side should be located in a dry temperature stable environment.
2) Damage will result if submerged in frozen liquid.
3) A fused or current limited DC power source is recommended to prevent damage during fault conditions.
4) Shield is tied to case on EMI versions only
5) Additional pressure ranges are available, consult factory.
Example: To specify the Model SDT Submersible Transmitter with 11-30V Input and 4-20mA Output having to
measure 15psi (34.6 ft/water) with a standard nut and polyurethane cable & electrical connection, 316ss Dia-
phragm, silicon oil fi ll, Viton grommet and 100 ft of cable: SDTSB0015NLSV (100ft cable)
WIRE LEGEND
COLOR
TEFLON
COLOR POLY-
URETHANE/
POLYOLEFIN
VOLTAGE
OUTPUT
CURRENT
(R-20MA)
OUTPUT
RED RED +Vin +Vin
BLACK BLACK –Vin –Vin
WHITE WHITE Vout N/A
GREEN GREEN CASE GROUND
BLUE BLUE
TEMPERATURE
ORANGE BROWN
STANDARD PRESSURE RANGES*
PSI BAR Reference Equivalents
0001 B0.2 0-2.31 ft water 0-0.7 m water
0006 B0.4 0-13.8 ft water 0-4.2 m water
0015 B001 0-34.6 ft water 0-10.5 m water
0030 B002 0-69.2 ft water 0-21.1 m water
0060 B004 0-138 ft water 0-42.2 m water
0100 B007 0-230 ft water 0-70.3 m water
0150 B010 0-345 ft water 0-105.4 m water

User Manual
4
Model SDT Transmitter Installation
CAUTION: Remove power before installing or
servicing. To install the Model SDT Transmitter,
connect the surface end of the cable to the Ametek
Model DMC Meter Controller or other power source
and indicator. Suspend the transmitter into a well
or tank supported only by its attached shielded
electronic cable. Insure that the opening in the well
or tank cover is large enough for possible future
removal of the transmitter.
Additional support to the transmitter is available
with an optional factory installed cable support. The
optional cable support is recommended when using
longer lengths of cable or when suspending the
transmitter into agitated liquids. The cable support
provides strain relief for the excess stress found
under these circumstances. See diagram of Model
SDT Transmitter with cable support using customer
supplied and installed support cable.
CAUTION - The cable grommet and support are
specially installed by factory-trained personnel to
insure watertightness. Any adjustment or removal
of these items may destroy the watertight feature
thus exposing the transmitter to water seepage,
an electrical short and transmitter failure. Any
adjustment or removal of the cable grommet or
cable support voids the warranty.
CAUTION - Waterproof cable should not be kinked
or nicked, this would allow water into the electronics
housing. Permanent damage will result. (Never cut
or splice the waterproof cable). The surface end
of the cable is used as the system’s atmospheric
reference, this end should not be sealed. Vent to dry
temperature stable environment.
External surge or lightning protectors are available
as optional items and are strongly recommended
for increased protection from secondary surges
or lightning strikes. The units are easy to install,
are maintenance-free and respond in less than
one nanosecond. Install in accordance with the
instructions:
1. Lightning protection devices should be placed
as close to the instrument as possible and
wired in accordance with National Electric
Code in an approved watertight enclosure.
2. If the distance between the meter and transmitter,
or the meter and recorder is less than 100 feet,
only 1 protector per line may be used.
3. Use No. 10 AWG ground wire or better from
protector to earth ground.
4. Provide a separate ground for each run of
shielded cable or metal conduit.
5. Keep the ground wire less than 1 foot long
and tie to a suitable ground rod or metal frame
ground. Surge capability is only as good as
the grounding method. All ground connections
must be installed.
6. Install all protectors in weathertight enclosures.
7. Run signal lines shielded and away from power
lines.
8. Wire according to the Electrical Code.
9. When used for an intrinsically safe installation,
only one LMA912 should be installed in the haz-
ardous location. Do not substitute protector types.
Caution - This or any installation cannot protect
against a direct lightning strike, or secondary
strikes of sufficient magnitude. Ametek cannot
accept liability for damage due to lightning or
secondary surges.
SURGE OR LIGHTNING PROTECTION
WARNING: Remove power before installing or servic-
ing.
To install the Model SDT Transmitter, connect the sur-
face end of the cable to the Ametek Model DMC Meter
Controller or other power source and indicator. Suspend
the transmitter into a well or tank supported only by its at-
tached shielded electronic cable. Insure that the opening in
the well or tank cover is large enough for possible future
removal of the transmitter.
Additional support to the transmitter is available with
an optional factory installed cable support. The optional
cable support is recommended when using longer lengths
of cable or when suspending the transmitter into agitated
liquids. The cable support provides strain relief for the
excess stress found under these circumstances. See dia-
gram of Model SDT Transmitter with cable support using
customer supplied and installed support cable.
Caution - The cable grommet and support are special-
ly installed by factory-trained personnel to insure wa-
tertightness. Any adjustment or removal of these items
may destroy the watertight feature thus exposing the
transmitter to water seepage, an electrical short and
transmitter failure. Any adjustment or removal of the
cable grommet or cable support voids the warranty.
Caution - Waterproof cable should not be kinked or
nicked. This may allow water into the electronics hous-
ing. Permanent damage will result. (Never cut or splice
the waterproof cable). The surface end of the cable is
used as the system’s atmospheric reference. This end
should not be sealed. Vent to dry temperature stable
environment.
MODEL SDT TRANSMITTER INSTALLATION
HOUSING COVER
ALLOW SLACK IN
ELECTRICAL CABLE
APPROXIMATE DISTANCE
TO FIRST WIRE TIE
CUSTOMER SUPPLIED AND INSTALLED
SUPPORT CABLE WITH TIES AT
REGULAR INTERVALS
USE PLASTIC TIE WRAPS
TO PREVENT CUTTING INTO
THE WATERPROOF SHEATH
OF THE CABLE
12.00
MODEL SDT WITH CABLE SUPPORT OPTION
Surge or lightning protectors are available as optional
items and are strongly recommended for protection from
secondary surges or lightning strikes. The units are easy to
install, are maintenance-free and respond in less than one
nanosecond. Install in accordance with the instructions:
1. Lightning protection devices should be placed as close
to the instrument as possible and wired in accordance with
National Electric Code in an approved watertight enclo-
sure.
2. If the distance between the meter and transmitter, or the
meter and recorder is less than 100 feet, only 1 protector
per line may be used.
3. Use No. 10 AWG ground wire or better from protector
to earth ground.
4. Provide a separate ground for each run of shielded
cable or metal conduit.
5. Keep the ground wire less than 1 foot long and tie to a
suitable ground rod or metal frame ground. Surge capabil-
ity is only as good as the grounding method. All ground
connections must be installed.
6. Install all protectors in weathertight enclosures.
7. Run signal lines shielded and away from power lines.
8. Wire according to the Electrical Code.
9. When used for an intrinsically safe installation, only
one LMA912 should be installed in the hazardous loca-
tion. Do not substitute protector types.
Caution - This or any installation cannot protect against
a direct lightning strike, or secondary strikes of suffi cient
magnitude. Ametek cannot accept liability for damage due
to lightning or secondary surges.
WARNING: Remove power before installing or servic-
ing.
To install the Model SDT Transmitter, connect the sur-
face end of the cable to the Ametek Model DMC Meter
Controller or other power source and indicator. Suspend
the transmitter into a well or tank supported only by its at-
tached shielded electronic cable. Insure that the opening in
the well or tank cover is large enough for possible future
removal of the transmitter.
Additional support to the transmitter is available with
an optional factory installed cable support. The optional
cable support is recommended when using longer lengths
of cable or when suspending the transmitter into agitated
liquids. The cable support provides strain relief for the
excess stress found under these circumstances. See dia-
gram of Model SDT Transmitter with cable support using
customer supplied and installed support cable.
Caution - The cable grommet and support are special-
ly installed by factory-trained personnel to insure wa-
tertightness. Any adjustment or removal of these items
may destroy the watertight feature thus exposing the
transmitter to water seepage, an electrical short and
transmitter failure. Any adjustment or removal of the
cable grommet or cable support voids the warranty.
Caution - Waterproof cable should not be kinked or
nicked. This may allow water into the electronics hous-
ing. Permanent damage will result. (Never cut or splice
the waterproof cable). The surface end of the cable is
used as the system’s atmospheric reference. This end
should not be sealed. Vent to dry temperature stable
environment.
MODEL SDT TRANSMITTER INSTALLATION
HOUSING COVER
ALLOW SLACK IN
ELECTRICAL CABLE
APPROXIMATE DISTANCE
TO FIRST WIRE TIE
CUSTOMER SUPPLIED AND INSTALLED
SUPPORT CABLE WITH TIES AT
REGULAR INTERVALS
USE PLASTIC TIE WRAPS
TO PREVENT CUTTING INTO
THE WATERPROOF SHEATH
OF THE CABLE
12.00
MODEL SDT WITH CABLE SUPPORT OPTION
Surge or lightning protectors are available as optional
items and are strongly recommended for protection from
secondary surges or lightning strikes. The units are easy to
install, are maintenance-free and respond in less than one
nanosecond. Install in accordance with the instructions:
1. Lightning protection devices should be placed as close
to the instrument as possible and wired in accordance with
National Electric Code in an approved watertight enclo-
sure.
2. If the distance between the meter and transmitter, or the
meter and recorder is less than 100 feet, only 1 protector
per line may be used.
3. Use No. 10 AWG ground wire or better from protector
to earth ground.
4. Provide a separate ground for each run of shielded
cable or metal conduit.
5. Keep the ground wire less than 1 foot long and tie to a
suitable ground rod or metal frame ground. Surge capabil-
ity is only as good as the grounding method. All ground
connections must be installed.
6. Install all protectors in weathertight enclosures.
7. Run signal lines shielded and away from power lines.
8. Wire according to the Electrical Code.
9. When used for an intrinsically safe installation, only
one LMA912 should be installed in the hazardous loca-
tion. Do not substitute protector types.
Caution - This or any installation cannot protect against
a direct lightning strike, or secondary strikes of suffi cient
magnitude. Ametek cannot accept liability for damage due
to lightning or secondary surges.
WARNING: Remove power before installing or servic-
ing.
To install the Model SDT Transmitter, connect the sur-
face end of the cable to the Ametek Model DMC Meter
Controller or other power source and indicator. Suspend
the transmitter into a well or tank supported only by its at-
tached shielded electronic cable. Insure that the opening in
the well or tank cover is large enough for possible future
removal of the transmitter.
Additional support to the transmitter is available with
an optional factory installed cable support. The optional
cable support is recommended when using longer lengths
of cable or when suspending the transmitter into agitated
liquids. The cable support provides strain relief for the
excess stress found under these circumstances. See dia-
gram of Model SDT Transmitter with cable support using
customer supplied and installed support cable.
Caution - The cable grommet and support are special-
ly installed by factory-trained personnel to insure wa-
tertightness. Any adjustment or removal of these items
may destroy the watertight feature thus exposing the
transmitter to water seepage, an electrical short and
transmitter failure. Any adjustment or removal of the
cable grommet or cable support voids the warranty.
Caution - Waterproof cable should not be kinked or
nicked. This may allow water into the electronics hous-
ing. Permanent damage will result. (Never cut or splice
the waterproof cable). The surface end of the cable is
used as the system’s atmospheric reference. This end
should not be sealed. Vent to dry temperature stable
environment.
MODEL SDT TRANSMITTER INSTALLATION
HOUSING COVER
ALLOW SLACK IN
ELECTRICAL CABLE
APPROXIMATE DISTANCE
TO FIRST WIRE TIE
CUSTOMER SUPPLIED AND INSTALLED
SUPPORT CABLE WITH TIES AT
REGULAR INTERVALS
USE PLASTIC TIE WRAPS
TO PREVENT CUTTING INTO
THE WATERPROOF SHEATH
OF THE CABLE
12.00
MODEL SDT WITH CABLE SUPPORT OPTION
Surge or lightning protectors are available as optional
items and are strongly recommended for protection from
secondary surges or lightning strikes. The units are easy to
install, are maintenance-free and respond in less than one
nanosecond. Install in accordance with the instructions:
1. Lightning protection devices should be placed as close
to the instrument as possible and wired in accordance with
National Electric Code in an approved watertight enclo-
sure.
2. If the distance between the meter and transmitter, or the
meter and recorder is less than 100 feet, only 1 protector
per line may be used.
3. Use No. 10 AWG ground wire or better from protector
to earth ground.
4. Provide a separate ground for each run of shielded
cable or metal conduit.
5. Keep the ground wire less than 1 foot long and tie to a
suitable ground rod or metal frame ground. Surge capabil-
ity is only as good as the grounding method. All ground
connections must be installed.
6. Install all protectors in weathertight enclosures.
7. Run signal lines shielded and away from power lines.
8. Wire according to the Electrical Code.
9. When used for an intrinsically safe installation, only
one LMA912 should be installed in the hazardous loca-
tion. Do not substitute protector types.
Caution - This or any installation cannot protect against
a direct lightning strike, or secondary strikes of suffi cient
magnitude. Ametek cannot accept liability for damage due
to lightning or secondary surges.
Model SDT with Cable Support Option

On-line order fax: [phone] or e-mail: [email protected]
Sales/Technical Support: [phone] | 820 Pennsylvania Blvd | Feasterville PA 19053 U.S.A.
© AMETEK, Inc. All rights reserved. Printed in the U.S.A.
Specifications are subject to change without notice. Visit our Web site for the most up-to-date information. www.ametekpmt.com
User Manual
FACTORY SERVICE
Factory service is available by contacting the
Customer Service Department. Supply the
following information:
1. Instrument Model Number and Serial Number
as shown on the Instrument Data Tag.
2. Description of problem being experienced.
3. Description and location of the installation.
For service:
Phone: [phone]
Fax: [phone]
PARTS / ORDERING
When ordering replacement transmitters, supply
the following information:
1. Part description and model number
2. Quantity of each transmitter required.
3. Shipping instructions and address.
4. P.O. number and address, or phone in your
credit card information
Mail, Telephone, Fax or E-mail orders to:
AMETEK US GAUGE, PMT PRODUCTS
820 Pennsylvania Blvd.
Feasterville, PA 19053
Phone: [phone]
Fax: [phone]
Email: [email protected]
ACCESSORIES
Part No. Description
LMA 912 30 VDC SURGE/LIGHTNING
PROTECTOR
Protects the excitation and signal lines
between an Ametek Model DMC Meter
Controller, or other power source and
indicator, and the Model SDT 4-20mA
output transmitter.
SJB-100 Termination Junction Box with
Desiccant and Seal Fittings
(LMA 912 mounting possible)
DDMC Meter/Controller/Power Supply
(120VAC/240VAC) Consult Factory
WARRANTY POLICY
AMETEK [“Seller”] warrants for a period of one year
from the date of shipment and that all products
manufactured by the seller are free from defects of
material and workmanship when used within the
service, range, and purpose for which they were
manufactured.
Seller will, at its option, repair, replace, or refund
the purchase price of parts found by Seller to be
defective in material or workmanship provided
that written notice of such defect requesting
instructions for repair, replacement, or refund is
received by Seller at the address below within the
warranty period and provided that any instructions
thereafter given by Seller are complied with.
This warranty shall not apply (i) to the performance
of any system of which Seller’s products are a
component part, (ii) to deterioration by corrosion
or any cause of failure other than defect of material
or workmanship, or (iii) to any of Seller’s products
or parts thereof which have been tampered with
or altered or repaired by anyone except Seller
or someone authorized by Seller, or subjected
to misuse, neglect, abuse or improper use or
misapplication such as breakage by negligence,
accident, vandalism, the elements, shock,
vibration, or exposure to any other service, range,
or environment of greater severity than that for
which the products were designed.
SELLER MAKES NO WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED. INCLUDING WITHOUT
LIMITATION ANY WARRANTIES OF FITNESS OR
OF MERCHANTABILITY WITH RESPECT TO ITS
PRODUCTS, OR ANY PART THEREOF, OTHER
THAN AS EXPRESSLY SET FORTH ABOVE. NOR
SHALL SELLER HAVE INCURRED ANY OTHER
OBLIGATIONS OR LIABILITIES OR BE LIABLE
FOR ANY ANTICIPATED OR LOST PROFITS,
INCIDENTAL DAMAGES, CONSEQUENTIAL
DAMAGES, TIME CHARGES, OR ANY OTHER
LOSSES INCURRED IN CONNECTION WITH
THE PURCHASE, INSTALLATION, REPAIR, OR
OPERATION OF ITS PRODUCTS (INCLUDING
ANY PARTS REPAIRED OR REPLACED).
This warranty does not extend to anyone other
than the original Buyer from Seller.
Service & Accessories
